* @file main.c
* @author Nations
* @version v1.0.0
*
* @copyright Copyright (c) 2019, Nations Technologies Inc. All rights reserved.
*/
#define HSE_VALUE (40000000)
#include <stdio.h>
#include "main.h"
#include "sys_var.h"
#include "key.h"
#include "n32g43x_gpio.h"
int main(void)
{
/* System Clocks Configuration */
RCC_Configuration();
/* NVIC configuration */
NVIC_Configuration();
/* Configure the GPIO ports */
GPIO_Configuration();
/* USART configuration */
USART_Configuration();
/* TIM Configuration */
TIM_Configuration();
DelayMs(200);//待上电稳定
ADC_Initial();
//检测上电类型
if(1)
{
/* Check if the system has resumed from solft reset */
if (RCC_GetFlagStatus(RCC_CTRLSTS_FLAG_SFTRSTF) != RESET)
{
/* solft reset flag set */
printf("\n\rsystem solft reset\n\r\n\r");
/* Clear reset flags */
RCC_ClrFlag();
}
else
{
/* WWDGRST flag is not set */
printf("\n\rnormal power on\n\r\n\r");
}
}
PrintSystemClock();
gpio_func_init();
printf("\n\r seat 8 io project\n\rbuild datetime : %s %s\n\r",__DATE__,__TIME__);
//printf("\n\rwhile\n\r");
mode_state = 1;
air_bag_ctrl.current_mode = mode_state;
air_bag_ctrl.schedule_table_pntr = air_bag_schedule_table[mode_state];
TimeOutSet(&StopWork_Timer, work_mode_total_duration[mode_state]);
statck_init();
statck_push(&air_bag_ctrl.schedule_table_pntr[0]);
while (1)
{
/* running led*/
{
if(IsTimeOut(&LedTimer))
{
TimeOutSet(&LedTimer,1000);
GpioToggle(LED);
}
}
#ifdef FY_1KEY_3LED
/* mode led */
set_led_mode(mode_state);
/* key led */
GpioSetOut(LED5,1);
// if(!GpioGet(KEY6))
// {
// GpioSetOut(LED5,1);
// }
// else
// {
// GpioSetOut(LED5,0);
// }
#endif
/* key func */
//if (IsTimeOut(&KeyScanTimer))
{
keyScan();
if( key_mode == KEY_MODE_ADC)
{
AdcKeyFunc();
//TimeOutSet(&KeyScanTimer,50);
}
if( key_mode == KEY_MODE_GPIO)
{
GpioKeyFunc();
//TimeOutSet(&KeyScanTimer,80);
}
}
}
}
/**
* @}
*/
/**
* @}
*/
#include "app.h"
#include "key.h"
#include "sys_var.h"
#ifdef FY_1KEY_3LED
void set_led_mode(uint8_t mode)
{
if(mode == 0x1)
{
GpioSetOut(LED4,1);
GpioSetOut(LED3,0);
GpioSetOut(LED2,0);
}
else if(mode == 0x2)
{
GpioSetOut(LED4,1);
GpioSetOut(LED3,1);
GpioSetOut(LED2,0);
}
else if(mode == 0x3)
{
GpioSetOut(LED4,1);
GpioSetOut(LED3,1);
GpioSetOut(LED2,1);
}
else
{
GpioSetOut(LED4,0);
GpioSetOut(LED3,0);
GpioSetOut(LED2,0);
}
}
#endif
void air_bag_init(void)
{
GpioInitOut( SW1 );
GpioInitOut( SW2 );
GpioInitOut( SW3 );
GpioInitOut( SW4 );
GpioInitOut( SW5 );
GpioInitOut( SW6 );
GpioInitOut( SW7 );
GpioInitOut( SW8 );
GpioInitOut( SW9 );
GpioInitOut( SW10 );
//GpioInitOut( SW11 );
//GpioInitOut( SW12 );
GpioInitOut( POWER_FB );
GpioInitOut( POWER_EN );
GpioInitOut( MOTOR_PWM);
GpioSetOut( SW1 ,0);
GpioSetOut( SW2 ,0);
GpioSetOut( SW3 ,0);
GpioSetOut( SW4 ,0);
GpioSetOut( SW5 ,0);
GpioSetOut( SW6 ,0);
GpioSetOut( SW7 ,0);
GpioSetOut( SW8 ,0);
GpioSetOut( SW9 ,0);
GpioSetOut( SW10 ,0);
//GpioSetOut( SW11 ,0);
//GpioSetOut( SW12 ,0);
GpioSetOut( POWER_FB ,1);
GpioSetOut( POWER_EN ,0);
GpioSetOut( MOTOR_PWM,0);
}
void air_bag_idle(void)
{
POWER_OFF;
MOTOR_OFF;
GpioSetOut( SW1 ,0);
GpioSetOut( SW2 ,0);
GpioSetOut( SW3 ,0);
GpioSetOut( SW4 ,0);
GpioSetOut( SW5 ,0);
GpioSetOut( SW6 ,0);
GpioSetOut( SW7 ,0);
GpioSetOut( SW8 ,0);
GpioSetOut( SW9 ,0);
GpioSetOut( SW10 ,0);
//GpioSetOut( SW11 ,0);
//GpioSetOut( SW12 ,0);
}
void air_bag_out(void)
{
GpioSetOut( SW1 ,0);
GpioSetOut( SW2 ,0);
GpioSetOut( SW3 ,0);
GpioSetOut( SW4 ,0);
GpioSetOut( SW5 ,0);
GpioSetOut( SW6 ,0);
GpioSetOut( SW7 ,0);
GpioSetOut( SW8 ,0);
GpioSetOut( SW9 ,0);
GpioSetOut( SW10 ,0);
}
void gpio_func_init(void)
{
#ifdef FY_1KEY_3LED
GpioInitIn(KEY6);
#elif defined(FY_1KEY_NOLED)
GpioInitIn(KEY4);
#endif
#ifdef FY_1KEY_3LED
GpioInitOut(LED);
GpioSetOut(LED,0);
GpioInitOut(LED2);
GpioSetOut(LED2,0);
GpioInitOut(LED3);
GpioSetOut(LED3,0);
GpioInitOut(LED4);
GpioSetOut(LED4,0);
GpioInitOut(LED5);
GpioSetOut(LED5,0);
#endif
air_bag_init();
}
void AdcKeyFunc(void)
{
static unsigned char last_adckey_code = 0;
static unsigned char last_adckey_type = 0;
if(( last_adckey_code != key.KeyEventCode || last_adckey_type != key.KeyEventType)
)
{
if(key.KeyEventCode > 0 && key.KeyEventType > 0 )
printf("\n\rADC key KeyEventCode : %d KeyEventType : %d \n\r",key.KeyEventCode , key.KeyEventType);
if( key.KeyEventCode == ADC_KEY_CODE_UP && key.KeyScanState >= KEYSCANSTATE_HOLD)
{
{
//上充下放
POWER_ON;
MOTOR_ON;
#ifdef FY_SEAT_10
WAIST_1_IN;
WAIST_2_OUT;
#endif
air_bag_out();
}
air_bag_ctrl.current_mode = SEAT_FUNC_MODE_IDLE;
TimeOutSet(&Out_15S_Before_Stop_Timer,0);
mode_state = 0;
}
else if( key.KeyEventCode == ADC_KEY_CODE_DOWN && key.KeyScanState >= KEYSCANSTATE_HOLD)
{
{
//下充上放
POWER_ON;
MOTOR_ON;
#ifdef FY_SEAT_10
WAIST_2_IN;
WAIST_1_OUT;
#endif
air_bag_out();
}
air_bag_ctrl.current_mode = SEAT_FUNC_MODE_IDLE;
TimeOutSet(&Out_15S_Before_Stop_Timer,0);
mode_state = 0;
}
else if( key.KeyEventCode == ADC_KEY_CODE_LEFT && key.KeyScanState >= KEYSCANSTATE_HOLD)
{
{
//全充
POWER_ON;
MOTOR_ON;
#ifdef FY_SEAT_10
WAIST_1_IN;
WAIST_2_IN;
#endif
air_bag_out();
}
air_bag_ctrl.current_mode = SEAT_FUNC_MODE_IDLE;
TimeOutSet(&Out_15S_Before_Stop_Timer,0);
mode_state = 0;
}
else if( key.KeyEventCode == ADC_KEY_CODE_RIGHT && key.KeyScanState >= KEYSCANSTATE_HOLD)
{
{
//全放
POWER_ON;
MOTOR_OFF;
#ifdef FY_SEAT_10
WAIST_1_OUT;
WAIST_2_OUT;
#endif
air_bag_out();
}
air_bag_ctrl.current_mode = SEAT_FUNC_MODE_IDLE;
TimeOutSet(&Out_15S_Before_Stop_Timer,0);
mode_state = 0;
}
else if( key.KeyEventCode == ADC_KEY_CODE_OK)
{
if( key.KeyEventType == KEYTYPE_HOLD)
{
printf("\n\rkey hold\n\r");
TimeOutSet(&ModeSwitch_Timer,1000);
if(mode_state)
{
mode_state = 0;
}
else
{
mode_state = 1;
}
air_bag_ctrl.current_mode = mode_state;
air_bag_ctrl.schedule_table_pntr = air_bag_schedule_table[air_bag_ctrl.current_mode];
air_bag_ctrl.current_schedule_index = 0;
air_bag_ctrl.last_schedule_index = 0;
air_bag_ctrl.current_schedule_duration = 0;
TimeOutSet(&StopWork_Timer,work_mode_total_duration[mode_state]);
statck_init();
air_bag_idle();
statck_push(&air_bag_ctrl.schedule_table_pntr[0]);
printf(" air_bag_ctrl.current_mode : %d\r\n",air_bag_ctrl.current_mode);
}
else if( key.KeyEventType == KEYTYPE_SINGLE)
{
//printf("\n\radc key down \n\r");
TimeOutSet(&ModeSwitch_Timer,1000);
if(mode_state)
{
mode_state = (mode_state + 1) % SEAT_FUNC_MODE_AMOUNT ;
if(mode_state == 0)
mode_state = 1;
}
air_bag_ctrl.current_mode = mode_state;
air_bag_ctrl.schedule_table_pntr = air_bag_schedule_table[air_bag_ctrl.current_mode];
air_bag_ctrl.current_schedule_index = 0;
air_bag_ctrl.last_schedule_index = 0;
air_bag_ctrl.current_schedule_duration = 0;
TimeOutSet(&StopWork_Timer,work_mode_total_duration[mode_state]);
statck_init();
air_bag_init();
statck_push(&air_bag_ctrl.schedule_table_pntr[0]);
printf(" air_bag_ctrl.current_mode : %d\r\n",air_bag_ctrl.current_mode);
}
#ifdef FY_SEAT_10
WAIST_1_IDLE;
WAIST_2_IDLE;
#endif
}
else
{
//无按键动作
if(!IsTimeOut(&Out_15S_Before_Stop_Timer))
{
{
//放气15S
POWER_ON;
MOTOR_OFF;
air_bag_idle();
}
}
else if(mode_state == 0)
{
//闭气
air_bag_idle();
POWER_OFF;
MOTOR_OFF;
#ifdef FY_SEAT_10
WAIST_1_IDLE;
WAIST_2_IDLE;
#endif
}
}
last_adckey_code = key.KeyEventCode;
last_adckey_type = key.KeyEventType;
}
// else if(mode_state) //循环工作中
// {
// if( key.KeyEventCode == ADC_KEY_CODE_OK && key.KeyEventType == KEYTYPE_LONGPRES)
// {
// //退出循环工作
// air_bag_ctrl.current_mode = SEAT_FUNC_MODE_IDLE;
// air_bag_ctrl.autoWorkFlag = 0;
// TimeOutSet(&Out_15S_Before_Stop_Timer,SECOND_15);
// }
// }
}
void GpioKeyFunc(void)
{
static unsigned char last_key_code = 0;
static unsigned char last_key_type = 0;
/* LED KEY */
if(last_key_code != key.KeyEventCode || last_key_type != key.KeyEventType)
{
if(key.KeyEventCode > 0 && key.KeyEventType > 0 )
printf("\n\rGPIO key KeyEventCode : %d KeyEventType : %d \n\r",key.KeyEventCode , key.KeyEventType);
if( key.KeyEventCode == GPIO_KEY_CODE_K6 && key.KeyEventType == KEYTYPE_SINGLE)
{
//printf("\n\rgpio key down \n\r");
TimeOutSet(&ModeSwitch_Timer,1000);
//if(mode_state)
{
mode_state = (mode_state + 1) % 4 ;
}
air_bag_ctrl.current_mode = mode_state;
air_bag_ctrl.schedule_table_pntr = air_bag_schedule_table[air_bag_ctrl.current_mode];
air_bag_ctrl.current_schedule_index = 0;
air_bag_ctrl.last_schedule_index = 0;
air_bag_ctrl.current_schedule_duration = 0;
TimeOutSet(&StopWork_Timer,work_mode_total_duration[mode_state]);
statck_init();
air_bag_init();
statck_push(&air_bag_ctrl.schedule_table_pntr[0]);
// printf(" air_bag_ctrl.current_mode : %d\r\n",air_bag_ctrl.current_mode);
}
last_key_code = key.KeyEventCode;
last_key_type = key.KeyEventType;
}
}
/**
* @file n32g43x_it.c
* @author Nations
* @version v1.0.0
*
* @copyright Copyright (c) 2019, Nations Technologies Inc. All rights reserved.
*/
#include <stdio.h>
#include "n32g43x_it.h"
#include "bsp.h"
#include "sys_var.h"
#include "util.h"
extern uint8_t mode_state;
/** @addtogroup N32G43X_StdPeriph_Template
* @{
*/
/******************************************************************************/
/* Cortex-M4 Processor Exceptions Handlers */
/******************************************************************************/
/**
* @brief This function handles NMI exception.
*/
void NMI_Handler(void)
{
}
/**
* @brief This function handles Hard Fault exception.
*/
void HardFault_Handler(void)
{
/* Go to infinite loop when Hard Fault exception occurs */
while (1)
{
}
}
/**
* @brief This function handles Memory Manage exception.
*/
void MemManage_Handler(void)
{
/* Go to infinite loop when Memory Manage exception occurs */
while (1)
{
}
}
/**
* @brief This function handles Bus Fault exception.
*/
void BusFault_Handler(void)
{
/* Go to infinite loop when Bus Fault exception occurs */
while (1)
{
}
}
/**
* @brief This function handles Usage Fault exception.
*/
void UsageFault_Handler(void)
{
/* Go to infinite loop when Usage Fault exception occurs */
while (1)
{
}
}
/**
* @brief This function handles SVCall exception.
*/
void SVC_Handler(void)
{
}
/**
* @brief This function handles Debug Monitor exception.
*/
void DebugMon_Handler(void)
{
}
/**
* @brief This function handles SysTick Handler.
*/
void SysTick_Handler(void)
{
}
/**
* @brief This function handles TIM2 update interrupt request.
*/
void TIM2_IRQHandler(void)
{
if (TIM_GetIntStatus(TIM2, TIM_INT_UPDATE) != RESET) //1ms 定时中断
{
TIM_ClrIntPendingBit(TIM2, TIM_INT_UPDATE);//重置定时器
//软定时器滴答
TimerTickHandler();
if( (air_bag_ctrl.current_mode != SEAT_FUNC_MODE_IDLE && !IsTimeOut(&StopWork_Timer) && IsTimeOut(&ModeSwitch_Timer) ))
{
int stack_idx;
for(stack_idx = 0;stack_idx < STACK_SIZE;stack_idx++)
{
if (schedule_stack[stack_idx].IsUsed)
{
if (schedule_stack[stack_idx].InDuration > 0)
{
//充气
POWER_ON;
air_bag_set_in(schedule_stack[stack_idx].OpAirBagGroup);
schedule_stack[stack_idx].InDuration --;
}
else
{
if (schedule_stack[stack_idx].OutDuration > 0)
{
//放气
POWER_ON;
air_bag_set_out(schedule_stack[stack_idx].OpAirBagGroup);
schedule_stack[stack_idx].OutDuration --;
if (schedule_stack[stack_idx].OutDuration == 0)
{
//停止放气
//放气完毕,出栈
//printf("out end idx %d\r\n",schedule_stack[stack_idx].sch_idx);
statck_pop(stack_idx);
if(0)
{
int i;
for (i = 0; i < STACK_SIZE; i++)
{
//printf(" st_idx : %d is_used : %d sch_idx : %d InD :%d OutD :%d NexD : %d \r\n",i,schedule_stack[i].IsUsed,schedule_stack[i].sch_idx,schedule_stack[i].InDuration,schedule_stack[i].OutDuration,schedule_stack[i].NextOpDuration);
}
}
}
}
}
if (schedule_stack[stack_idx].NextOpDuration > 0)
{
schedule_stack[stack_idx].NextOpDuration --;
//下一动作入栈
if (schedule_stack[stack_idx].NextOpDuration == 0)
{
if(schedule_stack[stack_idx].sch_idx + 1 <= schedule_stack[stack_idx].sch_idx_max)
{
statck_push(&air_bag_ctrl.schedule_table_pntr[schedule_stack[stack_idx].sch_idx+1]);
//printf("next op idx %d\r\n",schedule_stack[stack_idx].sch_idx + 1);
{
int i;
for (i = 0; i < STACK_SIZE; i++)
{
//printf(" st_idx : %d is_used : %d sch_idx : %d InD :%d OutD :%d NexD : %d \r\n",i,schedule_stack[i].IsUsed,schedule_stack[i].sch_idx,schedule_stack[i].InDuration,schedule_stack[i].OutDuration,schedule_stack[i].NextOpDuration);
}
}
}
else
{
statck_push(&air_bag_ctrl.schedule_table_pntr[0]);
//printf("cycle end return 0 idx %d\r\n",schedule_stack[stack_idx].sch_idx);
{
int i;
for (i = 0; i < STACK_SIZE; i++)
{
//printf(" st_idx : %d is_used : %d sch_idx : %d InD :%d OutD :%d NexD : %d \r\n",i,schedule_stack[i].IsUsed,schedule_stack[i].sch_idx,schedule_stack[i].InDuration,schedule_stack[i].OutDuration,schedule_stack[i].NextOpDuration);
}
}
}
}
}
if(schedule_stack[stack_idx].InDuration == 0 &&
schedule_stack[stack_idx].OutDuration == 0 &&
schedule_stack[stack_idx].NextOpDuration == 0)
{
statck_pop(stack_idx);
}
}
}
}
else if( (air_bag_ctrl.current_mode != SEAT_FUNC_MODE_IDLE && IsTimeOut(&StopWork_Timer)))
{
statck_init();
air_bag_idle();
mode_state = 0;
air_bag_ctrl.current_mode = SEAT_FUNC_MODE_IDLE;
printf(" timeout air_bag_ctrl.current_mode : %d\r\n",air_bag_ctrl.current_mode);
}
}
}
/**
* @brief This function handles lin usart interrupt request.
*/
void USART_LIN_S_IRQHandler(void)
{
}
void EXTI15_10_IRQHandler(void)
{
#ifdef CFG_LOW_POWER_MODE
if (EXTI_GetITStatus(LPM_WAKEUP_LINE) != RESET)
{
/* Clear the Key Button EXTI line pending bit */
EXTI_ClrITPendBit(LPM_WAKEUP_LINE);
}
#endif
}
/**
* @}
*/
/*****************************************************************************
* Copyright (c) 2022, Nations Technologies Inc.
*
* All rights reserved.
* ****************************************************************************/
/**
* @file bsp.c
* @author Nations
* @version V1.2.2
*/
#include <stdio.h>
#include "bsp.h"
USART_InitType USART_InitStructure;
TIM_TimeBaseInitType TIM_TimeBaseStructure;
/**
* @brief Configures GPIO.
* @param GPIOx x can be A to G to select the GPIO port.
* @param Pin This parameter can be GPIO_PIN_0~GPIO_PIN_15.
*/
void GpioInitOut(GPIO_Module* GPIOx, uint16_t Pin)
{
GPIO_InitType GPIO_InitStructure;
/* Check the parameters */
assert_param(IS_GPIO_ALL_PERIPH(GPIOx));
/* Enable the GPIO Clock */
if (GPIOx == GPIOA)
{
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOA, ENABLE);
}
else if (GPIOx == GPIOB)
{
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOB, ENABLE);
}
else if (GPIOx == GPIOC)
{
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOC, ENABLE);
}
else if (GPIOx == GPIOD)
{
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOD, ENABLE);
}
/* Configure the GPIO pin */
if (Pin <= GPIO_PIN_ALL)
{
GPIO_InitStruct(&GPIO_InitStructure);
GPIO_InitStructure.Pin = Pin;
GPIO_InitStructure.GPIO_Current = GPIO_DC_12mA;
GPIO_InitStructure.GPIO_Pull = GPIO_Pull_Up;
GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP;
GPIO_InitPeripheral(GPIOx, &GPIO_InitStructure);
}
}
/**
* @brief Configures GPIO.
* @param GPIOx x can be A to G to select the GPIO port.
* @param Pin This parameter can be GPIO_PIN_0~GPIO_PIN_15.
*/
void GpioInitIn(GPIO_Module* GPIOx, uint16_t Pin)
{
GPIO_InitType GPIO_InitStructure;
/* Check the parameters */
assert_param(IS_GPIO_ALL_PERIPH(GPIOx));
/* Enable the GPIO Clock */
if (GPIOx == GPIOA)
{
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOA, ENABLE);
}
else if (GPIOx == GPIOB)
{
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOB, ENABLE);
}
else if (GPIOx == GPIOC)
{
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOC, ENABLE);
}
else if (GPIOx == GPIOD)
{
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOD, ENABLE);
}
/* Configure the GPIO pin */
if (Pin <= GPIO_PIN_ALL)
{
GPIO_InitStruct(&GPIO_InitStructure);
GPIO_InitStructure.Pin = Pin;
GPIO_InitStructure.GPIO_Pull = GPIO_Pull_Up;
GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Input;
GPIO_InitPeripheral(GPIOx, &GPIO_InitStructure);
}
}
/**
* @brief Turns selected gpio as output low/hight level.
* @param GPIOx x can be A to G to select the GPIO port.
* @param Pin This parameter can be GPIO_PIN_0~GPIO_PIN_15.
* @param value This parameter can be 0/1.
*/
void GpioSetOut(GPIO_Module* GPIOx, uint16_t Pin,uint8_t value)
{
GPIO_InitType GPIO_InitStructure;
if(value)
{
/* Configure the GPIO pin */
if (Pin <= GPIO_PIN_ALL)
{
GPIO_InitStruct(&GPIO_InitStructure);
GPIO_InitStructure.Pin = Pin;
GPIO_InitStructure.GPIO_Current = GPIO_DC_12mA;
GPIO_InitStructure.GPIO_Pull = GPIO_Pull_Up;
GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP;
GPIO_InitPeripheral(GPIOx, &GPIO_InitStructure);
}
GPIOx->PBSC = Pin;
}
else
{
/* Configure the GPIO pin */
if (Pin <= GPIO_PIN_ALL)
{
GPIO_InitStruct(&GPIO_InitStructure);
GPIO_InitStructure.Pin = Pin;
GPIO_InitStructure.GPIO_Current = GPIO_DC_4mA;
GPIO_InitStructure.GPIO_Pull = GPIO_No_Pull;
GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP;
GPIO_InitPeripheral(GPIOx, &GPIO_InitStructure);
}
GPIOx->PBC = Pin;
}
}
/**
* @brief Toggles the selected gpio.
* @param GPIOx x can be A to G to select the GPIO port.
* @param Pin This parameter can be GPIO_PIN_0~GPIO_PIN_15.
*/
uint8_t GpioGet(GPIO_Module* GPIOx, uint16_t Pin)
{
return GPIO_ReadInputDataBit(GPIOx, Pin);
}
/**
* @brief Toggles the selected gpio.
* @param GPIOx x can be A to G to select the GPIO port.
* @param Pin This parameter can be GPIO_PIN_0~GPIO_PIN_15.
*/
void GpioToggle(GPIO_Module* GPIOx, uint16_t Pin)
{
GPIOx->POD ^= Pin;
}
/**
* @brief Configures tim2 clocks.
*/
void TIM_Configuration(void)
{
/*
公式1:频率Fpwm = 1/T周期 = TIMER_CLK/[(Period+1)*(Prescaler+1)]
①、TIMER_CLK是TIMEx挂在系统时钟APB1总线上的时钟频率;
②、Period是设置在下一个更新事件装入活动的自动重装载寄存器周期的值(计数值);
③、Prescaler是预分频值;
④、频率单位:hz,周期单位:s;
*/
/* Time base configuration */
TIM_InitTimBaseStruct(&TIM_TimeBaseStructure);
TIM_TimeBaseStructure.Period = 5;
TIM_TimeBaseStructure.Prescaler = 8999;
TIM_TimeBaseStructure.ClkDiv = 0;
TIM_TimeBaseStructure.CntMode = TIM_CNT_MODE_UP;
TIM_InitTimeBase(TIM2, &TIM_TimeBaseStructure);
/* TIM2 enable update irq */
TIM_ConfigInt(TIM2, TIM_INT_UPDATE, ENABLE);
/* TIM2 enable counter */
TIM_Enable(TIM2, ENABLE);
}
/**
* @brief Configures the different system clocks.
*/
void RCC_Configuration(void)
{
/* PCLK1 = HCLK/4 */
RCC_ConfigPclk2(RCC_HCLK_DIV1);
/* TIM2 clock enable */
RCC_EnableAPB1PeriphClk(RCC_APB1_PERIPH_TIM2, ENABLE);
#ifdef _UART_DEBUG_
/* Enable GPIO clock */
UART_DEBUG_GPIO_APBxClkCmd(UART_DEBUG_GPIO_CLK, ENABLE);
/* Enable UART_DEBUG_CLK Clock */
UART_DEBUG_APBxClkCmd(UART_DEBUG_CLK, ENABLE);
#endif
}
/**
* @brief Configures the different GPIO ports.
*/
void GPIO_Configuration(void)
{
GPIO_InitType GPIO_InitStructure;
/* Initialize GPIO_InitStructure */
GPIO_InitStruct(&GPIO_InitStructure);
#ifdef _UART_DEBUG_
/* Initialize GPIO_InitStructure */
GPIO_InitStruct(&GPIO_InitStructure);
/* Configure LPUART Tx as alternate function push-pull */
GPIO_InitStructure.Pin = UART_DEBUG_TxPin;
GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP; /******重要 *******/
GPIO_InitStructure.GPIO_Alternate = UART_DEBUG_Tx_GPIO_AF;
GPIO_InitPeripheral(UART_DEBUG_GPIO, &GPIO_InitStructure);
/* Configure LPAURT Rx as alternate function push-pull and pull-up */
GPIO_InitStructure.Pin = UART_DEBUG_RxPin;
GPIO_InitStructure.GPIO_Pull = GPIO_Pull_Up; /******重要 *******/
GPIO_InitStructure.GPIO_Alternate = UART_DEBUG_Rx_GPIO_AF;
GPIO_InitPeripheral(UART_DEBUG_GPIO, &GPIO_InitStructure);
#endif
}
/**
* @brief Configures the nested vectored interrupt controller.
*/
void NVIC_Configuration(void)
{
NVIC_InitType NVIC_InitStructure;
/* Configure the NVIC Preemption Priority Bits */
NVIC_PriorityGroupConfig(NVIC_PriorityGroup_0);
/* Enable the TIM2 global Interrupt */
NVIC_InitStructure.NVIC_IRQChannel = TIM2_IRQn;
NVIC_InitStructure.NVIC_IRQChannelPreemptionPriority = 0;
NVIC_InitStructure.NVIC_IRQChannelSubPriority = 2;
NVIC_InitStructure.NVIC_IRQChannelCmd = ENABLE;
NVIC_Init(&NVIC_InitStructure);
#ifdef _UART_DEBUG_
/* Enable the LPUART Interrupt */
NVIC_InitStructure.NVIC_IRQChannel = UART5_IRQn;
NVIC_InitStructure.NVIC_IRQChannelPreemptionPriority = 0;
NVIC_InitStructure.NVIC_IRQChannelSubPriority = 1;
NVIC_InitStructure.NVIC_IRQChannelCmd = ENABLE;
NVIC_Init(&NVIC_InitStructure);
#endif
}
/* USART configuration ------------------------------------------------------*/
void USART_Configuration(void)
{
USART_InitType USART_InitStructure;
USART_StructInit(&USART_InitStructure);
#ifdef _UART_DEBUG_
USART_StructInit(&USART_InitStructure);
/* UART_DEBUG configuration ------------------------------------------------------*/
USART_InitStructure.BaudRate = 19200;
USART_InitStructure.WordLength = USART_WL_8B;
USART_InitStructure.StopBits = USART_STPB_1;
USART_InitStructure.Parity = USART_PE_NO;
USART_InitStructure.HardwareFlowControl = USART_HFCTRL_NONE;
USART_InitStructure.Mode = USART_MODE_RX | USART_MODE_TX;
USART_Init(UART_DEBUG, &USART_InitStructure);
/* Enable USARTz Receive and Transmit interrupts */
//USART_ConfigInt(UART_DEBUG, USART_INT_RXDNE, ENABLE);
//USART_ConfigInt(UART_DEBUG, USART_INT_TXDE, ENABLE);
/* Enable the UART_DEBUG */
USART_Enable(UART_DEBUG, ENABLE);
#endif
}
void ADC_Initial(void)
{
/* Enable GPIOB clocks */
RCC_EnableAPB2PeriphClk(RCC_APB2_PERIPH_GPIOB, ENABLE);
/* Enable ADC clocks */
RCC_EnableAHBPeriphClk(RCC_AHB_PERIPH_ADC, ENABLE);
/* RCC_ADCHCLK_DIV16*/
ADC_ConfigClk(ADC_CTRL3_CKMOD_AHB, RCC_ADCHCLK_DIV16);
RCC_ConfigAdc1mClk(RCC_ADC1MCLK_SRC_HSE, RCC_ADC1MCLK_DIV8); //selsect HSE as RCC ADC1M CLK Source
//GPIO_Configuration
{
GPIO_InitType GPIO_InitStructure;
GPIO_InitStruct(&GPIO_InitStructure);
/* Configure PC0 PC1 as analog input -------------------------*/
GPIO_InitStructure.Pin = ADC_KEY_PIN;
GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Analog;
GPIO_InitPeripheral(ADC_KEY_PORT, &GPIO_InitStructure);
}
// ADC Initial
{
ADC_InitType ADC_InitStructure;
/* ADC configuration ------------------------------------------------------*/
ADC_InitStructure.MultiChEn = DISABLE;
ADC_InitStructure.ContinueConvEn = DISABLE;
ADC_InitStructure.ExtTrigSelect = ADC_EXT_TRIGCONV_NONE;
ADC_InitStructure.DatAlign = ADC_DAT_ALIGN_R;
ADC_InitStructure.ChsNumber = 1;
ADC_Init(ADC, &ADC_InitStructure);
/* Enable ADC */
ADC_Enable(ADC, ENABLE);
/* Check ADC Ready */
while(ADC_GetFlagStatusNew(ADC,ADC_FLAG_RDY) == RESET)
;
/* Start ADC1 calibration */
ADC_StartCalibration(ADC);
/* Check the end of ADC1 calibration */
while (ADC_GetCalibrationStatus(ADC))
;
}
}
uint16_t ADC_GetData(uint8_t ADC_Channel)
{
uint16_t dat;
ADC_ConfigRegularChannel(ADC, ADC_Channel, 1, ADC_SAMP_TIME_55CYCLES5);
/* Start ADC Software Conversion */
ADC_EnableSoftwareStartConv(ADC,ENABLE);
while(ADC_GetFlagStatus(ADC,ADC_FLAG_ENDC)==0){
}
ADC_ClearFlag(ADC,ADC_FLAG_ENDC);
ADC_ClearFlag(ADC,ADC_FLAG_STR);
dat=ADC_GetDat(ADC);
return dat;
}
/**
* @brief 配置低功耗模式
* @param
* @param
*/
void LowPowrModeInit(void)
{
#ifdef CFG_LOW_POWER_MODE
printf("Low Power Mode Configuration\n");
/* Enable PWR and BKP clock */
RCC_EnableAPB1PeriphClk(RCC_APB1_PERIPH_PWR, ENABLE);
/* Enable WKUP pin */
PWR_WakeUpPinEnable(LPM_WAKEUP_NO, ENABLE);
#endif
}
/**
* @brief 打印系统时钟信息
* @param
* @param
*/
void PrintSystemClock(void)
{
RCC_ClocksType RCC_Clocks;
RCC_GetClocksFreqValue(&RCC_Clocks);
printf("SysclkFreq : %d\n", RCC_Clocks.SysclkFreq);
printf("HclkFreq : %d\n", RCC_Clocks.HclkFreq);
printf("Pclk1Freq : %d\n", RCC_Clocks.Pclk1Freq);
printf("Pclk2Freq : %d\n", RCC_Clocks.Pclk2Freq);
printf("AdcPllClkFreq : %d\n", RCC_Clocks.AdcPllClkFreq);
printf("AdcHclkFreq : %d\n", RCC_Clocks.AdcHclkFreq);
}
/**
* @brief Configures system clock after wake-up from low power mode: enable HSE, PLL
* and select PLL as system clock source.
* @param freq: PLL clock eg 108000000
* @param src
* This parameter can be one of the following values:
* @arg SYSCLK_PLLSRC_HSI,
* @arg SYSCLK_PLLSRC_HSIDIV2,
* @arg SYSCLK_PLLSRC_HSI_PLLDIV2,
* @arg SYSCLK_PLLSRC_HSIDIV2_PLLDIV2,
* @arg SYSCLK_PLLSRC_HSE,
* @arg SYSCLK_PLLSRC_HSEDIV2,
* @arg SYSCLK_PLLSRC_HSE_PLLDIV2,
* @arg SYSCLK_PLLSRC_HSEDIV2_PLLDIV2,
*/
void SetSysClockToPLL(uint32_t freq, uint32_t RCC_SYSCLKSource)
{
uint32_t pllsrcclk;
uint32_t pllsrc;
uint32_t pllmul;
uint32_t plldiv = RCC_PLLDIVCLK_DISABLE;
uint32_t latency;
uint32_t pclk1div, pclk2div;
uint32_t msi_ready_flag = RESET;
uint8_t src = SYSCLK_PLLSRC_HSE;
ErrorStatus HSEStartUpStatus;
ErrorStatus HSIStartUpStatus;
if (HSE_VALUE != 8000000)
{
/* HSE_VALUE == 8000000 is needed in this project! */
while (1);
}
/* SYSCLK, HCLK, PCLK2 and PCLK1 configuration */
if ((src == SYSCLK_PLLSRC_HSI) || (src == SYSCLK_PLLSRC_HSIDIV2)
|| (src == SYSCLK_PLLSRC_HSI_PLLDIV2) || (src == SYSCLK_PLLSRC_HSIDIV2_PLLDIV2))
{
/* Enable HSI */
RCC_ConfigHsi(RCC_HSI_ENABLE);
/* Wait till HSI is ready */
HSIStartUpStatus = RCC_WaitHsiStable();
if (HSIStartUpStatus != SUCCESS)
{
/* If HSI fails to start-up, the application will have wrong clock
configuration. User can add here some code to deal with this
error Go to infinite loop */
while (1);
}
if ((src == SYSCLK_PLLSRC_HSIDIV2) || (src == SYSCLK_PLLSRC_HSIDIV2_PLLDIV2))
{
pllsrc = RCC_PLL_HSI_PRE_DIV2;
pllsrcclk = HSI_VALUE/2;
if(src == SYSCLK_PLLSRC_HSIDIV2_PLLDIV2)
{
plldiv = RCC_PLLDIVCLK_ENABLE;
pllsrcclk = HSI_VALUE/4;
}
}
else if ((src == SYSCLK_PLLSRC_HSI) || (src == SYSCLK_PLLSRC_HSI_PLLDIV2))
{
pllsrc = RCC_PLL_HSI_PRE_DIV1;
pllsrcclk = HSI_VALUE;
if(src == SYSCLK_PLLSRC_HSI_PLLDIV2)
{
plldiv = RCC_PLLDIVCLK_ENABLE;
pllsrcclk = HSI_VALUE/2;
}
}
}
else if ((src == SYSCLK_PLLSRC_HSE) || (src == SYSCLK_PLLSRC_HSEDIV2)
|| (src == SYSCLK_PLLSRC_HSE_PLLDIV2) || (src == SYSCLK_PLLSRC_HSEDIV2_PLLDIV2))
{
/* Enable HSE */
RCC_ConfigHse(RCC_HSE_ENABLE);
/* Wait till HSE is ready */
HSEStartUpStatus = RCC_WaitHseStable();
if (HSEStartUpStatus != SUCCESS)
{
/* If HSE fails to start-up, the application will have wrong clock
configuration. User can add here some code to deal with this
error Go to infinite loop */
while (1);
}
if ((src == SYSCLK_PLLSRC_HSEDIV2) || (src == SYSCLK_PLLSRC_HSEDIV2_PLLDIV2))
{
pllsrc = RCC_PLL_SRC_HSE_DIV2;
pllsrcclk = HSE_VALUE/2;
if(src == SYSCLK_PLLSRC_HSEDIV2_PLLDIV2)
{
plldiv = RCC_PLLDIVCLK_ENABLE;
pllsrcclk = HSE_VALUE/4;
}
}
else if ((src == SYSCLK_PLLSRC_HSE) || (src == SYSCLK_PLLSRC_HSE_PLLDIV2))
{
pllsrc = RCC_PLL_SRC_HSE_DIV1;
pllsrcclk = HSE_VALUE;
if(src == SYSCLK_PLLSRC_HSE_PLLDIV2)
{
plldiv = RCC_PLLDIVCLK_ENABLE;
pllsrcclk = HSE_VALUE/2;
}
}
}
latency = (freq/32000000);
if(freq > 54000000)
{
pclk1div = RCC_HCLK_DIV4;
pclk2div = RCC_HCLK_DIV2;
}
else
{
if(freq > 27000000)
{
pclk1div = RCC_HCLK_DIV2;
pclk2div = RCC_HCLK_DIV1;
}
else
{
pclk1div = RCC_HCLK_DIV1;
pclk2div = RCC_HCLK_DIV1;
}
}
if(((freq % pllsrcclk) == 0) && ((freq / pllsrcclk) >= 2) && ((freq / pllsrcclk) <= 32))
{
pllmul = (freq / pllsrcclk);
if(pllmul <= 16)
{
pllmul = ((pllmul - 2) << 18);
}
else
{
pllmul = (((pllmul - 17) << 18) | (1 << 27));
}
}
else
{
while(1);
}
/* Cheak if MSI is Ready */
if(RESET == RCC_GetFlagStatus(RCC_CTRLSTS_FLAG_MSIRD))
{
/* Enable MSI and Config Clock */
RCC_ConfigMsi(RCC_MSI_ENABLE, RCC_MSI_RANGE_4M);
/* Waits for MSI start-up */
while(SUCCESS != RCC_WaitMsiStable());
msi_ready_flag = SET;
}
/* Select MSI as system clock source */
RCC_ConfigSysclk(RCC_SYSCLK_SRC_MSI);
FLASH_SetLatency(latency);
/* HCLK = SYSCLK */
RCC_ConfigHclk(RCC_SYSCLKSource);//RCC_SYSCLK_DIV1
/* PCLK2 = HCLK */
RCC_ConfigPclk2(pclk2div);
/* PCLK1 = HCLK */
RCC_ConfigPclk1(pclk1div);
/* Disable PLL */
RCC_EnablePll(DISABLE);
RCC_ConfigPll(pllsrc, pllmul, plldiv);
/* Enable PLL */
RCC_EnablePll(ENABLE);
/* Wait till PLL is ready */
while (RCC_GetFlagStatus(RCC_CTRL_FLAG_PLLRDF) == RESET);
/* Select PLL as system clock source */
RCC_ConfigSysclk(RCC_SYSCLK_SRC_PLLCLK);
/* Wait till PLL is used as system clock source */
while (RCC_GetSysclkSrc() != 0x0C);
if(msi_ready_flag == SET)
{
/* MSI oscillator OFF */
RCC_ConfigMsi(RCC_MSI_DISABLE, RCC_MSI_RANGE_4M);
}
}
void LPM_WakeupExtiInit(GPIO_Module* GPIOx, uint16_t Pin)
{
}
void AllGpioDeInit(void)
{
#ifdef _LPUART_DEBUG_
GpioInitIn(UART_DEBUG_GPIO,UART_DEBUG_TxPin);
GpioInitIn(UART_DEBUG_GPIO,UART_DEBUG_RxPin);
#endif
#ifdef _UART_DEBUG_
GpioInitIn(UART_DEBUG_GPIO,UART_DEBUG_TxPin);
GpioInitIn(UART_DEBUG_GPIO,UART_DEBUG_RxPin);
#endif
GpioInitIn(LED);
}
#ifdef _UART_DEBUG_
/* retarget the C library printf function to the LPUART */
int fputc(int ch, FILE* f)
{
USART_SendData(UART_DEBUG, (uint8_t)ch);
while (USART_GetFlagStatus(UART_DEBUG, USART_FLAG_TXDE) == RESET)
;
return (ch);
}
#endif
#if !defined(_LPUART_DEBUG_) && !defined(_UART_DEBUG_)
int fputc(int ch, FILE* f)
{
return (ch);
}
#endif
#ifdef USE_FULL_ASSERT
/**
* @brief Reports the name of the source file and the source line number
* where the assert_param error has occurred.
* @param file pointer to the source file name
* @param line assert_param error line source number
*/
void assert_failed(const uint8_t* expr, const uint8_t* file, uint32_t line)
{
/* User can add his own implementation to report the file name and line number,
ex: printf("Wrong parameters value: file %s on line %d\r\n", file, line) */
/* Infinite loop */
//while (1)
{
}
}
#endif
/**
* @}
*/
/**
* @}
*/
现在的初始化(配置)有问题吗?如何在只改细节的情况下修改
最新发布
