MQTT协议系列之（一）：Quality of Service

What is Quality of Service?

The Quality of Service (QoS) level is an agreement between the sender of a message and the receiver of a message that defines the guarantee of delivery for a specific message. There are 3 QoS levels in MQTT:

• At most once (0)

    The minimal QoS level is zero. This service level guarantees a best-effort delivery. There is no guarantee of delivery. The recipient does not acknowledge receipt of the message and the message is not stored and re-transmitted by the sender. QoS level 0 is often called “fire and forget” and provides the same guarantee as the underlying TCP protocol.

• At least once (1)

    QoS level 1 guarantees that a message is delivered at least one time to the receiver. The sender stores the message until it gets a  PUBACK packet from the receiver that acknowledges receipt of the message. It is possible for a message to be sent or delivered multiple times.

• Exactly once (2).

    QoS 2 is the highest level of service in MQTT. This level guarantees that each message is received only once by the intended recipients. QoS 2 is the safest and slowest quality of service level. The guarantee is provided by at least two request/response flows (a four-part handshake) between the sender and the receiver. The sender and receiver use the packet identifier of the original PUBLISH message to coordinate delivery of the message.



Reference：

1. Quality of Service 0,1 & 2 - MQTT Essentials: Part 6
