SpringAop解析流程

@Target(ElementType.TYPE)
@Retention(RetentionPolicy.RUNTIME)
@Documented
@Import(AspectJAutoProxyRegistrar.class)
public @interface EnableAspectJAutoProxy {

	/**
	 * 指示是否要创建基于子类（CGLIB）的代理，而不是基于标准Java接口的代理。
	 * 而不是基于标准Java接口的代理。默认是{@code false}。
	 */
	boolean proxyTargetClass() default false;

	/**
	 * 表示代理应该被AOP框架作为{@code ThreadLocal}公开，以便通过{@link org.springframework.aop.framework.AopContext}类进行检索。
	 * 用于通过{@link org.springframework.aop.framework.AopContext}类进行检索。
	 * 默认情况下是关闭的，即不保证{@code AopContext}的访问会有效。
	 * @since 4.3.1
	 */
	boolean exposeProxy() default false;

}

class AspectJAutoProxyRegistrar implements ImportBeanDefinitionRegistrar {

	/**
	 * 注册、升级和配置AspectJ自动代理创建者，其依据是导入的@{@link EnableAspectJAutoProxy#proxyTargetClass()}属性的值。
	 * {@code @Configuration}类的属性。
	 */
	@Override
	public void registerBeanDefinitions(
			AnnotationMetadata importingClassMetadata, BeanDefinitionRegistry registry) {
		//注册AnnotationAwareAspectJAutoProxyCreator为BeanDefinition
		AopConfigUtils.registerAspectJAnnotationAutoProxyCreatorIfNecessary(registry);
		// 从配置类里面获取注解EnableAspectJAutoProxy的属性
		AnnotationAttributes enableAspectJAutoProxy =
				AnnotationConfigUtils.attributesFor(importingClassMetadata, EnableAspectJAutoProxy.class);
		/**
		 * 根据配置类EnableAspectJAutoProxy注解的属性proxyTargetClass，exposeProxy
		 * 如果为true的话就将键值对绑定到BeanDefinition的PropertyValues
		 */
		if (enableAspectJAutoProxy != null) {
			if (enableAspectJAutoProxy.getBoolean("proxyTargetClass")) {
				AopConfigUtils.forceAutoProxyCreatorToUseClassProxying(registry);
			}
			if (enableAspectJAutoProxy.getBoolean("exposeProxy")) {
				AopConfigUtils.forceAutoProxyCreatorToExposeProxy(registry);
			}
		}
	}
}

@Nullable
	public static BeanDefinition registerAspectJAnnotationAutoProxyCreatorIfNecessary(BeanDefinitionRegistry registry) {
		return registerAspectJAnnotationAutoProxyCreatorIfNecessary(registry, null);
	}

@Nullable
	public static BeanDefinition registerAspectJAnnotationAutoProxyCreatorIfNecessary(
			BeanDefinitionRegistry registry, @Nullable Object source) {
		return registerOrEscalateApcAsRequired(AnnotationAwareAspectJAutoProxyCreator.class, registry, source);
	}

private static BeanDefinition registerOrEscalateApcAsRequired(
			Class<?> cls, BeanDefinitionRegistry registry, @Nullable Object source) {

		Assert.notNull(registry, "BeanDefinitionRegistry must not be null");
		/**
		 * 判断bf里面是否有org.springframework.aop.config.internalAutoProxyCreator这个类
		 */
		if (registry.containsBeanDefinition(AUTO_PROXY_CREATOR_BEAN_NAME)) {
			BeanDefinition apcDefinition = registry.getBeanDefinition(AUTO_PROXY_CREATOR_BEAN_NAME);
			if (!cls.getName().equals(apcDefinition.getBeanClassName())) {
				int currentPriority = findPriorityForClass(apcDefinition.getBeanClassName());
				int requiredPriority = findPriorityForClass(cls);
				if (currentPriority < requiredPriority) {
					apcDefinition.setBeanClassName(cls.getName());
				}
			}
			return null;
		}
		/**
		 * 构建名称org.springframework.aop.config.internalAutoProxyCreator的bd设置一些属性
		 * 注册到beanDefinitionMap里面
		 */
		RootBeanDefinition beanDefinition = new RootBeanDefinition(cls);
		//默认为null
		beanDefinition.setSource(source);
		beanDefinition.getPropertyValues().add("order", Ordered.HIGHEST_PRECEDENCE);
		beanDefinition.setRole(BeanDefinition.ROLE_INFRASTRUCTURE);
		registry.registerBeanDefinition(AUTO_PROXY_CREATOR_BEAN_NAME, beanDefinition);
		return beanDefinition;
	}

@Override
	public Object postProcessBeforeInstantiation(Class<?> beanClass, String beanName) {
		/**
		 * 创建缓存key
		 *          该bean如果是FactoryBean就添加前缀&
		 */
		Object cacheKey = getCacheKey(beanClass, beanName);

		if (!StringUtils.hasLength(beanName) || !this.targetSourcedBeans.contains(beanName)) {
			if (this.advisedBeans.containsKey(cacheKey)) {
				return null;
			}
			/**
			 * 判断是否是Advice|Pointcut|Advisor|AopInfrastructureBean
			 * 判断是否有注解@Aspect和字段不能有ajc$
			 */
  			if (isInfrastructureClass(beanClass) || shouldSkip(beanClass, beanName)) {
				this.advisedBeans.put(cacheKey, Boolean.FALSE);
				return null;
			}
		}

		// 如果我们有一个自定义的TargetSource，在这里创建代理。
		// 抑制目标bean的不必要的默认实例化:
		// TargetSource将以自定义的方式处理目标实例。
		TargetSource targetSource = getCustomTargetSource(beanClass, beanName);
		if (targetSource != null) {
			if (StringUtils.hasLength(beanName)) {
				this.targetSourcedBeans.add(beanName);
			}
			Object[] specificInterceptors = getAdvicesAndAdvisorsForBean(beanClass, beanName, targetSource);
			Object proxy = createProxy(beanClass, beanName, specificInterceptors, targetSource);
			this.proxyTypes.put(cacheKey, proxy.getClass());
			return proxy;
		}

		return null;
	}

protected boolean shouldSkip(Class<?> beanClass, String beanName) {
		// TODO: 考虑通过缓存方面名称的列表进行优化
		List<Advisor> candidateAdvisors = findCandidateAdvisors();
		for (Advisor advisor : candidateAdvisors) {
			if (advisor instanceof AspectJPointcutAdvisor &&
					((AspectJPointcutAdvisor) advisor).getAspectName().equals(beanName)) {
				return true;
			}
		}
		// 判断beanName是否是.Origina结尾
		return super.shouldSkip(beanClass, beanName);
	}

protected List<Advisor> findCandidateAdvisors() {
		// 根据superclass规则，添加所有实现了Advisor接口的。
		List<Advisor> advisors = super.findCandidateAdvisors();
		// 在bean工厂中为所有AspectJ方面建立Advisors。
		if (this.aspectJAdvisorsBuilder != null) {
			advisors.addAll(this.aspectJAdvisorsBuilder.buildAspectJAdvisors());
		}
		return advisors;
	}

public List<Advisor> findAdvisorBeans() {
		// 确定advisor bean的列表，如果尚未缓存的话。
		String[] advisorNames = this.cachedAdvisorBeanNames;
		if (advisorNames == null) {
			// 通过注解的方式这里是返回的是空
			advisorNames = BeanFactoryUtils.beanNamesForTypeIncludingAncestors(
					this.beanFactory, Advisor.class, true, false);
			this.cachedAdvisorBeanNames = advisorNames;
		}
		if (advisorNames.length == 0) {
			return new ArrayList<>();
		}

		List<Advisor> advisors = new ArrayList<>();
		for (String name : advisorNames) {
			if (isEligibleBean(name)) {
				if (this.beanFactory.isCurrentlyInCreation(name)) {
					if (logger.isTraceEnabled()) {
						logger.trace("Skipping currently created advisor '" + name + "'");
					}
				}
				else {
					try {
						advisors.add(this.beanFactory.getBean(name, Advisor.class));
					}
					catch (BeanCreationException ex) {
						Throwable rootCause = ex.getMostSpecificCause();
						if (rootCause instanceof BeanCurrentlyInCreationException) {
							BeanCreationException bce = (BeanCreationException) rootCause;
							String bceBeanName = bce.getBeanName();
							if (bceBeanName != null && this.beanFactory.isCurrentlyInCreation(bceBeanName)) {
								if (logger.isTraceEnabled()) {
									logger.trace("Skipping advisor '" + name +
											"' with dependency on currently created bean: " + ex.getMessage());
								}
								// 忽略：表示对我们试图建议的Bean的引用。
								// 我们想找到当前创建的Bean本身以外的顾问。
								continue;
							}
						}
						throw ex;
					}
				}
			}
		}
		return advisors;
	}

public List<Advisor> buildAspectJAdvisors() {
		List<String> aspectNames = this.aspectBeanNames;

		if (aspectNames == null) {
			synchronized (this) {
				aspectNames = this.aspectBeanNames;
				if (aspectNames == null) {
					List<Advisor> advisors = new ArrayList<>();
					aspectNames = new ArrayList<>();
					//拿到所有的bean
					String[] beanNames = BeanFactoryUtils.beanNamesForTypeIncludingAncestors(
							this.beanFactory, Object.class, true, false);
					for (String beanName : beanNames) {
						//根据includePatterns匹配beanName
						if (!isEligibleBean(beanName)) {
							continue;
						}
						// 我们必须注意不要急于实例化Bean，因为在这种情况下，
						// 他们会被Spring容器缓存起来，但不会被编织。
						Class<?> beanType = this.beanFactory.getType(beanName, false);
						if (beanType == null) {
							continue;
						}
						// 判断该bean是否有Aspect注解并且成员属性不能有ajc$
						if (this.advisorFactory.isAspect(beanType)) {
							aspectNames.add(beanName);
							AspectMetadata amd = new AspectMetadata(beanType, beanName);
							if (amd.getAjType().getPerClause().getKind() == PerClauseKind.SINGLETON) {
								MetadataAwareAspectInstanceFactory factory =
										new BeanFactoryAspectInstanceFactory(this.beanFactory, beanName);
								List<Advisor> classAdvisors = this.advisorFactory.getAdvisors(factory);
								//将单例实例的Advisors缓存
								if (this.beanFactory.isSingleton(beanName)) {
									this.advisorsCache.put(beanName, classAdvisors);
								}
								else {
									this.aspectFactoryCache.put(beanName, factory);
								}
								advisors.addAll(classAdvisors);
							}
							else {
								// Per target or per this.
								if (this.beanFactory.isSingleton(beanName)) {
									throw new IllegalArgumentException("Bean with name '" + beanName +
											"' is a singleton, but aspect instantiation model is not singleton");
								}
								MetadataAwareAspectInstanceFactory factory =
										new PrototypeAspectInstanceFactory(this.beanFactory, beanName);
								this.aspectFactoryCache.put(beanName, factory);
								advisors.addAll(this.advisorFactory.getAdvisors(factory));
							}
						}
					}
					this.aspectBeanNames = aspectNames;
					return advisors;
				}
			}
		}

		if (aspectNames.isEmpty()) {
			return Collections.emptyList();
		}
		List<Advisor> advisors = new ArrayList<>();
		for (String aspectName : aspectNames) {
			List<Advisor> cachedAdvisors = this.advisorsCache.get(aspectName);
			if (cachedAdvisors != null) {
				advisors.addAll(cachedAdvisors);
			}
			else {
				MetadataAwareAspectInstanceFactory factory = this.aspectFactoryCache.get(aspectName);
				advisors.addAll(this.advisorFactory.getAdvisors(factory));
			}
		}
		return advisors;
	}

public List<Advisor> getAdvisors(MetadataAwareAspectInstanceFactory aspectInstanceFactory) {
		Class<?> aspectClass = aspectInstanceFactory.getAspectMetadata().getAspectClass();
		String aspectName = aspectInstanceFactory.getAspectMetadata().getAspectName();
		validate(aspectClass);

		// 我们需要用一个装饰器来包装MetadataAwareAspectInstanceFactory。
		// 这样它就只会实例化一次。
		MetadataAwareAspectInstanceFactory lazySingletonAspectInstanceFactory =
				new LazySingletonAspectInstanceFactoryDecorator(aspectInstanceFactory);

		List<Advisor> advisors = new ArrayList<>();
		//遍历Aspect类的所有方法
		for (Method method : getAdvisorMethods(aspectClass)) {
			/**
			 * 在Spring Framework 5.2.7之前， advisors.size()被作为 declarationOrderInAspect
			 * 来代表声明方法列表中的 "current position"。
			 * 然而，从Java 7开始，"current position"不再有效，因为JDK不再按照源代码中的声明顺序返回声明的方法。
			 * 因此，我们现在将所有建议方法的 declarationOrderInAspect 硬编码为 0。
			 * 以支持跨JVM启动的可靠建议排序。
			 * 具体来说，0的值与JVM中使用的默认值一致。
			 * AspectJPrecedenceComparator.getAspectDeclarationOrder(Advisor)。
			 */
			Advisor advisor = getAdvisor(method, lazySingletonAspectInstanceFactory, 0, aspectName);
			if (advisor != null) {
				advisors.add(advisor);
			}
		}

		// 如果是每个目标aspect，就发出假的实例化的aspect。
		if (!advisors.isEmpty() && lazySingletonAspectInstanceFactory.getAspectMetadata().isLazilyInstantiated()) {
			Advisor instantiationAdvisor = new SyntheticInstantiationAdvisor(lazySingletonAspectInstanceFactory);
			advisors.add(0, instantiationAdvisor);
		}

		// 解析DeclareParents字段。
		for (Field field : aspectClass.getDeclaredFields()) {
			Advisor advisor = getDeclareParentsAdvisor(field);
			if (advisor != null) {
				advisors.add(advisor);
			}
		}

		return advisors;
	}

private List<Method> getAdvisorMethods(Class<?> aspectClass) {
		List<Method> methods = new ArrayList<>();
		//将aspectClass遍历所有的方法添加到methods集合里，排除Pointcut方法
		ReflectionUtils.doWithMethods(aspectClass, methods::add, adviceMethodFilter);
		if (methods.size() > 1) {
			//根据Around.class, Before.class, After.class, AfterReturning.class, AfterThrowing.class顺序排序
			methods.sort(adviceMethodComparator);
		}
		return methods;
	}

public Advisor getAdvisor(Method candidateAdviceMethod, MetadataAwareAspectInstanceFactory aspectInstanceFactory,
			int declarationOrderInAspect, String aspectName) {
		//校验要被代理的class的ajType和父类
		validate(aspectInstanceFactory.getAspectMetadata().getAspectClass());

		AspectJExpressionPointcut expressionPointcut = getPointcut(
				candidateAdviceMethod, aspectInstanceFactory.getAspectMetadata().getAspectClass());
		if (expressionPointcut == null) {
			return null;
		}

		return new InstantiationModelAwarePointcutAdvisorImpl(expressionPointcut, candidateAdviceMethod,
				this, aspectInstanceFactory, declarationOrderInAspect, aspectName);
	}

private AspectJExpressionPointcut getPointcut(Method candidateAdviceMethod, Class<?> candidateAspectClass) {
		AspectJAnnotation<?> aspectJAnnotation =
				AbstractAspectJAdvisorFactory.findAspectJAnnotationOnMethod(candidateAdviceMethod);
		if (aspectJAnnotation == null) {
			return null;
		}
		//构建解析切点表达式 初始化参数名称和参数类型
		AspectJExpressionPointcut ajexp =
				new AspectJExpressionPointcut(candidateAspectClass, new String[0], new Class<?>[0]);
		//赋值注解切点的表达式
		ajexp.setExpression(aspectJAnnotation.getPointcutExpression());
		if (this.beanFactory != null) {
			ajexp.setBeanFactory(this.beanFactory);
		}
		return ajexp;
	}

public InstantiationModelAwarePointcutAdvisorImpl(AspectJExpressionPointcut declaredPointcut,
			Method aspectJAdviceMethod, AspectJAdvisorFactory aspectJAdvisorFactory,
			MetadataAwareAspectInstanceFactory aspectInstanceFactory, int declarationOrder, String aspectName) {

		this.declaredPointcut = declaredPointcut;
		this.declaringClass = aspectJAdviceMethod.getDeclaringClass();
		this.methodName = aspectJAdviceMethod.getName();
		this.parameterTypes = aspectJAdviceMethod.getParameterTypes();
		this.aspectJAdviceMethod = aspectJAdviceMethod;
		this.aspectJAdvisorFactory = aspectJAdvisorFactory;
		this.aspectInstanceFactory = aspectInstanceFactory;
		this.declarationOrder = declarationOrder;
		this.aspectName = aspectName;

		if (aspectInstanceFactory.getAspectMetadata().isLazilyInstantiated()) {
			// 切入点的静态部分是一种惰性类型。
			Pointcut preInstantiationPointcut = Pointcuts.union(
					aspectInstanceFactory.getAspectMetadata().getPerClausePointcut(), this.declaredPointcut);

			// 使它动态:必须从预实例化到后实例化状态。
			// 如果它不是一个动态的切入点，那么它可以被优化出来
			// 在第一次评估之后，由Spring AOP基础设施完成。
			this.pointcut = new PerTargetInstantiationModelPointcut(
					this.declaredPointcut, preInstantiationPointcut, aspectInstanceFactory);
			this.lazy = true;
		}
		else {
			// 单例aspect.
			this.pointcut = this.declaredPointcut;
			this.lazy = false;
			this.instantiatedAdvice = instantiateAdvice(this.declaredPointcut);
		}
	}

private Advice instantiateAdvice(AspectJExpressionPointcut pointcut) {
		Advice advice = this.aspectJAdvisorFactory.getAdvice(this.aspectJAdviceMethod, pointcut,
				this.aspectInstanceFactory, this.declarationOrder, this.aspectName);
		return (advice != null ? advice : EMPTY_ADVICE);
	}

public Advice getAdvice(Method candidateAdviceMethod, AspectJExpressionPointcut expressionPointcut,
			MetadataAwareAspectInstanceFactory aspectInstanceFactory, int declarationOrder, String aspectName) {

		Class<?> candidateAspectClass = aspectInstanceFactory.getAspectMetadata().getAspectClass();
		validate(candidateAspectClass);

		AspectJAnnotation<?> aspectJAnnotation =
				AbstractAspectJAdvisorFactory.findAspectJAnnotationOnMethod(candidateAdviceMethod);
		if (aspectJAnnotation == null) {
			return null;
		}

		// If we get here, we know we have an AspectJ method.
		// Check that it's an AspectJ-annotated class
		if (!isAspect(candidateAspectClass)) {
			throw new AopConfigException("Advice must be declared inside an aspect type: " +
					"Offending method '" + candidateAdviceMethod + "' in class [" +
					candidateAspectClass.getName() + "]");
		}

		if (logger.isDebugEnabled()) {
			logger.debug("Found AspectJ method: " + candidateAdviceMethod);
		}

		AbstractAspectJAdvice springAdvice;
		//根据aspectJAnnotation的注解类型创建对应的Advice
		switch (aspectJAnnotation.getAnnotationType()) {
			case AtPointcut:
				if (logger.isDebugEnabled()) {
					logger.debug("Processing pointcut '" + candidateAdviceMethod.getName() + "'");
				}
				return null;
			case AtAround:
				springAdvice = new AspectJAroundAdvice(
						candidateAdviceMethod, expressionPointcut, aspectInstanceFactory);
				break;
			case AtBefore:
				springAdvice = new AspectJMethodBeforeAdvice(
						candidateAdviceMethod, expressionPointcut, aspectInstanceFactory);
				break;
			case AtAfter:
				springAdvice = new AspectJAfterAdvice(
						candidateAdviceMethod, expressionPointcut, aspectInstanceFactory);
				break;
			case AtAfterReturning:
				springAdvice = new AspectJAfterReturningAdvice(
						candidateAdviceMethod, expressionPointcut, aspectInstanceFactory);
				AfterReturning afterReturningAnnotation = (AfterReturning) aspectJAnnotation.getAnnotation();
				if (StringUtils.hasText(afterReturningAnnotation.returning())) {
					springAdvice.setReturningName(afterReturningAnnotation.returning());
				}
				break;
			case AtAfterThrowing:
				springAdvice = new AspectJAfterThrowingAdvice(
						candidateAdviceMethod, expressionPointcut, aspectInstanceFactory);
				AfterThrowing afterThrowingAnnotation = (AfterThrowing) aspectJAnnotation.getAnnotation();
				if (StringUtils.hasText(afterThrowingAnnotation.throwing())) {
					springAdvice.setThrowingName(afterThrowingAnnotation.throwing());
				}
				break;
			default:
				throw new UnsupportedOperationException(
						"Unsupported advice type on method: " + candidateAdviceMethod);
		}

		// 现在配置通知…
		springAdvice.setAspectName(aspectName);
		springAdvice.setDeclarationOrder(declarationOrder);
		// 解析注解argNames用,分割
		String[] argNames = this.parameterNameDiscoverer.getParameterNames(candidateAdviceMethod);
		if (argNames != null) {
			springAdvice.setArgumentNamesFromStringArray(argNames);
		}
		springAdvice.calculateArgumentBindings();

		return springAdvice;
	}

@Override
	public Object postProcessAfterInitialization(@Nullable Object bean, String beanName) {
		if (bean != null) {
			Object cacheKey = getCacheKey(bean.getClass(), beanName);
			if (this.earlyProxyReferences.remove(cacheKey) != bean) {
				return wrapIfNecessary(bean, beanName, cacheKey);
			}
		}
		return bean;
	}

protected Object wrapIfNecessary(Object bean, String beanName, Object cacheKey) {
		if (StringUtils.hasLength(beanName) && this.targetSourcedBeans.contains(beanName)) {
			return bean;
		}
		if (Boolean.FALSE.equals(this.advisedBeans.get(cacheKey))) {
			return bean;
		}
		if (isInfrastructureClass(bean.getClass()) || shouldSkip(bean.getClass(), beanName)) {
			this.advisedBeans.put(cacheKey, Boolean.FALSE);
			return bean;
		}

		// 如果我们有advice，就创建代理。
		Object[] specificInterceptors = getAdvicesAndAdvisorsForBean(bean.getClass(), beanName, null);
		if (specificInterceptors != DO_NOT_PROXY) {
			//将要代理的bean缓存
			this.advisedBeans.put(cacheKey, Boolean.TRUE);
			//实例化代理对象实例
			Object proxy = createProxy(
					bean.getClass(), beanName, specificInterceptors, new SingletonTargetSource(bean));
			//添加到代理类型
			this.proxyTypes.put(cacheKey, proxy.getClass());
			return proxy;
		}

		this.advisedBeans.put(cacheKey, Boolean.FALSE);
		return bean;
	}

protected Object[] getAdvicesAndAdvisorsForBean(
			Class<?> beanClass, String beanName, @Nullable TargetSource targetSource) {
		//获取符合条件的advisor
		List<Advisor> advisors = findEligibleAdvisors(beanClass, beanName);
		if (advisors.isEmpty()) {
			return DO_NOT_PROXY;
		}
		return advisors.toArray();
	}

protected List<Advisor> findEligibleAdvisors(Class<?> beanClass, String beanName) {
		List<Advisor> candidateAdvisors = findCandidateAdvisors();
		//根据类型是IntroductionAdvisor还是PointcutAdvisor做不同的匹配
		List<Advisor> eligibleAdvisors = findAdvisorsThatCanApply(candidateAdvisors, beanClass, beanName);
		// 添加ExposeInvocationInterceptor
		extendAdvisors(eligibleAdvisors);
		if (!eligibleAdvisors.isEmpty()) {
			eligibleAdvisors = sortAdvisors(eligibleAdvisors);
		}
		return eligibleAdvisors;
	}

protected Object createProxy(Class<?> beanClass, @Nullable String beanName,
			@Nullable Object[] specificInterceptors, TargetSource targetSource) {
		//给BeanDefinition添加一个attributes
		if (this.beanFactory instanceof ConfigurableListableBeanFactory) {
			AutoProxyUtils.exposeTargetClass((ConfigurableListableBeanFactory) this.beanFactory, beanName, beanClass);
		}
		//创建AOP代理的工厂
		ProxyFactory proxyFactory = new ProxyFactory();
		//复制配置。
		proxyFactory.copyFrom(this);
		//如果AOP代理的工厂是一个代理类
		if (!proxyFactory.isProxyTargetClass()) {
			if (shouldProxyTargetClass(beanClass, beanName)) {
				proxyFactory.setProxyTargetClass(true);
			}
			else {
				evaluateProxyInterfaces(beanClass, proxyFactory);
			}
		}

		Advisor[] advisors = buildAdvisors(beanName, specificInterceptors);
		proxyFactory.addAdvisors(advisors);
		proxyFactory.setTargetSource(targetSource);
		customizeProxyFactory(proxyFactory);

		proxyFactory.setFrozen(this.freezeProxy);
		if (advisorsPreFiltered()) {
			proxyFactory.setPreFiltered(true);
		}

		// 如果Bean类在覆盖类加载器中没有本地加载，则使用原始的ClassLoader
		ClassLoader classLoader = getProxyClassLoader();
		if (classLoader instanceof SmartClassLoader && classLoader != beanClass.getClassLoader()) {
			classLoader = ((SmartClassLoader) classLoader).getOriginalClassLoader();
		}
		return proxyFactory.getProxy(classLoader);
	}

public Object getProxy(@Nullable ClassLoader classLoader) {
		return createAopProxy().getProxy(classLoader);
	}

protected final synchronized AopProxy createAopProxy() {
		if (!this.active) {
			//赋值active为true 回调AdvisedSupportListener的activated方法
			activate();
		}
		//获取默认的DefaultAopProxyFactory
		return getAopProxyFactory().createAopProxy(this);
	}

public AopProxy createAopProxy(AdvisedSupport config) throws AopConfigException {
		if (!NativeDetector.inNativeImage() &&
				(config.isOptimize() || config.isProxyTargetClass() || hasNoUserSuppliedProxyInterfaces(config))) {
			Class<?> targetClass = config.getTargetClass();
			if (targetClass == null) {
				throw new AopConfigException("TargetSource cannot determine target class: " +
						"Either an interface or a target is required for proxy creation.");
			}
			//如果目标类是接口或是一个代理类都用jdk动态代理
			if (targetClass.isInterface() || Proxy.isProxyClass(targetClass)) {
				return new JdkDynamicAopProxy(config);
			}
			return new ObjenesisCglibAopProxy(config);
		}
		else {
			return new JdkDynamicAopProxy(config);
		}
	}

public Object getProxy(@Nullable ClassLoader classLoader) {
		if (logger.isTraceEnabled()) {
			logger.trace("Creating CGLIB proxy: " + this.advised.getTargetSource());
		}

		try {
			Class<?> rootClass = this.advised.getTargetClass();
			Assert.state(rootClass != null, "Target class must be available for creating a CGLIB proxy");

			Class<?> proxySuperClass = rootClass;
			//如果目标类是cglib代理过的
			if (rootClass.getName().contains(ClassUtils.CGLIB_CLASS_SEPARATOR)) {
				proxySuperClass = rootClass.getSuperclass();
				Class<?>[] additionalInterfaces = rootClass.getInterfaces();
				for (Class<?> additionalInterface : additionalInterfaces) {
					this.advised.addInterface(additionalInterface);
				}
			}

			// 验证该类，必要时写入日志信息。
			validateClassIfNecessary(proxySuperClass, classLoader);

			// 配置CGLIB增强器...
			Enhancer enhancer = createEnhancer();
			if (classLoader != null) {
				enhancer.setClassLoader(classLoader);
				if (classLoader instanceof SmartClassLoader &&
						((SmartClassLoader) classLoader).isClassReloadable(proxySuperClass)) {
					enhancer.setUseCache(false);
				}
			}
			enhancer.setSuperclass(proxySuperClass);
			enhancer.setInterfaces(AopProxyUtils.completeProxiedInterfaces(this.advised));
			enhancer.setNamingPolicy(SpringNamingPolicy.INSTANCE);
			enhancer.setStrategy(new ClassLoaderAwareGeneratorStrategy(classLoader));

			Callback[] callbacks = getCallbacks(rootClass);
			Class<?>[] types = new Class<?>[callbacks.length];
			for (int x = 0; x < types.length; x++) {
				types[x] = callbacks[x].getClass();
			}
			// fixedInterceptorMap只在这时被填充，在上面的getCallbacks调用之后。
			enhancer.setCallbackFilter(new ProxyCallbackFilter(
					this.advised.getConfigurationOnlyCopy(), this.fixedInterceptorMap, this.fixedInterceptorOffset));
			enhancer.setCallbackTypes(types);

			// 生成代理类并创建一个代理实例。
			return createProxyClassAndInstance(enhancer, callbacks);
		}
		catch (CodeGenerationException | IllegalArgumentException ex) {
			throw new AopConfigException("Could not generate CGLIB subclass of " + this.advised.getTargetClass() +
					": Common causes of this problem include using a final class or a non-visible class",
					ex);
		}
		catch (Throwable ex) {
			// TargetSource.getTarget() failed
			throw new AopConfigException("Unexpected AOP exception", ex);
		}
	}

protected Object createProxyClassAndInstance(Enhancer enhancer, Callback[] callbacks) {
		//获取代理类class
		Class<?> proxyClass = enhancer.createClass();
		Object proxyInstance = null;

		if (objenesis.isWorthTrying()) {
			try {
				//通过spring objenesis创建实例
				proxyInstance = objenesis.newInstance(proxyClass, enhancer.getUseCache());
			}
			catch (Throwable ex) {
				logger.debug("Unable to instantiate proxy using Objenesis, " +
						"falling back to regular proxy construction", ex);
			}
		}
		//如果Objenesis失败采用默认构造函数的常规实例化…
		if (proxyInstance == null) {
			try {
				Constructor<?> ctor = (this.constructorArgs != null ?
						proxyClass.getDeclaredConstructor(this.constructorArgTypes) :
						proxyClass.getDeclaredConstructor());
				ReflectionUtils.makeAccessible(ctor);
				proxyInstance = (this.constructorArgs != null ?
						ctor.newInstance(this.constructorArgs) : ctor.newInstance());
			}
			catch (Throwable ex) {
				throw new AopConfigException("Unable to instantiate proxy using Objenesis, " +
						"and regular proxy instantiation via default constructor fails as well", ex);
			}
		}

		((Factory) proxyInstance).setCallbacks(callbacks);
		return proxyInstance;
	}

后面都是Objenesis相关的

public <T> T newInstance(Class<T> clazz, boolean useCache) {
		if (!useCache) {
			return newInstantiatorOf(clazz).newInstance();
		}
		return getInstantiatorOf(clazz).newInstance();
	}

protected <T> ObjectInstantiator<T> newInstantiatorOf(Class<T> clazz) {
		Boolean currentWorthTrying = this.worthTrying;
		try {
			//默认StdInstantiatorStrategy
			ObjectInstantiator<T> instantiator = this.strategy.newInstantiatorOf(clazz);
			if (currentWorthTrying == null) {
				this.worthTrying = Boolean.TRUE;
			}
			return instantiator;
		}
		catch (ObjenesisException ex) {
			if (currentWorthTrying == null) {
				Throwable cause = ex.getCause();
				if (cause instanceof ClassNotFoundException || cause instanceof IllegalAccessException) {
					// Indicates that the chosen instantiation strategy does not work on the given JVM.
					// Typically a failure to initialize the default SunReflectionFactoryInstantiator.
					// Let's assume that any subsequent attempts to use Objenesis will fail as well...
					this.worthTrying = Boolean.FALSE;
				}
			}
			throw ex;
		}
		catch (NoClassDefFoundError err) {
			// Happening on the production version of Google App Engine, coming out of the
			// restricted "sun.reflect.ReflectionFactory" class...
			if (currentWorthTrying == null) {
				this.worthTrying = Boolean.FALSE;
			}
			throw new ObjenesisException(err);
		}
	}

public T newInstance() {
        try {
            return this.mungedConstructor.newInstance((Object[])null);
        } catch (Exception var2) {
            throw new ObjenesisException(var2);
        }
    }
