数据可视化---使用matplotlib绘制高级图表(2)

题目一：绘制人口金字塔图

编写程序。根据第8.6，绘制如下图的人口金字塔图。

运行代码：

#绘制人口金字塔图
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
plt.rcParams['font.sans-serif'] = 'SimHei'
plt.rcParams['axes.unicode_minus'] = False

df = pd.read_excel(r"D:\数据可视化\14\population.xlsx")
df_male = df.groupby(by='Gender').get_group("Male")
list_male = df_male['Number'].values.tolist()
df_female = df.groupby(by='Gender').get_group('Female')
list_female = df_female['Number'].values.tolist()
df_age = df.groupby('AgeGroup').sum()
count = df_age.shape[0]
y = np.arange(1, 11)
labels = []
for i in range(count):
    age = df_age.index[i]
    labels.append(age)
fig = plt.figure()
ax = fig.add_subplot(111)
ax.barh(y, list_male, tick_label=labels, label = '男', color='#6699FF')
ax.barh(y, list_female, tick_label=labels, label = '女', color='#CC6699')
ax.set_ylabel("年龄段(岁)")
ax.set_xticks([-100000, -75000, -50000, -25000, 0, 25000, 50000, 75000, 100000])
ax.set_xticklabels(['100000', '75000', '50000', '25000', '0', '25000', '50000', '75000', '100000'])
ax.set_xlabel('人数(个)')
ax.set_title('某城市人口
