PRODUCT INTRODUCTION

Dear Customer

Thank you for purchasing this product. For optimum performance and safety,please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.

FEATURES

Extends 1080p HDMI signals up to 200m over a single UTP Cat5e/6 cable

●Support Point-to-Point, Point-to-Many and Many-to-Many networkconfiguration

●HDCP compliant

●Can be cascaded for many layers by adding more Ethernet switches

●With wideband IR (38kHz) control to the source

●Support TCP/IP protocol

● Applications: 1: N solutions (store, restaurant, classroom, monitor, projector, TCP/IP network)

NOTICE

Our company reserves the right to make changes in the hardware, packaging andany accompanying documentation without prior written notice.

TABL .E OF CONTENTS

Specifications

Package Contents

Panel Descriptions

Connecting and Operating

Typical Application

Maintenance

Product Service

Warranty

SPECIFICATIONS

Operating Temperature Range	-5 to +35℃(+23 to +95℉)
Operating Humidity Range	5 to 90%RH (No Condensation)
Input Video Signal	0.5-1.0 Volts P-P
Input DDC Signal	5 volts p-p(TTL)
Support Video Format	DTV/HDTV:480i/576i/480P/576P/720P/1080P
Video Output	HDMI
Transmission Distance	1080P 8-bit 200m(Maximum) over single CAT5E/6 /24AWG/Solid
Power consumption	TX:4watts; RX:3.5watts((Maximum)
IR Frequency	38kHz
Dimension (L×W×H)	146x75x27mm
Net Weight	Receiver:220g,Transmitter:2
