一、添加生命与法力属性

1.添加生命属性：Source/Crunch/Public/GAS/CAttributeSet.h

private:
	UPROPERTY()
	FGameplayAttributeData Health;

FGameplayAttributeData 的定义：

Plugins/Runtime/GameplayAbilities/Source/GameplayAbilities/Public/AttributeSet.h：

USTRUCT(BlueprintType)
struct GAMEPLAYABILITIES_API FGameplayAttributeData
{
	GENERATED_BODY()
	FGameplayAttributeData()
		: BaseValue(0.f)
		, CurrentValue(0.f)
	{}

	FGameplayAttributeData(float DefaultValue)
		: BaseValue(DefaultValue)
		, CurrentValue(DefaultValue)
	{}

	virtual ~FGameplayAttributeData()
	{}

	/** Returns the current value, which includes temporary buffs */
	float GetCurrentValue() const;

	/** Modifies current value, normally only called by ability system or during initialization */
	virtual void SetCurrentValue(float NewValue);

	/** Returns the base value which only includes permanent changes */
	float GetBaseValue() const;

	/** Modifies the permanent base value, normally only called by ability system or during initialization */
	virtual void SetBaseValue(float NewValue);

protected:
	UPROPERTY(BlueprintReadOnly, Category = "Attribute")
	float BaseValue;

	UPROPERTY(BlueprintReadOnly, Category = "Attribute")
	float CurrentValue;
};

FGameplayAttributeData是虚幻引擎GAS(GameplayAbilitySystem)中用于表示游戏属性的核心数据结构。该结构体具有以下关键特性：

双值存储机制：

BaseValue：基础值，仅包含永久性修改（如角色初始属性或装备加成）
CurrentValue：当前值，包含临时buff/debuff效果

主要功能方法：

GetCurrentValue()/SetCurrentValue()：获取/设置包含临时效果的当前值
GetBaseValue()/SetBaseValue()：获取/设置永久性基础值
两个构造函数：支持默认初始化为0或指定默认值

设计特点：

通过UPROPERTY宏实现蓝图可读性
推荐通过GameplayEffects修改属性以实现网络同步和预测回滚
通常定义在AttributeSet类中并由其处理网络同步

实际应用示例：

移动速度属性(MoveSpeed)的实现会使用此结构体
伤害(Damage)和护甲(Armor)等战斗属性也采用相同结构
装备系统可通过修改BaseValue实现永久属性加成

2.生成getter和setter函数，不过，有专门的宏函数：

Plugins/Runtime/GameplayAbilities/Source/GameplayAbilities/Public/AttributeSet.h：


 * To use this in your game you can define something like this, and then add game-specific functions as necessary:
 *
 *	#define ATTRIBUTE_ACCESSORS(ClassName, PropertyName) \
 *	GAMEPLAYATTRIBUTE_PROPERTY_GETTER(ClassName, PropertyName) \
 *	GAMEPLAYATTRIBUTE_VALUE_GETTER(PropertyName) \
 *	GAMEPLAYATTRIBUTE_VALUE_SETTER(PropertyName) \
 *	GAMEPLAYATTRIBUTE_VALUE_INITTER(PropertyName)
 *
 *	ATTRIBUTE_ACCESSORS(UMyHealthSet, Health)
 */

#define GAMEPLAYATTRIBUTE_PROPERTY_GETTER(ClassName, PropertyName) \
	static FGameplayAttribute Get##PropertyName##Attribute() \
	{ \
		static FProperty* Prop = FindFieldChecked<FProperty>(ClassName::StaticClass(), GET_MEMBER_NAME_CHECKED(ClassName, PropertyName)); \
		return Prop; \
	}

#define GAMEPLAYATTRIBUTE_VALUE_GETTER(PropertyName) \
	FORCEINLINE float Get##PropertyName() const \
	{ \
		return PropertyName.GetCurrentValue(); \
	}

#define GAMEPLAYATTRIBUTE_VALUE_SETTER(PropertyName) \
	FORCEINLINE void Set##PropertyName(float NewVal) \
	{ \
		UAbilitySystemComponent* AbilityComp = GetOwningAbilitySystemComponent(); \
		if (ensure(AbilityComp)) \
		{ \
			AbilityComp->SetNumericAttributeBase(Get##PropertyName##Attribute(), NewVal); \
		}; \
	}

#define GAMEPLAYATTRIBUTE_VALUE_INITTER(PropertyName) \
	FORCEINLINE void Init##PropertyName(float NewVal) \
	{ \
		PropertyName.SetBaseValue(NewVal); \
		PropertyName.SetCurrentValue(NewVal); \
	}

这是Unreal Engine游戏能力系统(GAS)中用于简化属性访问的宏定义系统，主要用于定义和管理游戏属性(如生命值、法力值等)。以下是关键点解析：

‌ATTRIBUTE_ACCESSORS宏‌：
