设计模式-抽象工厂

适用于产品组装。工厂方法是生产不同牌子的某一单一产品如cpu。抽象工厂是生产有多种配件，且需要自由组装的产品如电脑。



思路：

要生产的产品是一个多组件的产品，每一个组件有一个接口，其实现类分别生产不同牌子的组件产品。

组装产品的工作交给工厂。因为可以组装多套产品，所以有一个抽象工厂，每个实现为一个组装方案。

客户端需要有各种子组件的抽象类引用，和抽象工厂类的引用。



抽象产品类 及其实现

public interface IMother {
    public void printName();
}

public interface IFather {
    public void printName();
}




//实现

//中国妈妈
public class ChineseMother implements IMother{
    private String name;
    public ChineseMother(String name) {
        this.name = name;
        System.out.println("create a cn mother.");
    }
    /**
     * @return the name
     */
    public String getName() {
        return name;
    }
    /**
     * @param name the name to set
     */
    public void setName(String name) {
        this.name = name;
    }
    @Override
    public void printName() {
        System.out.println(this.getClass().getName() + ":" + this.name);

    }
}
//美国妈妈
public class AmericanMother implements IMother{
    private String name;
    public AmericanMother(String name) {
        this.name = name;
        System.out.println("create a us mother.");
    }
    /**
     * @return the name
     */
    public String getName() {
        return name;
    }
    /**
     * @param name the name to set
     */
    public void setName(String name) {
        this.name = name;
    }
    @Override
    public void printName() {
        System.out.println(this.getClass().getName() + ":" + this.name);

    }
}

//中国爸爸
public class ChineseFather implements IFather{
    private String name;
    public ChineseFather(String name) {
        this.name = name;
        System.out.println("create a cn father.");
    }
    /**
     * @return the name
     */
    public String getName() {
        return name;
    }
    /**
     * @param name the name to set
     */
    public void setName(String name) {
        this.name = name;
    }
    @Override
    public void printName() {
        System.out.println(this.getClass().getName() + ":" + this.name);

    }
}

//美国爸爸
public class AmericanFather implements IFather{
    private String name;
    public AmericanFather(String name) {
        this.name = name;
        System.out.println("create a us father.");
    }
    /**
     * @return the name
     */
    public String getName() {
        return name;
    }
    /**
     * @param name the name to set
     */
    public void setName(String name) {
        this.name = name;
    }
    @Override
    public void printName() {
        System.out.println(this.getClass().getName() + ":" + this.name);

    }
}

家庭工厂（组装工厂）
抽象工厂类  定义组装方式
public interface IFamilyFactory {
    public IFather createFather(String name);
    public IMother createMother(String name);
}


实现类   选择具体子组件

public class ChineseFamilyFactory implements IFamilyFactory{

    @Override
    public IFather createFather(String name) {
        return new ChineseFather(name);
    }

    @Override
    public IMother createMother(String name) {
        return new ChineseMother(name);
    }

}

public class AmericanFamilyFactory implements IFamilyFactory{

    @Override
    public IFather createFather(String name) {
        return new AmericanFather(name);
    }

    @Override
    public IMother createMother(String name) {
        return new AmericanMother(name);
    }

}



客户端

public class Main {
    public static void main(String[] args) {
        IFamilyFactory cnFamilyFactory = new ChineseFamilyFactory();
        IFamilyFactory usFamilyFactory = new AmericanFamilyFactory();

        IFather cnFather = cnFamilyFactory.createFather("cn father-test");
        IMother cnMother = cnFamilyFactory.createMother("cn mother-test");

        IFather usFather = usFamilyFactory.createFather("us father-test");
        IMother usMother = usFamilyFactory.createMother("us mother-test");

        cnFather.printName();
        cnMother.printName();
        usFather.printName();
        usMother.printName();
    }
}

• 优点：
• 当一个产品族中的多个对象被设计成一起工作时，它能保证客户端始终只使用同一个产品族中的对象。
• 增加新的具体工厂和产品族很方便，无须修改已有系统，符合“开闭原则”
