File: client-go/applyconfigurations/storage/v1beta1/csinodedriver.go

在client-go组织下的client-go/applyconfigurations/storage/v1beta1/csinodedriver.go文件是用于定义和应用CSINodeDriver对象的配置。

CSINodeDriverApplyConfiguration是一个配置应用器的结构体,用于设置和应用CSINodeDriver对象的各种配置选项。

CSINodeDriver结构体代表了一个CSI (Container Storage Interface) 驱动在Kubernetes中的节点配置。它包含了驱动的名称、节点ID、支持的拓扑键和可分配资源等信息。

以下是CSINodeDriver结构体中的几个重要字段的作用:

  • Name: 驱动的名称。
  • NodeID: 驱动关联的节点ID。
  • TopologyKeys: 驱动支持的拓扑键列表,用于表示该驱动在节点拓扑中的位置。
  • Allocatable: 驱动可分配的资源配置。

CSINodeDriverApplyConfiguration结构体中的几个方法用于设置和应用CSINodeDriver对象的配置选项。这些方法包括:

  • WithName(name string):设置驱动的名称。
  • WithNodeID(nodeID string):设置驱动关联的节点ID。
  • WithTopologyKeys(topologyKeys []string):设置驱动支持的拓扑键。
  • WithAllocatable(allocatable corev1.ResourceList):设置驱动可分配的资源配置。

通过在CSINodeDriver对象上调用这些方法,并传入对应的参数,可以设置和应用CSINodeDriver对象的各种配置选项。

File: client-go/applyconfigurations/core/v1/resourcequotaspec.go

在client-go项目中的client-go/applyconfigurations/core/v1/resourcequotaspec.go文件是用于指定ResourceQuota资源配额规范的配置。

ResourceQuotaSpecApplyConfiguration是一个结构体类型,用于定义对ResourceQuotaSpec应用的配置。它包含以下字段:

  • hard: 用于指定资源的硬限制值,即最大限制值。
  • scopes: 用于指定资源配额的作用范围。
  • scopeSelector: 用于指定一个选择器,用于选择由此配额规范所限制的范围。

ResourceQuotaSpec是一个结构体类型,用于定义资源配额规范。它包含以下字段:

  • hard: 用于指定资源的硬限制值,即最大限制值。
  • scopes: 一个字符串类型的切片,用于指定资源配额的作用范围。
  • scopeSelector: 一个指向 ScopeSelector类型的指针,用于指定一个选择器,用于选择由此配额规范所限制的范围。

WithHard是一个用于设置ResourceQuotaSpecApplyConfigurationhard字段的函数,它接受一个ResourceList作为参数,并返回一个函数类型。 WithScopes是一个用于设置ResourceQuotaSpecApplyConfigurationscopes字段的函数,它接受一个字符串类型的切片作为参数,并返回一个函数类型。 WithScopeSelector是一个用于设置ResourceQuotaSpecApplyConfigurationscopeSelector字段的函数,它接受一个ScopeSelectorApplyConfiguration类型的指针作为参数,并返回一个函数类型。

这些函数用于根据需求设置ResourceQuotaSpecApplyConfiguration结构体的字段值,以便对ResourceQuotaSpec的配置进行修改或应用。通过使用这些函数,可以方便地进行资源配额规范的定制和设置。

File: client-go/applyconfigurations/core/v1/replicationcontrollercondition.go

在Kubernetes的client-go项目中,client-go/applyconfigurations/core/v1/replicationcontrollercondition.go文件定义了ReplicationControllerCondition的配置项。

ReplicationControllerConditionApplyConfiguration是一个用于配置ReplicationControllerCondition的结构体。它提供了一些函数,以方便用户进行配置。下面是该结构体定义的一些函数以及它们的作用:

  • WithType(conditionType string):设置ReplicationControllerCondition的类型。
  • WithStatus(status string):设置ReplicationControllerCondition的状态。
  • WithLastTransitionTime(time metav1.Time):设置ReplicationControllerCondition的上次转换时间。
  • WithReason(reason string):设置ReplicationControllerCondition的原因。
  • WithMessage(message string):设置ReplicationControllerCondition的消息。

这些函数的作用是用于根据用户提供的配置值,设置ReplicationControllerCondition的属性。通过使用这些函数,用户可以很方便地配置ReplicationControllerCondition的各个属性。

ReplicationControllerCondition是Kubernetes中的一个核心API对象。它用于描述ReplicationController的状态及其相关条件。ReplicationControllerCondition记录了ReplicationController的状态变化,包括类型、状态、上次转换时间、原因和消息等信息。

因此,ReplicationControllerConditionApplyConfiguration结构体以及其提供的函数,可以帮助用户方便地配置ReplicationControllerCondition的各个属性,并最终创建一个符合要求的ReplicationControllerCondition对象。

File: client-go/applyconfigurations/flowcontrol/v1beta1/policyruleswithsubjects.go

在K8s组织下的client-go项目中,client-go/applyconfigurations/flowcontrol/v1beta1/policyruleswithsubjects.go文件的作用是定义了policyruleswithsubjects的apply configuration。

PolicyRulesWithSubjects是FlowControl v1beta1 API中的一种资源类型,它定义了一系列策略规则,每个规则都包括所需的主体和资源规则。该资源类型用于配置Kubernetes流量控制机制,以限制用户和服务对Kubernetes资源的访问。

PolicyRulesWithSubjectsApplyConfiguration结构体定义了PolicyRulesWithSubjects资源的apply configuration,它包含了修改PolicyRulesWithSubjects资源的各种方法和字段。

WithSubjects方法是PolicyRulesWithSubjectsApplyConfiguration结构体的一个函数,它用于设置policyruleswithsubjects的subjects字段,即指定拥有该策略规则的主体列表。

WithResourceRules方法是PolicyRulesWithSubjectsApplyConfiguration结构体的一个函数,它用于设置policyruleswithsubjects的resourceRules字段,即指定对资源的规则列表。

WithNonResourceRules方法是PolicyRulesWithSubjectsApplyConfiguration结构体的一个函数,它用于设置policyruleswithsubjects的nonResourceRules字段,即指定对非资源的规则列表。

这些函数提供了一种链式调用的方式来设置PolicyRulesWithSubjects资源的各个字段,以便方便地构建和修改该资源的配置。

File: client-go/applyconfigurations/resource/v1alpha2/podschedulingcontextspec.go

在Kubernetes(K8s)的client-go项目中,client-go/applyconfigurations/resource/v1alpha2/podschedulingcontextspec.go文件是用来定义Pod调度上下文规范(PodSchedulingContextSpec)的。

Pod调度上下文规范是用于指定Pod在调度过程中的相关信息和约束条件。它包括以下字段:

  1. NodeSelector - 指定通过标签选择器来筛选可用节点。
  2. Affinity - 指定Pod与特定节点之间的亲和性和反亲和性。
  3. Taints - 指定节点上的容忍度,用于影响Pod是否可以被调度到该节点上。
  4. PriorityClassName - 指定Pod的优先级类名,用于调度决策。
  5. Priority - 指定Pod的优先级,用于调度决策。
  6. PreemptionPolicy - 指定Pod的抢占策略,即是否允许该Pod抢占其他较低优先级的Pod。

PodSchedulingContextSpecApplyConfiguration 是PodSchedulingContextSpec的应用配置结构体,它通过应用配置的方式修改PodSchedulingContextSpec的字段值。

PodSchedulingContextSpec 结构体定义了Pod调度上下文规范的字段,并提供了一些获取字段值的方法。

WithSelectedNode 是一个方法,用于设置PodSchedulingContextSpec的SelectedNode字段的值。SelectedNode字段表示已经选择的节点。

WithPotentialNodes 是一个方法,用于设置PodSchedulingContextSpec的PotentialNodes字段的值。PotentialNodes字段表示可能的节点列表。

这些方法的作用是在应用配置时,方便设置PodSchedulingContextSpec的字段值,以满足具体的调度需求。

综上所述,client-go/applyconfigurations/resource/v1alpha2/podschedulingcontextspec.go文件中定义了Pod调度上下文规范(PodSchedulingContextSpec)、应用配置结构体(PodSchedulingContextSpecApplyConfiguration)以及相关的设置方法(WithSelectedNode、WithPotentialNodes),用于在Kubernetes的client-go项目中控制和配置Pod的调度规则和策略。

File: client-go/pkg/version/base.go

Introduction to client-go/pkg/version/base.go in the client-go project in K8s

The client-go/pkg/version/base.go file is a part of the client-go project in Kubernetes (K8s). It plays a crucial role in providing version information about the client-go library.

In Kubernetes, client-go is a client library that provides a set of functions and interfaces for interacting with the Kubernetes API server. It is widely used by developers to write custom controllers, operators, and other applications that need to interact with the Kubernetes API.

The base.go file is responsible for defining the version information for the client-go library. It contains several variables that store version-related information such as the Git commit, the version number, and the build date. These variables are used to provide information about the version of client-go being used.

Let's now take a closer look at the specific variables mentioned in your question:

gitMajor, gitMinor, gitVersion, gitCommit, gitTreeState, buildDate
  • gitMajor: This variable represents the major version number of the client-go library. It indicates significant changes and updates to the library.

  • gitMinor: This variable represents the minor version number of the client-go library. It indicates smaller updates and improvements to the library.

  • gitVersion: This variable represents the complete version string of the client-go library. It combines the gitMajor and gitMinor variables to provide a comprehensive version number.

  • gitCommit: This variable stores the Git commit hash of the client-go library. It uniquely identifies the specific commit in the Git repository from which the library was built.

  • gitTreeState: This variable indicates the state of the Git tree from which the client-go library was built. It can have one of the following values: "clean", "dirty", or "unknown". "clean" means that the repository has no uncommitted changes, "dirty" means there are uncommitted changes, and "unknown" means the state could not be determined.

  • buildDate: This variable represents the date and time when the client-go library was built. It provides information about when the library was last compiled.

These variables are typically used by developers and operators to identify the version and build details of the client-go library they are using. They can be accessed programmatically to display version information or to perform version-specific operations.

It's important to note that the specific usage and implementation details of these variables may vary across different versions of client-go. Therefore, it's always recommended to refer to the official documentation and the source code of the specific version you are working with for the most accurate and up-to-date information.

File: client-go/kubernetes/typed/storage/v1beta1/fake/fake_storage_client.go

File: client-go/applyconfigurations/extensions/v1beta1/ingressloadbalanceringress.go

client-go/applyconfigurations/extensions/v1beta1/ingressloadbalanceringress.go文件的作用是定义了针对IngressLoadBalancerIngress对象的配置应用逻辑。

在Kubernetes中,Ingress是一种用于在集群中公开服务的资源对象。IngressLoadBalancerIngress代表了通过负载均衡器暴露的Ingress IP地址或主机名等信息。

IngressLoadBalancerIngressApplyConfiguration结构体定义了对IngressLoadBalancerIngress对象应用配置的方法。它包含了以下几个重要的方法:

  • WithIP(ip string):配置IngressLoadBalancerIngress对象的IP地址。
  • WithHostname(hostname string):配置IngressLoadBalancerIngress对象的主机名。
  • WithPorts(ports ...int32):配置IngressLoadBalancerIngress对象的端口信息。

这些方法通过链式调用可以对IngressLoadBalancerIngress对象进行配置。例如,可以使用WithIP方法设置IngressLoadBalancerIngress对象的IP地址,然后使用WithPorts方法设置端口信息。

IngressLoadBalancerIngress结构体表示一个通过负载均衡器暴露的Ingress的地址信息。它包含了以下字段:

  • IP:代表Ingress的IP地址。
  • Hostname:代表Ingress的主机名。
  • Ports:代表暴露的端口列表。

通过使用这些方法和结构体,可以方便地对IngressLoadBalancerIngress对象进行配置和处理。这样的设计可以帮助用户在使用client-go库与Kubernetes进行交互时更加灵活地处理IngressLoadBalancerIngress对象的配置。

File: client-go/kubernetes/typed/discovery/v1beta1/fake/fake_endpointslice.go

在client-go/kubernetes/typed/discovery/v1beta1/fake/fake_endpointslice.go文件中,FakeEndpointSlice定义了一个假的EndpointSlice资源,用于在测试中模拟EndpointSlice对象的行为。

endpointslicesResource和endpointslicesKind是用于标识EndpointSlice资源的信息。

FakeEndpointSlices结构体包含了用于模拟EndpointSlice资源操作的函数。

  • Get用于获取指定名称的EndpointSlice资源。
  • List用于获取所有EndpointSlice资源的列表。
  • Watch用于创建一个用于监听EndpointSlice资源变化的Watcher。
  • Create用于创建一个EndpointSlice资源。
  • Update用于更新指定名称的EndpointSlice资源。
  • Delete用于删除指定名称的EndpointSlice资源。
  • DeleteCollection用于删除所有EndpointSlice资源。
  • Patch用于部分更新指定名称的EndpointSlice资源。
  • Apply用于应用指定的EndpointSlice资源。

这些函数提供了对EndpointSlice资源的常见操作,方便在测试中模拟和验证业务逻辑。

File: client-go/transport/cache.go

在client-go的transport包中的cache.go文件主要定义了一些缓存数据的结构和方法,并提供了一些与缓存交互的函数。

  1. DialerStopCh变量:是一个chan struct{}类型的通道,用于传递信号以停止Dialer的监听。

  2. tlsCache变量:是一个sync.Map类型的缓存,用于存储TLS配置和HTTP传输层的缓存。

  3. tlsTransportCache结构体:定义了一个TLS传输缓存的结构体,包含了一个读写锁和一个缓存,用于存储TLS传输层缓存的数据。

  4. tlsCacheKey结构体:定义了一个TLS缓存的键结构,用来标识缓存数据。

  5. String函数:是tlsCacheKey结构体的方法,返回一个描述唯一键的字符串。

  6. get函数:是tlsTransportCache结构体的方法,根据tlsCacheKey获取对应的缓存项。

  7. tlsConfigKey函数:是一个用于生成TLS配置键的函数,可根据给定的TLS配置生成唯一的键。

这些结构体和函数主要是为了方便在client-go中复用和管理TLS配置和HTTP传输层的缓存。例如,当需要创建一个TLS配置时,可以先检查缓存中是否已有对应的配置,如果有则直接使用缓存中的配置,避免重复创建。同时,这些缓存项也可以在传输层的HTTP请求中被复用。

File: client-go/applyconfigurations/core/v1/secretkeyselector.go

在K8s组织下的client-go项目中,client-go/applyconfigurations/core/v1/secretkeyselector.go这个文件定义了与core/v1版本的SecretKeySelector相关的apply配置。

SecretKeySelectorApplyConfiguration结构体用于指定要应用的SecretKeySelector的配置。它包含以下字段:

  • Name:指定要引用的 Secret 资源的名称。
  • Key:指定要从 Secret 中获取的密钥的名称。
  • Optional:指定密钥是否可选。如果设置为 true,则表示如果未找到密钥,则返回空字符串。如果设置为 false(默认值),则表示如果未找到密钥,则返回错误。

SecretKeySelector结构体表示要从 Secret 中选择的密钥。它包含以下字段:

  • Name:引用的 Secret 资源的名称。
  • Key:要在 Secret 中选择的密钥的名称。
  • Optional:指定密钥是否可选。

WithName函数用于设置要引用的 Secret 资源的名称。它接受一个字符串参数,返回一个函数,用于进一步配置 SecretKeySelectorApplyConfiguration 结构体。

WithKey函数用于设置要从 Secret 中选择的密钥的名称。它接受一个字符串参数,返回一个函数,用于进一步配置 SecretKeySelectorApplyConfiguration 结构体。

WithOptional函数用于设置密钥是否可选。它接受一个布尔值参数,返回一个函数,用于进一步配置 SecretKeySelectorApplyConfiguration 结构体。

这些函数可以根据具体需求来配置 SecretKeySelectorApplyConfiguration 结构体的字段值,从而实现对 SecretKeySelector 对象的定制化配置。

File: client-go/applyconfigurations/flowcontrol/v1beta1/flowschemastatus.go

在K8s组织下的client-go项目中,client-go/applyconfigurations/flowcontrol/v1beta1/flowschemastatus.go文件是用于定义FlowSchemaStatus对象及其应用配置的文件。

FlowSchemaStatus是FlowSchema对象的状态信息,它包含了FlowSchema的条件信息,用于描述FlowSchema的运行状态。WithConditions函数用于设置FlowSchemaStatus对象的条件信息,可以方便地进行状态更新。

FlowSchemaStatusApplyConfiguration是一个结构体,用于应用配置到FlowSchemaStatus对象。该结构体提供了一系列方法,用于设置FlowSchemaStatus对象的不同字段,如设置FlowSchemaStatus的conditions字段。

通过使用FlowSchemaStatusApplyConfiguration结构体可以对FlowSchemaStatus对象进行配置,并且提供了对FlowSchemaStatus对象的流式编程样式操作,使得配置变得更加简洁和可读。

综上所述,flowschemastatus.go文件的作用是定义FlowSchemaStatus对象的状态信息和应用配置方法,并且提供了一些方法用于设置FlowSchemaStatus对象的不同字段,以及更新FlowSchema对象的条件信息。

File: client-go/rest/warnings.go

在client-go项目中的client-go/rest/warnings.go文件是用于处理Kubernetes API服务器返回的警告信息的。警告信息是服务器在响应请求时返回的一种特殊的响应头,用于向客户端传达非致命性、但值得注意的问题或建议。

以下是关于warnings.go文件中的各个部分作用的详细说明:

defaultWarningHandler和defaultWarningHandlerLock

  • defaultWarningHandler是一个警告信息处理函数的全局变量,默认情况下为 nil,即没有默认警告处理函数。
  • defaultWarningHandlerLock是默认警告处理函数的互斥锁,用于多线程场景下对 defaultWarningHandler的并发访问进行同步。

WarningHandler

  • WarningHandler是一个函数类型,用于定义自定义的警告信息处理函数。

NoWarnings

  • NoWarnings是一个内部结构体,表示没有警告信息存在。

WarningLogger

  • WarningLogger是一个接口类型,用于进行警告信息的日志记录。

warningWriter

  • warningWriter是一个结构体,用于封装一个警告信息写入器。

WarningWriterOptions

  • WarningWriterOptions是一个选项结构体,用于配置警告信息写入器。

SetDefaultWarningHandler

  • SetDefaultWarningHandler函数用于设置默认警告处理函数,可以在每个请求的上下文中使用。

getDefaultWarningHandler

  • getDefaultWarningHandler函数用于获取默认警告处理函数。

HandleWarningHeader

  • HandleWarningHeader函数用于处理返回响应中的警告头,并根据情况调用警告处理函数。

NewWarningWriter

  • NewWarningWriter函数根据给定的警告处理函数和选项创建一个新的警告信息写入器。

WarningCount

  • WarningCount函数用于获取给定响应的警告数量。

handleWarnings

  • handleWarnings函数用于处理返回响应中的警告信息,并将其写入警告信息写入器。

以上是关于client-go/rest/warnings.go文件中的各个变量和函数的作用的详细解释。这些组件一起提供了一个可扩展的机制,用于处理Kubernetes API服务器返回的警告信息。用户可以根据自己的需求实现自定义的警告处理逻辑。

File: client-go/applyconfigurations/networking/v1alpha1/ipaddress.go

在K8s组织下的client-go项目中,client-go/applyconfigurations/networking/v1alpha1/ipaddress.go文件是用于定义网络v1alpha1版本的IPAddress资源对象的应用配置。

IPAddressApplyConfiguration是用于配置IPAddress资源对象的应用配置结构体。它包含了一系列用于配置IPAddress资源对象属性的函数,例如WithKind、WithAPIVersion、WithName等。

IPAddress结构体代表了一个IPAddress资源对象的定义,它包含了IPAddress资源对象的元数据和规范。

ExtractIPAddress函数用于从IPAddress资源对象中提取IPAddress结构体。

ExtractIPAddressStatus函数用于从IPAddress资源对象中提取IPAddressStatus字段。

extractIPAddress函数用于从原始的IPAddress资源对象的JSON数据中提取IPAddress结构体。

WithKind函数用于设置IPAddress资源对象的Kind属性。

WithAPIVersion函数用于设置IPAddress资源对象的APIVersion属性。

WithName函数用于设置IPAddress资源对象的Name属性。

WithGenerateName函数用于设置IPAddress资源对象的GenerateName属性。

WithNamespace函数用于设置IPAddress资源对象的Namespace属性。

WithUID函数用于设置IPAddress资源对象的UID属性。

WithResourceVersion函数用于设置IPAddress资源对象的ResourceVersion属性。

WithGeneration函数用于设置IPAddress资源对象的Generation属性。

WithCreationTimestamp函数用于设置IPAddress资源对象的CreationTimestamp属性。

WithDeletionTimestamp函数用于设置IPAddress资源对象的DeletionTimestamp属性。

WithDeletionGracePeriodSeconds函数用于设置IPAddress资源对象的DeletionGracePeriodSeconds属性。

WithLabels函数用于设置IPAddress资源对象的Labels属性。

WithAnnotations函数用于设置IPAddress资源对象的Annotations属性。

WithOwnerReferences函数用于设置IPAddress资源对象的OwnerReferences属性。

WithFinalizers函数用于设置IPAddress资源对象的Finalizers属性。

ensureObjectMetaApplyConfigurationExists函数用于确保ObjectMetaApplyConfiguration字段存在。

WithSpec函数用于设置IPAddress资源对象的Spec属性。

这些函数提供了一种方便的方式来设置IPAddress资源对象的属性,以及从资源对象中提取属性。通过使用这些函数,可以轻松地创建、修改和访问IPAddress资源对象的属性。

File: client-go/applyconfigurations/admissionregistration/v1/rule.go

在Kubernetes的client-go项目中,client-go/applyconfigurations/admissionregistration/v1/rule.go文件定义了一组用于创建或修改AdmissionRegistration的Rule对象的Apply配置结构体和函数。

AdmissionRegistration是Kubernetes的一种资源类型,用于定义准入控制策略。Rule表示一个准入规则,用于指定针对哪些API资源进行准入控制的操作。RuleApplyConfiguration结构体是一个应用配置的容器,它提供了一系列函数来设置和修改Rule对象的字段。

具体来说,以下是每个结构体和函数的作用:

  1. RuleApplyConfiguration结构体:用于配置AdmissionRegistration中的Rule对象。

  2. Rule结构体:表示AdmissionRegistration的Rule对象,包含以下字段:

    • APIGroups:定义API分组,指定针对哪些API资源进行准入控制。
    • APIVersions:定义API版本,指定API资源的版本。
    • Resources:指定可用的资源,如Pod、Deployment等。
    • Scope:指定规则的作用范围,可以是"Cluster"(集群级别)或"Namespace"(命名空间级别)。
  3. WithAPIGroups函数:用于设置RuleApplyConfiguration中的APIGroups字段,指定API分组。

  4. WithAPIVersions函数:用于设置RuleApplyConfiguration中的APIVersions字段,指定API版本。

  5. WithResources函数:用于设置RuleApplyConfiguration中的Resources字段,指定可用的资源。

  6. WithScope函数:用于设置RuleApplyConfiguration中的Scope字段,指定准入规则的作用范围。

这些函数允许在创建或修改AdmissionRegistration的Rule对象时,根据需要设置相应的字段值。通过使用这些函数,可以更方便地配置AdmissionRegistration的Rule对象,并在应用配置时进行灵活的定制。

File: client-go/applyconfigurations/core/v1/podip.go

在K8s组织下的client-go项目中,client-go/applyconfigurations/core/v1/podip.go文件的作用是用于配置Pod的IP地址。

该文件中定义了一系列结构体和函数,用于对Pod的IP地址进行配置,并对应了相应的API对象和操作方法。

以下是对其中涉及的结构体和函数的详细介绍:

  1. PodIPApplyConfiguration结构体:

    • 该结构体用于配置Pod的IP地址信息。
    • 包含了一些字段,如IP、IPs、IPFamily等,用于指定Pod的IP地址。
    • 通过该结构体可以基于Pod的现有配置创建一个新的PodIP配置对象。
  2. PodIP结构体:

    • 该结构体是Pod的IP地址配置的API对象。
    • 通过该对象,可以对Pod的IP地址进行管理和操作,如获取、更新、删除IP地址等。
  3. WithIP函数:

    • WithIP函数用于在PodIPApplyConfiguration对象上设置Pod的IP地址。
    • 该函数接收一个IP地址作为参数,并返回一个修改后的PodIPApplyConfiguration对象。
    • 可以使用该函数为PodIPApplyConfiguration对象指定一个IP地址。
  4. PodIPApplyConfiguration结构体的一些方法(如WithIPsWithIPFamily等):

    • 这些方法用于在PodIPApplyConfiguration对象上设置其他相关的IP地址配置,如设置多个IP地址、指定IP地址类型等。
    • 这些方法接收相应的参数,并返回一个修改后的PodIPApplyConfiguration对象。

通过这些结构体和函数,可以方便地对Pod的IP地址进行配置,例如创建一个新的PodIP配置对象、设置Pod的IP地址等。

File: client-go/applyconfigurations/core/v1/iscsipersistentvolumesource.go

在client-go项目中的iscsipersistentvolumesource.go文件是core/v1包中定义了ISCSIPersistentVolumeSource结构体及其相关配置的文件。该文件是Kubernetes API中定义了用于表示iSCSI持久卷的配置参数。

ISCSIPersistentVolumeSourceApplyConfiguration结构体是ISCISPersistentVolumeSource对象的一部分,用于应用对iSCSI持久卷的配置的更改。

以下是这些结构体和函数的详细解释:

  1. ISCSIPersistentVolumeSource结构体:该结构体定义了iSCSI持久卷的配置参数,包括目标地址、iSCSI Qualified Name(IQN)、逻辑单元号(LUN)、iSCSI接口、文件系统类型等。

  2. WithTargetPortal:设置iSCSI持久卷的目标地址。

  3. WithIQN:设置iSCSI持久卷的iSCSI Qualified Name(IQN)。

  4. WithLun:设置iSCSI持久卷的逻辑单元号(LUN)。

  5. WithISCSIInterface:设置使用的iSCSI接口。

  6. WithFSType:设置iSCSI持久卷的文件系统类型。

  7. WithReadOnly:设置是否将iSCSI持久卷设置为只读。

  8. WithPortals:设置iSCSI持久卷的多个目标地址。

  9. WithDiscoveryCHAPAuth:设置iSCSI持久卷的发现期间的CHAP认证。

  10. WithSessionCHAPAuth:设置iSCSI持久卷的会话期间的CHAP认证。

  11. WithSecretRef:设置iSCSI持久卷的认证密钥的引用。

  12. WithInitiatorName:设置iSCSI持久卷的发起者名称。

这些函数用于设置ISCSIPersistentVolumeSource结构体中对应的字段的值,从而实现了对iSCSI持久卷的配置参数的定制化设置。

File: client-go/applyconfigurations/core/v1/volumeresourcerequirements.go

在client-go项目中,volumeresourcerequirements.go文件位于client-go/applyconfigurations/core/v1/目录下。该文件的作用是定义了用于应用配置的相关结构体和函数,以便在Kubernetes集群中创建、更新或删除Volume资源时使用。

该文件中定义了以下几个结构体:

  1. VolumeResourceRequirementsApplyConfiguration: 这是一个应用配置的结构体,用于描述Volume资源的资源需求。它包含两个字段:LimitsRequests,分别表示资源的限制和需求。

  2. VolumeResourceRequirements: 这是一个Volume资源的资源需求结构体,用于描述该Volume的资源需求。它包含两个字段:LimitsRequests,分别表示资源的限制和需求。

  3. WithLimits: 这是一个函数,它接受资源限制参数,返回一个函数类型的值。用于在创建或更新Volume资源时,设置资源的限制。

  4. WithRequests: 这是一个函数,它接受资源需求参数,返回一个函数类型的值。用于在创建或更新Volume资源时,设置资源的需求。

这些结构体和函数的作用是为了方便开发者在使用client-go库时,能够方便地设置和应用Volume资源的资源需求。通过使用这些结构体和函数,开发者可以在创建或更新Volume资源时,根据实际需求设置资源的限制和需求,以达到合理使用资源的目的。

File: client-go/applyconfigurations/core/v1/claimsource.go

在K8s组织下的client-go项目中,client-go/applyconfigurations/core/v1/claimsource.go文件是用于处理core/v1命名空间资源的声明源(Claim Source)的配置的文件。

该文件中定义了三个结构体:ClaimSourceApplyConfiguration、WithResourceClaimName和WithResourceClaimTemplateName。

  1. ClaimSourceApplyConfiguration:用于配置声明源的应用配置。它是一个与ClaimSource一起使用的辅助结构体,用于设置声明源的属性。

  2. WithResourceClaimName:是一个函数,用于将给定的声明源的名称设置为指定的值。例如,可以使用该函数将PersistentVolumeClaim的名称设置为指定的名称。

  3. WithResourceClaimTemplateName:是一个函数,用于将给定的声明源的模板名称设置为指定的值。例如,可以使用该函数将StatefulSet的模板名称设置为指定的名称。

这些函数通常与k8s.io/client-go/applyconfigurations包中的其他函数一起使用,用于创建或修改Kubernetes API对象的声明源配置。这些配置文件可以用于在Kubernetes集群中创建或更新资源对象,以达到所需的状态。通过使用这些函数,可以方便地应用和管理Kubernetes集群中各种资源的声明源。

File: client-go/kubernetes/typed/rbac/v1/fake/fake_clusterrole.go

In the client-go project under the Kubernetes organization, the file fake_clusterrole.go in the client-go/kubernetes/typed/rbac/v1/fake package is used for creating fake objects for cluster roles.

clusterrolesResource and clusterrolesKind

The clusterrolesResource and clusterrolesKind variables in the fake_clusterrole.go file represent the resource and kind of the cluster roles. These variables are used to define the API resource and kind for the cluster roles in the Kubernetes RBAC (Role-Based Access Control) API.

FakeClusterRoles

The FakeClusterRoles structure in the fake_clusterrole.go file is a mock implementation of the ClusterRoleInterface interface. It provides methods for interacting with cluster roles in a fake or testing environment.

Get, List, Watch, Create, Update, Delete, DeleteCollection, Patch, Apply

The Get, List, Watch, Create, Update, Delete, DeleteCollection, Patch, and Apply functions in the FakeClusterRoles structure represent the different operations that can be performed on cluster roles.

  • Get retrieves a specific cluster role by name.
  • List retrieves a list of cluster roles.
  • Watch watches for changes to cluster roles.
  • Create creates a new cluster role.
  • Update updates an existing cluster role.
  • Delete deletes a cluster role.
  • DeleteCollection deletes a collection of cluster roles.
  • Patch applies a partial update to a cluster role.
  • Apply applies changes to a cluster role.

These functions provide the basic CRUD (Create, Read, Update, Delete) operations for managing cluster roles in the client-go project. They allow developers to interact with cluster roles programmatically and perform operations such as creating, updating, and deleting cluster roles.

Please note that the information provided is based on the search results and may not cover all the details of the mentioned file and its functions. It is recommended to refer to the official documentation or the source code for a more comprehensive understanding of the client-go project and its components.

File: client-go/discovery/discovery_client.go

在K8s组织下的client-go项目中,client-go/discovery/discovery_client.go是用于处理Kubernetes API的发现功能。它提供了与集群交互并获取有关可用的API组、版本、资源和服务器信息的方法。

下面是相关变量和结构体的作用:

  • DiscoveryInterface:定义了执行与API发现相关操作的接口。
  • AggregatedDiscoveryInterface:定义了聚合式API发现相关操作的接口。
  • CachedDiscoveryInterface:定义了缓存API发现相关操作的接口。
  • ServerGroupsInterface:定义了获取API组信息的接口。
  • ServerResourcesInterface:定义了获取API组和版本相关资源信息的接口。
  • ServerVersionInterface:定义了获取服务器版本信息的接口。
  • OpenAPISchemaInterface:定义了获取OpenAPI模式信息的接口。
  • OpenAPIV3SchemaInterface:定义了获取OpenAPI V3模式信息的接口。
  • DiscoveryClient:实现了DiscoveryInterface接口,用于与集群进行API发现。
  • ErrGroupDiscoveryFailed:表示组发现失败的错误。

以下是一些重要的函数和方法:

  • apiVersionsToAPIGroup:根据API版本返回匹配的API组。
  • GroupsAndMaybeResources:返回API组及其相关资源的信息。
  • downloadLegacy:从服务器上下载API组信息的原始数据。
  • downloadAPIs:从服务器上下载API组的信息。
  • isV2Beta1ContentType:判断Content-Type是否为v2beta1。
  • ServerGroups:获取所有API组的信息。
  • ServerResourcesForGroupVersion:获取给定API组和版本的资源信息。
  • ServerGroupsAndResources:获取所有API组及其相关资源的信息。
  • Error:表示获取API失败的错误。
  • IsGroupDiscoveryFailedError:判断是否为组发现失败的错误。
  • GroupDiscoveryFailedErrorGroups:返回组发现失败的API组信息。
  • ServerPreferredResources:根据API版本返回首选的资源列表。
  • fetchGroupVersionResources:获取给定组和版本的资源信息。
  • ServerPreferredNamespacedResources:根据API版本返回首选的命名空间资源列表。
  • ServerVersion:获取服务器的版本信息。
  • OpenAPISchema:获取服务器的OpenAPI模式信息。
  • OpenAPIV3:获取服务器的OpenAPI V3模式信息。
  • WithLegacy:使用遗留方式进行发现。
  • withRetries:在遇到临时错误时进行重试。
  • setDiscoveryDefaults:设置API发现的默认值。
  • NewDiscoveryClientForConfig:基于给定的配置创建DiscoveryClient。
  • NewDiscoveryClientForConfigAndClient:基于给定的配置和客户端创建DiscoveryClient。
  • NewDiscoveryClientForConfigOrDie:基于给定的配置创建DiscoveryClient。如果失败则终止程序。
  • NewDiscoveryClient:创建默认配置的DiscoveryClient。
  • RESTClient:在给定的HTTP传输参数下创建一个进行REST操作的客户端。

这些函数和方法提供了从Kubernetes集群中获取API组、版本、资源和服务器信息的能力,并且可以让开发者更方便地与集群进行交互。

本文由 mdnice 多平台发布

评论
添加红包

请填写红包祝福语或标题

红包个数最小为10个

红包金额最低5元

当前余额3.43前往充值 >
需支付:10.00
成就一亿技术人!
领取后你会自动成为博主和红包主的粉丝 规则
hope_wisdom
发出的红包
实付
使用余额支付
点击重新获取
扫码支付
钱包余额 0

抵扣说明:

1.余额是钱包充值的虚拟货币,按照1:1的比例进行支付金额的抵扣。
2.余额无法直接购买下载,可以购买VIP、付费专栏及课程。

余额充值
