Spring Boot向Vue发送消息通过WebSocket实现通信

注意：如果后端有contextPath，如/app，那么前端访问的url就是ip:port/app/ws

如果是前后端在一起，如前端打包放到boot中，前端的ip:port可以不写

后端实现步骤

• 添加Spring Boot WebSocket依赖
• 配置WebSocket端点和消息代理
• 创建控制器，使用SimpMessagingTemplate发送消息

前端实现步骤

• 安装sockjs-client和stompjs库
• 封装WebSocket连接工具类
• 在Vue组件中建立连接，订阅主题

详细实现步骤

后端（Spring Boot）实现步骤

1. 添加依赖

<!-- pom.xml -->
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-websocket</artifactId>
</dependency>

2. 配置WebSocket

@Configuration
@EnableWebSocketMessageBroker
public class WebSocketConfig implements WebSocketMessageBrokerConfigurer {

    @Override
    public void registerStompEndpoints(StompEndpointRegistry registry) {
        // 注册WebSocket端点，前端连接此地址
        registry.addEndpoint("/ws")
                .setAllowedOriginPatterns("*") // 解决跨域问题
                .withSockJS(); // 支持SockJS
    }

    @Override
    public void configureMessageBroker(MessageBrokerRegistry registry) {
        // 客户端订阅的主题前缀
        registry.enableSimpleBroker("/topic");
    }
}

3. 发送消息的Controller

@RestController
public class MessageController {

    @Autowired
    private SimpMessagingTemplate messagingTemplate;

    // 发送消息到所有客户端
    @GetMapping("/send")
    public void sendToAll(String message) {
        messagingTemplate.convertAndSend("/topic/messages", message);
    }

}

前端（Vue）实现步骤

1. 安装依赖

npm install sockjs-client stompjs

2. 封装WebSocket工具类

// src/utils/websocket.js
import SockJS from 'sockjs-client';
import Stomp from 'stompjs';
let stompClient = null;
export function connect(url,callback) {
    const socket = new SockJS(url);
    stompClient = Stomp.over(socket);
    stompClient.connect({}, () => {
        stompClient.subscribe('/topic/messages', (message) => {
            callback(message.body)
        });
    });
}
export function disconnect() {
    if (stompClient) {
        stompClient.disconnect();
    }
}

3. Vue组件集成

<template>
  <div>
    <div>收到消息: {{ receivedMsg }}</div>
  </div>
</template>
<script>
import { connect, disconnect } from '@/ws/websocket';

export default {
  data() {
    return {
      inputMsg: '',
      receivedMsg: ''
    };
  },
  mounted() {
    connect('http://localhost:8088/ws',(msg)=>{
      this.receivedMsg = msg;
    });
  },
  beforeDestroy() {
    disconnect();
  },
  methods: {
  }
};
</script>

测试

向指定客户端发送消息

使用不同端口

后端

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-websocket</artifactId>
        </dependency>

package com.config;

import org.springframework.context.annotation.Configuration;
import org.springframework.messaging.simp.config.MessageBrokerRegistry;
import org.springframework.web.socket.config.annotation.EnableWebSocketMessageBroker;
import org.springframework.web.socket.config.annotation.StompEndpointRegistry;
import org.springframework.web.socket.config.annotation.WebSocketMessageBrokerConfigurer;

/**
 * @author cyz
 */
@Configuration
@EnableWebSocketMessageBroker
public class WebSocketConfig implements WebSocketMessageBrokerConfigurer {
    @Override
    public void registerStompEndpoints(StompEndpointRegistry registry) {
        // 客户端连接的端点（WebSocket URL）
        registry.addEndpoint("/ws")
                // 允许所有来源（根据需求调整）
                .setAllowedOrigins("*")
                // 支持 SockJS 降级（兼容不支持 WebSocket 的浏览器）
                .withSockJS();
    }

    @Override
    public void configureMessageBroker(MessageBrokerRegistry registry) {
        // 客户端订阅的地址前缀（STOMP 主题）
        registry.enableSimpleBroker("/portCheckProgress");
    }
}

package com;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.messaging.simp.SimpMessagingTemplate;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.RestController;
/**
 * @author cyz
 * @since 2025/4/1 下午5:15
 */
@RestController
public class MessageController {
    @Autowired
    private SimpMessagingTemplate messagingTemplate;
    @GetMapping("/send-to-user")
    public void sendToUser(@RequestParam String userCode, @RequestParam String message) {
        String destination =  "/portCheckProgress/info/"+userCode;
        messagingTemplate.convertAndSend(destination, message);
    }
}

package com;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

/**
 * @author cyz
 * @since 2025/4/1 下午5:12
 */
@SpringBootApplication
public class Application {
    public static void main(String[] args) {
        SpringApplication.run(Application.class, args);
    }
}

前端

// src/utils/websocket.js
import SockJS from 'sockjs-client';
import Stomp from 'stompjs';
let stompClient = null;
export function connect(url,userCode,callback) {
    const socket = new SockJS(url);
    stompClient = Stomp.over(socket);
    stompClient.connect({}, () => {
        stompClient.subscribe('/portCheckProgress/info/'+userCode, (message) => {
            callback(message.body)
        });
    });
}
export function disconnect() {
    if (stompClient) {
        stompClient.disconnect();
    }
}

<template>
  <div>
    <div>收到消息: {{ receivedMsg }}</div>
  </div>
</template>
<script>
import { connect, disconnect } from '@/ws/websocket';

export default {
  data() {
    return {
      inputMsg: '',
      receivedMsg: ''
    };
  },
  mounted() {
    var split = location.href.split("?userCode=");
    var userCode = split[1]
    connect('http://localhost:8088/ws',userCode,(msg)=>{
      this.receivedMsg = msg;
    });
  },
  beforeDestroy() {
    disconnect();
  },
  methods: {
  }
};
</script>

测试

向2中发送消息

 向3中发送消息

后端是https

使用不同端口

可以在后端多启动一个端口，然后重定向到https端口即可，如下

package com.config;


import org.apache.catalina.connector.Connector;
import org.springframework.boot.web.embedded.tomcat.TomcatServletWebServerFactory;
import org.springframework.boot.web.servlet.server.ServletWebServerFactory;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

/**
 * @author cyz
 */
@Configuration
public class HttpAndHttpsConfig {

    @Bean
    public ServletWebServerFactory servletContainer() {
        TomcatServletWebServerFactory tomcat = new TomcatServletWebServerFactory();
        tomcat.addAdditionalTomcatConnectors(createHttpConnector());
        return tomcat;
    }

    private Connector createHttpConnector() {
        Connector connector = new Connector("org.apache.coyote.http11.Http11NioProtocol");
        connector.setScheme("http");
        connector.setSecure(false);
        // 与HTTPS端口一致
        connector.setPort(8087);
        // 重定向到HTTPS端口
        connector.setRedirectPort(8088);
        return connector;
    }
}

前端写的是http协议及其端口

使用同一端口

可以使用同一个端口，不过可能要添加一些配置（不一定，看boot版本）

如下
