Gradient Descent

Today, I’m going to try this method to solve a linear regression problem.

Function can be written as:

$$h(\theta )={\theta }_0+{\theta }_{1}x$$

The cost function, “Squared error function”, or “Mean squared error” is:

$$J({\theta }_0,{\theta }_1)=\frac{1}{2}m\sum _{i=1}^m=\frac{1}{2m}(\widehat{y_i}-y_i{)}^2=\frac{1}{2m}(h_{\theta }(x_i)-y_i{)}^2$$

Iterate until function $J(\theta )$ to

$$MinJ({\theta }_0,{\theta }_1)$$

Iterate by:

$${\theta }_j:={\theta }_j-\alpha \frac{\partial }{\partial {\theta }_j}J({\theta }_0,{\theta }_1)$$

“:=” means renew the value.

Import

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
from mpl_toolkits.mplot3d import axes3d
from sklearn import preprocessing
import warnings
%matplotlib inline
%config InlineBackend.figure_format = 'retina'
warnings.filterwarnings('ignore')

data = pd.read_csv("./Salary_Data.csv")
display(data)

	YearsExperience	Salary
0	1.1	39343.0
1	1.3	46205.0
2	1.5	37731.0
3	2.0	43525.0
4	2.2	39891.0
5	2.9	56642.0
6	3.0	60150.0
7	3.2	54445.0
8	3.2	64445.0
9	3.7	57189.0
10	3.9	63218.0
11	4.0	55794.0
12	4.0	56957.0
13	4.1	57081.0
14	4.5	61111.0
15	4.9	67938.0
16	5.1	66029.0
17	5.3	83088.0
18	5.9	81363.0
19	6.0	93940.0
20	6.8	91738.0
21	7.1	98273.0
22	7.9	101302.0
23	8.2	113812.0
24	8.7	109431.0
25	9.0	105582.0
26	9.5	116969.0
27	9.6	112635.0
28	10.3	122391.0
29	10.5	121872.0

Preprocessing

The scale of the data is too big, so we need to normalize them by:

$$z=\frac{x-min(x)}{max(x)-min(x)}$$

x = data.values[:, 0]
y = data.values[:, 1]
x = preprocessing.normalize([x]).T
y = preprocessing.normalize([y]).T

Functions

Then define some functinos:

def h(t0, t1):
    '''linear function'''
    return t0 + t1 * x


def J(t0, t1):
    '''cost function'''
    sum = 0.5 * (1 / len(x)) * np.sum(np.power((t0 + t1 * x) - y, 2))
    return sum


def gd(t0, t1, alpha, n_iter):
    '''main function'''
    theta = [t0, t1]
    temp = np.array([t0, t1])
    cost = []

    k = 0
    while True:
        t0 = theta[0] - alpha * (1 / len(x)) * np.sum((theta[0] + theta[1] * x) - y)
        t1 = theta[1] - alpha * (1 / len(x)) * np.sum(((theta[0] + theta[1] * x) - y) * x)
        theta = [t0, t1]
        cost.append(J(t0, t1))
        temp = np.vstack([temp, theta])
        k += 1
        if k >= n_iter:
            break
    return cost, temp, theta

Output

cost, temp, theta = gd(0, 1, 1, 500)
print("The result is: h = %.2f + %.2f * x" % (theta[0], theta[1]))
yh = h(theta[0], theta[1])
fig1 = plt.figure(dpi=150)
plt.plot(x, yh)
plt.plot(x, y, 'o', markersize=1.5)
for i in range(len(x)):
    plt.plot([x[i], x[i]], [y[i], yh[i]], "r--", linewidth=0.8)
plt.title("Fit")
plt.tight_layout()
plt.show()

The result is: h = 0.06 + 0.71 * x

fig2 = plt.figure(dpi=150)
plt.plot(range(len(cost)), cost, 'r')
plt.title("Cost Function")
plt.tight_layout()
plt.show()

Compared to Normal Equation

$$\theta =(X^{T}X{)}^{-1}{X}^{T}y$$

X = x
X.shape

(30, 1)

one = np.ones((30, 1))
one.shape
X = np.concatenate([one, X], axis=1)

(30, 1)

theta = np.linalg.pinv(X.T @ X) @ X.T @ y
theta

array([[0.05839456],
       [0.70327706]])

print("The result is: h = %.2f + %.2f * x" % (theta[0], theta[1]))
yh = h(theta[0], theta[1])
fig1 = plt.figure(dpi=150)
plt.plot(x, yh)
plt.plot(x, y, 'o', markersize=1.5)
for i in range(len(x)):
    plt.plot([x[i], x[i]], [y[i], yh[i]], "r--", linewidth=0.8)
plt.title("Fit")
plt.tight_layout()
plt.show()

The result is: h = 0.06 + 0.70 * x

print("gd cost:", cost[-1])
print("ne cost:", J(theta[0], theta[1]))

gd cost: 8.042499159722341e-05
ne cost: 8.014548878265756e-05
