Mybatis-基本环境搭建

环境搭建流程

• mybatis的环境搭建
  • 创建maven工程并导入坐标
  • 创建实体类和dao的接口
  • 创建mybatis 的主配置文件 SqlMapConfig.xml文件
  • 创建映射配置文件UserDaoImpl.xm


案例代码

1.实体类-User

package edu.yjsj.domain;

import java.io.Serializable;

public class User implements Serializable {
    private int id;
    private String userName;
    private String userPwd;

    public int getId() {
        return id;
    }

    public void setId(int id) {
        this.id = id;
    }

    public String getUserName() {
        return userName;
    }

    public void setUserName(String userName) {
        this.userName = userName;
    }

    public String getUserPwd() {
        return userPwd;
    }

    public void setUserPwd(String userPwd) {
        this.userPwd = userPwd;
    }

    @Override
    public String toString() {
        return "User{" +
                "id=" + id +
                ", userName='" + userName + '\'' +
                ", userPwd='" + userPwd + '\'' +
                '}';
    }
}

2.JDBC接口-UserDaoImpl

package edu.yjsj.dao;

import edu.yjsj.domain.User;

import java.util.List;

public interface UserDaoImpl {
    public List<User> selectAll();
}

3.主配置文件-SqlMapConfig.xml

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE configuration
        PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
        "http://mybatis.org/dtd/mybatis-3-config.dtd">
<!-- mybatis的主配置文件 -->
<configuration>
    <!-- 配置环境 -->
    <environments default="mysql">
        <!-- 配置mysql环境 -->
        <environment id="mysql">
            <!-- 配置事务类型 -->
            <transactionManager type="JDBC"></transactionManager>
            <!-- 配置数据源（连接池） -->
            <dataSource type="POOLED">
                <!-- 配置数据库的四个基本信息 -->
                <property name="driver" value="com.mysql.jdbc.Driver"/>
                <property name="url" value="jdbc:mysql://182.92.198.191:3306/mybatis"/>
                <property name="username" value="root"/>
                <property name="password" value="123456"/>
            </dataSource>
        </environment>
    </environments>
    <!-- 指定映射文件的位置，映射配置文件指的是每个dao独立的配置文件 -->
    <mappers>
        <mapper resource="edu/yjsj/dao/UserDaoImpl.xml"/>
    </mappers>
</configuration>

配置主xml文件时，如同手写JDBC编程一样但是简化了很多，要注意的是== 指定映射文件的时候一定要写“/”来分文件夹级别，千万不要写成“.”否则会有如下错误==

4.映射配置文件- UserDaoImpl.xml

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
        "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="edu.yjsj.dao.UserDaoImpl">
    <!-- 配置查询所有 -->
    <select id="selectAll" resultType="edu.yjsj.domain.User">
        select * from user
    </select>
</mapper>

5.pom.xml文件

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>edu.yjsj</groupId>
    <artifactId>mybatis_01_eesy</artifactId>
    <version>1.0-SNAPSHOT</version>
    <packaging>jar</packaging>

    <dependencies>
        <dependency>
            <groupId>org.mybatis</groupId>
            <artifactId>mybatis</artifactId>
            <version>3.4.2</version>
        </dependency>
        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <version>5.1.44</version>
        </dependency>
        <dependency>
            <groupId>log4j</groupId>
            <artifactId>log4j</artifactId>
            <version>1.2.17</version>
        </dependency>
        <dependency>
            <groupId>junit</groupId>
            <artifactId>junit</artifactId>
            <version>4.12</version>
        </dependency>
    </dependencies>
</project>

6.log4j配置文件

### 设置###
log4j.rootLogger = debug,stdout,D,E

### 输出信息到控制抬 ###
log4j.appender.stdout = org.apache.log4j.ConsoleAppender
log4j.appender.stdout.Target = System.out
log4j.appender.stdout.layout = org.apache.log4j.PatternLayout
log4j.appender.stdout.layout.ConversionPattern = [%-5p] %d{yyyy-MM-dd HH:mm:ss,SSS} method:%l%n%m%n

### 输出DEBUG 级别以上的日志到=E://logs/error.log ###
log4j.appender.D = org.apache.log4j.DailyRollingFileAppender
log4j.appender.D.File = E://logs/log.log
log4j.appender.D.Append = true
log4j.appender.D.Threshold = DEBUG
log4j.appender.D.layout = org.apache.log4j.PatternLayout
log4j.appender.D.layout.ConversionPattern = %-d{yyyy-MM-dd HH:mm:ss}  [ %t:%r ] - [ %p ]  %m%n

### 输出ERROR 级别以上的日志到=E://logs/error.log ###
log4j.appender.E = org.apache.log4j.DailyRollingFileAppender
log4j.appender.E.File =E://logs/error.log
log4j.appender.E.Append = true
log4j.appender.E.Threshold = ERROR
log4j.appender.E.layout = org.apache.log4j.PatternLayout
log4j.appender.E.layout.ConversionPattern = %-d{yyyy-MM-dd HH:mm:ss}  [ %t:%r ] - [ %p ]  %m%n

7.主测试类-main

package edu.yjsj.test;

import edu.yjsj.dao.UserDaoImpl;
import edu.yjsj.domain.User;
import org.apache.ibatis.io.Resources;
import org.apache.ibatis.session.SqlSession;
import org.apache.ibatis.session.SqlSessionFactory;
import org.apache.ibatis.session.SqlSessionFactoryBuilder;

import java.io.InputStream;
import java.util.List;

/**
 * mybatis的入门案例
 */
public class MybatisTest {
    public static void main(String[] args) throws Exception {
        //1.读取配置文件
        InputStream in = Resources.getResourceAsStream("SqlMapConfig.xml");
        //2.创建SqlSessionFactory工厂
        SqlSessionFactoryBuilder builder = new SqlSessionFactoryBuilder();
        SqlSessionFactory factory = builder.build(in);
        //3.使用工厂产生SqlSession对象
        SqlSession session = factory.openSession();
        //4.使用SqlSession创建Dao接口的代理对象
        UserDaoImpl userDao = session.getMapper(UserDaoImpl.class);
        //5.使用代理对象执行方法
        List<User> userList = userDao.selectAll();
        for (User user:userList) {
            System.out.println(user);
        }
        //6.释放资源
        session.close();
        in.close();
    }
}

8.测试结果

9.学习总结mybatis通过配置文件的形式达到编程结果，是过程简单，同时有很高的可移植性
