Django之关系模型的序列化

一、关系模型的序列化-多查1

1.1、模型准备

from django.db import models


# Create your models here.
class Classes(models.Model):
  name = models.CharField(max_length=20, verbose_name='班级')

class Student(models.Model):


  SEX_CHOICES = ((1,'男')), (2, '女')


  name = models.CharField(max_length=20, verbose_name='姓名')
  age = models.IntegerField(null=True, blank=True, verbose_name='年龄')
  sex = models.IntegerField(choices=SEX_CHOICES, default=1, verbose_name='性别')
  classes = models.ForeignKey(Classes, on_delete=models.SET_NULL,null=True,verbose_name='班级')

1.2、迁移模型

python manage.py makemigrations
python manage.py migrate

1.3、初始化数据

insert into t_class (name) values ('Python');
insert into t_class (name) values ('SQL');
insert into t_student(name,age,sex,classes) values ('BaiZhan',18,1,1);
insert into t_student(name,age,sex,classes) values ('SXT',20,2,1);

1.4、serializers

class ClassSerializer(serializers.ModelSerializer):
  class Meta:
    model = Classes
    fields = '__all__'

说明：

只是在StudentSerializer类的meta中 fields 字段中添加了 classes 字段，那么序列化时，显示的只是对应的班级的主键id，如：{"id": 3, "name": "terry", "age": 18, "sex": 1, "classes":1}

如果想序列化对应的班级的信息，那么需要在 StudentSerializer 中，重新指定 classes 字段

class StudentSerializer(serializers.ModelSerializer):
  #新增 所属班级 属性
  classes = ClassesSerializer()


  class Meta:
    model = Student
    fields = ['id', 'name', 'age', 'sex', 'classes']

• 当前修改后的序列化内容为：{"id": 3, "name": "terry", "age": 18, "sex": 1, "classes": {"id": 1, "name": "\u4e00\u73ed"}}

测试

GET http://127.0.0.1:8000/rest_app/students/



二、关系模型的序列化-1查多

以上只是显示了一对多关系中，关系多方查询1的数据的序列化，下面展示如何序列化1查多方多的数据

models：

class Student(models.Model):


  SEX_CHOICES = ((1,'男')), (2, '女')


  name = models.CharField(max_length=20, verbose_name='姓名')
  age = models.IntegerField(null=True, blank=True, verbose_name='年龄')
  sex = models.IntegerField(choices=SEX_CHOICES, default=1, verbose_name='性别')

  # 必须增加属性 related_name='students'
  classes = models.ForeignKey(Classes, related_name='students', null=True, on_delete=models.SET_NULL, verbose_name='班级')

serializers：

from rest_framework import serializers


from .models import Classes, Student


class StudentSerializer(serializers.ModelSerializer):
  class Meta:
    model = Student
    fields = ['id','name','age','sex']


class Class2Serializer(serializers.ModelSerializer):
  # 通过related_name反向查询的字段，创建序列化器对象
  students = StudentSerializer(many=True,read_only=True)
  class Meta:
    model = Classes
    fields = ['id','name','students']

注意

StudentSerializer 必须在 ClassesSerializer 上面

urls:

path('classes/<int:pk>/', views.classes_detail),

views：

def classes_detail(request, pk):
  try:
    classes = Classes.objects.get(pk=pk)
  except Classes.DoesNotExist:
    return HttpResponse(status=404)


  if request.method == 'GET':
    serializer = ClassesSerializer(classes)
    return JsonResponse(serializer.data)
  else:
    # 其他情况暂不处理
    return HttpResponse(status=503)

 测试

GET http://127.0.0.1:8000/rest_app/classes/1/

三、手动处理关系字段

由于serializers类的引用关系的原因，serializers类中能只能有1方引入另1方，不如互相引入

如果业务需求，需要2个关系字段都序列化，那么就需要使用到 serializers.RelatedField 类，手动处理关系字段

serializers：

from rest_framework import serializers


from .models import Classes, Student


class StudentRelateFiled(serializers.RelatedField):
  # 重写to_representation方法,将外键关联的对象转换为指定的格式
  def to_representation(self, value):
    return {'id':value.id,'name':value.name,'age':value.age}


class ClassSerializer(serializers.ModelSerializer):
  students = StudentRelateFiled(many=True,read_only=True)
  class Meta:
    model = Classes
    fields = ['id','name','students']


class StudentSerializer(serializers.ModelSerializer):
  # 通过外键关联的类，创建序列化器对象
  classes = ClassSerializer()
  class Meta:
    model = Student
    fields = ['id','name','age','sex','classes']



注意事项

• 上面3个类的先后顺序不能错

测试：

GET http://127.0.0.1:8000/rest_app/classes2/1/
