HLS Optimization: Pipeline V.S. Unroll

最新推荐文章于 2022-09-03 18:45:00 发布
最新推荐文章于 2022-09-03 18:45:00 发布
阅读量308 收藏
点赞数
CC 4.0 BY-SA版权
原文链接：http://www.cnblogs.com/wordchao/p/10947470.html
博客介绍了PIPELINE和UNROLL的功能。PIPELINE可减少启动间隔，允许循环或函数内操作并发执行；UNROLL则用于展开for循环，创建多个独立操作而非单一操作集合。

PIPELINE:

  • Reduces the initiation interval
  • Concurrent execution

UNROLL:

  • Unroll for-loops
  • Multiple independent operations



PIPELINE: Reduces the initiation interval by allowing the concurrent
execution of operations within a loop or function.

UNROLL: Unroll for-loops to create multiple independent operations
rather than a single collection of operations.

转载于:https://www.cnblogs.com/wordchao/p/10947470.html
