[HDLBits]Count1to10


NOTICE:The comparison if (q < 1010) is not valid because 1010 is an integer, not a binary number. To compare q with 4'b1010, you should explicitly write it as 4'b1010.


module top_module (
    input clk,
    input reset,
    output [3:0] q);
    always @(posedge clk) begin
        if (reset) begin
            q <= 4'b0001;
        end
        else begin
            if (q < 4'b1010) begin
                q <= q+1;
            end
            else
                q <= 4'b0001;
        end
    end
endmodule
