问题现象：

DG搭建完成后，主库归档不能自动同步到备库。

问题排查：

主库告警日志报错：

PING[ARC2]: Heartbeat failed to connect to standby 'cjcdb02'. Error is 16058.

报错原因：

备库故障，主库无法连接备库，备库恢复后，主库没有尝试重连备库。

解决方案：

主库重新激活log_archive_dest_state_2
过程如下：
主库：
切换归档

SQL> alter system switch logfile ;
System altered.
SQL> archive log list;
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination       /arch
Oldest online log sequence     15
Next log sequence to archive   17
Current log sequence       17

备库：
没有接收到归档日志

SQL> archive log list;
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination       /arch
Oldest online log sequence     0
Next log sequence to archive   0
Current log sequence       0

查看备库告警日志，没有报错，RFS进程已经启动

RFS connections are allowed

主库：
主库告警日志：

Use the following SQL commands on the standby database to create
standby redo logfiles that match the primary database:
ALTER DATABASE ADD STANDBY LOGFILE 'srl1.f' SIZE 52428800;
ALTER DATABASE ADD STANDBY LOGFILE 'srl2.f' SIZE 52428800;
ALTER DATABASE ADD STANDBY LOGFILE 'srl3.f' SIZE 52428800;
ALTER DATABASE ADD STANDBY LOGFILE 'srl4.f' SIZE 52428800;
Tue Aug 04 15:29:26 2020
ALTER SYSTEM SET log_archive_dest_state_2='ENABLE' SCOPE=MEMORY SID='*';
Tue Aug 04 15:29:26 2020
PING[ARC2]: Heartbeat failed to connect to standby 'cjcdb02'. Error is 16058.
Tue Aug 04 15:29:28 2020

主库连接一次备库失败后，没有尝试重连。

主库：
重新激活

SQL> alter system set log_archive_dest_state_2=defer;
SQL> alter system set log_archive_dest_state_2=enable;

主库告警日志：

Tue Aug 04 15:33:58 2020
ALTER SYSTEM SET log_archive_dest_state_2='DEFER' SCOPE=BOTH;
Tue Aug 04 15:34:22 2020
ALTER SYSTEM SET log_archive_dest_state_2='ENABLE' SCOPE=BOTH;
Tue Aug 04 15:34:22 2020
Thread 1 cannot allocate new log, sequence 20
Checkpoint not complete
  Current log# 1 seq# 19 mem# 0: /oracle/oradata/cjcdb01/redo01.log
Thread 1 cannot allocate new log, sequence 20
Private strand flush not complete
  Current log# 1 seq# 19 mem# 0: /oracle/oradata/cjcdb01/redo01.log
Thread 1 advanced to log sequence 20 (LGWR switch)
  Current log# 2 seq# 20 mem# 0: /oracle/oradata/cjcdb01/redo02.log
Tue Aug 04 15:34:29 2020
Archived Log entry 17 added for thread 1 sequence 19 ID 0x3995c964 dest 1:
Tue Aug 04 15:34:29 2020
ARC0: Standby redo logfile selected for thread 1 sequence 19 for destination LOG_ARCHIVE_DEST_2
Tue Aug 04 15:34:29 2020
******************************************************************
LGWR: Setting 'active' archival for destination LOG_ARCHIVE_DEST_2
******************************************************************
LNS: Standby redo logfile selected for thread 1 sequence 20 for destination LOG_ARCHIVE_DEST_2

备库告警日志：

Tue Aug 04 15:34:21 2020
RFS[1]: Assigned to RFS process 11502
RFS[1]: Opened log for thread 1 sequence 14 dbid 966115684 branch 1047470758
Tue Aug 04 15:34:21 2020
RFS[2]: Assigned to RFS process 11504
RFS[2]: Opened log for thread 1 sequence 16 dbid 966115684 branch 1047470758
Tue Aug 04 15:34:21 2020
RFS[3]: Assigned to RFS process 11506
RFS[3]: Opened log for thread 1 sequence 15 dbid 966115684 branch 1047470758
Archived Log entry 1 added for thread 1 sequence 14 rlc 1047470758 ID 0x3995c964 dest 2:
RFS[1]: Opened log for thread 1 sequence 17 dbid 966115684 branch 1047470758
Archived Log entry 2 added for thread 1 sequence 16 rlc 1047470758 ID 0x3995c964 dest 2:
Archived Log entry 3 added for thread 1 sequence 17 rlc 1047470758 ID 0x3995c964 dest 2:
Archived Log entry 4 added for thread 1 sequence 15 rlc 1047470758 ID 0x3995c964 dest 2:
RFS[2]: Opened log for thread 1 sequence 18 dbid 966115684 branch 1047470758
Archived Log entry 5 added for thread 1 sequence 18 rlc 1047470758 ID 0x3995c964 dest 2:
RFS[2]: Selected log 4 for thread 1 sequence 19 dbid 966115684 branch 1047470758
Tue Aug 04 15:34:28 2020
Archived Log entry 6 added for thread 1 sequence 19 ID 0x3995c964 dest 1:
Tue Aug 04 15:34:28 2020
Primary database is in MAXIMUM PERFORMANCE mode
RFS[4]: Assigned to RFS process 11514
RFS[4]: Selected log 4 for thread 1 sequence 20 dbid 966115684 branch 1047470758
