DMDSC搭建主备

前置准备

拥有DSC0、DSC1、monitor、Salve
DSC0与DSC1为DSC集群作为主机
monitor作为监控DSC集群监控器
Slave作为备机
./dmcss dcr_ini=/dm8/data/dmdcr.ini #启动css集群
monitor操作：ep startup GRP_ASM#启动asm集群
monitor操作：ep startup GRP_DSC#启动dsc集群

数据库服务

对DSC0或者DSC1备份数据库。

./dmrman dcr_ini=/dm8/data/dmdcr.ini
backup database '/dm8/data/dsc0_config/dm.ini' backupset '/dm8/bak/';

初始化实例Salve

Salve还原

发送备份

scp -r /dm8/bak 192.168.0.4:/dm8

还原操作

./dmrman
RESTORE DATABASE '/dm8/data/Slave/dm.ini' FROM BACKUPSET'/dm8/bak';

RECOVER DATABASE '/dm8/data/Slave/dm.ini' FROM BACKUPSET '/dm8/bak';

RECOVER DATABASE '/dm8/data/Slave/dm.ini' UPDATE DB_MAGIC;

编辑DSC集群DSC0与DSC1的dm.ini文件

ALTER_MODE_STATUS = 0 #不允许手工方式修改实例模式/状态
ENABLE_OFFLINE_TS = 2 #不允许备库 OFFLINE 表空间
ARCH_INI = 1 #开启归档模式
MAL_INI = 1

修改dmmal.ini

[mal_inst0]
    mal_inst_name  = DSC0
    mal_host       = 192.168.0.2
    mal_port       = 9340

[mal_inst1]
    mal_inst_name  = DSC1
    mal_host       = 192.168.0.3
    mal_port       = 9341



[mal_inst2]
    mal_inst_name  = Salve
    mal_host       = 192.168.0.4
    mal_port       = 9342

修改 DSC0 的 dmarch.ini 文件

ARCH_WAIT_APPLY = 1

[ARCHIVE_LOCAL1]

ARCH_TYPE = LOCAL

ARCH_DEST = /dm8/data/dsc0_config/arch

ARCH_FILE_SIZE = 128

ARCH_SPACE_LIMIT = 51200

[ARCHIVE_REMOTE]

ARCH_TYPE = REMOTE

ARCH_DEST = DSC1

ARCH_FILE_SIZE = 128

ARCH_SPACE_LIMIT = 51200

ARCH_INCOMING_PATH = /dm8/data/dsc1_config/arch

[ARCHIVE_REALTIME]

ARCH_TYPE = REALTIME

ARCH_DEST = Salve

修改 DSC1 的 dmarch.ini 文件

ARCH_WAIT_APPLY = 1

[ARCHIVE_LOCAL1]

ARCH_TYPE = LOCAL

ARCH_DEST = /dm8/data/dsc0_config/arch

ARCH_FILE_SIZE = 128

ARCH_SPACE_LIMIT = 51200

[ARCHIVE_REMOTE]

ARCH_TYPE = REMOTE

ARCH_DEST = DSC0

ARCH_FILE_SIZE = 128

ARCH_SPACE_LIMIT = 51200

ARCH_INCOMING_PATH = /dm8/data/dsc1_config/arch

[ARCHIVE_REALTIME]

ARCH_TYPE = REALTIME

ARCH_DEST = Salve

修改DSC0与DSC1的dmwatcher.ini文件

DSC0

[GRP1]

DW_TYPE = GLOBAL

DW_MODE = MANUAL

DW_ERROR_TIME = 60

INST_RECOVER_TIME = 60

INST_ERROR_TIME = 35

INST_INI = /dm8/data/dm.ini

DCR_INI = /dm8/data/dmdcr.ini

INST_OGUID = 1000

INST_AUTO_RESTART = 0

DSC1

[GRP1]

DW_TYPE = GLOBAL

DW_MODE = MANUAL

DW_ERROR_TIME = 60

INST_RECOVER_TIME = 60

INST_ERROR_TIME = 35

INST_INI = /dm8/data/DSC1/dm.ini

DCR_INI = /dm8/data/DSC1/dmdcr.ini

INST_OGUID = 1000

INST_AUTO_RESTART = 0

修改Salve的dm.ini

ALTER_MODE_STATUS = 0 #不允许手工方式修改实例模式/状态

ENABLE_OFFLINE_TS = 2 #不允许备库 OFFLINE 表空间

ARCH_INI = 1 #开启归档模式

MAL_INI = 1 #开启 MAL 系统

修改Salve的dmarch.ini

arch_wait_apply=1

[ARCHIVE_LOCAL1]

ARCH_TYPE = LOCAL

ARCH_DEST = /dm8/data/arch

ARCH_FILE_SIZE = 128

ARCH_SPACE_LIMIT = 51200

[ARCHIVE_REALTIME1]

ARCH_TYPE = REALTIME

ARCH_DEST = DSC0/DSC1

配置备库Salve的dmmal.ini

[mal_inst0]
    mal_inst_name  = DSC0
    mal_host       = 192.168.0.2
    mal_port       = 9340

[mal_inst1]
    mal_inst_name  = DSC1
    mal_host       = 192.168.0.3
    mal_port       = 9341



[mal_inst2]
    mal_inst_name  = Salve
    mal_host       = 192.168.0.4
    mal_port       = 9342

配置Salve的dmwatcher.ini

[GRP1]
DW_TYPE = GLOBAL
DW_MODE = MANUAL
DW_ERROR_TIME = 60
INST_RECOVER_TIME = 60
INST_ERROR_TIME = 35
INST_INI = /dm8/data/Salve/dm.ini
INST_OGUID = 1000
INST_STARTUP_CMD = /dm8/bin/dmserver
INST_AUTO_RESTART = 1

将所有实例配置成mount状态后配置主备

在这里插入代码片

DSC0

 ./dmcss dcr_ini=/dm8/data/dsc0_config/dmdcr.ini

 ./dmasmsvr dcr_ini=/dm8/data/dsc0_config/dmdcr.ini
./dmserver /dm8/data/dsc0_config/dm.ini dcr_ini=/dm8/data/dsc0_config/dmdcr.ini mount

DSC1

 ./dmcss dcr_ini=/dm8/data/dsc1_config/dmdcr.ini
 ./dmasmsvr dcr_ini=/dm8/data/dsc1_config/dmdcr.ini
./dmserver /dm8/data/dsc1_config/dm.ini dcr_ini=/dm8/data/dsc1_config/dmdcr.ini mount

Slave

./dmserver /dm8/data/Slave/dm.ini mount

设置主备库

启动命令行工具 DIsql，连接 DMDSC 集群中的任意一个节点

SP_SET_OGUID(1000);#设置OGUID

ALTER DATABASE PRIMARY;#修改库为Primary 模式。

DIsql 连接单节点备库，修改OGUID及修改库为 Standby 模式

SP_SET_OGUID(1000);#修改OGUID

ALTER DATABASE STANDBY;#修改库为 Standby 模式

启动所有节点守护进程

./dmwatcher /dm8/config/dsc0_config/dmwatcher.ini

./dmwatcher /dm8/config/dsc1_config/dmwatcher.ini

./dmwatcher /dm8/data/DAMENG/dmwatcher.ini

配置监视器 dmmonitor.ini

MON_DW_CONFIRM = 0 #0监控监视器模式 1确认监视器模式

MON_LOG_PATH = /dm8/data/monitor_log

MON_LOG_INTERVAL = 60

MON_LOG_FILE_SIZE = 64

MON_LOG_SPACE_LIMIT = 0

MON_DW_CONFIRM = 0

[GRP1]

MON_INST_OGUID = 1000

MON_DW_IP = 192.168.20.15:3567/192.168.20.16:3567

MON_DW_IP = 192.168.20.14:3567

启动监视器

./dmmonitor /dm8/data/dmmonitor.ini

登录数据库测试，验证数据库是否正常同步
