【Qt】嵌入式开发控件阴影替代方案

最近在海思上用Qt做一个界面时，发现当给窗口添加阴影（QGraphicsDropShadowEffect）时，鼠标移动到该窗口上的部分控件上会出现非常明显的卡顿，经查阅是阴影导致的CPU占用过高。
于是就着手查找QGraphicsDropShadowEffect的替代方案。

具体实现如下：

void BaseLayer::mouseMoveEvent(QMouseEvent *e) {
    int x = e->pos().x();       // 获取鼠标位置
    if(x < 10) {
        // m_leftMenu->popOut();
        m_leftMenu->show_();
        this->update(QRect(m_leftMenu->x()-10, m_leftMenu->y()-10, m_leftMenu->width()+2*10, m_leftMenu->height()+2*10).adjusted(-10, -10, 10, 10));
    } else if(x > m_leftMenu->width()+10 && m_leftMenu->status() == LeftMenu::Showing) {
        // m_leftMenu->popIn();
        m_leftMenu->hide_();
        this->update(QRect(0, (height()/2)-(m_leftMenu->height()/2)-10, m_leftMenu->width()+2*20, m_leftMenu->height()+2*20).adjusted(-10, -10, 10, 10));
    }
    if(width()-10<x && x<width()) {
        // m_rightMenu->popOut();
        m_rightMenu->show_();
        this->update(QRect(m_rightMenu->x()-10, m_rightMenu->y()-10, m_rightMenu->width()+2*10, m_rightMenu->height()+2*10).adjusted(-10, -10, 10, 10));
    } else if(x < width()-m_rightMenu->width() && m_rightMenu->status() == RightMenu::Showing) {
        // m_rightMenu->popIn();
        m_rightMenu->hide_();
        this->update(QRect(width()-m_rightMenu->width()-10, (height()/2)-(m_rightMenu->height()/2), m_rightMenu->width()+2*20, m_rightMenu->height()+2*20).adjusted(-10, -10, 10, 10));
    }
    int y = e->pos().y();
    if(y>this->height()-30) {
        m_toolBar->popOut();
        // m_toolBar->show_();
        this->update(QRect(m_toolBar->x(), height()-m_toolBar->height()-10, m_toolBar->width()+2*10, m_toolBar->height()+2*10).adjusted(-10, -10, 10, 10));
    } else if(y<this->height()-m_toolBar->height()-30 && m_toolBar->status() == ToolBar::Showing) {
        m_toolBar->popIn();
        // m_toolBar->hide_();
        this->update(QRect(m_toolBar->x(), height()-m_toolBar->height()-10, m_toolBar->width()+2*10, m_toolBar->height()+2*10).adjusted(-10, -10, 10, 10));
    }
    QWidget::mouseMoveEvent(e); // 调用基类方法
}

void BaseLayer::paintEvent(QPaintEvent *event) {
    Q_UNUSED(event)
    QPainter painter(this);
    painter.setRenderHint(QPainter::Antialiasing, true);

    int shadowWidth = 30;
    QColor color(10, 10, 10, 50);
    if(m_leftMenu->status()==LeftMenu::Showing) {
        for (int i = 0; i < shadowWidth; i++) { //当 i 从 0 增加时，透明度从 120 逐渐减少到 0，从而产生一种渐变的阴影效果
            int alpha = 120 - static_cast<int>(pow(i, 0.5) * 40);
            alpha = qMax(alpha, 0);  // 确保alpha值不小于0
            color.setAlpha(alpha);
            painter.setPen(color);
            painter.drawRoundedRect(m_leftMenu->x()-i, m_leftMenu->y()-i, m_leftMenu->width()+2*i,
                                    m_leftMenu->height()+2*i, 15, 15);    // 圆角阴影边框;
        }
    }
    if(m_rightMenu->status()==RightMenu::Showing) {
        for (int i = 0; i < shadowWidth; i++) { //当 i 从 0 增加时，透明度从 120 逐渐减少到 0，从而产生一种渐变的阴影效果
            int alpha = 120 - static_cast<int>(pow(i, 0.5) * 40);
            alpha = qMax(alpha, 0);  // 确保alpha值不小于0
            color.setAlpha(alpha);
            painter.setPen(color);
            painter.drawRoundedRect(m_rightMenu->x()-i, m_rightMenu->y()-i, m_rightMenu->width()+2*i,
                                    m_rightMenu->height()+2*i, 15, 15);     // 圆角阴影边框;

        }
    }
    if(m_toolBar->status()==ToolBar::Showing) {
        for (int i = 0; i < shadowWidth; i++) { //当 i 从 0 增加时，透明度从 120 逐渐减少到 0，从而产生一种渐变的阴影效果
            int alpha = 120 - static_cast<int>(pow(i, 0.5) * 40);
            alpha = qMax(alpha, 0);  // 确保alpha值不小于0
            color.setAlpha(alpha);
            painter.setPen(color);
            painter.drawRoundedRect(m_toolBar->x()-i, m_toolBar->y()-i, m_toolBar->width()+2*i,
                                    m_toolBar->height()+2*i, 15, 15);     // 圆角阴影边框;
        }
    }
}

效果展示


代码逻辑解释：鼠标移动到特定位置后弹出菜单栏或工具栏，在其显示区域处由内到外绘制若干个颜色逐渐变淡的圆角矩形，从而实现阴影效果。

QGraphicsDropShadowEffect 效果

    QGraphicsDropShadowEffect * effect = new QGraphicsDropShadowEffect(this);
    effect->setOffset(0, 0);//设置阴影距离
    effect->setColor(QColor(0,0,0,255));//设置阴影颜色
    effect->setBlurRadius(20);//设置阴影圆角
    this->setGraphicsEffect(effect);

看着差不多
