Mac下编译Captuocr：mkmf.rb can't find header files for ruby at 错误

编译CaptuocrToy： https://github.com/gragrance/CaptuocrToy

1.运行命令的时候：sudo gem install -n /usr/local/bin cocoapods 报错：mkmf.rb can't find header files for ruby at /System/Library/Frameworks/Ruby.framework/Versions/2.3/usr/lib/ruby/include/ruby.h

参考帖子解决方案：https://stackoverflow.com/questions/20559255/error-while-installing-json-gem-mkmf-rb-cant-find-header-files-for-ruby/35895505

For Xcode 11 on macOS 10.14, this can happen even after installing Xcode and installing command-line tools and accepting the license with

sudo xcode-select --install
sudo xcodebuild -license accept

The issue is that Xcode 11 ships the macOS 10.15 SDK which includes headers for ruby2.6, but not for macOS 10.14's ruby2.3. You can verify that this is your problem by running

ruby -rrbconfig -e 'puts RbConfig::CONFIG["rubyhdrdir"]'

which on macOS 10.14 with Xcode 11 prints the non-existent path

/Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX10.15.sdk/System/Library/Frameworks/Ruby.framework/Versions/2.3/usr/include/ruby-2.3.0

However, Xcode 11 installs a macOS 10.14 SDK within /Library/Developer/CommandLineTools/SDKs/MacOS10.14.sdk. It isn't necessary to pollute the system directories by installing the old header files as suggested in other answers. Instead, by selecting that SDK, the appropriate ruby2.3 headers will be found:

sudo xcode-select --switch /Library/Developer/CommandLineTools
ruby -rrbconfig -e 'puts RbConfig::CONFIG["rubyhdrdir"]'

This should now correctly print

/Library/Developer/CommandLineTools/SDKs/MacOSX10.14.sdk/System/Library/Frameworks/Ruby.framework/Versions/2.3/usr/include/ruby-2.3.0

Likewise, gem install should work while that SDK is selected.

To switch back to the current Xcode SDK, use

sudo xcode-select --switch /Applications/Xcode.app



2. 运行BuildArea/autobuild.sh命令，同样有个错误：

(base) iotlabs-MacBook-Pro:CaptuocrToy iotlab$ BuildArea/autobuild.sh

=== START TO BUILD CAPTUOCR ===

xcode-select: error: tool 'xcodebuild' requires Xcode, but active developer directory '/Library/Developer/CommandLineTools' is a command line tools instance

mv: rename build/Build/Products/Release/Captuocr.app to /Users/iotlab/Documents/Captuocr_20200402_184754.app: No such file or directory



解决：

(base) iotlabs-MacBook-Pro:CaptuocrToy iotlab$ sudo xcode-select -s /Applications/Xcode.app/Contents/Developer
