交叉编译OPENCV-FFMPEG-X264，并且在安卓中调用这三个包直接拉流rtsp。

xiaommianyang

已于 2025-01-08 09:28:41 修改

阅读量420

点赞数

文章标签： opencv ffmpeg android

于 2025-01-03 16:54:34 首次发布

本文链接：https://blog.youkuaiyun.com/xiaommianyang/article/details/144913828

版权

参考了下面博主的文章直接用了博主的资源已经测试了是可以运行的工具

我没有自己编译文件，但是博主的文件是有用的！！！

项目地址

// 这就是调用opencv拉流代码。
// nanodet
    {
        ncnn::MutexLockGuard g(lock);

        if (g_yolo)
        {
            std::vector<Object> objects;
            std::vector<Object> objects_s;
            std::string rtsp1 = "rtsp://XXXXXXXX/h265/ch1/main/av_stream";
            cv::VideoCapture stream1 = cv::VideoCapture(rtsp1,cv::CAP_FFMPEG);
            if (1){
                cv::Mat frame;
                stream1.read(frame);
                cv::imwrite("/sdcard/test/output2.jpg", frame); // 保存图片
            }

// CMakeLists.txt文件内容
project(yolov8ncnn)

cmake_minimum_required(VERSION 3.10)

#set(OpenCV_DIR ${CMAKE_SOURCE_DIR}/opencv-mobile-4.5.1-android/sdk/native/jni)
#find_package(OpenCV REQUIRED core imgproc highgui)

#set(OpenCV_DIR /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/jni)
#find_package(OpenCV REQUIRED)
#find_package(OpenCV REQUIRED  opencv_core opencv_videoio opencv_highgui opencv_imgproc opencv_imgcodecs opencv_dnn opencv_core)
#find_package(OpenCV REQUIRED core imgproc highgui)

set(ncnn_DIR ${CMAKE_SOURCE_DIR}/ncnn-20220420-android-vulkan/arm64-v8a/lib/cmake/ncnn)
find_package(ncnn REQUIRED)

#set(FFMPEG_DIR ${CMAKE_SOURCE_DIR}/ffmpeg/product/arm64-v8a)

# 添加FFmpeg的include目录
include_directories(/home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/include)

# 添加FFmpeg的库目录
link_directories(/home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/lib)

# 添加opencv的include目录
include_directories(/home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/jni/include)

# 添加opencv的库目录
link_directories(/home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/libs/arm64-v8a)


# 添加x264的include目录
include_directories(/home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/X264/product/arm64-v8a/include)

# 添加x264的库目录
link_directories(/home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/X264/product/arm64-v8a/lib)



# 添加FFmpeg的链接库
add_library(avcodec SHARED IMPORTED)
set_target_properties(avcodec PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/lib/libavcodec.so)

add_library(avformat SHARED IMPORTED)
set_target_properties(avformat PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/lib/libavformat.so)


add_library(avutil SHARED IMPORTED)
set_target_properties(avutil PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/lib/libavutil.so)

add_library(swscale SHARED IMPORTED)
set_target_properties(swscale PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/lib/libswscale.so)

add_library(swresample SHARED IMPORTED)
set_target_properties(swresample PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/lib/libswresample.so)

add_library(avdevice SHARED IMPORTED)
set_target_properties(avdevice PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/lib/libavdevice.so)

add_library(avfilter SHARED IMPORTED)
set_target_properties(avfilter PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/ffmpeg/product/arm64-v8a/lib/libavfilter.so)


# 添加opencv的链接库
add_library(opencv_videoio SHARED IMPORTED)
set_target_properties(opencv_videoio PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/libs/arm64-v8a/libopencv_videoio.so)

add_library(opencv_photo SHARED IMPORTED)
set_target_properties(opencv_photo PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/libs/arm64-v8a/libopencv_photo.so)

add_library(opencv_highgui SHARED IMPORTED)
set_target_properties(opencv_highgui PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/libs/arm64-v8a/libopencv_highgui.so)

add_library(opencv_imgproc SHARED IMPORTED)
set_target_properties(opencv_imgproc PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/libs/arm64-v8a/libopencv_imgproc.so)

add_library(opencv_imgcodecs SHARED IMPORTED)
set_target_properties(opencv_imgcodecs PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/libs/arm64-v8a/libopencv_imgcodecs.so)

add_library(opencv_dnn SHARED IMPORTED)
set_target_properties(opencv_dnn PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/libs/arm64-v8a/libopencv_dnn.so)

add_library(opencv_core SHARED IMPORTED)
set_target_properties(opencv_core PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/Opencv-4.6.0/product/arm64-v8a/sdk/native/libs/arm64-v8a/libopencv_core.so)

add_library(x264 SHARED IMPORTED)
set_target_properties(x264 PROPERTIES IMPORTED_LOCATION /home/sjy/zzc/ncnn-android-yolov8/app/src/main/jni/X264/product/arm64-v8a/lib/libx264.so)


add_library(yolov8ncnn SHARED yolov8ncnn.cpp yolo.cpp  ndkcamera.cpp )

target_link_libraries(yolov8ncnn ncnn ${OpenCV_LIBS} camera2ndk mediandk
        # opencv
        opencv_videoio
        opencv_photo
        opencv_highgui
        opencv_imgproc
        opencv_imgcodecs
        opencv_dnn
        opencv_core


        ${avformat}
        ${avdevice}
        ${avcodec}
        ${avutil}
        ${swscale}
        ${swresample}
        ${avfilter}




        ${x264}


        # android jni库
        jnigraphics
        android
        log
        )
