前面一篇文章介绍了C#和secs集成的例子

java与SECS/GEM基础通信

S2F17获取时间

半导体行业-SECS/GEM协议 JAVA与SECS/GEM通信 S10F3 终端单个显示例子 Springboot集成SECS/GEM通信协议-优快云博客

springboot与secs例子下载-----> 更多详细资料

 $('#S5F1ERR').click(function(){
                $.ajax({
                    type: 'GET',
                    url: '/S5F1ERR',
                    data: {
                        id: 1
                    },
                    success: function (res) {
                        $('#msg').text("发送成功");
                        hideMsg()
                    }
                })
            });

            $('#S5F1CanclERR').click(function(){
                $.ajax({
                    type: 'GET',
                    url: '/S5F1CanclERR',
                    data: {
                        id: 1
                    },
                    success: function (res) {
                        $('#msg').text("发送成功");
                        hideMsg()
                    }
                })
            });

@RequestMapping("/S5F1ERR")
    @ResponseBody
    public String S5F1ERR() throws InterruptedException {
        SecsMessage msg = null;
        Secs2 secs2=null;
        Optional<SecsMessage> reply=null;
        byte result=0x00;
        try {
            secs2=Secs2.list(
                    Secs2.binary((byte) 0x08),	/* 0 */
                    Secs2.uint2(6),	/* 1 */
                    Secs2.ascii("The boiler temperature exceeds the range")
            );
            reply = SecsBase.comm.send(5, 1, true,secs2);
            msg = reply.get();
            secs2 = reply.get().secs2();
            try{
                result=secs2.getByte(0);
            } catch (Secs2Exception e ) {
                SecsBase.comm.gem().s9f7(msg);
            }
        }catch (SecsException e){
            return "secs设备还没有连接上主机";
        }
        return "OK";
    }

    @RequestMapping("/S5F1CanclERR")
    @ResponseBody
    public String S5F1Cancl() throws InterruptedException {
        SecsMessage msg = null;
        Secs2 secs2=null;
        Optional<SecsMessage> reply=null;
        byte result=0x00;
        try {
            secs2=Secs2.list(
                    Secs2.binary((byte) 0x00),	/* 0 */
                    Secs2.uint2(6),	/* 1 */
                    Secs2.ascii("The boiler temperature exceeds the range")
            );
            reply = SecsBase.comm.send(5, 1, true,secs2);
            msg = reply.get();
            secs2 = reply.get().secs2();
            try{
                result=secs2.getByte(0);
            } catch (Secs2Exception e ) {
                SecsBase.comm.gem().s9f7(msg);
            }
        }catch (SecsException e){
            return "secs设备还没有连接上主机";
        }
        return "OK";
    }
