SparkStreaming 代码示例

HelloWorld实现

• 需求：通过SparkStreaming读取kafka某个主题的数据并打印输出到控制台。

官方文档: https://spark.apache.org/docs/latest/streaming-kafka-0-10-integration.html

1）添加依赖

<dependencies>

    <dependency>

        <groupId>org.apache.spark</groupId>

        <artifactId>spark-streaming_2.12</artifactId>

        <version>3.3.1</version>

    </dependency>

    <dependency>

        <groupId>org.apache.spark</groupId>

        <artifactId>spark-core_2.12</artifactId>

        <version>3.3.1</version>

</dependency>

<dependency>

    <groupId>org.apache.spark</groupId>

    <artifactId>spark-streaming-kafka-0-10_2.12</artifactId>

    <version>3.3.1</version>

 </dependency>

</dependencies>

2）编写代码

package com.atguigu;

import org.apache.kafka.clients.consumer.ConsumerConfig;

import org.apache.kafka.clients.consumer.ConsumerRecord;

import org.apache.spark.api.java.function.Function;

import org.apache.spark.streaming.Duration;

import org.apache.spark.streaming.api.java.JavaInputDStream;

import org.apache.spark.streaming.api.java.JavaStreamingContext;

import org.apache.spark.streaming.kafka010.ConsumerStrategies;

import org.apache.spark.streaming.kafka010.KafkaUtils;

import org.apache.spark.streaming.kafka010.LocationStrategies;

import java.util.ArrayList;

import java.util.HashMap;

public class Test01_HelloWorld {

    public static void main(String[] args) throws InterruptedException {

        // 创建流环境

        JavaStreamingContext javaStreamingContext = new JavaStreamingContext("local[*]", "HelloWorld", Duration.apply(3000));

        // 创建配置参数

        HashMap<String, Object> map = new HashMap<>();

        map.put(ConsumerConfig.BOOTSTRAP_SERVERS_CONFIG,"hadoop102:9092,hadoop103:9092,hadoop104:9092");

        map.put(ConsumerConfig.KEY_DESERIALIZER_CLASS_CONFIG, "org.apache.kafka.common.serialization.StringDeserializer");

        map.put(ConsumerConfig.VALUE_DESERIALIZER_CLASS_CONFIG, "org.apache.kafka.common.serialization.StringDeserializer");

        map.put(ConsumerConfig.GROUP_ID_CONFIG,"atguigu");

        map.put(ConsumerConfig.AUTO_OFFSET_RESET_CONFIG,"latest");

        // 需要消费的主题

        ArrayList<String> strings = new ArrayList<>();

        strings.add("topic_db");

        JavaInputDStream<ConsumerRecord<String, String>> directStream = KafkaUtils.createDirectStream(javaStreamingContext, LocationStrategies.PreferBrokers(), ConsumerStrategies.<String, String>Subscribe(strings,map));

        directStream.map(new Function<ConsumerRecord<String, String>, String>() {

            @Override

            public String call(ConsumerRecord<String, String> v1) throws Exception {

                return v1.value();

            }

        }).print(100);

        // 执行流的任务

        javaStreamingContext.start();

        javaStreamingContext.awaitTermination();

    }

}

3）更改日志打印级别

        如果不希望运行时打印大量日志，可以在resources文件夹中添加log4j2.properties文件，并添加日志配置信息

# Set everything to be logged to the console

rootLogger.level = ERROR

rootLogger.appenderRef.stdout.ref = console

# In the pattern layout configuration below, we specify an explicit `%ex` conversion

# pattern for logging Throwables. If this was omitted, then (by default) Log4J would

# implicitly add an `%xEx` conversion pattern which logs stacktraces with additional

# class packaging information. That extra information can sometimes add a substantial

# performance overhead, so we disable it in our default logging config.

# For more information, see SPARK-39361.

appender.console.type = Console

appender.console.name = console

appender.console.target = SYSTEM_ERR

appender.console.layout.type = PatternLayout

appender.console.layout.pattern = %d{yy/MM/dd HH:mm:ss} %p %c{1}: %m%n%ex

# Set the default spark-shell/spark-sql log level to WARN. When running the

# spark-shell/spark-sql, the log level for these classes is used to overwrite

# the root logger's log level, so that the user can have different defaults

# for the shell and regular Spark apps.

logger.repl.name = org.apache.spark.repl.Main

logger.repl.level = warn

logger.thriftserver.name = org.apache.spark.sql.hive.thriftserver.SparkSQLCLIDriver

logger.thriftserver.level = warn

# Settings to quiet third party logs that are too verbose

logger.jetty1.name = org.sparkproject.jetty

logger.jetty1.level = warn

logger.jetty2.name = org.sparkproject.jetty.util.component.AbstractLifeCycle

logger.jetty2.level = error

logger.replexprTyper.name = org.apache.spark.repl.SparkIMain$exprTyper

logger.replexprTyper.level = info

logger.replSparkILoopInterpreter.name = org.apache.spark.repl.SparkILoop$SparkILoopInterpreter

logger.replSparkILoopInterpreter.level = info

logger.parquet1.name = org.apache.parquet

logger.parquet1.level = error

logger.parquet2.name = parquet

logger.parquet2.level = error

# SPARK-9183: Settings to avoid annoying messages when looking up nonexistent UDFs in SparkSQL with Hive support

logger.RetryingHMSHandler.name = org.apache.hadoop.hive.metastore.RetryingHMSHandler

logger.RetryingHMSHandler.level = fatal

logger.FunctionRegistry.name = org.apache.hadoop.hive.ql.exec.FunctionRegistry

logger.FunctionRegistry.level = error

# For deploying Spark ThriftServer

# SPARK-34128: Suppress undesirable TTransportException warnings involved in THRIFT-4805

appender.console.filter.1.type = RegexFilter

appender.console.filter.1.regex = .*Thrift error occurred during processing of message.*

appender.console.filter.1.onMatch = deny appender.console.filter.1.onMismatch = neutral

4）启动生产者生产数据

[atguigu@hadoop102 ~]$ kafka-console-producer.sh --broker-list hadoop102:9092 --topic topicA

hello spark

5）在Idea控制台输出如下内容

-------------------------------------------

Time: 1602731772000 ms

-------------------------------------------

hello spark

2.3 HelloWorld解析

DStream是Spark Streaming的基础抽象，代表持续性的数据流和经过各种Spark算子操作后的结果数据流。

在内部实现上，每一批次的数据封装成一个RDD，一系列连续的RDD组成了DStream。对这些RDD的转换是由Spark引擎来计算。

说明：DStream中批次与批次之间计算相互独立。如果批次设置时间小于计算时间会出现计算任务叠加情况，需要多分配资源。通常情况，批次设置时间要大于计算时间。
