SpringCloud网关集成Swagger

一：引入Swagger依赖

<!--使用swagger规范接口-->
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger2</artifactId>
            <version>${swagger2.version}</version>
        </dependency>
        <!--swagger访问页面-->
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger-ui</artifactId>
            <version>${swagger2.version}</version>
        </dependency>

二：网关服务配置
1、配置类

import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import springfox.documentation.builders.ApiInfoBuilder;
import springfox.documentation.service.ApiInfo;
import springfox.documentation.spi.DocumentationType;
import springfox.documentation.spring.web.plugins.Docket;
import springfox.documentation.swagger.web.*;
import springfox.documentation.swagger2.annotations.EnableSwagger2;

@Configuration
@EnableSwagger2
public class SwaggerConfig {

    //是否开启swagger
    @Value("${swagger.enable}")
    private boolean enableSwagger;

    @Bean
    public Docket createRestApi() {
        return new Docket(DocumentationType.SWAGGER_2)
                .apiInfo(apiInfo())
                .enable(enableSwagger);
    }

    private ApiInfo apiInfo() {
        return new ApiInfoBuilder()
                .title("xxx项目")
                .description("接口文档")
                .termsOfServiceUrl("url")
                .version("1.0")
                .build();
    }

    @Bean
    UiConfiguration uiConfig() {
        return new UiConfiguration(true, false, -1, -1,
                ModelRendering.MODEL, true, DocExpansion.LIST, null, null,
                OperationsSorter.ALPHA, true, TagsSorter.ALPHA, null);
    }
}

2、多环境下的yml中是否开启swagger
本地环境：
application-dev
swagger:
enable: true

生产环境：
application-prd
swagger:
enable: false

三：其他服务配置
1、配置类

import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import springfox.documentation.builders.ApiInfoBuilder;
import springfox.documentation.builders.ParameterBuilder;
import springfox.documentation.builders.PathSelectors;
import springfox.documentation.builders.RequestHandlerSelectors;
import springfox.documentation.schema.ModelRef;
import springfox.documentation.service.ApiInfo;
import springfox.documentation.service.Parameter;
import springfox.documentation.spi.DocumentationType;
import springfox.documentation.spring.web.plugins.Docket;
import springfox.documentation.swagger.web.*;
import springfox.documentation.swagger2.annotations.EnableSwagger2;

import java.util.ArrayList;
import java.util.List;

/**
 * @Auther: 61431
 * @Date: 2020/2/11 11:10
 * @Description:
 */
@Configuration
@EnableSwagger2
public class SwaggerConfig {

    @Value("${swagger.enable}")
    private boolean enableSwagger;

    @Bean
    public Docket api() {

        ParameterBuilder ticketPar = new ParameterBuilder();
        List<Parameter> pars = new ArrayList<Parameter>();
        ticketPar.name("Authorization").description("身份token")
                .modelRef(new ModelRef("string")).parameterType("header")
                .required(false).build(); //header中的ticket参数非必填，传空也可以
        pars.add(ticketPar.build());    //根据每个方法名也知道当前方法在设置什么参数
        return new Docket(DocumentationType.SWAGGER_2)
                .apiInfo(apiInfo())
                .enable(enableSwagger)
                .select()
                .apis(RequestHandlerSelectors.any())
                .paths(PathSelectors.any())
                .build()
                .globalOperationParameters(pars);
    }

    //基本信息，页面展示
    private ApiInfo apiInfo() {
        return new ApiInfoBuilder()
                .title("xxx接口文档")
                .description("接口描述")
                .build();
    }

    @Bean
    UiConfiguration uiConfig() {
        return new UiConfiguration(true, false, -1, -1,
                ModelRendering.MODEL, true, DocExpansion.LIST, null, null,
                OperationsSorter.ALPHA, true, TagsSorter.ALPHA, null);
    }

}

2、多环境下的yml中是否开启swagger
本地环境：
application-dev
swagger:
enable: true

生产环境：
application-prd
swagger:
enable: false

四、访问路径和效果
1、访问路径
http://localhost:网关端口/swagger-ui.html
2、切换服务

3、展示效果
