openlayers 绘图功能，编辑多边形，长度面积测量，tip提示（七）

本篇介绍一下使用openlayers添加tips，比如测量时，实时显示长度、面积等，两种方法：

1. 使用Overlay，会添加指定的HTML元素到dom中，会跟随地图的平移】缩放等动作
2. 使用vector样式，会渲染到地图的canvas中，会跟随地图的平移】缩放等动作
   推荐第2种，与地图无缝集成，实现简单

1 需求

• 基础多边形绘制，编辑功能
• 绘制编辑时跟随鼠标给出提示
• 多边形的边显示长度，中心显示面积

2 分析

主要是 openlayers 中 styleFunc 功能的使用，效果如下

3 实现

<template>
  <div id="map" class="map"></div>
  <div class="toolbar">
    <el-button type="primary" @click="handleClick">{{ drawFlag ? '结束' : '开始' }}绘制</el-button>
    <el-button type="warning" :disabled="!drawFlag" @click="handleCancelClick">撤销上步</el-button>
    <el-button type="success" @click="handleShowDataClick(true)"
      >{{ showLength ? '隐藏' : '显示' }}边长</el-button
    >
    <el-button type="success" @click="handleShowDataClick(false)"
      >{{ showArea ? '隐藏' : '显示' }}面积</el-button
    >
  </div>
</template>

<script setup lang="ts">
import { Collection, Feature, Map, View } from 'ol';
import { get } from 'ol/proj';
import { RegularShape, Style } from 'ol/style';
import { Draw, Modify, Select, Snap } from 'ol/interaction.js';
import { Vector as VectorSource } from 'ol/source.js';
import { Vector as VectorLayer } from 'ol/layer.js';
import { Circle, Fill, Stroke, Text } from 'ol/style.js';
import { LineString, Point, Polygon } from 'ol/geom';
import { getArea, getLength } from 'ol/sphere.js';

const projection = get('EPSG:4326');
const source = new VectorSource({ wrapX: false });
const map = shallowRef();
const draw = shallowRef();
const vector = shallowRef();
const modify = shallowRef();
const select = shallowRef();
const snap = shallowRef();
const features = ref(new Collection()); //保存绘制的features
const activeFeatures = ref(new Collection()); //选中的features
const drawFlag = ref(false);
const showLength = ref(true);
const showArea = ref(true);
const tips = ref('');

const labelStyle = new Style({
  text: new Text({
    font: '14px Microsoft YaHei',
    fill: new Fill({
      color: 'rgba(255, 255, 255, 1)'
    }),
    backgroundFill: new Fill({
      color: 'rgba(0, 0, 0, 0.7)'
    }),
    padding: [3, 3, 3, 3],
    textBaseline: 'bottom',
    offsetY: -15
  }),
  image: new RegularShape({
    radius: 8,
    points: 3,
    angle: Math.PI,
    displacement: [0, 10],
    fill: new Fill({
      color: 'rgba(0, 0, 0, 0.7)'
    })
  })
});

const tipStyle = new Style({
  text: new Text({
    font: '12px Microsoft YaHei',
    fill: new Fill({
      color: 'rgba(255, 255, 255, 1)'
    }),
    backgroundFill: new Fill({
      color: 'rgba(0, 0, 0, 0.5)'
    }),
    padding: [2, 2, 2, 2],
    textAlign: 'left',
    offsetX: 15
  })
});

const modifyStyle = new Style({
  image: new Circle({
    radius: 5,
    stroke: new Stroke({
      color: 'rgba(255, 255, 255, 0.4)'
    }),
    fill: new Fill({
      color: 'rgba(255, 255, 255, 0.4)'
    })
  }),
  text: new Text({
    text: '拖动顶点进行修改',
    font: '12px Microsoft YaHei',
    fill: new Fill({
      color: 'rgba(255, 255, 255, 1)'
    }),
    backgroundFill: new Fill({
      color: 'rgba(0, 0, 0, 0.7)'
    }),
    padding: [5, 5, 5, 5],
    textAlign: 'left',
    offsetX: 15
  })
});

const edgeStyle = new Style({
  text: new Text({
    font: '12px Microsoft YaHei',
    fill: new Fill({
      color: 'rgba(255, 255, 255, 1)'
    }),
    backgroundFill: new Fill({
      color: 'rgba(0, 0, 0, 0.4)'
    }),
    padding: [2, 2, 2, 2],
    textBaseline: 'bottom',
    offsetY: -12
  }),
  image: new RegularShape({
    radius: 6,
    points: 3,
    angle: Math.PI,
    displacement: [0, 8],
    fill: new Fill({
      color: 'rgba(0, 0, 0, 0.4)'
    })
  })
});

onMounted(() => {
  initMap();
  initInteraction();
});

const initMap = () => {
  vector.value = new VectorLayer({
    source: source,
    style: feature => styleFunc(feature, showLength.value, showArea.value)
  });
  map.value = new Map({
    target: 'map',
    view: new View({
      center: [116.406393, 39.909006],
      projection: projection,
      zoom: 5
    }),
    layers: [vector.value]
  });
};

const initInteraction = () => {
  draw.value = new Draw({
    active: false,
    features: features.value,
    source: source,
    type: 'Polygon',
    style: feature => drawStyleFunc(feature, showLength.value, showArea.value, tips.value)
  });
  draw.value.on('drawstart', e => {
    console.log('e', e);
  });
  draw.value.on('drawend', e => {
    console.log('features.value', features.value);
    console.log('coord', e.feature.getGeometry().getCoordinates());
  });
  map.value.addInteraction(draw.value);
  draw.value.setActive(false);

  select.value = new Select({
    features: activeFeatures.value,
    style: selectStyleFunc
  });

  select.value.on('select', e => {
    modify.value.setActive(true);
  });

  map.value.addInteraction(select.value);
  select.value.setActive(false);

  modify.value = new Modify({
    features: select.value.getFeatures(), // Modify 将处理 Select 交互所选的要素
    pixelTolerance: 10, //设置吸附像素值
    insertVertexCondition: handleInsertVertexCondition,
    style: feature => modifyStyleFunc(feature, showLength.value, showArea.value)
  });

  modify.value.on('modifystart', event => {});

  modify.value.on('modifyend', event => {
    console.log('modifyend', event.features);
  });

  map.value.addInteraction(modify.value);
  modify.value.setActive(false);
  // 用于处理绘制或者编辑多边形时，与已经存在图形的自动吸附，如下是只吸附顶点，不媳妇边
  snap.value = new Snap({
    source: source,
    edge: false //不吸附边
  });
  map.value.addInteraction(snap.value);
};

const handleClick = () => {
  drawFlag.value = !drawFlag.value;
  draw.value.setActive(drawFlag.value);
  select.value.setActive(!drawFlag.value);
  modify.value.setActive(!drawFlag.value);
  select.value.getFeatures().clear();
  tips.value = '点击鼠标定位第一个顶点';
};
const handleCancelClick = () => {
  draw.value.removeLastPoint();
};
const handleShowDataClick = isLength => {
  if (isLength) {
    showLength.value = !showLength.value;
  } else {
    showArea.value = !showArea.value;
  }
  draw.value.getOverlay().changed();
  vector.value.changed();
};

const drawStyleFunc = (feature, showLength, showArea, tip) => {
  const styles = [];
  const geometry = feature.getGeometry();
  const type = geometry.getType();
  const coord = geometry.getCoordinates();
  const tStyle = tipStyle.clone();

  if (type === 'LineString') {
    for (let i = 0; i < coord.length - 1; i++) {
      const line = new LineString([coord[i], coord[i + 1]]);
      const label = formatLength(line);
      const point = new Point(line.getCoordinateAt(0.5));
      const style = edgeStyle.clone();
      style.setGeometry(point);
      style.getText().setText(label);
      if (showLength) {
        styles.push(style);
      }
      styles.push(
        new Style({
          geometry: line,
          stroke: new Stroke({
            color: 'orange',
            lineDash: coord.length > 2 && i < coord.length - 2 ? [] : [10],
            width: 2
          })
        })
      );
    }

    const point = new Point(geometry.getLastCoordinate());
    tStyle.setGeometry(point);
    if (coord.length <= 3) {
      tips.value = '继续定位顶点';
    } else if (coord.length > 3) {
      tips.value = '点击第一个点可结束绘制';
    }
  }
  if (type === 'Polygon') {
    if (showArea) {
      const label = formatArea(geometry);
      const point = geometry.getInteriorPoint();
      const style = labelStyle.clone();
      // style.setGeometry(point);
      style.getText().setText(label);
      styles.push(style);
    }
  }
  tStyle.getText().setText(tip);
  styles.push(tStyle);
  return styles;
};

const selectStyleFunc = feature => {
  const styles = [];
  const coord = feature.getGeometry().getCoordinates().flat(1);
  for (let i = 0; i < coord.length - 1; i++) {
    styles.push(
      new Style({
        geometry: new Point(coord[i]),
        image: new Circle({
          radius: 4,
          fill: new Fill({
            color: '#ffff'
          }),
          stroke: new Stroke({
            color: 'orange',
            width: 2
          })
        })
      })
    );
  }
  styles.push(
    new Style({
      stroke: new Stroke({
        color: 'orange',
        width: 2
      }),
      fill: new Fill({
        color: '#ffff'
      })
    })
  );
  return styles;
};

const modifyStyleFunc = (feature, showLength, showArea) => {
  const layer = map.value.getLayers().item(0);
  const features = layer.getSource().getFeatures();
  const geometry = feature.getGeometry();
  const coord = geometry.getCoordinates();
  const type = geometry.getType();
  const coords = features.map(feature => feature.getGeometry().getCoordinates()).flat(2);
  let styles = [];
  // 只有鼠标在顶点时才能触发编辑功能
  if (coords.find(c => c.toString() === coord.toString())) {
    styles.push(
      new Style({
        geometry: new Point(coord),
        image: new Circle({
          radius: 6,
          fill: new Fill({
            color: '#ffff'
          }),
          stroke: new Stroke({
            color: 'red',
            width: 2
          })
        })
      }),
      modifyStyle
    );
  }

  if (type === 'Point') {
    const feature = activeFeatures.value.getArray()[0];
    const geometry = feature.getGeometry();
    const coord = feature.getGeometry().getCoordinates()[0];
    if (showLength) {
      for (let i = 0; i < coord.length - 1; i++) {
        const line = new LineString([coord[i], coord[i + 1]]);
        const label = formatLength(line);
        const point = new Point(line.getCoordinateAt(0.5));
        const style = edgeStyle.clone();
        style.setGeometry(point);
        style.getText().setText(label);
        styles.push(style);
      }
    }
    if (showArea) {
      const label = formatArea(geometry);
      const point = geometry.getInteriorPoint();
      const style = labelStyle.clone();
      style.setGeometry(point);
      style.getText().setText(label);
      styles.push(style);
    }
  }

  return styles;
};
const handleInsertVertexCondition = e => {
  // 点击或者拖动边时不插入新顶点
  return false;
};
const styleFunc = (feature, showLength, showArea) => {
  const styles = [];
  const geometry = feature.getGeometry();
  const type = geometry.getType();
  if (type === 'Polygon') {
    const coord = geometry.getCoordinates()[0];
    if (showLength) {
      for (let i = 0; i < coord.length - 1; i++) {
        const line = new LineString([coord[i], coord[i + 1]]);
        const label = formatLength(line);
        const point = new Point(line.getCoordinateAt(0.5));
        const style = edgeStyle.clone();
        style.setGeometry(point);
        style.getText().setText(label);
        styles.push(style);
      }
    }
    if (showArea) {
      const label = formatArea(geometry);
      const point = geometry.getInteriorPoint();
      const style = labelStyle.clone();
      style.setGeometry(point);
      style.getText().setText(label);
      styles.push(style);
    }
  }
  styles.push(
    new Style({
      fill: new Fill({
        color: [128, 128, 255, 0.5]
      }),
      stroke: new Stroke({
        color: 'blue',
        width: 2
      })
    })
  );
  return styles;
};

const formatArea = polygon => {
  const area = getArea(polygon, { projection: 'EPSG:4326' });
  let output; //根据面积大小实时换算成平方千米
  if (area > 10000) {
    //平方千米
    output = Math.round((area / 1000000) * 100) / 100 + ' km\xB2';
  } else {
    //平方米
    output = Math.round(area * 100) / 100 + ' m\xB2';
  }
  return output;
};

const formatLength = line => {
  const length = getLength(line, { projection: 'EPSG:4326' });
  let output; //根据面积大小实时换算成平方千米
  if (length > 100) {
    output = Math.round((length / 1000) * 100) / 100 + ' km';
  } else {
    output = Math.round(length * 100) / 100 + ' m';
  }
  return output;
};
</script>
<style scoped lang="scss">
.map {
  width: 100%;
  height: 100%;
  background: #fff;
}
.toolbar {
  position: absolute;
  top: 20px;
  left: 100px;
}
</style>

4 问题

• 跟随鼠标的tip背景会加深
