RIP综合实验

RIP路由配置与访问控制：多设备间信息交换与策略详解

最新推荐文章于 2025-12-03 19:42:25 发布

原创最新推荐文章于 2025-12-03 19:42:25 发布 · 置顶 · 386 阅读

0 ·

CC 4.0 BY-SA版权

文章标签：

#网络 #华为

sysname R1

interface GigabitEthernet0/0/0
ip address 14.1.1.1 255.255.255.0
rip summary-address 172.16.0.0 255.255.252.0
#
interface GigabitEthernet0/0/1
ip address 12.1.1.1 255.255.255.0
rip authentication-mode md5 usual plain cisco
rip summary-address 172.16.0.0 255.255.252.0

interface LoopBack0
ip address 1.1.1.1 255.255.255.0
#
interface LoopBack1
ip address 172.16.1.1 255.255.255.0
#
interface LoopBack2
ip address 172.16.2.1 255.255.255.0

interface LoopBack3
ip address 172.16.3.1 255.255.255.0

rip 100
version 2
network 172.16.0.0
network 1.0.0.0
network 12.0.0.0
network 14.0.0.0

sysname R2

acl number 2000
rule 5 permit source 7.0.0.0 0

interface GigabitEthernet0/0/0
ip address 12.1.1.2 255.255.255.0
rip authentication-mode md5 usual plain cisco
rip metricin 2000 10
nat server protocol tcp global 2.2.2.3 telnet inside 7.7.7.7 telnet
#
interface GigabitEthernet0/0/1
ip address 23.1.1.1 255.255.255.0
#

interface LoopBack0
ip address 2.2.2.2 255.255.255.0
#
rip 100
version 2
network 12.0.0.0
network 23.0.0.0
network 2.0.0.0

sysname R3

acl number 2000
rule 5 permit source 1.1.1.0 0
rule 10 permit source 172.16.1.0 0
rule 15 permit source 172.16.2.0 0
rule 20 permit source 172.16.3.0 0
rule 25 permit source 172.16.0.0 0

interface GigabitEthernet0/0/0
ip address 23.1.1.2 255.255.255.0
#
interface GigabitEthernet0/0/1
ip address 34.1.1.1 255.255.255.0
rip metricin 2000 5
#
interface LoopBack0
ip address 3.3.3.3 255.255.255.0
#
rip 100
version 2
network 23.0.0.0
network 34.0.0.0
network 3.0.0.0

sysname R4

acl number 2000
rule 5 permit source 12.1.1.0 0
rule 10 permit source 1.1.1.0 0

#
interface GigabitEthernet0/0/2
ip address 46.1.1.1 255.255.255.0
rip version 1
#
interface GigabitEthernet0/0/1
ip address 34.1.1.2 255.255.255.0
#
interface GigabitEthernet0/0/0
ip address 14.1.1.2 255.255.255.0
rip metricin 2000 10
#
interface GigabitEthernet4/0/0
ip address 45.1.1.1 255.255.255.0
#
interface LoopBack0
ip address 4.4.4.4 255.255.255.0
#
rip 100
version 2
network 14.0.0.0
network 34.0.0.0
network 45.0.0.0
network 4.0.0.0
network 46.0.0.0

sysname R5

interface GigabitEthernet0/0/2
ip address 45.1.1.2 255.255.255.0
#
interface LoopBack0
ip address 5.5.5.5 255.255.255.0
#
interface LoopBack1
ip address 100.1.1.1 255.255.255.0
#
rip 100
default-route originate
version 2
network 45.0.0.0
network 5.0.0.0

sysname R6

#
acl number 2000
rule 5 deny source 1.0.0.0 0
rule 10 deny source 172.16.0.0 0
rule 15 permit
#
interface S GigabitEthernet0/0/0
link-protocol ppp
ip address 46.1.1.2 255.255.255.0
#
interface GigabitEthernet0/0/1
ip address 67.1.1.1 255.255.255.0
#
interface LoopBack0
ip address 6.6.6.6 255.255.255.0
#
rip 100
version 1
network 6.0.0.0
network 46.0.0.0
network 67.0.0.0
filter-policy 2000 import Serial4/0/0
#
