帧动画
帧动画(Frame Animation)
1、帧动画的特性:
a. 用于生成连续的Gif效果图。
b. DrawableAnimation也是指此动画
2、帧动画的优缺点:
缺点:效果单一,逐帧播放需要很多图片,占用控件较大
优点:制作简单
补间动画
补间动画特性:
a.渐变动画支持四种类型:平移(Translate)、旋转(Rotate)、缩放(Scale)、不透明度
b. 只是显示的位置变动,View的实际位置未改变,表现为View移动到其他地方,点击事件仍在原处才能响应。
c. 组合使用步骤较复杂。
d. View Animation 也是指此动画
补间动画的优缺点:
缺点:当平移动画执行完停在最后的位置,结果焦点还在原来的位置(控件的属性没有真的被改变)
优点:相对于逐帧动画来说,补间动画更为连贯自然
属性动画
从 Android 3.0 就推出了属性动画,在以前使用的是视图动画,那么属性动画的优势在哪呢?都知道,视图动画对于一个 View 的操作仅仅只是一个表象的操作,就是说,视图动画中,仅仅只是对它视图的操作,而它真实的坐标和属性并没有发生变化,那么属性动画就是对一个 View 或者非 View 属性的操作,这一强大功能让它解决了视图动画的缺陷。 和视图动画一样的是,属性动画(Animator )也分为动画和动画集:ValueAnimator(ValueAnimator 算不上实现动画,ObjectAnimator 和TimeAnimator 继承自 ValueAnimator,一般由前者 ObjectAnimator 和 TimeAnimator 来实现动画,后面会说明 ValueAnimator) 和 AnimatorSet,而 ValueAnimator 又分为 ObjectAnimator 和 TimeAnimator,一般我们都使用 ObjectAnimator。 属性动画和视图动画一样,都可以使用 xml 和 代码的方式实现,大家可以看一下 视图动画 来了解一下,其 xml 的实现方式是大同小异的。所以这里只对一些 xml 实现方式的不同之处作解释,不会像视图动画那篇做详细说明。 因为属性动画和视图动画实现方式不太一样,所以我们可能先了解一下代码实现方式,这样对于 xml 理解会更家容易。代码方法 ObjectAnimator 有很多实现动画的方法,一般我们使用 ofFloat() 方法:
//图片用自己喜欢的
<?xml version="1.0" encoding="utf-8"?>
<animation-list xmlns:android="http://schemas.android.com/apk/res/android">
<item android:drawable="@drawable/progress_loading_image_01" android:duration="50"></item>
<item android:drawable="@drawable/progress_loading_image_02" android:duration="50"></item>
<item android:drawable="@drawable/progress_loading_image_03" android:duration="50"></item>
<item android:drawable="@drawable/progress_loading_image_04" android:duration="50"></item>
<item android:drawable="@drawable/progress_loading_image_05" android:duration="50"></item>
<item android:drawable="@drawable/progress_loading_image_06" android:duration="50"></item>
<item android:drawable="@drawable/progress_loading_image_07" android:duration="50"></item>
<item android:drawable="@drawable/progress_loading_image_08" android:duration="50"></item>
</animation-list>
<?xml version="1.0" encoding="utf-8"?>
<alpha xmlns:android="http://schemas.android.com/apk/res/android"
android:fromAlpha="1.0"
android:toAlpha="0.0"
android:duration="2000"
android:fillBefore="true"
>
</alpha>
<?xml version="1.0" encoding="utf-8"?>
<rotate xmlns:android="http://schemas.android.com/apk/res/android"
android:fromDegrees="0.0"
android:toDegrees="720"
android:pivotX="200"
android:pivotY="200"
android:fillBefore="true"
android:duration="2000"
>
</rotate>
<?xml version="1.0" encoding="utf-8"?>
<scale xmlns:android="http://schemas.android.com/apk/res/android"
android:fromYScale="1.0"
android:fromXScale="1.0"
android:toXScale="4.0"
android:toYScale="3.0"
android:pivotY="100"
android:pivotX="100"
android:fillBefore="true"
android:duration="2000"
>
</scale>
<?xml version="1.0" encoding="utf-8"?>
<translate xmlns:android="http://schemas.android.com/apk/res/android"
android:duration="2000"
android:fillBefore="true"
android:fromXDelta="0"
android:fromYDelta="0"
android:toXDelta="200"
android:toYDelta="300">
</translate>
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
android:layout_height="match_parent"
tools:context=".MainActivity"
android:orientation="vertical">
<Button
android:text="播放帧动画"
android:id="@+id/zhen"
android:layout_width="match_parent"
android:layout_height="wrap_content" />
<Button
android:text="补间动画"
android:id="@+id/btnstartfragmen"
android:layout_width="match_parent"
android:layout_height="wrap_content" />
<ImageView
android:background="@drawable/darawable"
android:id="@+id/image123"
android:layout_width="match_parent"
android:layout_height="match_parent" />
</LinearLayout>
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
android:layout_height="match_parent"
tools:context=".Main2Activity"
android:orientation="vertical">
<Button
android:id="@+id/btn1"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:text="透明" />
<Button
android:id="@+id/btn2"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:text="旋转" />
<Button
android:id="@+id/btn3"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:text="缩放" />
<Button
android:id="@+id/btn4"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:text="平移" />
<ImageView
android:background="@drawable/hj"
android:id="@+id/img456"
android:layout_gravity="center"
android:layout_width="wrap_content"
android:layout_height="wrap_content" />
</LinearLayout>
package com.example.myapplication;
import android.content.Intent;
import android.graphics.drawable.AnimationDrawable;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.ImageView;
import android.widget.ListView;
public class MainActivity extends AppCompatActivity implements View.OnClickListener {
ImageView imageView;
AnimationDrawable drawable;
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
imageView = findViewById(R.id.image123);
findViewById(R.id.zhen).setOnClickListener(this);
findViewById(R.id.btnstartfragmen).setOnClickListener(this);
drawable = (AnimationDrawable) imageView.getBackground();
}
@Override
public void onClick(View v) {
switch (v.getId()) {
case R.id.zhen:
boolean running = drawable.isRunning();
if (running == true) {
drawable.stop();
} else {
drawable.start();
}
break;
case R.id.btnstartfragmen:
Intent intent=new Intent(this,Main2Activity.class);
startActivity(intent);
break;
default:
break;
}
}
}
package com.example.myapplication;
import android.graphics.drawable.AnimationDrawable;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.view.animation.Animation;
import android.view.animation.AnimationUtils;
import android.widget.ImageView;
public class Main2Activity extends AppCompatActivity implements View.OnClickListener {
ImageView view;
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main2);
findViewById(R.id.btn1).setOnClickListener(this);
findViewById(R.id.btn2).setOnClickListener(this);
findViewById(R.id.btn3).setOnClickListener(this);
findViewById(R.id.btn4).setOnClickListener(this);
view=findViewById(R.id.img456);
}
@Override
public void onClick(View v) {
switch (v.getId()){
case R.id.btn1:
Animation animation = AnimationUtils.loadAnimation(this, R.anim.alpha);
view.startAnimation(animation);
break;
case R.id.btn2:
Animation animation1 = AnimationUtils.loadAnimation(this, R.anim.rotate);
view.startAnimation(animation1);
break;
case R.id.btn3:
Animation animation2 = AnimationUtils.loadAnimation(this, R.anim.scale);
view.startAnimation(animation2);
break;
case R.id.btn4:
Animation animation3 = AnimationUtils.loadAnimation(this, R.anim.translate);
view.startAnimation(animation3);
break;
}
}
}
package com.example.rikao_1;
import android.animation.Animator;
import android.animation.AnimatorInflater;
import android.animation.AnimatorSet;
import android.animation.ObjectAnimator;
import android.animation.PropertyValuesHolder;
import android.animation.ValueAnimator;
import android.graphics.Color;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.view.animation.Animation;
import android.view.animation.AnticipateInterpolator;
import android.widget.Button;
import android.widget.ImageView;
import android.widget.TextView;
import android.widget.Toast;
public class Main2Activity extends AppCompatActivity implements View.OnClickListener {
TextView textView;
ImageView imageView;
int count = 1;
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main2);
textView = findViewById(R.id.shuxing_text);
findViewById(R.id.btn_2start).setOnClickListener(this);
findViewById(R.id.btn_2startdaima).setOnClickListener(this);
findViewById(R.id.btn_2startsuofang).setOnClickListener(this);
findViewById(R.id.btn_2pingyi).setOnClickListener(this);
findViewById(R.id.btn_baccolor).setOnClickListener(this);
findViewById(R.id.btn_set_property).setOnClickListener(this);
imageView = findViewById(R.id.shuxing_image);
textView.setOnClickListener(new View.OnClickListener() {
@Override
public void onClick(View v) {
Toast.makeText(Main2Activity.this, "我被点击了", Toast.LENGTH_SHORT).show();
}
});
}
@Override
public void onClick(View v) {
switch (v.getId()) {
case R.id.btn_2start:
alphaProperty();
break;
case R.id.btn_2startdaima:
alphaPropertydaima();
break;
case R.id.btn_2startsuofang:
scaleProperty();
break;
case R.id.btn_2pingyi:
scalePingyi();
break;
case R.id.btn_baccolor:
ChangeBacColor();
break;
case R.id.btn_set_property:
setProperty();
break;
default:
break;
}
}
private void setProperty() {
ObjectAnimator animator=ObjectAnimator.ofArgb(textView,"backgroundColor", Color.BLUE,Color.GREEN);
ObjectAnimator animator1 = ObjectAnimator.ofFloat(textView, "translationX", 0, 100);
ObjectAnimator animator2 = ObjectAnimator.ofFloat(textView, "scaleX", 1.0f, 3.0f);
ObjectAnimator animator3 = ObjectAnimator.ofFloat(textView, "rotation", 0, 720);
ObjectAnimator animator4 = ObjectAnimator.ofFloat(textView, "alpha", 1.0f);
//属性动画集合
AnimatorSet animatorSet=new AnimatorSet();
animatorSet.setDuration(8000);
//开始执行属性动画 with 和一起执行 before 在play之前的动画 aftre在play动画之后
animatorSet.play(animator).with(animator1).before(animator2).after(animator3).with(animator4);
animatorSet.start();
//
// PropertyValuesHolder propertyValuesHolder=PropertyValuesHolder.ofInt("backgroundColor",Color.YELLOW,Color.RED);
// PropertyValuesHolder propertyValuesHolder1=PropertyValuesHolder.ofFloat("translationY",0,200);
// PropertyValuesHolder propertyValuesHolder2=PropertyValuesHolder.ofFloat("scaleX",1,3);
// PropertyValuesHolder propertyValuesHolder3=PropertyValuesHolder.ofFloat("rotation",0,360);
// PropertyValuesHolder propertyValuesHolder4=PropertyValuesHolder.ofFloat("alpha",0,200);
//
//
// ObjectAnimator objectAnimator = ObjectAnimator.ofPropertyValuesHolder(textView, propertyValuesHolder, propertyValuesHolder1, propertyValuesHolder2, propertyValuesHolder3, propertyValuesHolder4);
//
// objectAnimator.setDuration(8000);
// objectAnimator.setRepeatCount(3);
// objectAnimator.start();
}
//通过属性动画设置背景颜色
private void ChangeBacColor() {
ObjectAnimator animator=ObjectAnimator.ofArgb(textView,"backgroundColor", Color.BLUE,Color.GREEN);
animator.setDuration(5000);
//设置执行次数
animator.setRepeatCount(3);
animator.start();
}
private void scalePingyi() {
//获取控件相对于Y轴位移
float translationY = textView.getTranslationY();
ObjectAnimator objectAnimator = ObjectAnimator.ofFloat(textView, "translationX", translationY, translationY+100);
objectAnimator.setDuration(5000);
objectAnimator.start();
}
private void scaleProperty() {
ObjectAnimator objectAnimator = ObjectAnimator.ofFloat(textView, "scaleX", 1.0f, 3.0f);
objectAnimator.setDuration(5000);
objectAnimator.addListener(new Animator.AnimatorListener() {
@Override
public void onAnimationStart(Animator animation) {
ObjectAnimator objectAnimator1 = ObjectAnimator.ofFloat(textView, "scaleX", 3.0f, 1.0f);
objectAnimator1.setDuration(5000);
objectAnimator1.start();
}
@Override
public void onAnimationEnd(Animator animation) {
}
@Override
public void onAnimationCancel(Animator animation) {
}
@Override
public void onAnimationRepeat(Animator animation) {
}
});
objectAnimator.start();
}
//旋转动画
private void alphaPropertydaima() {
ObjectAnimator objectAnimator = ObjectAnimator.ofFloat(textView, "rotation", 0, 720);
objectAnimator.setDuration(5000);
objectAnimator.setRepeatMode(ObjectAnimator.REVERSE);
objectAnimator.setInterpolator(new AnticipateInterpolator());
objectAnimator.start();
}
//加载xml文件 实现属性动画
private void alphaProperty() {
ValueAnimator animator = (ValueAnimator) AnimatorInflater.loadAnimator(Main2Activity.this, R.animator.alpha);
//关联textview
animator.setTarget(textView);
//设置执行时间
animator.setDuration(5000);
//设置重复次数
animator.setRepeatCount(3);
//用来统计动画执行的次数
animator.addListener(new Animator.AnimatorListener() {
@Override
public void onAnimationStart(Animator animation) {
Toast.makeText(Main2Activity.this, "开始", Toast.LENGTH_SHORT).show();
}
@Override
public void onAnimationEnd(Animator animation) {
Toast.makeText(Main2Activity.this, "结束", Toast.LENGTH_SHORT).show();
}
@Override
public void onAnimationCancel(Animator animation) {
count++;
Toast.makeText(Main2Activity.this, "重复了" + count + "次", Toast.LENGTH_SHORT).show();
}
@Override
public void onAnimationRepeat(Animator animation) {
}
});
animator.start();
}
}
