桂云网络OSG：桂花流程引擎自定义配置扩展示例

篇章引言

桂花流程引擎(Osmanthus)，是基于Camunda 7.20+扩展，旨在满足国内精细化的审批需求的国产流程引擎。桂花流程引擎为桂云网络公司旗下的标准化流程产品，之所以取名为“桂花”，其一是因为桂云网络公司主商标“桂云”的实物化产品品牌延伸，其二是因为桂花是中国传统文化名花，其淡雅的清香给人一种古典而唯美的体验感官。桂花流程引擎中“桂花”为桂云网络公司指定在商标尼斯分类第0901组软件类产品的商标，本文由桂云网络OSG独家贡献。

关键字: 桂云网络, 桂云, OSG, 桂花流程引擎, 桂花流程, 桂花, bpmn

在流程引擎中，需要使用到缓存，缓存是可以自定义扩展的，本文主要讲解桂花流程引擎配置类自定义扩展示例

实现过程

桂花流程引擎(Osmanthus)的缓存，我们需要定义是否启用缓存enabled、生效时间ttl和缓存的前缀prefix三个参数。在spring-boot-starter中定义相关的配置参数，定义一个缓存属性类

public class CacheProperty {
    private boolean enabled;
    private int ttl;
    private String prefix;

    public boolean isEnabled() {
        return enabled;
    }

    public void setEnabled(boolean enabled) {
        this.enabled = enabled;
    }

    public int getTtl() {
        return ttl;
    }

    public void setTtl(int ttl) {
        this.ttl = ttl;
    }

    public String getPrefix() {
        return prefix;
    }

    public void setPrefix(String prefix) {
        this.prefix = prefix;
    }

    @Override
    public String toString() {
        return joinOn(this.getClass())
                .add("enabled=" + enabled)
                .add("ttl=" + ttl)
                .add("prefix=" + prefix)
                .toString();
    }
}

然后在CamundaBpmProperties类中，增加一个属性cache

package org.camunda.bpm.spring.boot.starter.property;

import org.apache.commons.lang3.RandomStringUtils;
import org.camunda.bpm.engine.ProcessEngineConfiguration;
import org.camunda.bpm.engine.ProcessEngines;
import org.camunda.bpm.spring.boot.starter.configuration.id.IdGeneratorConfiguration;
import org.springframework.boot.context.properties.ConfigurationProperties;
import org.springframework.boot.context.properties.NestedConfigurationProperty;

import java.net.URL;
import java.util.Arrays;
import java.util.HashSet;
import java.util.Set;
import java.util.StringJoiner;

import static org.springframework.core.io.support.ResourcePatternResolver.CLASSPATH_ALL_URL_PREFIX;

@ConfigurationProperties(CamundaBpmProperties.PREFIX)
public class CamundaBpmProperties {

  public static final String PREFIX = "camunda.bpm";
  public static final String UNIQUE_ENGINE_NAME_PREFIX = "processEngine";
  public static final String UNIQUE_APPLICATION_NAME_PREFIX = "processApplication";

  public static final String[] DEFAULT_BPMN_RESOURCE_SUFFIXES = new String[]{"bpmn20.xml", "bpmn" };
  public static final String[] DEFAULT_CMMN_RESOURCE_SUFFIXES = new String[]{"cmmn11.xml", "cmmn10.xml", "cmmn" };
  public static final String[] DEFAULT_DMN_RESOURCE_SUFFIXES = new String[]{"dmn11.xml", "dmn" };

  static String[] initDeploymentResourcePattern() {
    final Set<String> suffixes = new HashSet<>();
    suffixes.addAll(Arrays.asList(DEFAULT_DMN_RESOURCE_SUFFIXES));
    suffixes.addAll(Arrays.asList(DEFAULT_BPMN_RESOURCE_SUFFIXES));
    suffixes.addAll(Arrays.asList(DEFAULT_CMMN_RESOURCE_SUFFIXES));

    final Set<String> patterns = new HashSet<>();
    for (String suffix : suffixes) {
      patterns.add(String.format("%s**/*.%s", CLASSPATH_ALL_URL_PREFIX, suffix));
    }

    return patterns.toArray(new String[patterns.size()]);
  }

  static StringJoiner joinOn(final Class<?> clazz) {
    return new StringJoiner(", ", clazz.getSimpleName() + "[", "]");
  }

  public static String getUniqueName(String name) {
    return name + RandomStringUtils.randomAlphanumeric(10);
  }

  /**
   * name of the process engine
   */
  private String processEngineName = ProcessEngines.NAME_DEFAULT;

  private Boolean generateUniqueProcessEngineName = false;

  private Boolean generateUniqueProcessApplicationName = false;

  private String idGenerator = IdGeneratorConfiguration.STRONG;

  private Boolean jobExecutorAcquireByPriority = null;

  private Integer defaultNumberOfRetries = null;

  /**
   * the history level to use
   */
  private String historyLevel = ProcessEngineConfiguration.HISTORY_FULL;

  /**
   * the default history level to use when 'historyLevel' is 'auto'
   */
  private String historyLevelDefault = ProcessEngineConfiguration.HISTORY_FULL;

  /**
   * enables auto deployment of processes
   */
  private boolean autoDeploymentEnabled = true;

  /**
   * resource pattern for locating process sources
   */
  private String[] deploymentResourcePattern = initDeploymentResourcePattern();

  /**
   * default serialization format to use
   */
  private String defaultSerializationFormat = Defaults.INSTANCE.getDefaultSerializationFormat();

  private URL licenseFile;

  /**
   * deactivate camunda auto configuration
   */
  private boolean enabled = true;

  /**
   * metrics configuration
   */
  @NestedConfigurationProperty
  private MetricsProperty metrics = new MetricsProperty();

  /**
   * database configuration
   */
  @NestedConfigurationProperty
  private DatabaseProperty database = new DatabaseProperty();

  /**
   * Spring eventing configuration
   */
  @NestedConfigurationProperty
  private EventingProperty eventing = new EventingProperty();

  /**
   * job execution configuration
   */
  @NestedConfigurationProperty
  private JobExecutionProperty jobExecution = new JobExecutionProperty();

  /**
   * webapp configuration
   */
  @NestedConfigurationProperty
  private WebappProperty webapp = new WebappProperty();

  @NestedConfigurationProperty
  private AuthorizationProperty authorization = new AuthorizationProperty();

  @NestedConfigurationProperty
  private GenericProperties genericProperties = new GenericProperties();

  @NestedConfigurationProperty
  private AdminUserProperty adminUser = new AdminUserProperty();

  @NestedConfigurationProperty
  private FilterProperty filter = new FilterProperty();

  // 增加的配置
  @NestedConfigurationProperty
  private CacheProperty cache = new CacheProperty();

  public String getProcessEngineName() {
    return processEngineName;
  }

  public void setProcessEngineName(String processEngineName) {
    this.processEngineName = processEngineName;
  }

  public String getHistoryLevel() {
    return historyLevel;
  }

  public void setHistoryLevel(String historyLevel) {
    this.historyLevel = historyLevel;
  }

  public String getHistoryLevelDefault() {
    return historyLevelDefault;
  }

  public void setHistoryLevelDefault(String historyLevelDefault) {
    this.historyLevelDefault = historyLevelDefault;
  }

  public boolean isAutoDeploymentEnabled() {
    return autoDeploymentEnabled;
  }

  public void setAutoDeploymentEnabled(boolean autoDeploymentEnabled) {
    this.autoDeploymentEnabled = autoDeploymentEnabled;
  }

  public String[] getDeploymentResourcePattern() {
    return deploymentResourcePattern;
  }

  public void setDeploymentResourcePattern(String[] deploymentResourcePattern) {
    this.deploymentResourcePattern = deploymentResourcePattern;
  }

  public String getDefaultSerializationFormat() {
    return defaultSerializationFormat;
  }

  public void setDefaultSerializationFormat(String defaultSerializationFormat) {
    this.defaultSerializationFormat = defaultSerializationFormat;
  }

  public URL getLicenseFile() {
    return licenseFile;
  }

  public void setLicenseFile(URL licenseFile) {
    this.licenseFile = licenseFile;
  }

  public MetricsProperty getMetrics() {
    return metrics;
  }

  public void setMetrics(MetricsProperty metrics) {
    this.metrics = metrics;
  }

  public DatabaseProperty getDatabase() {
    return database;
  }

  public void setDatabase(DatabaseProperty database) {
    this.database = database;
  }

  public EventingProperty getEventing() {
    return eventing;
  }

  public void setEventing(EventingProperty eventing) {
    this.eventing = eventing;
  }

  public JobExecutionProperty getJobExecution() {
    return jobExecution;
  }

  public void setJobExecution(JobExecutionProperty jobExecution) {
    this.jobExecution = jobExecution;
  }

  public WebappProperty getWebapp() {
    return webapp;
  }

  public void setWebapp(WebappProperty webapp) {
    this.webapp = webapp;
  }

  public AuthorizationProperty getAuthorization() {
    return authorization;
  }

  public void setAuthorization(AuthorizationProperty authorization) {
    this.authorization = authorization;
  }

  public GenericProperties getGenericProperties() {
    return genericProperties;
  }

  public void setGenericProperties(GenericProperties genericProperties) {
    this.genericProperties = genericProperties;
  }

  public AdminUserProperty getAdminUser() {
    return adminUser;
  }

  public void setAdminUser(AdminUserProperty adminUser) {
    this.adminUser = adminUser;
  }

  public FilterProperty getFilter() {
    return filter;
  }

  public void setFilter(FilterProperty filter) {
    this.filter = filter;
  }

  // 增加的配置
  public CacheProperty getCache() {
    return cache;
  }

  // 增加的配置
  public void setCache(CacheProperty cache) {
    this.cache = cache;
  }

  public String getIdGenerator() {
    return idGenerator;
  }

  public void setIdGenerator(String idGenerator) {
    this.idGenerator = idGenerator;
  }

  public Boolean getJobExecutorAcquireByPriority() {
    return jobExecutorAcquireByPriority;
  }

  public void setJobExecutorAcquireByPriority(Boolean jobExecutorAcquireByPriority) {
    this.jobExecutorAcquireByPriority = jobExecutorAcquireByPriority;
  }

  public Integer getDefaultNumberOfRetries() {
    return defaultNumberOfRetries;
  }

  public void setDefaultNumberOfRetries(Integer defaultNumberOfRetries) {
    this.defaultNumberOfRetries = defaultNumberOfRetries;
  }

  public boolean isEnabled() {
    return enabled;
  }

  public void setEnabled(boolean enabled) {
    this.enabled = enabled;
  }

  public Boolean getGenerateUniqueProcessEngineName() {
    return generateUniqueProcessEngineName;
  }

  public void setGenerateUniqueProcessEngineName(Boolean generateUniqueProcessEngineName) {
    this.generateUniqueProcessEngineName = generateUniqueProcessEngineName;
  }

  public Boolean getGenerateUniqueProcessApplicationName() {
    return generateUniqueProcessApplicationName;
  }

  public void setGenerateUniqueProcessApplicationName(Boolean generateUniqueProcessApplicationName) {
    this.generateUniqueProcessApplicationName = generateUniqueProcessApplicationName;
  }

  @Override
  public String toString() {
    return joinOn(this.getClass())
      .add("enabled=" + enabled)
      .add("processEngineName=" + processEngineName)
      .add("generateUniqueProcessEngineName=" + generateUniqueProcessEngineName)
      .add("generateUniqueProcessApplicationName=" + generateUniqueProcessApplicationName)
      .add("historyLevel=" + historyLevel)
      .add("historyLevelDefault=" + historyLevelDefault)
      .add("autoDeploymentEnabled=" + autoDeploymentEnabled)
      .add("deploymentResourcePattern=" + Arrays.toString(deploymentResourcePattern))
      .add("defaultSerializationFormat=" + defaultSerializationFormat)
      .add("licenseFile=" + licenseFile)
      .add("metrics=" + metrics)
      .add("database=" + database)
      .add("jobExecution=" + jobExecution)
      .add("webapp=" + webapp)
      .add("authorization=" + authorization)
      .add("genericProperties=" + genericProperties)
      .add("adminUser=" + adminUser)
      .add("filter=" + filter)
      .add("cache=" + cache) // 增加的配置
      .add("idGenerator=" + idGenerator)
      .add("jobExecutorAcquireByPriority=" + jobExecutorAcquireByPriority)
      .add("defaultNumberOfRetries" + defaultNumberOfRetries)
      .toString();
  }

}

这样即可完成缓存的配置参数，如

camunda:
  bpm:
    generic-properties:
      properties:
        historyTimeToLive: P1D
    database:
      schema-update: true
    auto-deployment-enabled: false
    history-level: full
    authorization:
      enabled: true
    job-execution:
      enabled: true

    # 缓存配置
    cache:
      enabled: true
      ttl: 7200
      prefix: "osg:bpm"

作者: 桂云网络, 桂云, OSG
