防火墙配置ENSP实验-USG6000V

   内网互联地址10.10.34.1通过防火墙接入，通过200.1.1.X接入INTERNET，组网图如下
interface GigabitEthernet1/0/0
 undo shutdown
 ip address 10.10.34.1 255.255.255.252
 service-manage ping permit     /端口可以被PING通
#
interface GigabitEthernet1/0/1
 undo shutdown
 ip address 200.1.1.2 255.255.255.252
 service-manage ping permit

接口加入安全组

firewall zone trust
 set priority 85
 add interface GigabitEthernet0/0/0
 add interface GigabitEthernet1/0/0
#
firewall zone untrust
 set priority 5
 add interface GigabitEthernet1/0/1

配置安全策略

security-policy
 rule name in_out
  source-zone trust
  destination-zone untrust
  service icmp
  action permit
 rule name local_trust     //本地能与trust和untrust区域相通
  source-zone local
  des
