问题说明：

数据库迁移到新服务器后，某一张视图查询缓慢，原库查询耗时3分钟，新库查询5小时以上。

环境说明：

新库：

DB:Oracle 11.2.0.4.0 RAC
OS:Redhat 7.6

原库：

DB:Oracle 11.2.0.4.0 单机
OS:AIX 5.1

问题分析：

处理此类问题，常见思路如下：
1 分别对比原库和新库该SQL对应的执行计划。
2 对比两个执行计划，找到差异部分或最耗时的部分。
3 分析执行计划差异原因，根据原因尝试解决问题。

本次案例视图引用的SQL使用了28个union all组成，关联了30多张表。

在执行如下SQL时，新库会卡住很久，甚至无法返回结果。

select count(*) from v_cjc_01;

视图内SQL类似如下：

create or replace view v_cjc_01 as
select col1,col2,col3,...col10
  from t1
 where xxx=yyy
union all
select col1,col2,col3,...col10
  from t2
 where zzz=yyy
union all
......
union all
select col1,col2,col3,...col10
  from t3
 where xxx=yyy and col2 not in (select col2 from t3 a where col1=aaa col3=bbb)
union all
select col1,col2,col3,...col10
  from t5
 where ttt=yyy;

查看执行计划，发现主要有两处不同

一：
原执行计划

|* 40 |     HASH JOIN                  |                             | 72408 |  2616K|  2264K| 28026   (1)| 00:05:37 |
|  41 |      VIEW                      | VW_JF_SET$5EF83EA7          | 72408 |  1414K|       |  3028   (1)| 00:00:37 |
|  42 |       UNION-ALL                |                             |       |       |       |            |          |
|* 43 |        TABLE ACCESS FULL       | CJC_T1_00000000000000000    | 72407 |  2050K|       |  1514   (1)| 00:00:19 |
|* 44 |        TABLE ACCESS FULL       | CJC_T1_00000000000000000    |     1 |    29 |       |  1514   (1)| 00:00:19 |
|  45 |      INDEX FAST FULL SCAN      | IDX_MB_ACCINF_ACCNO         |  9179K|   148M|       | 12212   (1)| 00:02:27 |
----------------------------------------------------------------------------------------------------------------------

新执行计划

|  13 |     NESTED LOOPS               |                             |   236 |  9676 |  2003   (1)| 00:00:25 |
|* 14 |      TABLE ACCESS FULL         | CJC_T1_00000000000000000    |   235 |  5640 |  1533   (1)| 00:00:19 |
|* 15 |      INDEX RANGE SCAN          | IDX_MB_ACCINF_ACCNO         |     1 |    17 |     2   (0)| 00:00:01 |
|  16 |     NESTED LOOPS               |                             |     1 |    41 |  1535   (1)| 00:00:19 |
|* 17 |      TABLE ACCESS FULL         | CJC_T1_00000000000000000    |     1 |    24 |  1533   (1)| 00:00:19 |
|* 18 |      INDEX RANGE SCAN          | IDX_MB_ACCINF_ACCNO         |     1 |    17 |     2   (0)| 00:00:01 |

二：

原执行计划

|* 16 |     HASH JOIN RIGHT ANTI NA    |                             |  6647 |  1174K|    12M| 26593   (1)| 00:05:20 |
|* 17 |      TABLE ACCESS FULL         | CJC_T2_00000000000000000    |   130K|    10M|       | 11309   (1)| 00:02:16 |
|* 18 |      TABLE ACCESS FULL         | CJC_T2_00000000000000000    |   664K|    60M|       | 11309   (1)| 00:02:16 |

新执行计划

|* 21 |     FILTER                     |                             |       |       |            |          |
|* 22 |      TABLE ACCESS FULL         | CJC_T2_00000000000000000    |  4928 |   202K| 11126   (1)| 00:02:14 |
|* 23 |      TABLE ACCESS FULL         | CJC_T2_00000000000000000    |     1 |    27 | 11124   (1)| 00:02:14 |

根据第一处不同，可以看到：
原执行计划，出现了VW_JF_SET$5EF83EA7，说明原库使用到了Join Factorization特性，
在该特性下，union all连接各个分支查询SQL时，会将各个分支部分中公共部分单独提出作为一个单独的结果集，
然后在和原union all剩下的部分做关联，从而减少了公共部分表重复扫描的问题，性能会有提升。

为什么新库没有使用到Join Factorization特性呢？

对比两个库的_OPTIMIZER_JOIN_FACTORIZATION参数，都是使用的默认值true。
说明优化器认为新库不适合使用Join Factorization特性。
但是从执行计划看两种表数据量都比较大，结果集也很大，新库使用的NESTED LOOPS明显比原库HASH JOIN性能差。

可以通过10053事件对比查看原库和新库对同一SQL是如何进行改写，如何计算cost的？

原库和新库分别执行：

alter session set tracefile_identifier='10053';
ALTER SESSION SET EVENTS='10053 trace name context forever, level 1';
select count(*) from v_cjc_01;
ALTER SESSION SET EVENTS '10053 trace name context off';
select value from v$diag_info where name='Default Trace File';

查看生成的trace文件：

搜索关键字 Final query after transformations

新库SQL改写部分：

UNION ALL
        (SELECT '0' "KERNAL_INTER4"
           FROM "CHEN"."CJC_T1_00000000000000000" "A",
                CHENPMB."MB_ACCINF"               "B"
          WHERE "B"."AIF_ACCNO" = "A"."CJC_T3_000000"
            AND "A"."MPB_BUSINESSTYPE" = '10'
            AND "A"."MPB_TRANTIME" IS NOT NULL
            AND LENGTH("A"."MPB_TRANTIME") = 14
            AND "A"."MPB_TRANTIME" > '20200501000000') UNION ALL
        (SELECT '0' "KERNAL_INTER4"
           FROM "CHEN"."CJC_T1_00000000000000000" "A",
                CHENPMB."MB_ACCINF"               "B"
          WHERE "B"."AIF_ACCNO" = "A"."CJC_T3_000000"
            AND "A"."MPB_BUSINESSTYPE" = '11'
            AND "A"."MPB_TRANTIME" IS NOT NULL
            AND LENGTH("A"."MPB_TRANTIME") = 14
            AND "A"."MPB_TRANTIME" > '20200501000000')

原库SQL改写部分：

UNION ALL
        (SELECT '0' "KERNAL_INTER4"
           FROM CHENPMB."EA_EACCT_INFO_S" "EA_EACCT_INFO_S"
          WHERE "EA_EACCT_INFO_S"."EA_ACCOUNT_OPEN_RESULT" = '1') UNION ALL
        (SELECT "VW_JF_SET$5EF83EA7"."ITEM_2" "KERNAL_INTER4"
           FROM ((SELECT "A"."CJC_T3_000000" "ITEM_1", '0' "ITEM_2"
                    FROM "CHEN"."CJC_T1_00000000000000000" "A"
                   WHERE "A"."MPB_TRANTIME" > '20200501000000'
                     AND LENGTH("A"."MPB_TRANTIME") = 14
                     AND "A"."MPB_TRANTIME" IS NOT NULL
                     AND "A"."MPB_BUSINESSTYPE" = '10') UNION ALL
                 (SELECT "A"."CJC_T3_000000" "ITEM_1", '0' "ITEM_2"
                    FROM "CHEN"."CJC_T1_00000000000000000" "A"
                   WHERE "A"."MPB_TRANTIME" > '20200501000000'
                     AND LENGTH("A"."MPB_TRANTIME") = 14
                     AND "A"."MPB_TRANTIME" IS NOT NULL
                     AND "A"."MPB_BUSINESSTYPE" = '11')) "VW_JF_SET$5EF83EA7",
                CHENPMB."MB_ACCINF" "B"
          WHERE "B"."AIF_ACCNO" = "VW_JF_SET$5EF83EA7"."ITEM_1")) "MB_YINGXIAO_COUNT1"

尝试按照原库10053转换的SQL改写新库SQL后，执行速度恢复正常，但是SQL改动量较大。

根据第二处不同，可以看到：

改写前原SQL部分：

select CUSTOMERID as CSTNO,
       TRANTIME as TRANTIME,
       '10' as TRANTYPE,
       to_date(TRANTIME, 'yyyymmddhh24miss') as TRANTIME1,
       createtime,
       1 as cnt,
       0 as amt,
       '0' as kernal_inter1,
       '0' as kernal_inter2,
       '0' as kernal_inter3,
       '0' as kernal_inter4
  from CJC_T2_00000000000000000 c
 where c.tranname = 'XX绑定'
   and c.retcode = '0000'
   and c.TRANTIME is not null
   and length(c.TRANTIME) = 14
   and c.TRANTIME > '20200501000000'
   and c.medicalcardno not in
       (select a.medicalcardno
          from CJC_T2_00000000000000000 a
         where a.tranname = 'XX解绑'
           and a.retcode = '0000')

新库SQL改写部分:

SELECT '0' "KERNAL_INTER4"
           FROM CHENPMB."CJC_T2_00000000000000000" "A",
                CHENPMB."CJC_T2_00000000000000000" "C"
          WHERE "C"."TRANNAME" = 'XX绑定'
            AND "C"."RETCODE" = '0000'
            AND "C"."TRANTIME" IS NOT NULL
            AND LENGTH("C"."TRANTIME") = 14
            AND "C"."TRANTIME" > '20200501000000'
            AND "C"."MEDICALCARDNO" = "A"."MEDICALCARDNO"
            AND "A"."TRANNAME" = 'XX解绑'
            AND "A"."RETCODE" = '0000'

原库SQL改写部分:

(SELECT '0' "KERNAL_INTER4"
           FROM CHENPMB."CJC_T2_00000000000000000" "C"
          WHERE "C"."TRANNAME" = 'XX绑定'
            AND "C"."RETCODE" = '0000'
            AND "C"."TRANTIME" IS NOT NULL
            AND LENGTH("C"."TRANTIME") = 14
            AND "C"."TRANTIME" > '20200501000000'
            AND NOT EXISTS
          (SELECT 0
                   FROM CHENPMB."CJC_T2_00000000000000000" "A"
                  WHERE LNNVL("A"."MEDICALCARDNO" <> "C"."MEDICALCARDNO")
                    AND "A"."TRANNAME" = 'XX解绑'
                    AND "A"."RETCODE" = '0000'))

根据执行计划可知，

原库将not in改写成NOT EXISTS，表关联走的 HASH JOIN RIGHT ANTI NA，效率较高。
尝试将新库SQL中not in改写成NOT EXISTS后，效率有明显提升，不到5分钟可以执行完成。

SQL是否还有优化空间呢？

可以看看Oracle给出的建议sql tuning advisor:

SQL>
DECLARE
  my_task_name VARCHAR2(30);
BEGIN
  my_task_name := DBMS_SQLTUNE.CREATE_TUNING_TASK(sql_id      => 'gzjy5nh7g0sfs',
                                                  scope       => 'COMPREHENSIVE',
                                                  time_limit  => 3600,
                                                  task_name   => 'cjc_sql_tuing_task',
                                                  description => 'SQL TUNE TEST');
  DBMS_SQLTUNE.EXECUTE_TUNING_TASK(task_name => 'cjc_sql_tuing_task');
END;
/

SELECT status FROM  DBA_ADVISOR_TASKS WHERE  task_name = 'cjc_sql_tuing_task';
SET LONG 10000
SET LONGCHUNKSIZE 1000
SET LINESIZE 300
SELECT DBMS_SQLTUNE.REPORT_TUNING_TASK('cjc_sql_tuing_task') FROM   DUAL;

建议如下：

1- SQL Profile Finding (see explain plans section below)
--------------------------------------------------------
  为此语句找到了性能更好的执行计划 2。选择以下 SQL 概要文件之一进行实施。
  Recommendation (estimated benefit: 95.14%)
  ------------------------------------------
  - 考虑接受推荐的 SQL 概要文件。
    execute dbms_sqltune.accept_sql_profile(task_name =>
            'cjc_sql_tuing_task', task_owner => 'CHENPMB', replace => TRUE);
  Recommendation (estimated benefit: 99.95%)
  ------------------------------------------
  - 考虑接受建议的 SQL 概要文件, 以便对此语句使用并行执行。
    execute dbms_sqltune.accept_sql_profile(task_name =>
            'cjc_sql_tuing_task', task_owner => 'CHENPMB', replace => TRUE,
            profile_type => DBMS_SQLTUNE.PX_PROFILE);
  与 DOP 128 并行执行此查询会使 SQL 概要文件计划上的响应时间缩短 99.13%。但是, 启用并行执行时要付出一些代价。它将增加语句的资源消耗
  (预计为 11.07%), 这会导致系统吞吐量降低。此外, 由于在非常短的持续时间内消耗了这些资源, 因此如果没有足够可用的硬件容量,
  并发语句的响应时间将受到负面影响。

2- Index Finding (see explain plans section below)

--------------------------------------------------
  通过创建一个或多个索引可以改进此语句的执行计划。
  Recommendation (estimated benefit: 99.7%)
  -----------------------------------------
  - 考虑运行可以改进物理方案设计的访问指导或者创建推荐的索引。
    create index CHENPMB.IDX$$_04000001 on
    CHENPMB.MB_PAY_LOG("MPL_TRANCODE","MPL_STT",LENGTH("MPL_TIME"),"MPL_TIME");
  - 考虑运行可以改进物理方案设计的访问指导或者创建推荐的索引。
    create index CHENPMB.IDX$$_04000002 on
    CHENPMB.MB_FINANCE_TRANS_INCREMENT("MFT_TRAN_STATUS",LENGTH("MFT_TRAN_TIME"
    ),"MFT_TRAN_CODE","MFT_TRAN_TIME");
  - 考虑运行可以改进物理方案设计的访问指导或者创建推荐的索引。
    create index CHEN.IDX$$_04000003 on CHEN.CJC_T1_00000000000000000("MPB_BUSI
    NESSTYPE",LENGTH("MPB_TRANTIME"),"MPB_TRANTIME","CJC_T3_000000");
  - 考虑运行可以改进物理方案设计的访问指导或者创建推荐的索引。
    create index CHENPMB.IDX$$_04000004 on
    CHENPMB.MB_LOANBYFINANCE_RECORD("MLR_TRANCODE","MLR_LOANTYPEFLAG","MLR_STAT
    US",LENGTH("MLR_TRANTIME"),"MLR_TRANTIME");
  - 考虑运行可以改进物理方案设计的访问指导或者创建推荐的索引。
    create index CHENPMB.IDX$$_04000006 on
    CHENPMB.MB_TRANFLOW_INCREMENT("TRF_BSNCODE","TRF_STT",LENGTH("TRF_SUBTIME")
    ,"TRF_SUBTIME","TRF_FLOWNO");
  Rationale
  ---------
    创建推荐的索引可以显著地改进此语句的执行计划。但是, 使用典型的 SQL 工作量运行 "访问指导"
    可能比单个语句更可取。通过这种方法可以获得全面的索引建议案, 包括计算索引维护的开销和附加的空间消耗。

最终建议：

1 将SQL中not in部分改写成not exists。
2 创建组合索引。

优化效果：
SQL由原来5小时查不出结果，优化到12秒完成查询。

###2021-03-31 22:00 chenjuchao###
