本文默认认为读者已搭建好完整的Spring Cloud 服务,本文仅在已有服务集群中引入 Prometheus 监控项目

注册发现基于Eureka

Eureka Server 导入依赖
Prometheus 不支持 Eureka ,需要使用consul 适配器模拟consul服务

        <dependency>
            <groupId>at.twinformatics</groupId>
            <artifactId>eureka-consul-adapter</artifactId>
            <version>1.3.0</version>
        </dependency>

业务服务修改

引入依赖


        <!-- Micrometer Prometheus registry  -->
        <dependency>
            <groupId>io.micrometer</groupId>
            <artifactId>micrometer-registry-prometheus</artifactId>
        </dependency>

添加Bean


    @Configuration
    @ConditionalOnClass({MeterRegistry.class})
    static class MeterRegistryConfig {
        @Value("${spring.application.name}")
        private String applicationName = "APP_NAME";

        @Bean
        MeterRegistryCustomizer<MeterRegistry> appMetricsCommonTags() {
            return registry -> registry.config().commonTags("application", applicationName);
        }
    }

application.yml 添加配置
开放 Prometheus Endpoint

management:
  endpoints:
    web:
      # https://docs.spring.io/spring-boot/docs/2.1.1.RELEASE/reference/htmlsingle/#production-ready-endpoints-exposing-endpoints
      exposure:
        include:  prometheus

安装 Prometheus

配置文件:

# my global config
global:
  scrape_interval:     15s # Set the scrape interval to every 15 seconds. Default is every 1 minute.
  evaluation_interval: 15s # Evaluate rules every 15 seconds. The default is every 1 minute.
  # scrape_timeout is set to the global default (10s).

# Load rules once and periodically evaluate them according to the global 'evaluation_interval'.
rule_files:
  # - "first_rules.yml"
  # - "second_rules.yml"

# A scrape configuration containing exactly one endpoint to scrape:
# Here it's Prometheus itself.
scrape_configs:
  - job_name: 'spring-actuator'
    metrics_path: '/actuator/prometheus'
    scrape_interval: 5s
    scheme: http
    consul_sd_configs:
    #consul 地址
      - server: '192.168.1.3:8761'
        #username: 'username'    eureka 如有权限控制需要打开
        #password: 'pwd'
        scheme: http
        services: [SERVICE_NAME1,SERVICE_NAME2]
