Deployment 加载nfs磁盘持久化配置过程

一: NFS服务器 nfs服务器: 10.10.10.69  path：/data 对于需要容器内数据持久化的，低成本的方案是自己部署nfs server。 对于性能有要求的可以使用企业级 NAS 或者 ceph glusterfs。     [root@node01 ~]# [root@node01 ~]# [root@node01 ~]# ps -ef|grep nfs root        1650       2  0 Sep09 ?        00:00:00 [nfsd] root        1651       2  0 Sep09 ?        00:00:00 [nfsd] root        1652       2  0 Sep09 ?        00:00:00 [nfsd] root        1654       2  0 Sep09 ?        00:00:00 [nfsd] root        1656       2  0 Sep09 ?        00:00:00 [nfsd] root        1657       2  0 Sep09 ?        00:00:00 [nfsd] root        1658       2  0 Sep09 ?        00:00:30 [nfsd] root        1659       2  0 Sep09 ?        00:05:34 [nfsd] root      177995  177905  0 20:48 pts/0    00:00:00 grep --color=auto nfs [root@node01 ~]# cat /etc/exports /data *(rw,async,no_root_squash,no_subtree_check)   [root@node01 ~]# [root@node01 ~]# showmount -e Export list for node01: /data * [root@node01 ~]#

二 创建 deployment   [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# cat nginx-deploy-nfs01.yaml apiVersion: apps/v1 kind: Deployment metadata:   name: nginx-deploy-nfs spec:   selector:     matchLabels:            app: nginx-deploy-nfs   replicas: 2   template:     metadata:       labels:         app: nginx-deploy-nfs     spec:       containers:       - name: nginx-deploy-nfs         image: nginx         ports:         - containerPort: 80         volumeMounts:           - mountPath: "/usr/share/nginx/html"             name: nfs       volumes:         - name: nfs           nfs:             server: 10.10.10.69             path: "/data/nginx01"   [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl apply -f   nginx-deploy-nfs01.yaml deployment.apps/nginx-deploy-nfs created [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl get deployment|grep nfs nginx-deploy-nfs             0/2     2            0           57s [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl get pod|grep nfs nginx-deploy-nfs-5c89969cd4-82vjf             1/1     Running             0          54s nginx-deploy-nfs-5c89969cd4-pl7jv             1/1     Running             0          54s [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl get pod -o wide|grep nfs nginx-deploy-nfs-5c89969cd4-82vjf             1/1     Running             0          11h     10.244.2.29   k8s3   <none>           <none> nginx-deploy-nfs-5c89969cd4-pl7jv             1/1     Running             0          11h     10.244.1.34   k8s2   <none>           <none> [root@k8s1 nfs]#   ############################################################################################ [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl exec -it nginx-deploy-nfs-5c89969cd4-82vjf /bin/bash root@nginx-deploy-nfs-5c89969cd4-82vjf:/# cat /etc/hosts # Kubernetes-managed hosts file. 127.0.0.1       localhost ::1     localhost ip6-localhost ip6-loopback fe00::0 ip6-localnet fe00::0 ip6-mcastprefix fe00::1 ip6-allnodes fe00::2 ip6-allrouters 10.244.2.29     nginx-deploy-nfs-5c89969cd4-82vjf root@nginx-deploy-nfs-5c89969cd4-82vjf:/# df Filesystem                1K-blocks     Used Available Use% Mounted on overlay                    51142248  6644672  44497576  13% / tmpfs                         65536        0     65536   0% /dev tmpfs                       1940400        0   1940400   0% /sys/fs/cgroup /dev/mapper/VG1-root       51142248  6644672  44497576  13% /etc/hosts shm                           65536        0     65536   0% /dev/shm 10.83.35.69:/data/nginx01  47683072 11531776  36151296  25% /usr/share/nginx/html tmpfs                       1940400       12   1940388   1% /run/secrets/kubernetes.io/serviceaccount tmpfs                       1940400        0   1940400   0% /proc/acpi tmpfs                       1940400        0   1940400   0% /proc/scsi tmpfs                       1940400        0   1940400   0% /sys/firmware root@nginx-deploy-nfs-5c89969cd4-82vjf:/#   [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl exec -it nginx-deploy-nfs-5c89969cd4-pl7jv  /bin/bash root@nginx-deploy-nfs-5c89969cd4-pl7jv:/# cat /etc/hosts # Kubernetes-managed hosts file. 127.0.0.1       localhost ::1     localhost ip6-localhost ip6-loopback fe00::0 ip6-localnet fe00::0 ip6-mcastprefix fe00::1 ip6-allnodes fe00::2 ip6-allrouters 10.244.1.34     nginx-deploy-nfs-5c89969cd4-pl7jv root@nginx-deploy-nfs-5c89969cd4-pl7jv:/usr/share/nginx/html# df Filesystem                1K-blocks     Used Available Use% Mounted on overlay                    51142248  6659992  44482256  14% / tmpfs                         65536        0     65536   0% /dev tmpfs                       1940400        0   1940400   0% /sys/fs/cgroup /dev/mapper/VG1-root       51142248  6659992  44482256  14% /etc/hosts shm                           65536        0     65536   0% /dev/shm 10.83.35.69:/data/nginx01  47683072 11532800  36150272  25% /usr/share/nginx/html tmpfs                       1940400       12   1940388   1% /run/secrets/kubernetes.io/serviceaccount tmpfs                       1940400        0   1940400   0% /proc/acpi tmpfs                       1940400        0   1940400   0% /proc/scsi tmpfs                       1940400        0   1940400   0% /sys/firmware root@nginx-deploy-nfs-5c89969cd4-pl7jv:/usr/share/nginx/html#

三 创建 service   [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# cat  nginx-service-nfs02.yaml apiVersion: v1 kind: Service metadata:   name: nginx-service-nfs02 spec:   type: NodePort   ports:    - protocol: TCP      port: 80      targetPort: 80   selector:     app: nginx-deploy-nfs [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl apply -f  nginx-service-nfs02.yaml service/nginx-service-nfs02 created [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl get service|grep nfs nginx-service-nfs02                  NodePort    10.1.157.40    <none>        80:31850/TCP     45s [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl describe service nginx-service-nfs02 Name:                     nginx-service-nfs02 Namespace:                default Labels:                   <none> Annotations:              kubectl.kubernetes.io/last-applied-configuration:                             {"apiVersion":"v1","kind":"Service","metadata":{"annotations":{},"name":"nginx-service-nfs02","namespace":"default"},"spec":{"ports":[{"po... Selector:                 app=nginx-deploy-nfs Type:                     NodePort IP:                       10.1.157.40 Port:                     <unset>  80/TCP TargetPort:               80/TCP NodePort:                 <unset>  31850/TCP Endpoints:                10.244.1.34:80,10.244.2.29:80 Session Affinity:         None External Traffic Policy:  Cluster Events:                   <none> [root@k8s1 nfs]#   通过ip端口检查map [root@k8s1 nfs]# [root@k8s1 nfs]# netstat -ntlp|grep 31850 tcp6       0      0 :::31850                :::*                    LISTEN      13962/kube-proxy    [root@k8s1 nfs]# [root@k8s1 nfs]#

四 创建 ingress   [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# cat  nginx-ingress-nfs03.yaml apiVersion: v1 kind: List items: - apiVersion: extensions/v1beta1   kind: Ingress   metadata:     name: nginx-ingress-nfs03     namespace: default     annotations:       nginx.ingress.kubernetes.io/rewrite-target: /   spec:     rules:     - host: 07.bqjr.cn       http:         paths:         - path: /           backend:             serviceName: nginx-service-nfs02             servicePort: 80 [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl apply -f  nginx-ingress-nfs03.yaml ingress.extensions/nginx-ingress-nfs03 created [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# [root@k8s1 nfs]# kubectl get ing NAME                                         HOSTS        ADDRESS      PORTS   AGE   nginx-ingress-nfs03                          07.taobao.cn   10.1.69.51   80      37s [root@k8s1 nfs]#
