ReentrantLock源码理解AQS

1，概述

ReentrantLock对于线程经常使用lock和unlock方法来调整线程的状态。下面将对ReentrantLock的源码进行详解，来了解ReentrantLock底层是如何使用AQS，并且了解线程底层具体运行的一个状态。

2，源码解读

环境：jdk 1.8

测试代码

public class Test001 {

    public static void main(String[] args) {

        ReentrantLock reentrantLock = new ReentrantLock();

        reentrantLock.lock();  // @1
        System.out.printf("业务逻辑");
        // reentrantLock.lock();   //@A 探究具体源码状态
        reentrantLock.unlock();
    }
}

在@1出断点
进入ReentrantLock

public void lock() {
    sync.lock();
}

final void lock() {
    if (compareAndSetState(0, 1))  //通过CAS原理，把当前线程的state状态从0改1
        setExclusiveOwnerThread(Thread.currentThread()); // @2
    else
        acquire(1);
}

继续 查看这个CAS方法 进入AbstractQueuedSynchronizer ，底层使用的Unsafe来做CAS

protected final boolean compareAndSetState(int expect, int update) {
    // See below for intrinsics setup to support this
    return unsafe.compareAndSwapInt(this, stateOffset, expect, update);
}

修改完之后回到ReentrantLock @2中
setExclusiveOwnerThread(Thread.currentThread()); 意思就是设置当前线程为独占线程，
此方法是AbstractQueuedSynchronizer 的父类AbstractOwnableSynchronizer

protected final void setExclusiveOwnerThread(Thread thread) {
    exclusiveOwnerThread = thread;
}

自此 lock方法处理完毕，

来看下unlock 进入ReentrantLock

public void unlock() {
    sync.release(1);//这个参数就是刚刚我们修改的state,他是被volatile 修饰的int类型
}

进入AQS的release方法`

public final boolean release(int arg) {
    if (tryRelease(arg)) {//arg=1
        Node h = head;   //head=null
        if (h != null && h.waitStatus != 0)
            unparkSuccessor(h);
        return true;//返回true
    }
    return false;
}

进入ReentrantLock 的tryRelease

protected final boolean tryRelease(int releases) {
    int c = getState() - releases;  //@1这里计算后C为0
    if (Thread.currentThread() != getExclusiveOwnerThread())//@2
        throw new IllegalMonitorStateException();
    boolean free = false;
    if (c == 0) {//c=0进入
        free = true;
        setExclusiveOwnerThread(null);//@3把当前线程清除
    }
    setState(c);  // 此时变为0
    return free;   //返回一个true
}

@1AbstractQueuedSynchronizer

protected final int getState() {
    return state;                 //状态已经在我们lock时变为1
}

@2 AbstractOwnableSynchronizer中

protected final Thread getExclusiveOwnerThread() {
    return exclusiveOwnerThread;//之前我们lock时已经把当前线程设置到此处 查看上述代码
}

@3 AbstractOwnableSynchronizer中

protected final void setExclusiveOwnerThread(Thread thread) {  //tread=null
    exclusiveOwnerThread = thread;
}

自此unlock状态结束

想要查看具体这个state的状态，还有node节点问题，打开@A注释 。此时注意两次调用lock看下下面的状态

public void lock() {
    sync.lock();
}

final void lock() {
    if (compareAndSetState(0, 1))
        setExclusiveOwnerThread(Thread.currentThread());
    else
        acquire(1);     //已经lock了一次state变为1，测试 肯定走这个方法
}

进入AbstractQueuedSynchronizer

public final void acquire(int arg) {
    if (!tryAcquire(arg) &&
        acquireQueued(addWaiter(Node.EXCLUSIVE), arg))//
        selfInterrupt();
}

进入ReentrantLock

protected final boolean tryAcquire(int acquires) {
    return nonfairTryAcquire(acquires);
}

final boolean nonfairTryAcquire(int acquires) {  //1
    final Thread current = Thread.currentThread();//获取当前线程
    int c = getState();  //1
    if (c == 0) {
        if (compareAndSetState(0, acquires)) {
            setExclusiveOwnerThread(current);
            return true;
        }
    }
    else if (current == getExclusiveOwnerThread()) {//@1
        int nextc = c + acquires;  //2
        if (nextc < 0) // overflow
            throw new Error("Maximum lock count exceeded");
        setState(nextc);//设置到state中
        return true;
    }
    return false;
}

@1AbstractOwnableSynchronizer

protected final Thread getExclusiveOwnerThread() {
    return exclusiveOwnerThread;
}

自此查看到state状态由1变为2，并且查看unlock方法又变为1

3,总结

再看下AQS中

private transient volatile Node head;//头结点

/**
 * Tail of the wait queue, lazily initialized.  Modified only via
 * method enq to add new wait node.
 */
private transient volatile Node tail;   /尾巴结点

/**
 * The synchronization state.
 */
private volatile int state;    //状态state

可以看出如上原理 node结点一个双向链表，每个node存入的是线程，整个链表形成一个线程的等待队列。每个node就是一个线程。
state参数 主要由不同的类自身决定如ReentrantLock，原理就是通过CAS+volatile来修改state的值，当有重入现象，state会加一，当线程被释放之后，state会减一最后到0。
