T527+FPGA solution:

Built in 8-core Cortex-A55, with a maximum clock speed of 1.8GHz; G57 MC1 GPU, 2Tops computing power NPU; At the same time, it is equipped with 1 x RISC-V+2 x DSP cores, with powerful 4K high-definition decoding performance, multiple display interfaces, 2 x Gigabit Ethernet ports, 4 x RS485 (5KV isolation, surge protection) and other interfaces.

It can achieve 12 screen splicing, same display, and different display, and is compatible with multiple operating systems. It is widely used in exhibition display, advertising content placement, new retail, supermarkets and other fields to display various media content.

T527 core board interface description:

Joint screen splicing

It can achieve any horizontal and vertical screen splicing mode within 12 screens, achieving point-to-point splicing effect.

Long screen display effect

Vertical bar screen display effect

Matrix screen display effect

Multi screen simultaneous display

It can achieve synchronous playback of the same video and image content on each screen within 12 screens.

Same display effect

​
Multi screen abnormal display

It can play different video and image content on each screen within 12 screens.

Abnormal effect

​
