mybatis对mapper.xml的解析（二)

对select,insert,update,delete的解析是通过buildStatementFromContext来完成的，具体的解析是XMLStatementBuilder来完成的.

支持的属性有

名称	说明
id	语句id
databaseId	不处理语句情况 1、在配置文件中设置了databaseIdProvider，并且当前设置的databaseId与配置文件中不一致时 2、配置文件 中没有设置，当前设置了databaseId 3、配置文件中没有设置databaseIdProvider,当前没有设置databaseId，有当前id对应的MappedStatement的databaseId不等于null
flushCache	布尔值，如果没有设置情况下，如果是select语句，则默认为false,否则为true
useCache	布尔值，如果没有设置情况上，select语句默认是true，否则为false
resultOrdered	布尔值，没有设置时，默认是false
parameterType	设置语句请求参数类型，可以使用别名
lang	设置语言驱动器,默认是XMLLanguageDriver
selectKey	生成主键节点
useGeneratedKey	如果没有设置，使用全局配置及当前语句是不是插入语句 。如果为true,则使用Jdbc3KeyGenerator,否则使用NoKeyGenerator
statementType	没有设置时默认是PREPARE类型
fetchSize	在StatementHandler中使用，来设置获取大小。
timeout	在StatementHandler中设置语句的执行超时时间
parameterMap	参数映射，已经不推荐使用
resultType	一种特殊的resultMap
resultMap	与resultType相当，两者二选一
resultSetType	用于在StatementHandler中设置语句的ResultType的类型
keyProperty	用于设置主属性，有多个属性时，用逗号分隔。用于KeyGenerator
keyColumn	用于设置数据库字段主键，有多个时，用逗号分隔。用于KeyGenerator以及用于StatementHandler初始化语句时
resultSets	有多个时，用逗号分隔。用于ResultSetHandler处理

selectKey支持的属性

名称	说明
databaseId	不处理语句情况 1、在配置文件中设置了databaseIdProvider，并且当前设置的databaseId与配置文件中不一致时 2、配置文件 中没有设置，当前设置了databaseId 3、配置文件中没有设置databaseIdProvider,当前没有设置databaseId，有当前id对应的MappedStatement的databaseId不等于null
resultType	返回的数据类型
statementType	如果没有设置，默认是PREPARE类型
keyProperty	主属性
keyColumn	数据库主键
order	在什么时候执行，没有设置时，默认是AFTER

1、解析语句中的include

XMLIncludeTransformer在解析include节点时，首先找到refid引用的节点，同时解析子节点property的name,value值对。接着在refid的引用的节点上应用applyIncludes递归调用。递归完后，用引用节点替换indlude节点。将引用节点的子结点添加到include之前，然后删除include节点。

在解析非include节点且节点类型是ELEMENT_NODE时，递归遍历子节点

如果解析的是引用节点，且节点是文本结点会作变量替换。

private void applyIncludes(Node source, final Properties variablesContext, boolean included) {
    if (source.getNodeName().equals("include")) {
      Node toInclude = findSqlFragment(getStringAttribute(source, "refid"), variablesContext);
      Properties toIncludeContext = getVariablesContext(source, variablesContext);
      applyIncludes(toInclude, toIncludeContext, true);
      if (toInclude.getOwnerDocument() != source.getOwnerDocument()) {
        toInclude = source.getOwnerDocument().importNode(toInclude, true);
      }
      source.getParentNode().replaceChild(toInclude, source);
      while (toInclude.hasChildNodes()) {
        toInclude.getParentNode().insertBefore(toInclude.getFirstChild(), toInclude);
      }
      toInclude.getParentNode().removeChild(toInclude);
    } else if (source.getNodeType() == Node.ELEMENT_NODE) {
      NodeList children = source.getChildNodes();
      for (int i = 0; i < children.getLength(); i++) {
        applyIncludes(children.item(i), variablesContext, included);
      }
    } else if (included && source.getNodeType() == Node.TEXT_NODE
        && !variablesContext.isEmpty()) {
      // replace variables ins all text nodes
      source.setNodeValue(PropertyParser.parse(source.getNodeValue(), variablesContext));
    }
  }

2、解析selectKey节点

此结点在insert节点下，解析后添加到configuration中的keyGenerators中，添加后，删除selectKey节点

private void processSelectKeyNodes(String id, Class<?> parameterTypeClass, LanguageDriver langDriver) {
    List<XNode> selectKeyNodes = context.evalNodes("selectKey");
    if (configuration.getDatabaseId() != null) {
      parseSelectKeyNodes(id, selectKeyNodes, parameterTypeClass, langDriver, configuration.getDatabaseId());
    }
    parseSelectKeyNodes(id, selectKeyNodes, parameterTypeClass, langDriver, null);
    removeSelectKeyNodes(selectKeyNodes);
  }

private void parseSelectKeyNodes(String parentId, List<XNode> list, Class<?> parameterTypeClass, LanguageDriver langDriver, String skRequiredDatabaseId) {
    for (XNode nodeToHandle : list) {
      String id = parentId + SelectKeyGenerator.SELECT_KEY_SUFFIX;
      String databaseId = nodeToHandle.getStringAttribute("databaseId");
      if (databaseIdMatchesCurrent(id, databaseId, skRequiredDatabaseId)) {
        parseSelectKeyNode(id, nodeToHandle, parameterTypeClass, langDriver, databaseId);
      }
    }
  }

  private void parseSelectKeyNode(String id, XNode nodeToHandle, Class<?> parameterTypeClass, LanguageDriver langDriver, String databaseId) {
    String resultType = nodeToHandle.getStringAttribute("resultType");
    Class<?> resultTypeClass = resolveClass(resultType);
    StatementType statementType = StatementType.valueOf(nodeToHandle.getStringAttribute("statementType", StatementType.PREPARED.toString()));
    String keyProperty = nodeToHandle.getStringAttribute("keyProperty");
    String keyColumn = nodeToHandle.getStringAttribute("keyColumn");
    boolean executeBefore = "BEFORE".equals(nodeToHandle.getStringAttribute("order", "AFTER"));

    //defaults
    boolean useCache = false;
    boolean resultOrdered = false;
    KeyGenerator keyGenerator = NoKeyGenerator.INSTANCE;
    Integer fetchSize = null;
    Integer timeout = null;
    boolean flushCache = false;
    String parameterMap = null;
    String resultMap = null;
    ResultSetType resultSetTypeEnum = null;

    SqlSource sqlSource = langDriver.createSqlSource(configuration, nodeToHandle, parameterTypeClass);
    SqlCommandType sqlCommandType = SqlCommandType.SELECT;

    builderAssistant.addMappedStatement(id, sqlSource, statementType, sqlCommandType,
        fetchSize, timeout, parameterMap, parameterTypeClass, resultMap, resultTypeClass,
        resultSetTypeEnum, flushCache, useCache, resultOrdered,
        keyGenerator, keyProperty, keyColumn, databaseId, langDriver, null);

    id = builderAssistant.applyCurrentNamespace(id, false);

    MappedStatement keyStatement = configuration.getMappedStatement(id, false);
    configuration.addKeyGenerator(id, new SelectKeyGenerator(keyStatement, executeBefore));
  }

private void removeSelectKeyNodes(List<XNode> selectKeyNodes) {
    for (XNode nodeToHandle : selectKeyNodes) {
      nodeToHandle.getParent().getNode().removeChild(nodeToHandle.getNode());
    }
  }

3、根据参数类型创建SqlSource

包含解析动态节点，创建DynamicSqlSource或者RawSqlSource

SqlSource sqlSource = langDriver.createSqlSource(configuration, context, parameterTypeClass);

4、创建MappedStatement,添加到Configuration中



//XMLStatementBuilder
builderAssistant.addMappedStatement(id, sqlSource, statementType, sqlCommandType,
        fetchSize, timeout, parameterMap, parameterTypeClass, resultMap, resultTypeClass,
        resultSetTypeEnum, flushCache, useCache, resultOrdered,
        keyGenerator, keyProperty, keyColumn, databaseId, langDriver, resultSets);

//MappedBuilderAssistant
public MappedStatement addMappedStatement(
      String id,
      SqlSource sqlSource,
      StatementType statementType,
      SqlCommandType sqlCommandType,
      Integer fetchSize,
      Integer timeout,
      String parameterMap,
      Class<?> parameterType,
      String resultMap,
      Class<?> resultType,
      ResultSetType resultSetType,
      boolean flushCache,
      boolean useCache,
      boolean resultOrdered,
      KeyGenerator keyGenerator,
      String keyProperty,
      String keyColumn,
      String databaseId,
      LanguageDriver lang,
      String resultSets) {

    if (unresolvedCacheRef) {
      throw new IncompleteElementException("Cache-ref not yet resolved");
    }

    id = applyCurrentNamespace(id, false);
    boolean isSelect = sqlCommandType == SqlCommandType.SELECT;

    MappedStatement.Builder statementBuilder = new MappedStatement.Builder(configuration, id, sqlSource, sqlCommandType)
        .resource(resource)
        .fetchSize(fetchSize)
        .timeout(timeout)
        .statementType(statementType)
        .keyGenerator(keyGenerator)
        .keyProperty(keyProperty)
        .keyColumn(keyColumn)
        .databaseId(databaseId)
        .lang(lang)
        .resultOrdered(resultOrdered)
        .resultSets(resultSets)
        .resultMaps(getStatementResultMaps(resultMap, resultType, id))
        .resultSetType(resultSetType)
        .flushCacheRequired(valueOrDefault(flushCache, !isSelect))
        .useCache(valueOrDefault(useCache, isSelect))
        .cache(currentCache);

    ParameterMap statementParameterMap = getStatementParameterMap(parameterMap, parameterType, id);
    if (statementParameterMap != null) {
      statementBuilder.parameterMap(statementParameterMap);
    }

    MappedStatement statement = statementBuilder.build();
    configuration.addMappedStatement(statement);
    return statement;
  }
