BP的心得

BP的概念
业务方案实践
数据处理
BP对象的ABAP实现
一些BP相关的方案设计心得

BP的概念

从后勤物流角度来看，后勤主要主数据是客户主数据和供应商主数据。我们在S/4HANA中学到的第一件事是客户 - 供应商集成（CVI），也称为业务合作伙伴（BP)。
在传统SAP ERP中，客户和供应商是作为两个不同的功能存在的。而在SAP S/4 HANA中，将两者统一维护为Business partner。所以传统的ERP系统中的事务代码都将被废弃，在SAP S/4 HANA 中统一通过事务代码BP使用角色的方式来实现的。
所以，传统SAP ERP 用户在转换为SAP S/4 HANA时，是需要对客户和供应商的主数据做调整的。

以上的官方解释。
个人理解就是不管组织还是个人，都是企业的一个伙伴，也就是BP，当与他发生采购业务时，那么就分配采购角色，维护供应商信息；客户同理；类似的还有UKM信贷角色，房地产管理的各类结算单位，零售业务的SITE角色之类。
业务都基于角色开展，BP是统筹的意思。当然非公司的个人也差不多。

业务方案实践

基于以上BP的个人理解，我个人倾向与把BP/客户/供应商的编码统一处理。当然有些升级项目可能旧数据存在两边的冲突，但还是建议变革做统一。
最简化的配置方案如下：
1.BP分组示例规划：

分组	描述
C001	客户分组1
C002	客户分组2
C003	客户分组3
V001	供应商分组1
V002	供应商分组2
V003	供应商分组3

核心点，客户与供应商的分组也是6个组，两边组1 1对应。
当然如果要做一些字段状态组控制或合作伙伴控制，还可以在客户/供应商账户组层配置。

2.号码段规划如下：
客户/供应商全部一个号码段，号码段为1-ZZZZZZZZZZ，所有的客户/供应商账户组都对应这个无意义的全号分组。

在BP层对BP的分组进行号码段规划，设置合适的编号范围。

在配置跨应用组件->主数据同步->客户/供应商集成->业务伙伴设置->供应商集成的设置->供应商集成的字段分配->分配键值->定义方向业务伙伴到供应商的编号分配
设置供应商账户组与BP分组的关系，1比1就OK，同时配置相同号码。
客户类似。

实现业务规则就是建BP统一的跨模块的方案，不论是供应商偶尔有销售也许需要扩客户，还是反过来，都可以用统一的BP编码扩充对应角色。

基于这样，才能发挥BP集成角色的意义。

**当然系统支持BP角色与供应商/客户有不同的编码。**那么结果就是BP是多余的，客户供应商还分属不同领域。也就没有BP存在的意义，仅仅是系统要求的。这样不符合BP设计的初衷，不建议。

数据处理

在做批量数据处理时，其实传统的LSMW录屏/MASS批修改还是可以使用的。但是录屏体验其实比较差。
这里如果做期初的数据批处理，如果没有ABAP开发独立程序，建议使用LTMC新功能，用WEB端实现导入。
网上文档有一些，晚点在整理。
关于ABAP实现，下一部分。

BP对象的ABAP实现

目前没发现SAP有对BP的BAPI或者EDI接口，过去客户/供应商的方式基本也无法使用了。
很多项目还是需要这方面的接口，批处理程序，甚至自定义的维护界面，系统内审批功能生效等等业务需求。
下面部分贴些BP处理的代码仅供参考。

1.用到的类型对象

  DATA:
    lt_data           TYPE cvis_ei_extern_t
  , ls_data           TYPE cvis_ei_extern
  , ls_address_help   TYPE bus_ei_bupa_address
  , ls_address_usages TYPE bus_ei_bupa_addressusage
  , ls_vend_company   TYPE vmds_ei_company
  , ls_with_tax       TYPE vmds_ei_wtax_type
  , ls_role           TYPE bus_ei_bupa_roles
  , lt_return2        TYPE TABLE OF bapiret2
  .
    DATA: lv_guid    TYPE bu_partner_guid.
      DATA:
    ls_return        TYPE cvis_bp_return,
    lv_task          TYPE c,  " I新建  U 更新
    lv_task_v        TYPE c, " 供应商逻辑处理
    lv_task_c        TYPE c, " 客户逻辑处理
    ls_but000        TYPE but000,
    ls_kna1          TYPE kna1,
    ls_lfa1          TYPE lfa1,
    ls_alv           TYPE zscmt0001,
    lt_bapiret2      TYPE TABLE OF bapiret2,
    ls_bapiret2      TYPE bapiret2,
    lv_bp            TYPE bu_partner,
    lv_create_applog TYPE boolean.

2.BP维护主题流程```

*—判断创建还是修改
	    "信贷限额
	  SELECT SINGLE * INTO ls_but000
   		 FROM but000 WHERE partner = cs_data-partner.
   		   IF sy-subrc = 0.
   		       lv_task = 'U'.
		  ELSE.
		    lv_task = 'I'.
		  ENDIF.

  lv_bp = cs_data-partner.
*--- 清空全局参数
  CALL FUNCTION 'BUP_MEMORY_CENTRAL_INIT'.
*--- 生成或者获取全局GUID
  CASE lv_task.
    WHEN 'I'.
      CALL FUNCTION 'GUID_CREATE'
        IMPORTING
          ev_guid_32 = ls_data-partner-header-object_instance-bpartnerguid.
    WHEN 'U'.
      SELECT SINGLE partner_guid
      FROM but000
      INTO lv_guid
      WHERE partner = lv_bp.
      ls_data-partner-header-object_instance-bpartnerguid = lv_guid.
      ls_data-partner-header-object_instance-bpartner = lv_bp.
    WHEN OTHERS.
      ENDCASE.


 ls_data-partner-header-object_task = lv_task.

  "BP 角色
  PERFORM f_add_role     USING lv_bp
                               cs_data
                      CHANGING ls_data.

  "基本视图
  PERFORM f_add_bp_general USING    lv_bp
                                    lv_task
                                    cs_data
                           CHANGING ls_data.

  "一般地址信息/电话 /传真/邮箱
  PERFORM f_add_bp_address USING    lv_bp
                                    lv_task
                                    cs_data
                           CHANGING ls_data.

  "银行信息
  PERFORM F_BANK_ACC USING   LV_BP
                            CS_DATA
                   CHANGING LS_DATA.

  "供应商信息
  PERFORM f_add_sup_general USING   lv_bp
                                    lv_task
                                    cs_data
                           CHANGING ls_data.

  "客户信息
  PERFORM f_add_cust_general USING lv_bp
                                   lv_task
                                   cs_data
                         CHANGING  ls_data.

  "信贷限额
  PERFORM f_add_ukm_general USING lv_bp
                                   lv_task
                                   cs_data
                         CHANGING  ls_data.
  "整合处理
 IF lv_task = 'I'.
    IF lv_task_v = 'X'.
      SELECT COUNT(*) FROM lfa1 WHERE lifnr = lv_bp.
      IF sy-subrc <> 0.
        ls_data-ensure_create-create_vendor   = abap_true.
      ENDIF.
    ENDIF.
    IF lv_task_c = 'X'.
      SELECT COUNT(*) FROM kna1 WHERE kunnr = lv_bp.
      IF sy-subrc <> 0.
        ls_data-ensure_create-create_customer = abap_true.
      ENDIF.
    ENDIF.
  ENDIF.

  APPEND ls_data TO lt_data.

  "全局数据校验
  cl_md_bp_maintain=>validate_single(
    EXPORTING i_data = ls_data
    IMPORTING et_return_map = DATA(lt_return_map) ).
  "数据校验消息处理
  LOOP AT lt_return_map ASSIGNING FIELD-SYMBOL(<ls_return_map>)
    WHERE type = 'E' OR  type = 'A'.
    MOVE-CORRESPONDING <ls_return_map> TO et_return.
    APPEND et_return.
    ev_status = 'E'.
  ENDLOOP.

  "数据提交处理
  IF ev_status = 'E'.
    RETURN.
  ELSE.
    cl_md_bp_maintain=>maintain(
      EXPORTING i_data = lt_data
      IMPORTING e_return = DATA(lt_return) ).
  ENDIF.

3.角色信息

FORM f_add_role  USING
                        u_bp  TYPE char10
                        u_alv TYPE zscmt0001
               CHANGING
                        c_data TYPE cvis_ei_extern.


  DATA: lt_but100 TYPE TABLE OF but100,
        ls_but100 TYPE but100,
        lt_roles  TYPE bus_ei_bupa_roles_t,
        ls_roles  TYPE bus_ei_bupa_roles.

  SELECT *
   INTO TABLE lt_but100
   FROM but100
   WHERE partner = u_bp.

  "财务供应商角色
  READ TABLE lt_but100 INTO ls_but100 WITH KEY partner = u_bp
                                               rltyp   = 'FLVN00'.
  IF sy-subrc <> 0.
    IF u_alv-flvn00 = 'X'.
      CLEAR ls_roles.
      ls_roles-task             = 'I'.
      ls_roles-data_key         = 'FLVN00'.
      ls_roles-data-valid_from  = sy-datum      .
      ls_roles-data-valid_to    = '99991231'    .
      APPEND ls_roles TO lt_roles.
    ENDIF.
  ENDIF.

  "财务客户角色
  READ TABLE lt_but100 INTO ls_but100 WITH KEY partner = u_bp
                                               rltyp   = 'FLCU00'.
  IF sy-subrc <> 0.
    IF u_alv-flcu00 = 'X'.
      CLEAR ls_roles.
      ls_roles-task             = 'I'.
      ls_roles-data_key         = 'FLCU00'.
      ls_roles-data-valid_from  = sy-datum      .
      ls_roles-data-valid_to    = '99991231'    .
      APPEND ls_roles TO lt_roles.
    ENDIF.
  ENDIF.


  "客户角色
  READ TABLE lt_but100 INTO ls_but100 WITH KEY partner = u_bp
                                               rltyp   = 'FLCU01'.
  IF sy-subrc <> 0.
    IF u_alv-flcu01 = 'X' .
      CLEAR ls_roles.
      ls_roles-task             = 'I'.
      ls_roles-data_key         = 'FLCU01'.
      ls_roles-data-valid_from  = sy-datum      .
      ls_roles-data-valid_to    = '99991231'    .
      APPEND ls_roles TO lt_roles.
    ENDIF.
  ENDIF.

  "采购角色

  READ TABLE lt_but100 INTO ls_but100 WITH KEY partner = u_bp
                                           rltyp   = 'FLVN01'.
  IF sy-subrc <> 0 .
    IF u_alv-flvn01 = 'X' .
      CLEAR ls_roles.
      ls_roles-task             = 'I'.
      ls_roles-data_key         = 'FLVN01'.
      ls_roles-data-valid_from  = sy-datum      .
      ls_roles-data-valid_to    = '99991231'    .
      APPEND ls_roles TO lt_roles.
    ENDIF.
  ENDIF.

  "信用角色

  READ TABLE lt_but100 INTO ls_but100 WITH KEY partner = u_bp
                                           rltyp   = 'UKM000'.
  IF sy-subrc <> 0 .
    IF u_alv-fukm000 = 'X' .
      CLEAR ls_roles.
      ls_roles-task             = 'I'.
      ls_roles-data_key         = 'UKM000'.
      ls_roles-data-valid_from  = sy-datum      .
      ls_roles-data-valid_to    = '99991231'    .
      APPEND ls_roles TO lt_roles.
    ENDIF.
  ENDIF.

  IF lt_roles IS NOT INITIAL.
    c_data-partner-central_data-role-roles = lt_roles.
  ENDIF.

ENDFORM.

4.BP基本信息

FORM f_add_bp_general  USING
                                u_bp  TYPE char10
                                u_task TYPE char1
                                u_alv TYPE zscmt0001
                       CHANGING c_data TYPE cvis_ei_extern.


  c_data-partner-header-object_instance-bpartner = u_bp.
  c_data-partner-header-object_task = u_task.

  c_data-partner-central_data-common-data-bp_control-category = '2'."类别
  c_data-partner-central_data-common-data-bp_control-grouping = u_alv-bu_group."分组 控制视图 号码段
  c_data-partner-central_data-common-data-bp_centraldata-searchterm1 = u_alv-bu_sort1_txt ."搜索项1
*  c_data-partner-central_data-common-data-bp_centraldata-searchterm2 = u_alv-sortl2 ."名称2 ."搜索项2
  c_data-partner-central_data-common-data-bp_centraldata-partnerlanguage = u_alv-langu ."语言
  c_data-partner-central_data-common-data-bp_centraldata-centralblock = u_alv-zdelete."集中冻结
  c_data-partner-central_data-common-data-bp_organization-name1 = u_alv-name1."'  ."名称1
  c_data-partner-central_data-common-data-bp_organization-name2 = u_alv-name2 ."名称2
* c_data-partner-central_data-common-data-bp_organization-name3 = u_alv-name3 ."名称3

  IF u_task = 'U' .
    c_data-partner-central_data-common-datax-bp_centraldata-searchterm1 = abap_true ."搜索项1
*    c_data-partner-central_data-common-datax-bp_centraldata-searchterm2 = abap_true ."名称2 ."搜索项2
    c_data-partner-central_data-common-datax-bp_centraldata-partnerlanguage = abap_true .
    c_data-partner-central_data-common-datax-bp_centraldata-centralblock = abap_true.
    c_data-partner-central_data-common-datax-bp_organization-name1 = abap_true.
    c_data-partner-central_data-common-datax-bp_organization-name2 = abap_true ."名称2
*    c_data-partner-central_data-common-datax-bp_organization-name3 = abap_true ."名称3
  ENDIF.

ENDFORM.

5.BP地址信息

FORM f_add_bp_address  USING    u_bp TYPE char10
                                 u_task TYPE char1
                                u_alv TYPE zscmt0001
                       CHANGING c_data TYPE cvis_ei_extern.

  DATA:
    lv_guid           TYPE bu_partner_guid,
    ls_but000         TYPE but000,
    ls_address_help   TYPE bus_ei_bupa_address,
    ls_address_usages TYPE bus_ei_bupa_addressusage,
    ls_phone          TYPE bus_ei_bupa_telephone,
    lt_phone          TYPE bus_ei_bupa_telephone_t,
    ls_fax            TYPE bus_ei_bupa_fax,
    lt_fax            TYPE bus_ei_bupa_fax_t,
    ls_smtp           TYPE bus_ei_bupa_smtp,
    lt_smtp           TYPE bus_ei_bupa_smtp_t.

  ls_address_help-task = u_task.

  CLEAR lv_guid.
  CASE u_task.
    WHEN 'U'.
      SELECT SINGLE address_guid
      FROM but020
      INTO lv_guid
      WHERE partner = u_bp.

      ls_address_help-data_key-guid = lv_guid.
    WHEN 'I'.
      CALL FUNCTION 'GUID_CREATE'
        IMPORTING
          ev_guid_32 = ls_address_help-data_key-guid.
    WHEN OTHERS.
  ENDCASE.


  ls_address_help-task          = u_task.
  ls_address_help-data-postal-data-city             = u_alv-zshi  ."城市
  ls_address_help-data-postal-data-standardaddress  = 'X'.
  ls_address_help-data-postal-data-postl_cod1       = u_alv-post_code1."邮政编码/城市
  ls_address_help-data-postal-data-street           = u_alv-zdizhi.
*  LS_ADDRESS_HELP-DATA-POSTAL-DATA-HOUSE_NO         = U_ALV-HSNM1   ."门牌号
  ls_address_help-data-postal-data-country          = u_alv-country ."国家
  ls_address_help-data-postal-data-countryiso       = u_alv-country ."国家
*  LS_ADDRESS_HELP-DATA-POSTAL-DATA-REGION           = U_ALV-REGIO   ."地区
  ls_address_help-data-postal-data-time_zone        = 'UTC+8'        ."defalut
  ls_address_help-data-postal-data-langu            = u_alv-langu       ."语言
  ls_address_help-data-postal-data-languiso         = u_alv-langu       ."语言
*  IF U_ALV-POBXCTY IS NOT INITIAL.
*    LS_ADDRESS_HELP-DATA-POSTAL-DATA-POBOX_CTRY = U_ALV-POBXCTY."通讯国家
*    LS_ADDRESS_HELP-DATA-POSTAL-DATA-PO_BOX_REG = U_ALV-POBXREG."通讯地区
*    LS_ADDRESS_HELP-DATA-POSTAL-DATA-POSTL_COD2 = U_ALV-PSTCD2."通讯邮编
*    LS_ADDRESS_HELP-DATA-POSTAL-DATA-PO_BOX_CIT = U_ALV-POBXLOC."通讯城市
*  ENDIF.

  IF u_task = 'U'.
    ls_address_help-data-postal-datax-city             = abap_true.
    ls_address_help-data-postal-datax-standardaddress  = abap_true.
    ls_address_help-data-postal-datax-postl_cod1       = abap_true.
    ls_address_help-data-postal-datax-street           = abap_true.
*    LS_ADDRESS_HELP-DATA-POSTAL-DATAX-HOUSE_NO         = ABAP_TRUE.
    ls_address_help-data-postal-datax-country          = abap_true.
    ls_address_help-data-postal-datax-countryiso       = abap_true.
*    LS_ADDRESS_HELP-DATA-POSTAL-DATAX-REGION           = ABAP_TRUE.
    ls_address_help-data-postal-datax-time_zone        = abap_true.
    ls_address_help-data-postal-datax-langu            = abap_true.
    ls_address_help-data-postal-datax-langu_iso        = abap_true.
*    IF U_ALV-POBXCTY IS NOT INITIAL.
*      LS_ADDRESS_HELP-DATA-POSTAL-DATAX-POBOX_CTRY = ABAP_TRUE.
*      LS_ADDRESS_HELP-DATA-POSTAL-DATAX-PO_BOX_REG = ABAP_TRUE.
*      LS_ADDRESS_HELP-DATA-POSTAL-DATAX-POSTL_COD2 = ABAP_TRUE.
*      LS_ADDRESS_HELP-DATA-POSTAL-DATAX-PO_BOX_CIT = ABAP_TRUE.
*    ENDIF.
  ENDIF.



  APPEND ls_address_help TO c_data-partner-central_data-address-addresses.

ENDFORM.

6.供应商信息

FORM f_add_sup_general  USING    u_bp TYPE char10
                                 u_task TYPE c
                                 u_alv TYPE zscmt0001
                        CHANGING c_data TYPE cvis_ei_extern.

  DATA: lt_company    TYPE vmds_ei_company_t,
        ls_company    TYPE vmds_ei_company,
        lt_purchasing TYPE vmds_ei_purchasing_t,
        ls_purchasing TYPE vmds_ei_purchasing,
        lt_functions  TYPE vmds_ei_functions_t.


  "供应商基本数据
  IF u_alv-flvn00 = 'X' OR  u_alv-flvn01 = 'X'.

    SELECT SINGLE *
     INTO @DATA(ls_lfa1)
     FROM lfa1
     WHERE lifnr = @u_alv-partner.

    IF sy-subrc EQ 0.
      c_data-vendor-header-object_instance-lifnr = u_bp.
      c_data-vendor-header-object_task = 'U'.
      IF u_alv-bu_group = 'A001'.
        c_data-vendor-central_data-central-datax-vbund = abap_true.
      ENDIF.
*      C_DATA-VENDOR-CENTRAL_DATA-CENTRAL-DATAX-STENR  =  ABAP_TRUE."税号
*      C_DATA-VENDOR-CENTRAL_DATA-CENTRAL-DATAX-STCEG  =  ABAP_TRUE."增值税登记号  20位
*      C_DATA-VENDOR-CENTRAL_DATA-CENTRAL-DATAX-FITYP  =  ABAP_TRUE."税收类型
*      C_DATA-VENDOR-CENTRAL_DATA-CENTRAL-DATAX-STCDT  =  ABAP_TRUE."税号类型\
    ELSE.

      c_data-vendor-header-object_task = 'I'.
      IF u_alv-bu_group = 'A001'.
        c_data-vendor-central_data-central-data-vbund   =  u_alv-partner+4(6)."贸易伙伴
      ENDIF.
    ENDIF.
*

*    C_DATA-VENDOR-CENTRAL_DATA-CENTRAL-DATA-STCEG   =  U_ALV-STCEG."增值税登记号  20位
*    C_DATA-VENDOR-CENTRAL_DATA-CENTRAL-DATA-FITYP   =  U_ALV-AFITP."税收类型
*    C_DATA-VENDOR-CENTRAL_DATA-CENTRAL-DATA-STCDT   =  U_ALV-ATOID."税号类型
  ENDIF.


  " 供应商公司数据
  IF u_alv-flvn00 = 'X'.
    SELECT SINGLE *
     INTO @DATA(ls_lfb1)
     FROM lfb1
     WHERE lifnr = @u_alv-partner
       AND bukrs = @u_alv-bukrs.
    IF sy-subrc = 0.
      ls_company-task           =  'U'.
      ls_company-datax-akont    =  abap_true."统御科目
      ls_company-datax-zterm    =  abap_true."付款条件
*      LS_COMPANY-DATAX-SPERR    =  ABAP_TRUE."所选公司代码 过账冻结
*      LS_COMPANY-DATAX-GUZTE    =  ABAP_TRUE."信用记录条件
*      LS_COMPANY-DATAX-ALTKN    =  ABAP_TRUE."先前的账户号
*      LS_COMPANY-DATAX-ZWELS    =  ABAP_TRUE."付款方式
    ELSE.
      ls_company-task          =  'I'.
    ENDIF.

    ls_company-data_key      =  u_alv-bukrs.
    ls_company-data-akont    =  u_alv-akont_ven."统御科目
    ls_company-data-zterm    =  u_alv-zterm_ven."付款条件
*    LS_COMPANY-DATA-SPERR    =  U_ALV-SPERB_B."所选公司代码 过账冻结
*    LS_COMPANY-DATA-GUZTE    =  U_ALV-GUZTE."信用记录条件
*    LS_COMPANY-DATA-ALTKN    =  U_ALV-ALTKN."先前的账户号
*    LS_COMPANY-DATA-ZWELS    =  U_ALV-ZWELS."付款方式
    APPEND ls_company TO lt_company.
    c_data-vendor-company_data-company = lt_company.
  ENDIF.


  "供应商采购数据
  IF u_alv-flvn01 = 'X'.
    SELECT SINGLE *
    INTO @DATA(ls_lfm1)
    FROM lfm1
    WHERE lifnr = @u_bp
      AND ekorg = @u_alv-ekorg.
    IF sy-subrc = 0.
      ls_purchasing-task   = 'U'.
      ls_purchasing-datax-waers   = abap_true. "货币.
      ls_purchasing-datax-kalsk   = abap_true. "方案组.
*      LS_PURCHASING-DATAX-LFABC   = ABAP_TRUE. "供应商等级
      ls_purchasing-datax-webre   = abap_true. "基于收货的发票验证
*      LS_PURCHASING-DATAX-SPERM   = ABAP_TRUE. "采购冻结在采购组
    ELSE.
      ls_purchasing-task   = 'I'.
      PERFORM f_add_sup_purch_functions USING   u_alv  " 供应商合作伙伴功能
                                       CHANGING lt_functions.
      IF lt_functions IS NOT INITIAL.
        ls_purchasing-functions-functions = lt_functions.
      ENDIF.
    ENDIF.

    ls_purchasing-data_key     = u_alv-ekorg.
    ls_purchasing-data-waers   = u_alv-waers. "货币.
    ls_purchasing-data-kalsk   = u_alv-kalsk. "方案组.
*    LS_PURCHASING-DATA-LFABC   = U_ALV-LFABC. "供应商等级
    ls_purchasing-data-webre   = u_alv-webre. "基于收货的发票验证
*    LS_PURCHASING-DATA-SPERM   = U_ALV-SPERM_M. "采购冻结在采购组
    APPEND ls_purchasing TO  lt_purchasing.
    c_data-vendor-purchasing_data-purchasing = lt_purchasing.
  ENDIF.

ENDFORM.

7.客户信息

FORM f_add_cust_general  USING
                                   u_bp TYPE char10
                                   u_task TYPE c
                                   u_alv TYPE zscmt0001
                          CHANGING c_data TYPE cvis_ei_extern.


  DATA: lt_company   TYPE cmds_ei_company_t,
        ls_company   TYPE cmds_ei_company,
        lt_sales     TYPE cmds_ei_sales_t,
        ls_sales     TYPE cmds_ei_sales,
        lt_texts     TYPE cvis_ei_text_t,
        ls_texts     TYPE cvis_ei_text,
        lt_functions TYPE cmds_ei_functions_t,
        lt_tax       TYPE cmds_ei_tax_ind_t.




  "客户销售组织数据
  IF u_alv-flcu01 = 'X' OR u_alv-flcu00 = 'X'.
    SELECT SINGLE *
      INTO @DATA(ls_kna1)
      FROM kna1
      WHERE kunnr = @u_bp.
    IF sy-subrc EQ 0.
      c_data-customer-header-object_instance-kunnr = u_bp.
      c_data-customer-header-object_task = 'U'.
*      IF u_alv-bu_group = 'A001'.
*        c_data-customer-central_data-central-datax-vbund   =  'X'."贸易伙伴
*      ENDIF.
    ELSE.
      c_data-customer-header-object_task = 'I'.
      c_data-customer-header-object_instance-kunnr = u_bp.
*      IF u_alv-bu_group = 'A001'.
*        c_data-customer-central_data-central-data-vbund   =  u_alv-partner+4(6)."贸易伙伴
*      ENDIF.

    ENDIF.

    IF u_alv-flcu01 = 'X'.


      SELECT SINGLE *
      INTO @DATA(ls_knvv)
      FROM knvv
      WHERE kunnr = @u_bp
        AND vkorg = @u_alv-vkorg
        AND vtweg = @u_alv-vtweg
        AND spart = @u_alv-spart.

      IF sy-subrc = 0.
        ls_sales-task = 'U'.
*      ls_sales-datax-kdgrp      = abap_true."运营方式
        ls_sales-datax-kalks      = abap_true."定价过程
        ls_sales-datax-konda      = abap_true."客户定价组
        ls_sales-datax-bzirk      = abap_true."销售地区
        ls_sales-datax-waers      = abap_true."币种
        ls_sales-datax-vsbed      = abap_true."装运条件
        ls_sales-datax-kkber      = abap_true."信控范围
        ls_sales-datax-vwerk      = abap_true."交货工厂
*        ls_sales-datax-ktgrd      = abap_true."账户分配组
*      ls_sales-datax-aufsd      = abap_true."冻结
*      ls_sales-datax-lifsd      = abap_true."
*      ls_sales-datax-faksd      = abap_true."
      ELSE.
        ls_sales-task = 'I'.
        PERFORM f_add_sale_functions USING      u_alv  " 客户伙伴功能
                                     CHANGING   lt_functions.
        IF lt_functions IS NOT INITIAL.
          ls_sales-functions-functions = lt_functions.
        ENDIF.
      ENDIF.

      ls_sales-data_key-vkorg   = u_alv-vkorg.
      ls_sales-data_key-vtweg   = u_alv-vtweg.
      ls_sales-data_key-spart   = u_alv-spart..
*    ls_sales-data-kdgrp       = u_alv-kdgrp."运营方式
      ls_sales-data-kalks       = u_alv-kalks."定价过程
      ls_sales-data-konda       = u_alv-konda."客户定价组
      ls_sales-data-bzirk       = u_alv-bzirk."销售地区
      ls_sales-data-waers       = u_alv-waers."币种
      ls_sales-data-vsbed       = u_alv-vsbed."装运条件
      ls_sales-data-kkber       = u_alv-kkber."信控范围
      ls_sales-data-vwerk       = u_alv-werks."交货工厂
      ls_sales-data-ktgrd       = u_alv-ktgrd."账户分配组

*    ls_sales-data-aufsd       = u_alv-aufsd."冻结
*    ls_sales-data-lifsd       = u_alv-lifsd."
*    ls_sales-data-faksd       = u_alv-faksd."
      APPEND ls_sales TO lt_sales.
      c_data-customer-sales_data-sales = lt_sales.
    ENDIF.


    " 客户公司代码
    IF  u_alv-flcu00 = 'X' .
      SELECT SINGLE *
       INTO @DATA(ls_knb1)
       FROM knb1
       WHERE kunnr = @u_bp
         AND bukrs = @u_alv-bukrs.
      IF sy-subrc = 0.
        ls_company-task          =  'U'.
        ls_company-datax-akont    =  abap_true."统御科目
        ls_company-datax-zterm    =  abap_true."付款条件
*      ls_company-datax-sperr    =  abap_true."所选公司代码 过账冻结
      ELSE.
        ls_company-task          =  'I'.
      ENDIF.

      ls_company-data_key      =  u_alv-bukrs.
      ls_company-data-akont    =  u_alv-akont_cus."统御科目
      ls_company-data-zterm    =  u_alv-zterm_cus."付款条件
*    ls_company-data-sperr    =  u_alv-sperb_b_k."所选公司代码 过账冻结

      APPEND ls_company TO lt_company.
      c_data-customer-company_data-company = lt_company.


      PERFORM f_add_sale_tax_typ USING      u_alv  " 客户伙伴功能
                                           u_bp
                               CHANGING   lt_tax.

      c_data-customer-central_data-tax_ind-tax_ind = lt_tax.

    ENDIF.

  ENDIF.
ENDFORM.

合作伙伴信息：

FORM f_add_sale_functions  USING   u_alv   TYPE zscmt0001
                         CHANGING  ct_functions TYPE  cmds_ei_functions_t.

  DATA: ls_knvp                 TYPE knvp,
        ls_functions            TYPE cmds_ei_functions,
        ls_cust_sales_functions TYPE cvis_customer_sales_func.
  DATA: lv_part_up TYPE zscmt0010-partner.

  CALL METHOD cvi_default_values_classic=>get_default_cust_functions
    EXPORTING
      i_account_group  = u_alv-bu_group "账户组
    RECEIVING
      r_functions_list = DATA(lt_partner_function).

  IF u_alv-zydc_sc_no IS NOT INITIAL.
    lv_part_up = u_alv-zydc_sc_no.
    SELECT SINGLE * FROM zscmt0010 INTO @DATA(ls_0010)
     WHERE partner = @lv_part_up."店中店上上级
    IF ls_0010-bu_group = 'K006' AND ls_0010-zydc_sc_no IS NOT INITIAL.
      lv_part_up = ls_0010-zydc_sc_no.
    ENDIF.
  ENDIF.


  LOOP AT lt_partner_function INTO ls_knvp.
    ls_functions-task = 'I'.
    ls_functions-data_key-parvw = ls_knvp-parvw.
    ls_functions-data_key-parza = ls_knvp-parza.
*    LS_FUNCTIONS-DATA-PARTNER = LS_KNVP-PARNR.
    ls_functions-data-defpa = ls_knvp-defpa.
    ls_functions-data-knref = ls_knvp-knref.

    IF lv_part_up IS NOT INITIAL.
      IF ls_functions-data_key-parvw = 'RE' OR ls_functions-data_key-parvw = 'RG' .
        ls_functions-data-partner = lv_part_up.
*     ELSE.
*        ls_functions-data-partner = u_alv-partner.
      ENDIF.
*    ELSE.
*      ls_functions-data-partner = u_alv-partner.
    ENDIF.

    APPEND ls_functions TO ct_functions.
    CLEAR:ls_functions.
  ENDLOOP.

ENDFORM.

税分类信息


FORM f_add_sale_tax_typ USING   u_alv   TYPE zscmt0001
                                u_bp    TYPE char10
                         CHANGING  ct_tax TYPE  cmds_ei_tax_ind_t.

  DATA: ls_knvi               TYPE knvi,
        ls_area               TYPE cvis_sales_area,
        ls_cust_sales_tax_typ TYPE cvis_customer_sales_func,
        lt_knvi               TYPE TABLE OF knvi,
        ls_tax                TYPE cmds_ei_tax_ind.


  SELECT *
    INTO TABLE lt_knvi
    FROM knvi
    WHERE kunnr = u_bp.

  ls_area-sales_org    = u_alv-vkorg.
  ls_area-dist_channel = u_alv-vtweg.
  ls_area-division     = u_alv-spart.


  CALL METHOD cvi_default_values_classic=>get_default_cust_tax_inds
    EXPORTING
      i_sales_area     = ls_area "账户组
    RECEIVING
      r_tax_indicators = DATA(lt_partner_tax_typ).


  LOOP AT lt_partner_tax_typ INTO DATA(ls_partner_tax_typ).
    READ TABLE lt_knvi INTO ls_knvi WITH KEY aland = ls_partner_tax_typ-aland
                                             tatyp = ls_partner_tax_typ-tatyp.
    IF sy-subrc = 0.
      ls_tax-task = 'U'.
      ls_tax-data-taxkd     = u_alv-taxkd.
      ls_tax-datax-taxkd    = abap_true.
      DELETE lt_knvi WHERE aland = ls_partner_tax_typ-aland AND
                           tatyp = ls_partner_tax_typ-tatyp.
    ELSE.
      ls_tax-task = 'I'.
    ENDIF.
    ls_tax-data-taxkd     = u_alv-taxkd.
    ls_tax-data_key-aland = ls_partner_tax_typ-aland.
    ls_tax-data_key-tatyp = ls_partner_tax_typ-tatyp.
    APPEND ls_tax TO ct_tax.
    CLEAR ls_tax.
  ENDLOOP.

  LOOP AT lt_knvi INTO ls_knvi.
    ls_tax-task = 'D'.
    ls_tax-data-taxkd     = ls_knvi-taxkd.
    ls_tax-data_key-aland = ls_knvi-aland.
    ls_tax-data_key-tatyp = ls_knvi-tatyp.
    APPEND ls_tax TO ct_tax.
    CLEAR ls_tax.
  ENDLOOP.



ENDFORM.

信贷限额信息


FORM f_add_ukm_general USING
                             u_bp TYPE char10
                             u_task TYPE c
                             u_alv TYPE zscmt0001
                    CHANGING c_data TYPE cvis_ei_extern.

  DATA:ls_profile  TYPE ukm_ei_bp_cms.
  DATA:lt_segments TYPE ukmt_ei_bp_cms_sgm.
  DATA:ls_segments TYPE ukm_ei_bp_cms_sgm.

  IF u_alv-fukm000 = 'X' AND u_task = 'I'.

    ls_profile-data-check_rule = '01'.
    ls_profile-data-limit_rule = 'B2B-EXIST'.
    ls_profile-data-risk_class = 'A'.
    ls_profile-data-credit_group = '0001'.

    ls_profile-datax-check_rule = 'X'.
    ls_profile-datax-limit_rule = 'X'.
    ls_profile-datax-risk_class = 'X'.
    ls_profile-datax-credit_group = 'X'.

    c_data-partner-ukmbp_data-profile = ls_profile.


*    IF u_alv-credit > 0.
    ls_segments-task = u_task.

    ls_segments-data_key-partner = u_bp.
    ls_segments-data_key-credit_sgmnt = 'Z001'.

    ls_segments-data-credit_limit = u_alv-credit.
    ls_segments-data-limit_valid_date = '99991231'.

    APPEND ls_segments TO lt_segments.


    c_data-partner-ukmbp_data-segments-segments = lt_segments.
*    ENDIF.

  ENDIF.

ENDFORM.
