数据结构与算法之求凸包

#include<iostream>
#include<stdlib.h>
#include<cmath>
using namespace std;
#define xmin -1000
#define xmax 1000
#define ymin -1000
#define ymax 1000
struct pointnode
{
	int x;
	int y;
};
struct chainnode
{
	struct pointnode point;
	struct chainnode *leftnode;
	struct chainnode *rightnode;
};
class doublelist
{
	public:
	doublelist(int initiationsize=5);
	~doublelist();
	void insertnode(int index,struct pointnode);
	void printlist();
	void erasenode(int index);
	void erasenode(chainnode* x);
	void printreverse();
	int size(){return listsize;}
	int issameline();
	struct chainnode* get(int index);
	pointnode makepointx(pointnode x1,pointnode x2,pointnode x3);
	pointnode findonepoint(int index);
	void sortlist();
	void convexclosure();
	int is_ins(pointnode z);
	private:
    chainnode* firstnode;
    int listsize;
};
int obtuseangle(pointnode x,pointnode rx,pointnode rrx);
double distance(pointnode z,pointnode x);
double polar(pointnode z,pointnode x);

void doublelist::convexclosure()
{
   if(listsize<3)return;
   //若共线返回两端点，未实现
   sortlist();
   cout<<endl<<"after sort:"<<endl;
   printlist();
   pointnode yminnode=findonepoint(4);
   chainnode *p=firstnode,*x,*rx,*rrx;
   for(int i=0;i<listsize;i++)
   {
   	if((p->point.x==yminnode.x)&&(p->point.y==yminnode.y))
   	break;
   	p=p->rightnode;
   }
    cout<<"the point min y is:"<<p->point.x<<","<<p->point.y<<endl;
   int firstflag=0;
   x=p;
   rx=x->rightnode;
   for(;(p!=rx)||(!firstflag);)
   {
   	rrx=rx->rightnode;
   	if(obtuseangle(x->point,rx->point,rrx->point))
   	{
   		x=rx;rx=rx->rightnode;
   		firstflag++;
   	}
   	else
   	{
   		erasenode(x);//erase x next node;
   		rx=x;
   		x=x->leftnode;
   	}
   }


}
int main(void)
{
	doublelist one;
	int n;
	cin>>n;
	struct pointnode z;
	for(int i=0;i<n;i++)
	{
	cin>>z.x>>z.y;
	one.insertnode(i,z);
	}
//	one.printreverse();
	one.convexclosure();

	one.printlist();
	return 0;
}
/*

13
1 0
3 3
5 4
4 5
4 7
2 6
1 5
-1 7
-2 4
-3 3
-4 2
-3 0
-1 3


13
-1 3
-1 7
-2 4
4 5
1 0
3 3
5 4
-3 3
-3 0
-4 2
4 7
1 5
2 6
*/
doublelist::doublelist(int initiationsize)
{
	firstnode=NULL;
	listsize=0;
}
doublelist::~doublelist()
{
	for(int i=0;i<listsize;i++)
	{
	struct chainnode* tempnode=firstnode->rightnode;
	delete firstnode;;
	firstnode=tempnode;
	}
}
void doublelist::printlist()
{
    struct chainnode *tempnode=firstnode;
    cout<<"this chain has node:"<<listsize<<endl;
	for(int i=0;i<listsize;i++)
	{

		cout<<tempnode->point.x<<" "<<tempnode->point.y<<endl;
		tempnode=tempnode->rightnode;
	}
	cout<<endl;
}
void doublelist::erasenode(int index)
{
	struct chainnode* tempnode=firstnode,*deletenode;

	  for(int i=0;i<index-1;i++)
	  		tempnode=tempnode->rightnode;
	  	deletenode=tempnode->rightnode;
	  	tempnode->rightnode=tempnode->rightnode->rightnode;
	  	tempnode->rightnode->leftnode=tempnode;
	listsize--;
}
void doublelist::erasenode(chainnode* x)
{
		struct chainnode *tempnode=x;
		if(x->rightnode==firstnode)
		firstnode=x->rightnode->rightnode;
	  	tempnode->rightnode=tempnode->rightnode->rightnode;
	  	tempnode->rightnode->leftnode=tempnode;
	listsize--;
}
void doublelist::printreverse()
{
    cout<<"print reverse list is:"<<endl;
	struct chainnode *tempnode=firstnode->leftnode;
		tempnode=tempnode->leftnode;
	struct chainnode *endnode=tempnode;
	while(tempnode->leftnode!=endnode)
	{
		cout<<tempnode->point.x<<" "<<tempnode->point.y<<endl;
		tempnode=tempnode->leftnode;
	}
	cout<<tempnode->point.x<<" "<<tempnode->point.y<<endl;
	cout<<endl;
}
void doublelist::insertnode(int index,struct pointnode z)
{
	if(listsize==0)
	{
		 struct chainnode *tempnode=new struct chainnode;
	       tempnode->point=z;
	       tempnode->rightnode=tempnode;
	       tempnode->leftnode=tempnode;
	       firstnode=tempnode;
	}
	else
	{

	if(index==0)
	  {
	  	 struct chainnode *tempnode=new struct chainnode;
	       tempnode->point=z;
	       tempnode->rightnode=firstnode;
	       tempnode->leftnode=firstnode->leftnode;
	       firstnode->leftnode=tempnode;
	       firstnode=tempnode;
	  }
	  else
	  {
	  	struct chainnode* tempnode=firstnode;
	  	for(int i=0;i<index-1;i++)
	  		tempnode=tempnode->rightnode;
	  	tempnode->rightnode=new chainnode{z,tempnode,tempnode->rightnode};
	  	tempnode->rightnode->rightnode->leftnode=tempnode->rightnode;
	  }}
	  listsize++;
}
int doublelist::issameline()
{
	if(listsize<3)return -1;
	chainnode *tempnode=firstnode;
	pointnode x,rx,rrx;
	for(int i=0;i<(listsize-2);i++)
	{
		x=tempnode->point;
		rx=tempnode->rightnode->point;
		rrx=tempnode->rightnode->rightnode->point;
		if(((rx.y-x.y)*1.0/(rx.x-x.x))!=((rx.y-rrx.y)*1.0/(rx.x-rrx.x)))
		return 0;
	    tempnode=tempnode->rightnode;
	}
	return 1;
}
struct chainnode* doublelist::get(int index)
{
	int i=0;
	 chainnode *tempnode=firstnode;
	 if(index==0)
	  	return tempnode;
	 else
	 {
	 while((i++<(index-1))&&(tempnode->rightnode!=NULL))
	 tempnode=tempnode->rightnode;
	 return tempnode->rightnode;
	 }
}
pointnode doublelist::makepointx(pointnode x1,pointnode x2,pointnode x3)
{
	int x4,y4,y41,y42,flag=0;
	pointnode z=x1;
	while((!flag)||(is_ins(z)))//直到找到一点合适z
	{
	x4=rand()%(x3.x-x1.x-1)+x1.x+1;
	if(x3.x>x2.x)
	{
	    if(x4<=x2.x)
	       y41=(int)(((x2.y-x1.y)*x4+(x1.y*x2.x-x2.y*x1.x))/(x2.x-x1.x));
    	else
	       y41=(int)(((x3.y-x2.y)*x4+(x2.y*x3.x-x3.y*x2.x))/(x3.x-x2.x));
	       y42=(int)(((x3.y-x1.y)*x4+(x1.y*x3.x-x3.y*x1.x))/(x3.x-x1.x));
	}
	else if(x3.x<x2.x)
	{
	       y41=(int)(((x2.y-x1.y)*x4+(x1.y*x2.x-x2.y*x1.x))/(x2.x-x1.x));
      	if(x4>x3.x)
	        y42=(int)(((x3.y-x2.y)*x4+(x2.y*x3.x-x3.y*x2.x))/(x3.x-x2.x));
      	else
 	       y42=(int)(((x3.y-x1.y)*x4+(x1.y*x3.x-x3.y*x1.x))/(x3.x-x1.x));
	}
	else
	{
		y41=(int)(((x2.y-x1.y)*x4+(x1.y*x2.x-x2.y*x1.x))/(x2.x-x1.x));
	    y42=(int)(((x3.y-x1.y)*x4+(x1.y*x3.x-x3.y*x1.x))/(x3.x-x1.x));
	}
	 if(y41<=(y42+1))continue;
	 else y4=rand()%(y41-y42-1)+y42+1;
	 if((y4<=y42)||(y4>=y41))
	  flag=0;
	  else
	  flag=1;
		z.x=x4;
	z.y=y4;
	}
	return z;
}
int obtuseangle(pointnode x,pointnode rx,pointnode rrx)
{//greater than 180 return 1;
	struct pointnode vectorquantity1,vectorquantity2;
	vectorquantity1.x=-(x.y-rx.y);
	vectorquantity1.y=x.x-rx.x;

	vectorquantity2.x=rrx.x-rx.x;
	vectorquantity2.y=rrx.y-rx.y;

	if((vectorquantity1.x*vectorquantity2.x+vectorquantity1.y*vectorquantity2.y)<0)
	return 1;
	else
	return 0;
}

double distance(pointnode z,pointnode x)
{
	return sqrt((x.x-z.x)*(x.x-z.x)+(x.y-z.y)*(x.y-z.y));
}

double polar(pointnode z,pointnode x)
{
   if((x.x>=z.x)&&(x.y<=z.y))
      return (x.x-z.x)/distance(z,x);
  else if((x.x>=z.x)&&(x.y>z.y))
      return 2-((x.x-z.x)/distance(z,x));
  else if((x.x<z.x)&&(x.y>=z.y))
      return (z.x-x.x)/distance(z,x)+2;
   //if((x.x<z.x)&&(x.y<z.y))
   else
      return 4-((z.x-x.x)/distance(z,x));
}
pointnode doublelist::findonepoint(int index)
{//1-xmin,2-ymax,3-xmax,4-ymin
	pointnode datanode;
	chainnode* tempnode=firstnode;
	datanode=firstnode->point;
	for(int i=0;i<listsize;i++)
	{
	   if((index==1)&&(tempnode->point.x<datanode.x))
	       datanode=tempnode->point;
	   if((index==2)&&(tempnode->point.y>datanode.y))
	       datanode=tempnode->point;
	   if((index==3)&&(tempnode->point.x>datanode.x))
	       datanode=tempnode->point;
	   if((index==4)&&(tempnode->point.y<datanode.y))
	       datanode=tempnode->point;
	    tempnode=tempnode->rightnode;
	}
	return datanode;
}
void doublelist::sortlist()
{
  	int i,j;
  	pointnode z=makepointx(findonepoint(1),findonepoint(2),findonepoint(3));
	 cout<<"point rand make z is:"<<z.x<<","<<z.y<<endl;
  	chainnode* inode,*jnode;
  	pointnode tempnode;
  	for(i=0;i<listsize;i++)
  	   for(j=i+1;j<listsize;j++)
  	   {
  	     inode=get(i);
  	     jnode=get(j);
  	     if(polar(z,jnode->point)<polar(z,inode->point))	{tempnode=inode->point;inode->point=jnode->point;jnode->point=tempnode;}
  	     else if((polar(z,jnode->point)==polar(z,inode->point))&&(distance(z,jnode->point)<distance(z,inode->point)))
  	     {tempnode=inode->point;inode->point=jnode->point;jnode->point=tempnode;}
  	   }

}
int doublelist::is_ins(pointnode z)
{

	 int flag=0;
	 chainnode* tempnode=firstnode;
	 for(int i=0;i<listsize;i++)
	 {
	 if((tempnode->point.x==z.x)&&(tempnode->point.y==z.y))
	{flag=1; break;}
	tempnode=tempnode->rightnode;
	}
	return flag;
}
