Unity在3D空间里同时满足鼠标和触屏拖动物体移动

hongchang2010

已于 2023-06-01 16:31:28 修改

阅读量678

点赞数

文章标签： unity 3d 计算机外设

于 2023-06-01 16:10:43 首次发布

本文链接：https://blog.youkuaiyun.com/hongchang2010/article/details/130990528

版权

该代码示例展示了如何在Unity3D中编写C#脚本来实现3D物体同时支持鼠标和触屏的拖动操作。通过IDragHandler等接口处理开始、进行和结束拖动的事件，以及根据输入设备（触屏或鼠标）切换拖动模式（平移或旋转）。同时，脚本还包括了对Rigidbody组件的控制，确保在拖动时物体运动正确。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

在3D空间里同时满足鼠标和触屏上拖动物体移动

下面展示一些 内联代码片。

// An highlighted block
using System;
using System.Collections;
using System.Collections.Generic;
using UnityEngine;
using UnityEngine.EventSystems;
using zSpace.Core;
//动态设置脚本执行顺序DefaultExecutionOrder
[DefaultExecutionOrder(ZCameraRig.ScriptPriority - 2)]
public class StylusDragable : MonoBehaviour, IDragHandler, IBeginDragHandler, IEndDragHandler,IPointerDownHandler,IPointerUpHandler
{
    private Vector3 _initialGrabOffset = Vector3.zero;
    private Quaternion _initialGrabRotation = Quaternion.identity;
    private bool _isKinematic = false;
    private enum Mode { None, Drag, Rotate }
    private enum Source { None, Stylus, Touch, Mouse }
    private Source m_souce = Source.None;
    private Mode m_mode = Mode.None;
    private float m_distance;
    private float m_rotateSpeed = 0.2f;
    private Camera m_eventCamera = null;
    private int m_currentPointerId = -1000;
    public event Action StartDragEvent;
    public event Action EndDragEvent;

    public Action<Collider> OnTriggerEnterListening;
    public Action<Collider> OnTriggerExitListening;

    private void OnTriggerEnter(Collider other)
    {
        OnTriggerEnterListening?.Invoke(other);
    }

    private void OnTriggerExit(Collider other)
    {
        OnTriggerExitListening?.Invoke(other);
    }
    public void OnBeginDrag(PointerEventData eventData)
    {
        if (m_currentPointerId > -10) return;

        if (eventData.pointerId < 0)
            MouseOnBeginDrag(eventData);
        else
            TouchOnBeginDrag(eventData);

        StartDragEvent?.Invoke();
        if (m_mode != Mode.None && m_currentPointerId > -10) RigidbodyFreeze();
    }
    public void OnDrag(PointerEventData eventData)
    {
        if (eventData.pointerId != m_currentPointerId) return;

        if (m_souce == Source.Touch)
            TouchOnDrag(eventData);
        else if (m_souce == Source.Mouse)
            MouseOnDrag(eventData);
        StartDragEvent?.Invoke();
    }
    public void OnEndDrag(PointerEventData eventData)
    {
        if (eventData.pointerId != m_currentPointerId) return;

        if (m_mode != Mode.None) RigidbodyRestore();

        if (m_souce == Source.Touch)
            TouchOnEndDrag(eventData);
        else if (m_souce == Source.Mouse)
            MouseOnEndDrag(eventData);
        EndDragEvent?.Invoke();
        m_mode = Mode.None;
        m_souce = Source.None;
        m_eventCamera = null;
        m_currentPointerId = -1000;
    }
    #region Touch
    public void TouchOnBeginDrag(PointerEventData eventData)
    {
        m_souce = Source.Touch;
        m_mode = Mode.None;

        if (eventData.pointerId != 0) return;
        m_currentPointerId = eventData.pointerId;

        if (Input.touchCount == 1)
        {
            m_mode = Mode.Drag;
            RaycastResult rayRes = eventData.pointerCurrentRaycast;
            if (rayRes.module == null || rayRes.module.eventCamera == null) return;
            this.m_distance = (Camera.main.transform.position - rayRes.worldPosition).magnitude;
            this.m_eventCamera = Camera.main;
            this._initialGrabOffset = Quaternion.Inverse(this.transform.rotation) * (this.transform.position - rayRes.worldPosition);
            this._initialGrabRotation = Quaternion.Inverse(Quaternion.Euler(rayRes.worldNormal)) * this.transform.rotation;
        }
        else
        {
            m_mode = Mode.Rotate;
            this._initialGrabRotation = this.transform.rotation;
            this._initialGrabOffset = eventData.position;
        }
    }
    public void TouchOnDrag(PointerEventData eventData)
    {
        if (eventData.pointerId != 0) return;

        if (m_mode == Mode.Drag)
        {
            if (this.m_eventCamera == null) return;
            Ray ray = this.m_eventCamera.ScreenPointToRay(new Vector3(eventData.position.x, eventData.position.y, m_distance));
            this.transform.position = (this.m_eventCamera.transform.position + ray.direction * m_distance) + (this.transform.rotation * this._initialGrabOffset);
        }
        else if (m_mode == Mode.Rotate)
        {
            Vector2 delta = eventData.position - new Vector2(_initialGrabOffset.x, _initialGrabOffset.y);
            Quaternion q1 = Quaternion.AngleAxis(delta.x * m_rotateSpeed, Vector3.down);
            Quaternion q2 = Quaternion.AngleAxis(delta.y * m_rotateSpeed, Vector3.right);
            this.transform.rotation = q2 * q1 * this._initialGrabRotation;
        }
    }
    public void TouchOnEndDrag(PointerEventData eventData)
    {

    }
    #endregion
    #region Mouse
    public void MouseOnBeginDrag(PointerEventData eventData)
    {
        m_souce = Source.Mouse;
        m_mode = Mode.None;
        m_currentPointerId = eventData.pointerId;

        if (eventData.button == PointerEventData.InputButton.Left)
        {
            m_mode = Mode.Drag;
            RaycastResult rayRes = eventData.pointerCurrentRaycast;
            //if (rayRes.module == null || rayRes.module.eventCamera == null) return;
            this.m_distance = (Camera.main.transform.position - rayRes.worldPosition).magnitude;
            this.m_eventCamera = Camera.main;
            this._initialGrabOffset = Quaternion.Inverse(this.transform.rotation) * (this.transform.position - rayRes.worldPosition);
            this._initialGrabRotation = Quaternion.Inverse(Quaternion.Euler(rayRes.worldNormal)) * this.transform.rotation;
        }
        else if (eventData.button == PointerEventData.InputButton.Right)
        {
            m_mode = Mode.Rotate;
            this._initialGrabRotation = this.transform.rotation;
            this._initialGrabOffset = eventData.position;
        }
    }
    public void MouseOnDrag(PointerEventData eventData)
    {
        if (m_mode == Mode.Drag)
        {
            if (this.m_eventCamera == null) return;
            Ray ray = this.m_eventCamera.ScreenPointToRay(new Vector3(eventData.position.x, eventData.position.y, m_distance));
            this.transform.position = (this.m_eventCamera.transform.position + ray.direction * m_distance) + (this.transform.rotation * this._initialGrabOffset);
        }
        else if (m_mode == Mode.Rotate)
        {
            Vector2 delta = eventData.position - new Vector2(_initialGrabOffset.x, _initialGrabOffset.y);
            Quaternion q1 = Quaternion.AngleAxis(delta.x * m_rotateSpeed, Vector3.down);
            Quaternion q2 = Quaternion.AngleAxis(delta.y * m_rotateSpeed, Vector3.right);
            this.transform.rotation = q2 * q1 * this._initialGrabRotation;
        }
    }
    public void MouseOnEndDrag(PointerEventData eventData)
    {

    }
    #endregion

    private void RigidbodyFreeze()
    {
        var rigidbody = this.GetComponent<Rigidbody>();
        if (rigidbody != null)
        {
            this._isKinematic = rigidbody.isKinematic;
            rigidbody.isKinematic = true;
        }
    }
    private void RigidbodyRestore()
    {
        var rigidbody = this.GetComponent<Rigidbody>();
        if (rigidbody != null)
        {
            rigidbody.isKinematic = this._isKinematic;
        }
    }

    private void OnDisable()
    {
        EndDragEvent?.Invoke();
    }

    public void OnPointerDown(PointerEventData eventData)
    {

        StartDragEvent?.Invoke();
    }

    public void OnPointerUp(PointerEventData eventData)
    {

        EndDragEvent?.Invoke();
    }
