Spring WebFlux 深度实践指南

Spring WebFlux 是 Spring Framework 5 引入的响应式 Web 框架，基于 Project Reactor 实现，支持非阻塞、函数式编程模型。本节将深入探讨 WebFlux 的核心功能，包括 REST API 构建、响应式数据库访问和实时通信。

4.3.1 构建 Reactive REST API

基础项目搭建

首先创建 Spring Boot WebFlux 项目（基于 Spring Initializr）：

<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-webflux</artifactId>
</dependency>

响应式控制器

注解式控制器（与传统Spring MVC类似但支持响应式类型）：

@RestController
@RequestMapping("/products")
public class ProductController {

    private final ProductService productService;

    // 构造函数注入
    public ProductController(ProductService productService) {
        this.productService = productService;
    }

    @GetMapping
    public Flux<Product> getAllProducts() {
        return productService.findAll();
    }

    @GetMapping("/{id}")
    public Mono<Product> getProductById(@PathVariable String id) {
        return productService.findById(id);
    }

    @PostMapping
    @ResponseStatus(HttpStatus.CREATED)
    public Mono<Product> createProduct(@RequestBody Mono<Product> productMono) {
        return productService.save(productMono);
    }

    @PutMapping("/{id}")
    public Mono<Product> updateProduct(
            @PathVariable String id,
            @RequestBody Mono<Product> productMono) {
        return productService.update(id, productMono);
    }

    @DeleteMapping("/{id}")
    @ResponseStatus(HttpStatus.NO_CONTENT)
    public Mono<Void> deleteProduct(@PathVariable String id) {
        return productService.delete(id);
    }
}

函数式端点（RouterFunction方式）：

@Configuration
public class ProductRouter {

    @Bean
    public RouterFunction<ServerResponse> route(ProductHandler handler) {
        return RouterFunctions.route()
            .GET("/fn/products", handler::getAll)
            .GET("/fn/products/{id}", handler::getById)
            .POST("/fn/products", handler::create)
            .PUT("/fn/products/{id}", handler::update)
            .DELETE("/fn/products/{id}", handler::delete)
            .build();
    }
}

@Component
public class ProductHandler {

    private final ProductService productService;

    public ProductHandler(ProductService productService) {
        this.productService = productService;
    }

    public Mono<ServerResponse> getAll(ServerRequest request) {
        return ServerResponse.ok()
            .contentType(MediaType.APPLICATION_NDJSON)
            .body(productService.findAll(), Product.class);
    }

    public Mono<ServerResponse> getById(ServerRequest request) {
        String id = request.pathVariable("id");
        return productService.findById(id)
            .flatMap(product -> ServerResponse.ok().bodyValue(product))
            .switchIfEmpty(ServerResponse.notFound().build());
    }

    public Mono<ServerResponse> create(ServerRequest request) {
        return request.bodyToMono(Product.class)
            .flatMap(productService::save)
            .flatMap(product -> ServerResponse
                .created(URI.create("/fn/products/" + product.getId()))
                .bodyValue(product));
    }

    public Mono<ServerResponse> update(ServerRequest request) {
        String id = request.pathVariable("id");
        return request.bodyToMono(Product.class)
            .flatMap(product -> productService.update(id, Mono.just(product)))
            .flatMap(product -> ServerResponse.ok().bodyValue(product))
            .switchIfEmpty(ServerResponse.notFound().build());
    }

    public Mono<ServerResponse> delete(ServerRequest request) {
        String id = request.pathVariable("id");
        return productService.delete(id)
            .then(ServerResponse.noContent().build());
    }
}

高级特性

流式响应（Server-Sent Events）：

@GetMapping(value = "/stream", produces = MediaType.TEXT_EVENT_STREAM_VALUE)
public Flux<ProductEvent> streamProducts() {
    return Flux.interval(Duration.ofSeconds(1))
        .map(sequence -> new ProductEvent(
            "product-" + sequence,
            "Event at " + Instant.now()
        ));
}

请求验证与异常处理：

@ControllerAdvice
public class GlobalErrorHandler extends AbstractErrorWebExceptionHandler {

    public GlobalErrorHandler(ErrorAttributes errorAttributes,
                            WebProperties.Resources resources,
                            ApplicationContext applicationContext,
                            ServerCodecConfigurer serverCodecConfigurer) {
        super(errorAttributes, resources, applicationContext);
        this.setMessageWriters(serverCodecConfigurer.getWriters());
    }

    @Override
    protected RouterFunction<ServerResponse> getRoutingFunction(ErrorAttributes errorAttributes) {
        return RouterFunctions.route(
            RequestPredicates.all(),
            request -> {
                Map<String, Object> errorProperties = getErrorAttributes(request, ErrorAttributeOptions.defaults());
                HttpStatus status = getHttpStatus(errorProperties);
                return ServerResponse.status(status)
                    .contentType(MediaType.APPLICATION_JSON)
                    .bodyValue(errorProperties);
            }
        );
    }

    private HttpStatus getHttpStatus(Map<String, Object> errorProperties) {
        return HttpStatus.valueOf((Integer)errorProperties.get("status"));
    }
}

// 自定义验证
public class ProductValidator {

    public static Mono<Product> validate(Product product) {
        return Mono.just(product)
            .flatMap(p -> {
                List<String> errors = new ArrayList<>();
                if (p.getName() == null || p.getName().isEmpty()) {
                    errors.add("Product name is required");
                }
                if (p.getPrice() <= 0) {
                    errors.add("Price must be positive");
                }
                if (!errors.isEmpty()) {
                    return Mono.error(new ValidationException(errors));
                }
                return Mono.just(p);
            });
    }
}

4.3.2 响应式数据库访问（R2DBC）

R2DBC 配置

添加依赖：

<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-data-r2dbc</artifactId>
</dependency>
<dependency>
    <groupId>io.r2dbc</groupId>
    <artifactId>r2dbc-postgresql</artifactId>
    <scope>runtime</scope>
</dependency>

配置 application.yml：

spring:
  r2dbc:
    url: r2dbc:postgresql://localhost:5432/mydb
    username: user
    password: pass
    pool:
      enabled: true
      max-size: 20

响应式Repository

定义实体：

@Data
@Table("products")
public class Product {

    @Id
    private Long id;
    private String name;
    private String description;
    private BigDecimal price;
    private Instant createdAt;
}

创建Repository接口：

public interface ProductRepository extends ReactiveCrudRepository<Product, Long> {

    Flux<Product> findByNameContaining(String name);

    @Query("SELECT * FROM products WHERE price > :minPrice")
    Flux<Product> findByPriceGreaterThan(BigDecimal minPrice);

    @Modifying
    @Query("UPDATE products SET price = price * :factor")
    Mono<Integer> updateAllPrices(BigDecimal factor);
}

复杂查询与事务

自定义查询实现：

public class ProductRepositoryImpl implements CustomProductRepository {

    private final DatabaseClient databaseClient;

    public ProductRepositoryImpl(DatabaseClient databaseClient) {
        this.databaseClient = databaseClient;
    }

    @Override
    public Flux<Product> complexSearch(ProductCriteria criteria) {
        return databaseClient.sql("""
                SELECT * FROM products
                WHERE name LIKE :name
                AND price BETWEEN :minPrice AND :maxPrice
                ORDER BY :sortField :sortDirection
                LIMIT :limit OFFSET :offset
                """)
            .bind("name", "%" + criteria.getName() + "%")
            .bind("minPrice", criteria.getMinPrice())
            .bind("maxPrice", criteria.getMaxPrice())
            .bind("sortField", criteria.getSortField())
            .bind("sortDirection", criteria.getSortDirection())
            .bind("limit", criteria.getPageSize())
            .bind("offset", (criteria.getPageNumber() - 1) * criteria.getPageSize())
            .map((row, metadata) -> toProduct(row))
            .all();
    }

    private Product toProduct(Row row) {
        // 行到对象的转换逻辑
    }
}

事务管理：

@Service
@RequiredArgsConstructor
public class ProductService {

    private final ProductRepository productRepository;
    private final TransactionalOperator transactionalOperator;

    public Mono<Void> transferStock(String fromId, String toId, int quantity) {
        return transactionalOperator.execute(status ->
            productRepository.findById(fromId)
                .flatMap(fromProduct -> {
                    if (fromProduct.getStock() < quantity) {
                        return Mono.error(new InsufficientStockException());
                    }
                    fromProduct.setStock(fromProduct.getStock() - quantity);
                    return productRepository.save(fromProduct)
                        .then(productRepository.findById(toId))
                        .flatMap(toProduct -> {
                            toProduct.setStock(toProduct.getStock() + quantity);
                            return productRepository.save(toProduct);
                        });
                })
        );
    }
}

性能优化

1. 连接池配置：

spring:
  r2dbc:
    pool:
      max-size: 20
      initial-size: 5
      max-idle-time: 30m

2. 批处理操作：

public Mono<Integer> batchInsert(List<Product> products) {
    return databaseClient.inConnectionMany(connection -> {
        Batch batch = connection.createBatch();
        products.forEach(product ->
            batch.add("INSERT INTO products(name, price) VALUES($1, $2)")
                .bind(0, product.getName())
                .bind(1, product.getPrice())
        );
        return Flux.from(batch.execute())
            .reduce(0, (count, result) -> count + result.getRowsUpdated());
    });
}

4.3.3 WebSocket 实时通信

基础WebSocket配置

配置类：

@Configuration
@EnableWebFlux
public class WebSocketConfig implements WebSocketMessageBrokerConfigurer {

    @Override
    public void registerStompEndpoints(StompEndpointRegistry registry) {
        registry.addEndpoint("/ws")
            .setHandshakeHandler(new DefaultHandshakeHandler())
            .setAllowedOrigins("*");
    }

    @Override
    public void configureMessageBroker(MessageBrokerRegistry registry) {
        registry.enableSimpleBroker("/topic");
        registry.setApplicationDestinationPrefixes("/app");
    }
}

响应式WebSocket处理

股票行情推送示例：

@Controller
public class StockTickerController {

    private final Flux<StockQuote> stockQuoteFlux;

    public StockTickerController(StockQuoteGenerator quoteGenerator) {
        this.stockQuoteFlux = Flux.interval(Duration.ofMillis(500))
            .map(sequence -> quoteGenerator.generate())
            .share(); // 热发布，多个订阅者共享数据
    }

    @MessageMapping("stocks.subscribe")
    @SendTo("/topic/stocks")
    public Flux<StockQuote> subscribe() {
        return stockQuoteFlux;
    }

    @MessageMapping("stocks.filter")
    public Flux<StockQuote> filter(@Payload String symbol) {
        return stockQuoteFlux.filter(quote ->
            quote.getSymbol().equals(symbol));
    }
}

客户端连接示例：

const socket = new SockJS('/ws');
const stompClient = Stomp.over(socket);

stompClient.connect({}, () => {
    stompClient.subscribe('/topic/stocks', (message) => {
        const quote = JSON.parse(message.body);
        updateStockTable(quote);
    });

    stompClient.send("/app/stocks.filter", {}, "AAPL");
});

高级特性

RSocket集成（更强大的响应式协议）：

@Controller
@MessageMapping("stock.service")
public class RSocketStockController {

    @MessageMapping("current")
    public Mono<StockQuote> current(String symbol) {
        return stockService.getCurrent(symbol);
    }

    @MessageMapping("stream")
    public Flux<StockQuote> stream(String symbol) {
        return stockService.getStream(symbol);
    }

    @MessageMapping("channel")
    public Flux<StockQuote> channel(Flux<String> symbols) {
        return symbols.flatMap(stockService::getStream);
    }
}

背压控制：

@MessageMapping("large.data.stream")
public Flux<DataChunk> largeDataStream() {
    return dataService.streamLargeData()
        .onBackpressureBuffer(50, // 缓冲区大小
            chunk -> log.warn("Dropping chunk due to backpressure"));
}

安全配置

@Configuration
@EnableWebFluxSecurity
public class SecurityConfig {

    @Bean
    public SecurityWebFilterChain securityFilterChain(ServerHttpSecurity http) {
        return http
            .authorizeExchange()
                .pathMatchers("/ws/**").authenticated()
                .anyExchange().permitAll()
            .and()
            .httpBasic()
            .and()
            .csrf().disable()
            .build();
    }

    @Bean
    public MapReactiveUserDetailsService userDetailsService() {
        UserDetails user = User.withUsername("user")
            .password("{noop}password")
            .roles("USER")
            .build();
        return new MapReactiveUserDetailsService(user);
    }
}

性能监控与最佳实践

监控端点配置

management:
  endpoints:
    web:
      exposure:
        include: health, metrics, prometheus
  metrics:
    tags:
      application: ${spring.application.name}

响应式应用监控

@Bean
public MeterRegistryCustomizer<MeterRegistry> metricsCommonTags() {
    return registry -> registry.config()
        .commonTags("application", "reactive-demo");
}

// 自定义指标
@Bean
public WebFilter metricsWebFilter(MeterRegistry registry) {
    return (exchange, chain) -> {
        String path = exchange.getRequest().getPath().toString();
        Timer.Sample sample = Timer.start(registry);

        return chain.filter(exchange)
            .doOnSuccessOrError((done, ex) -> {
                sample.stop(registry.timer("http.requests",
                    "uri", path,
                    "status", exchange.getResponse().getStatusCode().toString(),
                    "method", exchange.getRequest().getMethodValue()));
            });
    };
}

最佳实践总结

1. 线程模型理解：

   • WebFlux 默认使用 Netty 事件循环线程
   • 阻塞操作必须使用 publishOn 切换到弹性线程池

2. 背压策略选择：

   • UI 客户端：使用 onBackpressureDrop 或 onBackpressureLatest
   • 服务间通信：使用 onBackpressureBuffer 配合合理缓冲区大小

3. 错误处理原则：

   • 尽早处理错误
   • 为每个 Flux/Mono 链添加错误处理
   • 区分业务异常和系统异常

4. 测试策略：

   • 使用 StepVerifier 测试响应式流
   • 使用 WebTestClient 测试控制器
   • 虚拟时间测试长时间操作

5. 性能调优：

   • 合理配置连接池
   • 监控关键指标（延迟、吞吐量、资源使用率）
   • 使用响应式日志框架（如 Logback 异步Appender）

通过以上全面实践，您将能够构建高性能、可扩展的响应式 Web 应用，充分利用 WebFlux 的非阻塞特性，处理高并发场景下的各种挑战。
