之前的文章介绍过宝塔端反代homepage主页的办法，服务器内网穿透+个人导航页搭建+宝塔反代+ssl一站式教学，但当时有个“小”问题：使用宝塔端nginx反代后，homepage背景图，网页图标无法正确被加载，经常过很久才会更新出新的背景图，问题出在：Homepage 的 Service Worker 缓存机制与反向代理环境不兼容。当在域名结尾添加上：?cachebust=1时，则可以正常显示背景图

所以今天教大家修改宝塔端反代规则正确适配Service Worker 缓存机制

打开宝塔

①点击网站

②点击你homepage反代用的站点

③点击配置文件

④在配置文件内容处右击，选择全选

将下面的配置文件粘贴进去：

server
{
    listen 80;
    listen 443 ssl;
    listen 443 quic;
    http2 on;
    server_name your-domain.com;
    index index.php index.html index.htm default.php default.htm default.html;
    root /www/wwwroot/your-domain.com;

    #CERT-APPLY-CHECK--START
    include /www/server/panel/vhost/nginx/well-known/your-domain.com.conf;
    #CERT-APPLY-CHECK--END
    include /www/server/panel/vhost/nginx/extension/your-domain.com/*.conf;

    #SSL-START SSL相关配置，请勿删除或修改下一行带注释的404规则
    #error_page 404/404.html;  # 严格保留原始注释状态！
    #HTTP_TO_HTTPS_START
    set $isRedcert 1;
    if ($server_port != 443) {
        set $isRedcert 2;
    }
    if ( $uri ~ /\.well-known/ ) {
        set $isRedcert 1;
    }
    if ($isRedcert != 1) {
        rewrite ^(/.*)$ https://$host$1 permanent;
    }
    #HTTP_TO_HTTPS_END
    ssl_certificate    /www/server/panel/vhost/cert/your-domain.com/fullchain.pem;
    ssl_certificate_key    /www/server/panel/vhost/cert/your-domain.com/privkey.pem;
    ssl_protocols TLSv1.1 TLSv1.2 TLSv1.3;
    ssl_ciphers EECDH+CHACHA20:EECDH+CHACHA20-draft:EECDH+AES128:RSA+AES128:EECDH+AES256:RSA+AES256:EECDH+3DES:RSA+3DES:!MD5;
    ssl_prefer_server_ciphers on;
    ssl_session_tickets on;
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 10m;
    add_header Strict-Transport-Security "max-age=31536000";
    add_header Alt-Svc 'quic=":443"; h3=":443"; h3-29=":443"; h3-27=":443";h3-25=":443"; h3-T050=":443"; h3-Q050=":443";h3-Q049=":443";h3-Q048=":443"; h3-Q046=":443"; h3-Q043=":443"';
    error_page 497  https://$host$request_uri;
    #SSL-END

    #ERROR-PAGE-START  错误页配置，可以注释、删除或修改
    error_page 404 /404.html;
    #error_page 502 /502.html;
    #ERROR-PAGE-END

    # === 核心：Homepage 反向代理 ===
    # 放在 ERROR-PAGE-END 之后，PHP 配置之前
    location / {
        proxy_pass http://127.0.0.1:3000;  # 修改为你的Homepage地址
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Forwarded-Host $host;

        # 修复资源路径
        proxy_redirect http:// https://;

        # 禁用缓存
        proxy_cache off;
        proxy_no_cache 1;
        proxy_cache_bypass 1;

        # 阻止PWA缓存
        add_header Cache-Control "no-store, no-cache, must-revalidate, proxy-revalidate, max-age=0";
        add_header Pragma "no-cache";
        add_header Expires 0;

        # WebSocket支持
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";

        proxy_read_timeout 3600s;
        proxy_send_timeout 3600s;
        proxy_buffering off;
    }

    # === 静态资源专项处理 ===
    location ~* \.(js|css|png|jpg|jpeg|gif|ico|svg|webp|woff2)$ {
        proxy_pass http://127.0.0.1:3000;
        proxy_set_header Host $host;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_redirect http:// https://;

        # 短缓存 + 强制验证
        expires 1h;
        add_header Cache-Control "public, must-revalidate, proxy-revalidate";
    }

    # === 彻底禁用Service Worker ===
    location = /service-worker.js { return 404; }
    location ~ ^/workbox-.*\.js$ { return 404; }

    #PHP-INFO-START  PHP引用配置
    include enable-php-00.conf;
    #PHP-INFO-END

    # === 关键：注释掉反向代理包含 ===
    # 避免与上面的手动配置冲突
    #include /www/server/panel/vhost/nginx/proxy/your-domain.com/*.conf;

    #REWRITE-START URL重写规则引用
    include /www/server/panel/vhost/rewrite/your-domain.com.conf;
    #REWRITE-END

    #禁止访问的文件或目录
    location ~ ^/(\.user.ini|\.htaccess|\.git|\.env|\.svn|\.project|LICENSE|README.md)
    {
        return 404;
    }

    #一键申请SSL证书验证目录相关设置
    location ~ \.well-known{
        allow all;
    }

    #禁止在证书验证目录放入敏感文件
    if ( $uri ~ "^/\.well-known/.*\.(php|jsp|py|js|css|lua|ts|go|zip|tar\.gz|rar|7z|sql|bak)$" ) {
        return 403;
    }

    access_log  /www/wwwlogs/your-domain.com.log;
    error_log  /www/wwwlogs/your-domain.com.error.log;
}

文中所有的your-domain.com需替换成你自己的域名，修改完成后，点击保存即可

此时你再打开homepage背景图将会正确被加载
