### 后端实现 (Spring Boot)
#### 项目结构
```
src/
├── main/
│ ├── java/com/watermark/
│ │ ├── config/ # 配置类
│ │ ├── controller/ # 控制器
│ │ ├── entity/ # 实体类
│ │ ├── repository/ # 数据访问层
│ │ ├── service/ # 服务层
│ │ ├── util/ # 工具类
│ │ └── Application.java
│ ├── resources/
│ │ ├── application.yml
│ │ └── wxpay/ # 微信支付证书
└── test/...
```
#### 核心代码
1. **实体类 (Entity)**
```java
// User.java
@Entity
@Table(name = "users")
public class User {
@Id
@GeneratedValue(strategy = GenerationType.IDENTITY)
private Long id;
@Column(unique = true, nullable = false)
private String openid; // 微信openid
@Column(nullable = false)
private String nickname;
private String avatar; // 头像URL
@Column(name = "register_time", nullable = false)
private LocalDateTime registerTime;
@Column(name = "is_vip", nullable = false)
private Boolean isVip = false;
@Column(name = "vip_expire")
private LocalDateTime vipExpire;
// Getters & Setters
}
// ParseRecord.java
@Entity
@Table(name = "parse_records")
public class ParseRecord {
@Id
@GeneratedValue(strategy = GenerationType.IDENTITY)
private Long id;
@ManyToOne
@JoinColumn(name = "user_id", nullable = false)
private User user;
@Column(name = "original_url", nullable = false, length = 1000)
private String originalUrl;
@Column(name = "result_url", length = 1000)
private String resultUrl;
@Column(name = "parse_time", nullable = false)
private LocalDateTime parseTime;
// Getters & Setters
}
// Banner.java
@Entity
@Table(name = "banners")
public class Banner {
@Id
@GeneratedValue(strategy = GenerationType.IDENTITY)
private Long id;
@Column(nullable = false)
private String imageUrl;
@Column
private String linkUrl;
@Column(nullable = false)
private Integer sortOrder = 0;
@Column(nullable = false)
private Boolean active = true;
// Getters & Setters
}
// PaymentOrder.java
@Entity
@Table(name = "payment_orders")
public class PaymentOrder {
@Id
private String orderId; // 商户订单号
@ManyToOne
@JoinColumn(name = "user_id", nullable = false)
private User user;
@Column(nullable = false)
private Integer amount; // 金额(分)
@Column(nullable = false)
private String status = "CREATED"; // CREATED/SUCCESS/FAILED
@Column(name = "create_time", nullable = false)
private LocalDateTime createTime;
@Column(name = "pay_time")
private LocalDateTime payTime;
// Getters & Setters
}
```
2. **微信支付服务**
```java
// WxPayService.java
@Service
public class WxPayService {
@Value("${wxpay.appId}")
private String appId;
@Value("${wxpay.mchId}")
private String mchId;
@Value("${wxpay.mchKey}")
private String mchKey;
@Value("${wxpay.notifyUrl}")
private String notifyUrl;
public Map<String, String> createOrder(User user, String productName, int amount) {
String orderId = "ORDER" + System.currentTimeMillis() + new Random().nextInt(1000);
Map<String, String> data = new HashMap<>();
data.put("appid", appId);
data.put("mch_id", mchId);
data.put("nonce_str", WxPayUtil.generateNonceStr());
data.put("body", productName);
data.put("out_trade_no", orderId);
data.put("total_fee", String.valueOf(amount));
data.put("spbill_create_ip", "用户IP");
data.put("notify_url", notifyUrl);
data.put("trade_type", "JSAPI");
data.put("openid", user.getOpenid());
try {
// 生成签名
String sign = WxPayUtil.generateSignature(data, mchKey);
data.put("sign", sign);
// 调用统一下单API
String xmlResult = WxPayUtil.requestOnce("https://api.mch.weixin.qq.com/pay/unifiedorder", data);
Map<String, String> result = WxPayUtil.xmlToMap(xmlResult);
if ("SUCCESS".equals(result.get("return_code")) && "SUCCESS".equals(result.get("result_code"))) {
// 返回小程序支付参数
Map<String, String> payParams = new HashMap<>();
payParams.put("appId", appId);
payParams.put("timeStamp", String.valueOf(System.currentTimeMillis() / 1000));
payParams.put("nonceStr", WxPayUtil.generateNonceStr());
payParams.put("package", "prepay_id=" + result.get("prepay_id"));
payParams.put("signType", "MD5");
payParams.put("paySign", WxPayUtil.generateSignature(payParams, mchKey));
return payParams;
}
} catch (Exception e) {
throw new RuntimeException("微信支付下单失败", e);
}
throw new RuntimeException("微信支付下单失败");
}
// 支付回调处理
public String handleNotify(HttpServletRequest request) {
try {
String xmlData = IOUtils.toString(request.getInputStream(), StandardCharsets.UTF_8);
Map<String, String> data = WxPayUtil.xmlToMap(xmlData);
if (WxPayUtil.isSignatureValid(data, mchKey)) {
if ("SUCCESS".equals(data.get("result_code"))) {
// 更新订单状态
paymentOrderService.updateOrderStatus(
data.get("out_trade_no"),
"SUCCESS",
LocalDateTime.now()
);
// 更新用户VIP状态
userService.activateVip(data.get("out_trade_no"));
return "<xml><return_code><![CDATA[SUCCESS]]></return_code></xml>";
}
}
} catch (Exception e) {
// 处理异常
}
return "<xml><return_code><![CDATA[FAIL]]></return_code></xml>";
}
}
```
3. **控制器**
```java
// ParseController.java
@RestController
@RequestMapping("/api/parse")
public class ParseController {
@PostMapping("/process")
public ResponseEntity<ParseResult> processUrl(@RequestBody ParseRequest request) {
// 解析逻辑
ParseResult result = parseService.processUrl(request.getUrl(), request.getUserId());
return ResponseEntity.ok(result);
}
@GetMapping("/history/{userId}")
public ResponseEntity<List<ParseRecord>> getHistory(
@PathVariable Long userId,
@RequestParam(defaultValue = "0") int page,
@RequestParam(defaultValue = "10") int size) {
Page<ParseRecord> records = parseService.getUserRecords(userId, PageRequest.of(page, size));
return ResponseEntity.ok(records.getContent());
}
}
// PaymentController.java
@RestController
@RequestMapping("/api/payment")
public class PaymentController {
@PostMapping("/create")
public ResponseEntity<Map<String, String>> createVipOrder(@RequestBody PaymentRequest request) {
User user = userService.getUserById(request.getUserId());
Map<String, String> payParams = wxPayService.createOrder(
user,
"VIP会员",
request.getAmount()
);
return ResponseEntity.ok(payParams);
}
@PostMapping("/notify")
public String paymentNotify(HttpServletRequest request) {
return wxPayService.handleNotify(request);
}
}
// BannerController.java
@RestController
@RequestMapping("/api/banner")
public class BannerController {
@GetMapping("/active")
public ResponseEntity<List<Banner>> getActiveBanners() {
return ResponseEntity.ok(bannerService.getActiveBanners());
}
@PostMapping
@PreAuthorize("hasRole('ADMIN')")
public ResponseEntity<Banner> createBanner(@RequestBody Banner banner) {
return ResponseEntity.ok(bannerService.saveBanner(banner));
}
}
```
### 前端实现 (Vue3 + HBuilderX)
#### 项目结构
```
src/
├── components/
│ ├── UrlParser.vue
│ ├── BannerSwiper.vue
│ └── VipCard.vue
├── pages/
│ ├── Home.vue
│ ├── My.vue
│ └── History.vue
├── store/
│ ├── index.js
│ └── user.js
├── api/
│ ├── parse.js
│ ├── user.js
│ ├── payment.js
│ └── banner.js
├── App.vue
└── main.js
```
#### 核心页面
1. **首页 (Home.vue)**
```vue
<template>
<div class="home">
<!-- 轮播图 -->
<BannerSwiper :banners="banners" />
<!-- 解析区域 -->
<UrlParser @parse="handleParse" />
<!-- VIP开通提示 -->
<VipCard v-if="!user.isVip" @click="goToVip" />
</div>
</template>
<script>
import { ref, onMounted } from 'vue';
import { useStore } from 'vuex';
import { getActiveBanners } from '@/api/banner';
import BannerSwiper from '@/components/BannerSwiper.vue';
import UrlParser from '@/components/UrlParser.vue';
import VipCard from '@/components/VipCard.vue';
export default {
components: { BannerSwiper, UrlParser, VipCard },
setup() {
const store = useStore();
const banners = ref([]);
const user = ref(store.state.user);
onMounted(async () => {
banners.value = await getActiveBanners();
});
const handleParse = async (url) => {
const result = await parseUrl(url);
// 处理解析结果
};
const goToVip = () => {
// 跳转到VIP开通页面
};
return { banners, user, handleParse, goToVip };
}
};
</script>
```
2. **用户中心 (My.vue)**
```vue
<template>
<div class="my-page">
<div class="user-card">
<img :src="user.avatar" class="avatar" />
<div class="user-info">
<h3>{{ user.nickname }}</h3>
<p>用户ID: {{ user.id }}</p>
<p>解析次数: {{ user.parseCount }}</p>
<p v-if="user.isVip">VIP会员 (有效期至: {{ formatDate(user.vipExpire) }})</p>
<p v-else>普通用户</p>
</div>
</div>
<div class="actions">
<button @click="goToHistory">解析记录</button>
<button v-if="!user.isVip" @click="openVip">开通会员</button>
</div>
</div>
</template>
<script>
import { ref } from 'vue';
import { useStore } from 'vuex';
import { getUserDetail } from '@/api/user';
import { formatDate } from '@/utils/date';
export default {
setup() {
const store = useStore();
const user = ref(store.state.user);
// 获取用户详情
const fetchUserDetail = async () => {
const detail = await getUserDetail(user.value.id);
user.value = { ...user.value, ...detail };
store.commit('setUser', user.value);
};
const openVip = async () => {
// 调用支付接口
const paymentParams = await createVipOrder(29900); // 299元
// 调用微信支付
uni.requestPayment({
...paymentParams,
success: () => {
// 支付成功,更新用户状态
fetchUserDetail();
},
fail: (err) => {
console.error('支付失败', err);
}
});
};
const goToHistory = () => {
uni.navigateTo({ url: '/pages/History' });
};
return { user, formatDate, openVip, goToHistory };
}
};
</script>
```
3. **微信支付工具类 (wxpay.js)**
```javascript
import { createVipOrder } from '@/api/payment';
export const wxPay = {
payForVip: async (amount) => {
try {
const paymentParams = await createVipOrder(amount);
return new Promise((resolve, reject) => {
uni.requestPayment({
...paymentParams,
success: resolve,
fail: reject
});
});
} catch (error) {
console.error('支付创建失败', error);
throw error;
}
}
};
```
### 后台管理系统功能
1. **用户管理**
- 用户ID、昵称、头像
- 注册时间
- VIP状态及有效期
- 解析次数统计
2. **解析记录**
- 原始URL
- 解析结果URL
- 解析时间
- 关联用户
3. **VIP管理**
- 微信支付对接
- 会员状态管理
- 支付订单跟踪
4. **轮播图管理**
- 图片上传
- 链接配置
- 排序控制
- 激活状态
### 部署配置
1. **微信支付配置 (application.yml)**
```yml
wxpay:
appId: wx1234567890abcdef # 小程序APPID
mchId: 1234567890 # 商户号
mchKey: your_mch_key # 商户API密钥
notifyUrl: https://yourdomain.com/api/payment/notify
```
2. **数据库配置**
```sql
CREATE TABLE users (
id BIGINT AUTO_INCREMENT PRIMARY KEY,
openid VARCHAR(100) NOT NULL UNIQUE,
nickname VARCHAR(100) NOT NULL,
avatar VARCHAR(500),
register_time DATETIME NOT NULL,
is_vip BOOLEAN DEFAULT false,
vip_expire DATETIME
);
CREATE TABLE parse_records (
id BIGINT AUTO_INCREMENT PRIMARY KEY,
user_id BIGINT NOT NULL,
original_url VARCHAR(1000) NOT NULL,
result_url VARCHAR(1000),
parse_time DATETIME NOT NULL,
FOREIGN KEY (user_id) REFERENCES users(id)
);
CREATE TABLE banners (
id BIGINT AUTO_INCREMENT PRIMARY KEY,
image_url VARCHAR(500) NOT NULL,
link_url VARCHAR(500),
sort_order INT DEFAULT 0,
active BOOLEAN DEFAULT true
);
CREATE TABLE payment_orders (
order_id VARCHAR(50) PRIMARY KEY,
user_id BIGINT NOT NULL,
amount INT NOT NULL,
status VARCHAR(20) DEFAULT 'CREATED',
create_time DATETIME NOT NULL,
pay_time DATETIME,
FOREIGN KEY (user_id) REFERENCES users(id)
);
```
### 前端转小程序说明
1. 使用HBuilderX的"发行->小程序"功能
2. 配置小程序APPID
3. 替换微信支付相关API调用
4. 调整UI组件适应小程序规范
