echarts

<div id="main" style="width:500px; height:500px"></div>

<script src="https://unpkg.com/echarts@5.5.0/dist/echarts.js"></script>
<script>
    // 初始化 ECharts 实例
    var myChart = echarts.init(document.getElementById('main'));




    let angle = 0;//角度，用来做简单的动画效果的
    let value = 55.33;
    option = {
        backgroundColor: "#061740",
        title: {
            text: '{a|' + value + '}{c|%}',
            x: 'center',
            y: 'center',
            textStyle: {
                rich: {
                    a: {
                        fontSize: 48,
                        color: '#29EEF3'
                    },

                    c: {
                        fontSize: 20,
                        color: '#ffffff',
                        // padding: [5,0]
                    }
                }
            }
        },
        legend: {
            type: "plain",
            orient: "vertical",
            right: 0,
            top: "10%",
            align: "auto",
            data: [{
                name: '涨价后没吃过',
                icon: "circle"
            }, {
                name: '天天吃',
                icon: "circle"
            }, {
                name: '三五天吃一次',
                icon: "circle"
            }, {
                name: '半个月吃一次',
                icon: "circle"
            }],
            textStyle: {
                color: "white",
                fontSize: 16,
                padding: [10, 1, 10, 0]
            },
            selectedMode: false
        },
        series: [{
            name: "ring5",
            type: 'custom',
            coordinateSystem: "none",
            renderItem: function (params, api) {
                return {
                    type: 'arc',
                    shape: {
                        cx: api.getWidth() / 2,
                        cy: api.getHeight() / 2,
                        r: Math.min(api.getWidth(), api.getHeight()) / 2 * 0.6,
                        startAngle: (0 + angle) * Math.PI / 180,
                        endAngle: (90 + angle) * Math.PI / 180
                    },
                    style: {
                        stroke: "#0CD3DB",
                        fill: "transparent",
                        lineWidth: 1.5
                    },
                    silent: true
                };
            },
            data: [0]
        }, {
            name: "ring5",
            type: 'custom',
            coordinateSystem: "none",
            renderItem: function (params, api) {
                return {
                    type: 'arc',
                    shape: {
                        cx: api.getWidth() / 2,
                        cy: api.getHeight() / 2,
                        r: Math.min(api.getWidth(), api.getHeight()) / 2 * 0.6,
                        startAngle: (180 + angle) * Math.PI / 180,
                        endAngle: (270 + angle) * Math.PI / 180
                    },
                    style: {
                        stroke: "#0CD3DB",
                        fill: "transparent",
                        lineWidth: 1.5
                    },
                    silent: true
                };
            },
            data: [0]
        }, {
            name: "ring5",
            type: 'custom',
            coordinateSystem: "none",
            renderItem: function (params, api) {
                return {
                    type: 'arc',
                    shape: {
                        cx: api.getWidth() / 2,
                        cy: api.getHeight() / 2,
                        r: Math.min(api.getWidth(), api.getHeight()) / 2 * 0.65,
                        startAngle: (270 + -angle) * Math.PI / 180,
                        endAngle: (40 + -angle) * Math.PI / 180
                    },
                    style: {
                        stroke: "#0CD3DB",
                        fill: "transparent",
                        lineWidth: 1.5
                    },
                    silent: true
                };
            },
            data: [0]
        }, {
            name: "ring5",
            type: 'custom',
            coordinateSystem: "none",
            renderItem: function (params, api) {
                return {
                    type: 'arc',
                    shape: {
                        cx: api.getWidth() / 2,
                        cy: api.getHeight() / 2,
                        r: Math.min(api.getWidth(), api.getHeight()) / 2 * 0.65,
                        startAngle: (90 + -angle) * Math.PI / 180,
                        endAngle: (220 + -angle) * Math.PI / 180
                    },
                    style: {
                        stroke: "#0CD3DB",
                        fill: "transparent",
                        lineWidth: 1.5
                    },
                    silent: true
                };
            },
            data: [0]
        }, {
            name: "ring5",
            type: 'custom',
            coordinateSystem: "none",
            renderItem: function (params, api) {
                let x0 = api.getWidth() / 2;
                let y0 = api.getHeight() / 2;
                let r = Math.min(api.getWidth(), api.getHeight()) / 2 * 0.65;
                let point = getCirlPoint(x0, y0, r, (90 + -angle))
                return {
                    type: 'circle',
                    shape: {
                        cx: point.x,
                        cy: point.y,
                        r: 4
                    },
                    style: {
                        stroke: "#0CD3DB",//粉
                        fill: "#0CD3DB"
                    },
                    silent: true
                };
            },
            data: [0]
        }, {
            name: "ring5",  //绿点
            type: 'custom',
            coordinateSystem: "none",
            renderItem: function (params, api) {
                let x0 = api.getWidth() / 2;
                let y0 = api.getHeight() / 2;
                let r = Math.min(api.getWidth(), api.getHeight()) / 2 * 0.65;
                let point = getCirlPoint(x0, y0, r, (270 + -angle))
                return {
                    type: 'circle',
                    shape: {
                        cx: point.x,
                        cy: point.y,
                        r: 4
                    },
                    style: {
                        stroke: "#0CD3DB",      //绿
                        fill: "#0CD3DB"
                    },
                    silent: true
                };
            },
            data: [0]
        }, {
            name: '吃猪肉频率',
            type: 'pie',
            radius: ['58%', '45%'],
            silent: true,
            clockwise: true,
            startAngle: 90,
            z: 0,
            zlevel: 0,
            label: {
                normal: {
                    position: "center",

                }
            },
            data: [{
                value: value,
                name: "",
                itemStyle: {
                    normal: {
                        color: { // 完成的圆环的颜色
                            colorStops: [{
                                offset: 0,
                                color: '#4FADFD' // 0% 处的颜色
                            }, {
                                offset: 1,
                                color: '#28E8FA' // 100% 处的颜色
                            }]
                        },
                    }
                }
            },
            {
                value: 100 - value,
                name: "",
                label: {
                    normal: {
                        show: false
                    }
                },
                itemStyle: {
                    normal: {
                        color: "#173164"
                    }
                }
            }
            ]
        },

        {
            name: "",
            type: "gauge",
            radius: "58%",
            center: ['50%', '50%'],
            startAngle: 0,
            endAngle: 359.9,
            splitNumber: 8,
            hoverAnimation: true,
            axisTick: {
                show: false
            },
            splitLine: {
                length: 60,
                lineStyle: {
                    width: 5,
                    color: "#061740"
                }
            },
            axisLabel: {
                show: false
            },
            pointer: {
                show: false
            },
            axisLine: {
                lineStyle: {
                    opacity: 0
                }
            },
            detail: {
                show: false
            },
            data: [{
                value: 0,
                name: ""
            }]
        },

        ]
    };

    //获取圆上面某点的坐标(x0,y0表示坐标，r半径，angle角度)
    function getCirlPoint(x0, y0, r, angle) {
        let x1 = x0 + r * Math.cos(angle * Math.PI / 180)
        let y1 = y0 + r * Math.sin(angle * Math.PI / 180)
        return {
            x: x1,
            y: y1
        }
    }

    function draw() {
        angle = angle + 3
        myChart.setOption(option, true)
        //window.requestAnimationFrame(draw);
    }

    setInterval(function () {
        //用setInterval做动画感觉有问题
        draw()
    }, 100);


    myChart.setOption(option);
</script>
