海关179加签上报+电子口岸加签实现

china-port-dds (中国电子口岸海关总署XML报文&海关179数据加签)

Gitee源码地址：https://gitee.com/wxm-cookies/china-port-dds

Version	Update Time	Status	Author	Description
1.0.0	2023-07-14 10:30	创建	Weixm	创建api文档

application.yml配置说明

名称	说明	默认值
task.cron	定时器cron	0/20 * * * * ?
dds.url	加签URL[本地加签客户端URL]	http://localhost:8080/rpc/eport/signature
dds.gain-url	获取加密数据URL
dds.gain-size	加密数据的获取条数	10
dds.notify-url	数据加密好后的回调URL
push-179-url	推单179的URL	https://customs.chinaport.gov.cn/ceb2grab/grab/realTimeDataUpload

Task说明

china-port-dds定时器轮询 -> 获取商城系统的加签数据 -> 循环需要加签数据 -> chinaport-data-signature加签 -> 签名回调给商城

公共响应(平台加签数据/Task加签回调 都基于以下格式，data为业务响应)

Field	Type	Description
code	Integer	状态码 200-成功
data	Object	数据
msg	String	描述

@Data
public class DdsR<T> implements Serializable {
    private Integer code;
    private T data;
    private String msg;

    public static <T> DdsR<T> ok(T data){
        DdsR<T> r = new DdsR<>();
        r.setCode(200);
        r.setData(data);
        r.setMsg("成功");
        return r;
    }

    public static <T> DdsR<T> error(String msg){
        DdsR<T> r = new DdsR<>();
        r.setCode(500);
        r.setData(null);
        r.setMsg(msg);
        return r;
    }
}

加签数据获取说明(平台准备接口 china-port-dds进行配置调用)

• URL: application.yml配置中dds.gain-url

• Type: GET

• Author: Weixm

• Description: 获取平台需要加签的数据List

• Request-fields:

  Field	Type	Description
  size	Integer	加签数据获取条数 application.yml中配置的dds.gain-size

• Response-fields:

  Field	Type	Description
  id	Integer	平台加签数据唯一标记
  type	String	类型[枚举ChinaPortDdsTypeEnum]
  reqValue	String	加签数据

• Request-example:

  curl -X GET -i http://localhost:11201/order/china/port/dds/get?size=20


• Response-example:

  {
      "code":200,
      "data":[
          {
              "id":5,
              "type":"179",
              "reqValue":"加签数据xxxxx"
          }
      ],
      "msg":"成功"
  }


• Java-example:

  @GetMapping("/get")
  public DdsR<List<ChinaPortDdsEntity>> get(@RequestParam("size") Integer size){
      try {
          List<ChinaPortDdsEntity> list = this.获取签名的List(size);
          return DdsR.ok(list);
      }catch (Exception e){
          return DdsR.error("查询失败");
      }
  }


  @Data
  public class ChinaPortDdsEntity implements Serializable {
      /**
       * ID
       */
      private Integer id;

      /**
       * 类型[枚举ChinaPortDdsTypeEnum]
       */
      private String type;

      /**
       * 加签请求
       */
      private String reqValue;
  }


加签数据回调说明(平台准备接口 china-port-dds进行配置调用)

• URL: application.yml配置中dds.notify-url

• Type: Post

• Author: Weixm

• Description: 加签数据返回

• Request-fields:

  Field	Type	Description
  id	Integer	平台加签数据唯一标记
  type	Integer	类型[枚举ChinaPortDdsTypeEnum]
  code	Integer	状态 200为成功
  result	JSONObject	String

• Request-example:

  curl -X POST http://localhost:11201/order/china/port/dds/notify -H "Content-Type: application/json;" -d "{\"msg\":\"成功\",\"code\":200,\"data\":{\"msg\":\"POST请求失败Failed to connect to localhost/0:0:0:0:0:0:0:1:8080\",\"result\":\"POST请求失败Failed to connect to localhost/0:0:0:0:0:0:0:1:8080\",\"code\":500,\"id\":6,\"type\":\"179\"}}"


• Response-example:

  {
      "code":200,
      "data":"成功",
      "msg":"成功"
  }


• Java-example:

  @PostMapping("/notify")
  public DdsR<String> notify(@RequestBody JSONObject param){
        JSONObject data = param.getJSONObject("data");
        //ID
        Integer id = data.getInteger("id");
        //类型
        String type = data.getString("type");
        //状态码
        if (new Integer("200").equals(data.getInteger("code"))){
            //成功处理
            this.处理回调成功加签数据(id,type,data);
        }else {
            //失败处理
            this.处理回调失败加签数据(id,data.getString("result"));
        }
        return DdsR.ok("成功");
  }


179响应示例

• 成功

  {
      "msg":"成功",
      "code":200,
      "data":{
          "result":"上传成功",
          "code":200,
          "id":20,
          "type":"179"
      }
  }


• 失败

  {
      "msg":"成功",
      "code":200,
      "data":{
          "result":"上传失败,入库失败: 唯一标识sessionID重复",
          "code":500,
          "id":20,
          "type":"179"
      }
  }


其他加签响应示例

• 成功

  {
      "msg":"成功",
      "code":200,
      "data":{
          "result":{
              "success":true,
              "certNo":"fzex4q",
              "x509Certificate":"7wj4ki",
              "digestValue":"rakt0t",
              "signatureValue":"pbyy9u"
          },
          "code":200,
          "id":20,
          "type":"621"
      }
  }


• 失败

  {
      "msg":"成功",
      "code":200,
      "data":{
          "result":"加签失败",
          "code":500,
          "id":20,
          "type":"621"
      }
  }
