基于opencv的人脸检测与识别(python)（2）

本篇延续上篇内容，主要讲解train_with_keras.py跟face_predict_test.py文件，参考博客：https://www.cnblogs.com/neo-T/p/6477378.html ，该博客对于CNN网络构建原理、操作步骤、以及代码介绍都很详细，所以本文就不再将代码细节详说，只对一些出现的问题做一下说明，有不懂得读者可以直接查阅该博客。

用Keras库开始训练

train_with_keras.py文件中主要有Dataset跟Model两个类，类Dataset主要函数load将前面load_dataset.py中所得到的数据读出并运用Keras库相关函数对数据进行训练集、验证集、测试集分类，并打印出各个集的数目，再对各个集进行One-hot处理跟归一化处理用于后面模型训练。

Dataset类

class Dataset:
    def __init__(self, path_name):
        # training set
        self.train_images = None
        self.train_labels = None

        # validation
        self.valid_images = None
        self.valid_labels = None

        # testing set
        self.test_images = None
        self.test_labels = None

        # loading direction
        self.path_name = path_name

        # input shape
        self.input_shape = None

    def load(self):

        # load dataset
        images, labels, nb_classes = load_data(self.path_name)
        images = np.array(images) # transform list to array
        _, img_rows, img_cols, img_channels = images.shape

        train_images, valid_images, train_labels, valid_labels = train_test_split(
                images, labels, test_size=0.3, random_state=random.randint(0, 100))
        _, test_images, _, test_labels = train_test_split(images, labels, test_size=0.5,
                                                          random_state=random.randint(0, 100))

        # if current dimension is 'th'，the order of the input picture data is：channels,rows,cols;
        # or is:rows,cols,channels
        # Reorganize the training dataset in the order of dimensions required by the keras library
        if K.image_dim_ordering() == 'th':
            train_images = train_images.reshape(train_images.shape[0], img_channels,
                                                img_rows, img_cols)
            valid_images = valid_images.reshape(train_images.shape[0], img_channels,
                                                img_rows, img_cols)
            test_images = test_images.reshape(train_images.shape[0], img_channels,
                                                img_rows, img_cols)
            self.input_shape = (img_channels, img_rows, img_cols)
        else:
            self.input_shape = (img_rows, img_cols, img_channels)

        # show the number of training set, validation, testing set
        print('train samples: ', train_images.shape[0])
        print('valid samples: ', valid_images.shape[0])
        print('test samples: ', test_images.shape[0])

        # use categorical_crossentropy as loss function, so vectorize those categories using
        # one-hot encode according to the number of categories.
        train_labels = np_utils.to_categorical(train_labels, nb_classes)
        valid_labels = np_utils.to_categorical(valid_labels, nb_classes)
        test_labels = np_utils.to_categorical(test_labels, nb_classes)

        # floating pixel data for normalization
        train_images = train_images.astype('float32')
        valid_images = valid_images.astype('float32')
        test_images = test_images.astype('float32')

        # normalization
        train_images /= 255
        valid_images /= 255
        test_images /= 255

        self.train_images = train_images
        self.train_labels = train_labels
        self.valid_images = valid_images
        self.valid_labels = valid_labels
        self.test_images = test_images
        self.test_labels = test_labels

原博客中函数train_test_split现在已经在model_selection模块中了需要进行更改。

images = np.array(images) # transform list to array

添加这句的原因是因为在后面进行One-hot处理时，要求的数据类型必须是array，而之前获得的images是list。

 if K.image_dim_ordering() == 'th':
            train_images = train_images.reshape(train_images.shape[0], img_channels,
                                                img_rows, img_cols)
            valid_images = valid_images.reshape(train_images.shape[0], img_channels,
                                                img_rows, img_cols)
            test_images = test_images.reshape(train_images.shape[0], img_channels,
                                                img_rows, img_cols)
            self.input_shape = (img_channels, img_rows, img_cols)
        else:
            self.input_shape = (img_rows, img_cols, img_channels)

这段因为最初获取的图片shape为[rows, cols， channels]，所以满足tensorflow处理数据的要求(其实如果使用 tensorflow 的话这段都可以不必写，反正得到的图片shape都满足)。

Model类

Model类主要是创建卷积网络，训练模型，保存和加载模型，评估和预测模型。这部分代码基本跟参考博客没有区别，是keras库训练模型的一般流程，如果对其中某些函数参数或者细节有疑惑的，可以查看前面的参考博客以及前篇列出的Keras中文库介绍。还是附上代码吧：

class Model:
    def __init__(self):
        self.model = None

    def build_model(self, dataset, nb_classes):
        # create a net model
        self.model = Sequential()

        # network layers
        self.model.add(Convolution2D(32, 3, 3, border_mode='same',
                       input_shape=dataset.input_shape))
        self.model.add(Activation('relu'))

        self.model.add(Convolution2D(32, 3, 3))
        self.model.add(Activation('relu'))

        self.model.add(MaxPooling2D(pool_size=(2, 2)))
        self.model.add(Dropout(0.25))

        self.model.add(Convolution2D(64, 3, 3, border_mode='same'))
        self.model.add(Activation('relu'))

        self.model.add(Convolution2D(64, 3, 3))
        self.model.add(Activation('relu'))

        self.model.add(MaxPooling2D(pool_size=(2, 2)))
        self.model.add(Dropout(0.25))

        self.model.add(Flatten())
        self.model.add(Dense(512))
        self.model.add(Activation('relu'))
        self.model.add(Dropout(0.5))
        self.model.add(Dense(nb_classes))
        self.model.add(Activation('softmax'))

        self.model.summary()  # summary of the output

    def train(self, dataset, batch_size=40, nb_epoch=50, data_augmentation=True):
        sgd = SGD(lr=0.01, decay=1e-6, momentum=0.9, nesterov=True) # Generate optimizer object
        self.model.compile(loss='categorical_crossentropy', optimizer=sgd,
                           metrics=['accuracy']) # 模型配置

        # Don't use data augmentation, that means, from the training data provided by us to
        # create new training data by rotating, flipping, adding noise etc.,and
        # artificially increase the number of model training data.
        if not data_augmentation:
            self.model.fit(dataset.train_images,
                           dataset.train_labels,
                           batch_size = batch_size,
                           nb_epoch = nb_epoch,
                           validation_data = (dataset.valid_images, dataset.valid_labels),
                           shuffle = True)
        # using data augmentation（ on-the-fly data augmentation）
        else:
            # Define a data generator
            datagen = ImageDataGenerator(
                    featurewise_center = False, # 是否使输入数据去中心化
                    samplewise_center = False, # 是否使输入数据的每个样本均值为0
                    featurewise_std_normalization = False, # 是否数据标准化（输入数据除以数据集的标准差）
                    samplewise_std_normalization = False, # 是否将每个样本数据除以自身的标准差
                    zca_whitening = False, # 是否对输入数据施以ZCA白化
                    rotation_range = 20, # 数据增强图片随机转动角度（0-180）
                    width_shift_range = 0.2, # 数据增强图片水平偏移的幅度（0-1）
                    height_shift_range = 0.2, # 垂直
                    horizontal_flip = True, # 是否随机水平翻转
                    vertical_flip = False) # 是否随机垂直翻转

            datagen.fit(dataset.train_images) # 计算整个训练样本的数量

            # using generator to train data
            self.model.fit_generator(datagen.flow(dataset.train_images, dataset.train_labels,
                                                  batch_size=batch_size),
                                     samples_per_epoch=dataset.train_images.shape[0],
                                     nb_epoch=nb_epoch,
                                     validation_data=(dataset.valid_images, dataset.valid_labels))

#    model path to restore model
    def save_model(self, file_path):
        self.model.save(file_path)

    def load_model(self, file_path):
        self.model = load_model(file_path)

    def evaluate(self, dataset):
        score = self.model.evaluate(dataset.test_images, dataset.test_labels, verbose=1)
        print("%s: %.2f%%"%(self.model.metrics_names[1], score[1]*100))

    def face_predict(self, image):
        # 转化为浮点数标准化
        image = image.astype('float32')
        image /= 255

        result = self.model.predict_proba(image)
        print('result:', result)

        result = self.model.predict_classes(image)

        return result[0]

训练精度也在99.5%左右。

实施测试

train_test_keras.py文件已经将训练好的模型保存在.\model\face.model.h5中。face_predict_test.py使用opencv获取实时图片，再用预测函数face_predict将得到的人脸与训练模型进行对比评估得到预测结果，并在图片上打印出预测标签。

if __name__ == '__main__':

# =============================================================================
#      choose specific camera on the terminal
#      if len(sys.argv) != 2:
#          print("Usage:%s camera_id\r\n" % (sys.argv[0]))
#          sys.exit()
# =============================================================================
    model = Model()
    model.load_model(file_path='.\\model\\face.model.h5')

    cap = cv.VideoCapture(0)

    cascade_path = ".\\haarcascades\\haarcascade_frontalface_alt2.xml"

    # cyclic detection and recognition of faces
    while True:
        _, image = cap.read()

        image = cv.flip(image, 1)
        image_gray = cv.cvtColor(image, cv.COLOR_BGR2GRAY)
        cascade = cv.CascadeClassifier(cascade_path)

        faceRects = cascade.detectMultiScale(image_gray, scaleFactor=1.2, minNeighbors=3,
                                             minSize=(32, 32))
        if len(faceRects) > 0:
            for faceRect in faceRects:
                y, x, h, w = faceRect

                imageRect = image[x-10:x+w+10, y-10:y+h+10]
                # 先变为设定图片大小，再变为四维矩阵进行模型预测
                imageRect = resize_image(imageRect, 64, 64)
                imageRect = imageRect.reshape((1, 64, 64, 3))

#                imageRect = imageRect.reshape((1, imageRect.shape[0], imageRect.shape[1],
#                                               imageRect.shape[2]))
                faceID = model.face_predict(imageRect)

                cv.rectangle(image, (y-10, x-10), (y+h+10, x+w+10), color=(0, 255, 0), thickness=2)
                cv.putText(image, '%s'%(faceID), (x+30, y+30), cv.FONT_HERSHEY_COMPLEX, 1, (255, 0, 255), 2)
                print('%s'% (faceID))

        cv.imshow("face detect", image)
        if cv.waitKey(5) == 27:
            break

    cap.release()
    cv.destroyAllWindows()

附上一张自己的测试图片：

总结

可以看到我的图片在s41文件夹中对应标签应该是40，确实是识别出来了，但是当我进行位置移动时，会识别成其他人脸，所以效果还是有待提高。考虑到本文所采用的训练集数量较小，模型可能训练有所偏差，所以后面可以考虑增加训练数据以及调整优化CNN网络结构。希望能对读者有所帮助。
