整合SpringBoot+Shiro+Redis之完整案例，包括重写cache、cacheManager、SessionDAO

一、创建springboot工程，导入pom文件依赖

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.5.4</version>
        <relativePath/> <!-- lookup parent from repository -->
    </parent>
    <groupId>com.zjhc</groupId>
    <artifactId>shiro-all</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <packaging>war</packaging>
    <name>shiro-all</name>
    <description>Demo project for Spring Boot</description>
    <properties>
        <java.version>1.8</java.version>
    </properties>
    <dependencies>
    <!-- 如果使用RedisProperties时需要引入 -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-redis</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-tomcat</artifactId>
            <scope>provided</scope>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>
        <!-- lombok -->
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
        <!-- shiro -->
        <dependency>
            <groupId>org.apache.shiro</groupId>
            <artifactId>shiro-spring</artifactId>
            <version>1.7.1</version>
        </dependency>
        <!-- mysql -->
        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <scope>5.1.47</scope>
        </dependency>
        <!-- mybatis plus-->
        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-boot-starter</artifactId>
            <version>3.2.0</version>
        </dependency>
        <!-- druid -->
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>druid</artifactId>
            <version>1.1.23</version>
        </dependency>
        <!--hutool工具包-->
        <dependency>
            <groupId>cn.hutool</groupId>
            <artifactId>hutool-all</artifactId>
            <version>5.7.7</version>
        </dependency>
        <!-- thymeleaf 模板-->
        <dependency>
            <groupId>org.thymeleaf.extras</groupId>
            <artifactId>thymeleaf-extras-java8time</artifactId>
        </dependency>
        <dependency>
            <groupId>org.thymeleaf</groupId>
            <artifactId>thymeleaf-spring5</artifactId>
        </dependency>
        <!--shiro标签+thymeleaf-->
        <dependency>
            <groupId>com.github.theborakompanioni</groupId>
            <artifactId>thymeleaf-extras-shiro</artifactId>
            <version>2.0.0</version>
        </dependency>
        <!-- shiro+redis 做session和缓存控制-->
        <dependency>
            <groupId>org.crazycake</groupId>
            <artifactId>shiro-redis</artifactId>
            <version>3.3.1</version>
        </dependency>
        <!-- Hibernate Validate-->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-validation</artifactId>
        </dependency>

        <!-- shiro ehcahce缓存-->
        <!--<dependency>-->
        <!--    <groupId>org.apache.shiro</groupId>-->
        <!--    <artifactId>shiro-ehcache</artifactId>-->
        <!--    <version>1.7.1</version>-->
        <!--</dependency>-->
        <dependency>
            <groupId>junit</groupId>
            <artifactId>junit</artifactId>
            <scope>test</scope>
        </dependency>
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
                <configuration>
                    <excludes>
                        <exclude>
                            <groupId>org.projectlombok</groupId>
                            <artifactId>lombok</artifactId>
                        </exclude>
                    </excludes>
                </configuration>
            </plugin>
        </plugins>
    </build>
</project>

二、yml文件配置

server:
  port: 6677
spring:
  datasource:
    url: jdbc:mysql://12.41.106.140:43306/shiro_db?useUnicode=true&useSSL=false&characterEncoding=utf8&serverTimezone=UTC
    username: root
    password: rnny@123456
    driver-class-name: com.mysql.cj.jdbc.Driver

  thymeleaf:
    cache: false

  redis:
    host: 12.41.106.140
    port: 16379
    password: rnny@123456
    jedis:
      pool:
        min-idle: 8
        max-wait: 10000
        max-active: 2000
        max-idle: 500

mybatis-plus:
  mapper-locations: classpath*:/mapper/**Mapper.xml
  configuration:
    log-impl: org.apache.ibatis.logging.stdout.StdOutImpl

三、根据MP插件生成mapper,entity,service,impl,mapper.xml

3.1 User类

1. User实体

@Data
@AllArgsConstructor
@NoArgsConstructor
@TableName(value = "user_info")
public class User implements Serializable {


    /**
     * 主键
     */
    @TableId(value = "uid", type = IdType.AUTO)
    private Integer uid;

    /**
     * 用户名
     */
    @TableField(value = "username")
    private String username;

    /**
     * 登录密码
     */
    @TableField(value = "password")
    private String password;

    /**
     * 用户真实姓名
     */
    @TableField(value = "name")
    private String name;

    /**
     * 手机号码
     */
    @TableField(value = "phone")
    private String phone;

    /**
     * 身份证号
     */
    @TableField(value = "idcard")
    private String idcard;

    /**
     * 用户状态；0:正常状态，1:账户被锁定
     */
    @TableField(value = "state")
    private String state;
}

2. UserService

public interface UserService extends IService<User>{


}

3. UserServiceImpl

@Service
public class UserServiceImpl extends ServiceImpl<UserMapper, User> implements UserService{


}

4. UserMapper

public interface UserMapper extends BaseMapper<User> {


    User getUserByUsername(String username);
    int insert(User user);
    int del(@Param("username")String username);
}

5. UserMapper.xml

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.zjhc.mapper.UserMapper">
  <resultMap id="BaseResultMap" type="com.zjhc.entity.User">
    <!--@mbg.generated-->
    <!--@Table user_info-->
    <id column="uid" jdbcType="INTEGER" property="uid" />
    <result column="username" jdbcType="VARCHAR" property="username" />
    <result column="password" jdbcType="VARCHAR" property="password" />
    <result column="name" jdbcType="VARCHAR" property="name" />
    <result column="phone" jdbcType="VARCHAR" property="phone" />
    <result column="idcard" jdbcType="VARCHAR" property="idcard" />
    <result column="state" jdbcType="CHAR" property="state" />
  </resultMap>
  <sql id="Base_Column_List">
    <!--@mbg.generated-->
    `uid`, username, `password`, `name`, phone, idcard, `state`
  </sql>
    <select id="getUserByUsername" resultMap="BaseResultMap">
      select * from user_info where username = #{username}
    </select>

  <insert id="insert" parameterType="com.zjhc.entity.User">
    <selectKey resultType="java.lang.Integer" keyProperty="uid" order="AFTER">
        select last_insert_id()
    </selectKey>
    insert into user_info
    <trim prefix="(" suffix=")" suffixOverrides=",">
      <if test="uid != null">
        uid,
      </if>
      <if test="username != null and username != ''">
        username,
      </if>
      <if test="password != null and password != ''">
        password,
      </if>
      <if test="name != null and name != ''">
        name,
      </if>
      <if test="phone != null and phone != ''">
        phone,
      </if>
      <if test="idcard != null and idcard != ''">
        idcard,
      </if>
      <if test="state != null and state != ''">
        state
      </if>
    </trim>
    <trim prefix="values(" suffix=")" suffixOverrides=",">
      <if test="uid != null">
        #{uid},
      </if>
      <if test="username != null and username != ''">
        #{username},
      </if>
      <if test="password != null and password != ''">
        #{password},
      </if>
      <if test="name != null and name != ''">
        #{name},
      </if>
      <if test="phone != null and phone != ''">
        #{phone},
      </if>
      <if test="idcard != null and idcard != ''">
        #{idcard},
      </if>
      <if test="state != null and state != ''">
        #{state}
      </if>
    </trim>
  </insert>

  <delete id="del">
    delete from user_info where username=#{username}
  </delete>
</mapper>

3.2 Role类

1. Role实体

@Data
@AllArgsConstructor
@NoArgsConstructor
@TableName(value = "sys_role")
public class Role {


    /**
     * 角色表主键
     */
    @TableId(value = "role_id", type = IdType.AUTO)
    private Integer roleId;

    /**
     * 角色名称
     */
    @TableField(value = "role_name")
    private String roleName;

    /**
     * 是否可用：0可用1不可用
     */
    @TableField(value = "avaliable")
    private String avaliable;

    /**
     * 角色描述
     */
    @TableField(value = "description")
    private String description;
}

2. RoleService

public interface RoleService extends IService<Role>{


}

3. RoleServiceImpl

@Service
public class RoleServiceImpl extends ServiceImpl<RoleMapper, Role> implements RoleService{


}

4. RoleMapper

public interface RoleMapper extends BaseMapper<Role> {


    Set<Role> findRolesByUserId(@Param("uid") Integer uid);
    void delPermission(int i, int i1);
    void addPermission(int i, int i1);
}

5. RoleMapper.xml

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.zjhc.mapper.RoleMapper">
  <resultMap id="BaseResultMap" type="com.zjhc.entity.Role">
    <!--@mbg.generated-->
    <!--@Table sys_role-->
    <id column="role_id" jdbcType="INTEGER" property="roleId" />
    <result column="role_name" jdbcType="VARCHAR" property="roleName" />
    <result column="avaliable" jdbcType="CHAR" property="avaliable" />
    <result column="description" jdbcType="VARCHAR" property="description" />
  </resultMap>
  <sql id="Base_Column_List">
    <!--@mbg.generated-->
    role_id, role_name, avaliable, description
  </sql>
    <select id="findRolesByUserId" resultMap="BaseResultMap" resultSets="java.util.Set" resultType="com.zjhc.entity.Role">
      SELECT r.* from sys_role r LEFT JOIN sys_user_role ur on r.role_id = ur.rid where ur.uid  = #{uid}
    </select>
    <delete id="delPermission">
    delete from sys_role_permission where role_id=1 and permission_id=3
    </delete>
  <insert id="addPermission">
    insert into sys_role_permission(role_id, permission_id) values(1,3)
  </insert>
</mapper>

3.3 Permissionlei

1. Permission实体

@Data
@AllArgsConstructor
@NoArgsConstructor
@TableName(value = "sys_permission")
public class Permission {


    /**
     * 权限表主键
     */
    @TableId(value = "id", type = IdType.AUTO)
    private Integer id;

    /**
     * 父权限编号，本权限可能是该父编号权限的子权限
     */
    @TableField(value = "parent_id")
    private Integer parentId;

    /**
     * 父编号列表
     */
    @TableField(value = "parent_ids")
    private String parentIds;

    /**
     * 权限编码,menu例子：role:*，button例子：role:create,role:update,role:delete,role:view
     */
    @TableField(value = "permission_Code")
    private String permissionCode;

    /**
     * 权限名称
     */
    @TableField(value = "permission_Name")
    private String permissionName;

    /**
     * 资源类型，[menu|button]
     */
    @TableField(value = "resource_type")
    private String resourceType;

    /**
     * 资源路径 如：/userinfo/list
     */
    @TableField(value = "url")
    private String url;

    /**
     * 是否可用0可用  1不可用
     */
    @TableField(value = "avaliable")
    private String avaliable;
}

2.PermissionService

public interface PermissionService extends IService<Permission>{


}

3.PermissionServiceImpl

@Service
public class PermissionServiceImpl extends ServiceImpl<PermissionMapper, Permission> implements PermissionService{


}

4.PermissionMapper

public interface PermissionMapper extends BaseMapper<Permission> {


    Set<Permission> findPermissionsByRoleId(@Param("roles") Set<Role> roles);
}

5.PermissionMapper.xml

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.zjhc.mapper.PermissionMapper">
  <resultMap id="BaseResultMap" type="com.zjhc.entity.Permission">
    <!--@mbg.generated-->
    <!--@Table sys_permission-->
    <id column="id" jdbcType="INTEGER" property="id" />
    <result column="parent_id" jdbcType="INTEGER" property="parentId" />
    <result column="parent_ids" jdbcType="VARCHAR" property="parentIds" />
    <result column="permission_Code" jdbcType="VARCHAR" property="permissionCode" />
    <result column="permission_Name" jdbcType="VARCHAR" property="permissionName" />
    <result column="resource_type" jdbcType="VARCHAR" property="resourceType" />
    <result column="url" jdbcType="VARCHAR" property="url" />
    <result column="avaliable" jdbcType="CHAR" property="avaliable" />
  </resultMap>
  <sql id="Base_Column_List">
    <!--@mbg.generated-->
    id, parent_id, parent_ids, permission_Code, permission_Name, resource_type, url,
    avaliable
  </sql>
    <select id="findPermissionsByRoleId" resultMap="BaseResultMap" resultSets="java.util.Set" resultType="com.zjhc.entity.Permission">
      SELECT p.* from sys_permission p LEFT JOIN sys_role_permission rp on p.id = rp.permission_id WHERE rp.role_id IN
      <foreach collection="roles" index="index" item="item" open="(" close=")" separator=",">
        #{item.roleId}
      </foreach>
    </select>
</mapper>

四、创建UserRealm

4.1 UserRealm

1. UserRealm实现

@Slf4j
public class UserRealm extends AuthorizingRealm {



    @Lazy
    @Autowired
    UserMapper userMapper;

    @Lazy
    @Autowired
    RoleMapper roleMapper;

    @Lazy
    @Autowired
    PermissionMapper permissionMapper;

    public String getName(){


        return "UserRealm";
    }

    /**
     * 授权
     * @param principalCollection
     * @return
     */
    @Override
    protected AuthorizationInfo doGetAuthorizationInfo(PrincipalCollection principalCollection) {


        log.info("=====================enter method UserRealm-doGetAuthorizationInfo获取角色权限");
        SimpleAuthorizationInfo info = new SimpleAuthorizationInfo();
        Subject subject = SecurityUtils.getSubject();
        //获取当前用户信息
        User user = (User) subject.getPrincipal();
        //User user = userMapper.getUserByUsername(username);
        //查询角色
        Set<Role> roles = this.roleMapper.findRolesByUserId(user.getUid());
        for(Role role : roles){


            info.addRole(role.getRoleName());
        }
        //查询权限
        Set<Permission> permissions = this.permissionMapper.findPermissionsByRoleId(roles);
        for(Permission permission : permissions){


            info.addStringPermission(permission.getPermissionCode());
        }
        return info;
    }

    /**
     * 认证
     * @param authenticationToken
     * @return
     * @throws AuthenticationException
     */
    @Override
    protected AuthenticationInfo doGetAuthenticationInfo(AuthenticationToken authenticationToken) throws AuthenticationException {


        log.info("=====================enter method UserRealm-doGetAuthenticationInfo进行登陆验证");
        UsernamePasswordToken userToken = (UsernamePasswordToken) authenticationToken;
        User user = userMapper.getUserByUsername(userToken.getUsername());
        if(null == user){


            throw new UnknownAccountException("账号不存在,请重试");
        }
        if("1".equals(user.getState())){


            throw new LockedAccountException("账户已被锁定");
        }
        return new SimpleAuthenticationInfo(user,user.getPassword(),new MyByteSource("!QAZ@WSX$RFV"),getName());
    }
  }

五、整合Redis重写Cache,CacheManager,SessionDAO
