vue2录像回放时间轴组件

<template>
  <div class="timeLineContainer" ref="timeLineContainer">
    <canvas
      ref="canvas"
      @mousemove="onMouseMove"
      @mouseleave="onMouseLeave"
      @click="onClick"
    ></canvas>

    <!-- 悬浮提示 -->
<!--    <div v-if="showTooltip" :style="tooltipStyle">{{ tooltipText }}</div>-->
  </div>
</template>

<script>
import moment from "moment";

export default {
  name: "PlaybackTimeline",
  props: {
    startTime: {
      type: Date,
      required: true,
    },
    endTime: {
      type: Date,
      required: true,
    },
    highlightedSegments: {
      type: Array,
      default: () => [],
    },
  },
  data() {
    return {
      width: null,
      height: 100,
      ctx: null,

      showTooltip: false,
      tooltipText: "",
      tooltipPosition: { x: 0, y: 0 },
      mouseX: null,

      drawPending: false, // 是否已经在等待重绘
      lastDrawTime: 0,
      minRedrawInterval: 50, // 最小重绘间隔，防抖用

      visibleSegmentsCache: [], // 当前可见区域内的 segments 缓存
    };
  },
  mounted() {
    this.init();
    window.addEventListener("resize", this.debounceRedraw);
  },
  beforeDestroy() {
    window.removeEventListener("resize", this.debounceRedraw);
  },
  watch: {
    highlightedSegments: {
      handler(newVal) {
        this.debounceRedraw();
      },
      deep: true,
    },
    startTime: "debounceRedraw",
    endTime: "debounceRedraw",
  },
  methods: {
    init() {
      const container = this.$refs.timeLineContainer;
      const canvas = this.$refs.canvas;
      const { width } = container.getBoundingClientRect();

      this.width = width;
      canvas.width = width;
      canvas.height = this.height;
      this.ctx = canvas.getContext("2d");

      this.debounceRedraw();
    },

    debounceRedraw() {
      if (this.drawPending) return;

      this.drawPending = true;
      requestAnimationFrame(() => {
        const now = Date.now();
        if (now - this.lastDrawTime > this.minRedrawInterval) {
          this.draw();
          this.lastDrawTime = now;
        }
        this.drawPending = false;
      });
    },

    onClick(e) {
      const rect = this.$refs.canvas.getBoundingClientRect();
      const x = e.clientX - rect.left;
      const y = e.clientY - rect.top;

      const { startTime, endTime, width, height } = this;
      const totalSeconds = (endTime.getTime() - startTime.getTime()) / 1000;
      const pxPerMs = width / totalSeconds / 1000;

      for (let seg of this.visibleSegmentsCache) {
        const startX = (seg.beginTime - startTime.getTime()) * pxPerMs;
        const endX = (seg.endTime - startTime.getTime()) * pxPerMs;

        const highlightStartX = Math.max(0, startX);
        const highlightEndX = Math.min(width, endX);

        const highlightTop = height / 2 - 6;
        const highlightBottom = height / 2 + 6;

        if (
          x >= highlightStartX &&
          x <= highlightEndX &&
          y >= highlightTop &&
          y <= highlightBottom
        ) {
          const clickedTime = new Date(startTime.getTime() + x / pxPerMs);
          this.$emit("highlight-click", {
            time: clickedTime,
            segment: seg,
          });
          return;
        }
      }
    },

    draw() {
      const { ctx, width, height, startTime, endTime } = this;
      ctx.clearRect(0, 0, width, height);
      ctx.fillStyle = "#1a1a1a";
      ctx.fillRect(0, 0, width, height);

      const totalSeconds = (endTime - startTime) / 1000;
      const pxPerMs = width / totalSeconds / 1000;

      // 刻度线绘制逻辑不变...
      this.drawTicks(pxPerMs);

      // 可视区域筛选出需要绘制的 segments
      this.visibleSegmentsCache = this.highlightedSegments.filter(seg => {
        return seg.beginTime <= endTime && seg.endTime >= startTime;
      });

      // 绘制高亮段
      this.visibleSegmentsCache.forEach((seg) => {
        const startX = Math.max(
          0,
          (seg.beginTime - startTime.getTime()) * pxPerMs
        );
        const endX = Math.min(
          width,
          (seg.endTime - startTime.getTime()) * pxPerMs
        );

        if (endX > startX) {
          ctx.fillStyle = "#FFD700"; // 黄色
          ctx.fillRect(startX, height / 2 - 6, endX - startX, 20);
        }
      });

      // 绘制鼠标线
      if (this.mouseX !== null) {
        ctx.strokeStyle = "#fff";
        ctx.beginPath();
        ctx.moveTo(this.mouseX, 0);
        ctx.lineTo(this.mouseX, height);
        ctx.stroke();
      }
    },


    drawTicks(pxPerMs) {
      const { ctx, width, height, startTime } = this;
      const intervalMinutes = this.calculateInterval();

      let current = new Date(startTime);
      let lastX = null;

      while (current <= this.endTime) {
        const msFromStart = current - startTime;
        const x = msFromStart * pxPerMs;

        if (x >= 0 && x <= width) {
          const isMajorTick = current.getMinutes() % intervalMinutes === 0;

          if (isMajorTick) {
            ctx.beginPath();
            ctx.strokeStyle = "#fff";
            ctx.moveTo(x, 0); ctx.lineTo(x, 15);
            ctx.stroke();

            ctx.fillStyle = "#ccc";
            ctx.font = "12px Arial";
            ctx.textAlign = "center";
            ctx.fillText(moment(current).format(intervalMinutes >= 1440 ? "YYYY-MM-DD" : "HH:mm"), x, 30);
          }

          if (isMajorTick && lastX !== null && x - lastX > 20) {
            const mid1 = lastX + (x - lastX) / 3;
            const mid2 = lastX + (x - lastX) * 2 / 3;

            ctx.beginPath();
            ctx.strokeStyle = "#666";
            ctx.moveTo(mid1, 4);
            ctx.lineTo(mid1, 10);
            ctx.moveTo(mid2, 4);
            ctx.lineTo(mid2, 10);
            ctx.stroke();
          }

          if (isMajorTick) lastX = x;
        }

        current.setMinutes(current.getMinutes() + intervalMinutes);
      }
    },

    calculateInterval() {
      const { startTime, endTime } = this;
      const totalHours = (endTime - startTime) / (60 * 60 * 1000);

      if (totalHours <= 12) return 30;
      else if (totalHours <= 24) return 60;
      else if (totalHours <= 48) return 120;
      else if (totalHours <= 72) return 180;
      else if (totalHours <= 168) return 360;
      else return 1440;
    },

    onMouseMove(e) {
      const rect = this.$refs.canvas.getBoundingClientRect();
      const x = e.clientX - rect.left;
      const time = this.getXTime(x);

      this.tooltipText = moment(time).format("YYYY-MM-DD HH:mm:ss");
      this.tooltipPosition = { x: e.clientX, y: e.clientY };

      this.mouseX = x;
      this.showTooltip = true;

      this.debounceRedraw();
    },

    onMouseLeave() {
      this.mouseX = null;
      this.showTooltip = false;
      this.debounceRedraw();
    },

    getXTime(x) {
      const ratio = x / this.width;
      return this.startTime.getTime() + ratio * (this.endTime.getTime() - this.startTime.getTime());
    },

    redraw() {
      this.debounceRedraw();
    },
  },
  computed: {
    tooltipStyle() {
      return {
        position: 'absolute',
        left: `${this.tooltipPosition.x + 10}px`,
        top: `${this.tooltipPosition.y - 30}px`,
        background: 'rgba(0,0,0,0.8)',
        color: '#fff',
        padding: '4px 8px',
        borderRadius: '3px',
        fontSize: '12px',
        pointerEvents: 'none',
        zIndex: 1000,
        visibility: this.showTooltip ? 'visible' : 'hidden',
        opacity: this.showTooltip ? 1 : 0,
        transition: 'opacity 0.2s ease'
      };
    }
  }
};
</script>

<style scoped>
.timeLineContainer {
  position: relative;
  width: 100%;
  height: 100px;
}
</style>

上面是子组件 接收的参数只需要开始时间，结束时间，时间轴时间段。

下面是父组件引用,其中这个方法handleHighlightClick是点击子组件黄色部分区域获取到当前时间

<div style="width: 100%; height: 50px;">
  <PlaybackTimeline
    :startTime="new Date(startTime)"
    :endTime="new Date(endTime)"
    :highlightedSegments="videoUrls[selectedIndex || 0].segments"
     @highlight-click="handleHighlightClick"
    />
</div>

注意：videoUrls[selectedIndex || 0].segments 是数组对象集合

           [{startTime:'',endTime:''},{startTime:'',endTime:''}]

           是这样的结构，所以传入多少个就是多少段黄色区间
