Hi一起来了解实时数据的IP解析吧

本文关键词：

• 实时ETL
• IP解析
• Blink–【阿里实时计算平台 Based on Flink】

前提：

之前的文章介绍了大数据离线平台的IP实时匹配，在那边文章中我说了将IP合并内容存储在ODPS【Hi一起来了解下大数据平台的IP解析吧】，是因为离线数据量一般很大，数据量增加之后离线任务启动的实例就很多，相当于全部的实例在同一时间去存储了IP合并内容的组件拉取数据，这个是危险的，所以不建议将IP内容存储在其他地方，而是就地存储ODPS，依赖于ODPS的内在资源分发机制来保证IP的的解析工作正常运行。

这里再次使用了IP内容表，但是是实时的ETL使用的，实时的数据量自然就没有离线那么大，所以运行的实例自然可以少一点，这样的话IP的存储组件就有了其他的不同选择。

这里我使用了OSS来进行存储IP数据。然后通过实时的UDF函数去解析【这里为什么使用UDF我在之前的文章中解释过，有兴趣的可以去看下，链接–>Hi一起来了解下大数据平台的IP解析吧】

IP信息上传OSS：

• 打开OSS-Browser【阿里云官网可以下载 链接–>OSS的使用】

• 将本地的IP合并内容直接拖拽上传即可



好了，离线文章基本已经解释了其他的相关信息，这里就直接上代码了

实现代码：

基于存储到内存：

package com.streamCompute.udx.IP.readOss.version02;

import java.io.BufferedReader;
import java.io.InputStream;
import java.io.InputStreamReader;
import java.util.*;
import java.util.concurrent.locks.ReentrantLock;

import com.aliyun.oss.OSS;
import com.aliyun.oss.OSSClientBuilder;
import com.aliyun.oss.model.GetObjectRequest;
import com.aliyun.oss.model.OSSObject;
import org.apache.flink.table.functions.FunctionContext;
import org.apache.flink.table.functions.ScalarFunction;

public class UDFGetIPCityInfo extends ScalarFunction {

  //OSS配置
  private InputStream in = null;
  private static String END_POINT = "XXXXX";
  private static String AK = "XXXX";
  private static String SK = "XXXX";
  private static String BUCKET_NAME = "ip";
  private static String OBJECT_NAME = "ipInfo/ip_info.txt";
  private static OSS ossClient;

  //定义锁
  private static ReentrantLock lock = new ReentrantLock();
  //存储IP信息数据
  private static ArrayList<IpDM> ipList = new ArrayList<IpDM>();

  public static void loadIpInfo() {
    lock.lock();
    while(true) {

      ArrayList<IpDM> ipTmp = new ArrayList<IpDM>();

      ossClient = new OSSClientBuilder().build(END_POINT, AK, SK);

      GetObjectRequest getObjectRequest = new GetObjectRequest(BUCKET_NAME, OBJECT_NAME);

      getObjectRequest.setRange(0, 20971520);  // 20M

      //读取文件
      OSSObject ossObject = ossClient.getObject(getObjectRequest);
      InputStream stream = ossObject.getObjectContent();
      BufferedReader reader = new BufferedReader(new InputStreamReader(stream));

      //这里判断  如果ipInfos 已经完整了，那么不需要继续插入  最多299284
      if(ipList.size()==299284){
        //static变量  同JVM通用  只加载一次即可
        break;
      }


      try{
        String line = "";
        while ((line = reader.readLine()) != null) {
          String[] lines = line.split(",");
          //处理数据
          ipTmp.add(new IpDM(lines));
        }
        //Ip信息排序  使用二分查找
        Collections.sort(ipTmp, new Comparator<IpDM>() {
          @Override
          public int compare(IpDM o1, IpDM o2) {
            return Long.valueOf(o1.getIp_begin_long()).compareTo(
                    Long.valueOf(o2.getIp_begin_long()));
          }
        });

        //如果临时存储不为空，那么将数据赋值给ipList
        if(ipTmp!=null){
          ipList = ipTmp;
        }
      }catch (Exception e){
        e.printStackTrace();
      }
      System.out.println("The size of this list is " + ipList.size());

      ossClient.shutdown(); // close connection
      break;
    }
    lock.unlock();
  }

  public static IpDM getIpDM(String ip) {
    long ipLong = ipDotDec2Long(ip);
    if (ipLong < 0L)
      return new IpDM();
    int begin = 0;
    int end = ipList.size() - 1;
    while (begin <= end) {
      int middle = (begin + end) / 2;
      IpDM middleIpDM = ipList.get(middle);
      if (middleIpDM == null)
        break;
      if (middleIpDM.getIp_begin_long() <= ipLong && middleIpDM
        .getIp_end_long() >= ipLong)
        return middleIpDM;
      if (middleIpDM.getIp_begin_long() > ipLong) {
        end = middle - 1;
        continue;
      }
      if (middleIpDM.getIp_end_long() < ipLong)
        begin = middle + 1;
    }
    return new IpDM();
  }

  private static long ipDotDec2Long(String ipDotDec) throws IllegalArgumentException {
    ipDotDec = ipDotDec.trim();
    String[] sa = ipDotDec.split("\\.");
    if (sa.length != 4)
      return -1L;
    long[] ipLong = new long[4];
    ipLong[0] = Long.parseLong(sa[0]);
    if (ipLong[0] < 0L || ipLong[0] > 255L)
      return -1L;
    ipLong[1] = Long.parseLong(sa[1]);
    if (ipLong[1] < 0L || ipLong[1] > 255L)
      return -1L;
    ipLong[2] = Long.parseLong(sa[2]);
    if (ipLong[2] < 0L || ipLong[2] > 255L)
      return -1L;
    ipLong[3] = Long.parseLong(sa[3]);
    if (ipLong[3] < 0L || ipLong[3] > 255L)
      return -1L;
    return (ipLong[0] << 24L) + (ipLong[1] << 16L) + (ipLong[2] << 8L) + ipLong[3];
  }

  public static class IpDM {
    private long ip_begin_long = 0L;

    private long ip_end_long = 0L;

    private String country_name = "";

    private String province_name = "";

    public IpDM() {}

    private String ipProcess(String src) {
      if (src.equals("local"))
        return "-1";
      if (src.equals(""))
        return "";
      return src;
    }

    public IpDM(String[] info) {
      this.ip_begin_long = Long.valueOf((info[0]));
      this.ip_end_long = Long.valueOf(info[1]);
      this.country_name = ipProcess(info[2]);
      this.province_name = ipProcess(info[3]);
    }

    public long getIp_begin_long() {
      return this.ip_begin_long;
    }

    public long getIp_end_long() {
      return this.ip_end_long;
    }

    public String getCountry_name() {
      return this.country_name;
    }

    public String getProvince_name() {
      return this.province_name;
    }
  }

  private String convNull(String text) {
    if (text == null)
      return "";
    return text;
  }

  public void open(FunctionContext context) {
    loadIpInfo();
  }

  public String eval(String ip, String flag) {
    if (ip == null || flag == null || "".equals(ip) || "".equals(flag))
      return null;
    IpDM ipEntry = getIpDM(ip);
    if (ipEntry != null) {
      if ("country".equals(flag))
        return ipEntry.getCountry_name();

      if ("province".equals(flag))
        return ipEntry.getProvince_name();

      if ("all".equals(flag))
        return convNull(ipEntry.getCountry_name()) + "," +
          convNull(ipEntry.getProvince_name());

      if ("range".equals(flag))
        return ipEntry.getIp_begin_long() + "-" + ipEntry.getIp_end_long();
      return null;
    }
    return null;
  }

  public void close() {
    ossClient.shutdown();//close connection
  }

  public static void main(String[] args) {

    UDFGetIPCityInfo demo = new UDFGetIPCityInfo();
    demo.open(null);
    System.out.println(demo.eval("12.12.12.12","all"));
  }
}

基于存储在本地：

package com.streamCompute.udx.IP.readOss;

import com.aliyun.oss.OSS;
import com.aliyun.oss.OSSClientBuilder;
import com.aliyun.oss.model.GetObjectRequest;
import org.apache.flink.table.functions.FunctionContext;
import org.apache.flink.table.functions.ScalarFunction;

import java.io.*;
import java.text.SimpleDateFormat;
import java.util.LinkedList;
import java.util.Collections;
import java.util.concurrent.locks.ReentrantLock;


/**
 * @ClassName GetIpInfoIntoMemory
 * @Description TODO
 * @Author Yun
 * @Date 2021/12/21 6:06 下午
 * @Version 1.0
 **/
public class GetIpInfoFromDisk extends ScalarFunction {

    private static ReentrantLock lock = new ReentrantLock();
    private InputStream in = null;
    private static String END_POINT = "XXXX";
    private static String AK = "XXXX";
    private static String SK = "XXXX";
    private static String BUCKET_NAME = "ip";
    private static String OBJECT_NAME = "ip_info.txt";
    private static OSS ossClient;
    private static String FILE_NAME = "ip_info.txt";
    private static SimpleDateFormat sdf = new SimpleDateFormat("yyyyMMdd HHmmss");

    private static LinkedList<IPCityEntry> ipInfos = new LinkedList<>();

    @Override
    public void open(FunctionContext context) throws Exception {

        lock.lock();
        while(true){
            ossClient = new OSSClientBuilder().build(END_POINT, AK, SK);

            //本地文件
            File file = new File(getProjectPath()+"/"+FILE_NAME);

            if(!file.exists()){
                // 下载文件到本地
                ossClient.getObject(new GetObjectRequest(BUCKET_NAME, OBJECT_NAME), new File(FILE_NAME));
            }

            BufferedReader reader_02 = new BufferedReader(new FileReader(file));
            String line = "";
            while ((line=reader_02.readLine())!=null) {
                String[] infos = line.split(",");
                //处理数据
                IPCityEntry entry = new IPCityEntry(Long.valueOf(infos[0]), Long.valueOf(infos[1]), infos[2], infos[3]);
                if(entry!=null && entry.toString().length()>0){
                    ipInfos.add(entry);
                }
            }

            System.out.println("The size of this list is "+ipInfos.size());

            //TODO 自定义实现排序  过滤一些空数据
            Collections.sort(ipInfos);

            Thread.sleep(60000);
            ossClient.shutdown();

            break;
        }
        lock.unlock();
    }
    public String eval(String ip) throws IOException {

        if (ip == null ||  "".equals(ip) )
            return null;
        return getInfoByIp(ip);
    }

    /**
     * 获取当前路径
     * @return
     * @throws IOException
     */
    public String getProjectPath() throws IOException {
        File file = new File("");
        String courseFile = file.getCanonicalPath();
        return courseFile;
    }

    public static String getInfoByIp(String ip) {
        long convertIP = convertIP(ip);
        if (convertIP == -1L)
            return "empty";
        int start = 0;
        int end = ipInfos.size() - 1;
        while (start <= end) {
            int mid = (start + end) / 2;
            IPCityEntry entry = ipInfos.get(mid);
            //如果为空 直接返回
            if(entry==null){
                return "empty";
            }
            int range = entry.getIpRange(convertIP);
            if (range == 0)
                return entry.toString();
            if (range < 0) {
                end = mid - 1;
                continue;
            }
            start = mid + 1;
        }
        return "empty";
    }
    public static long convertIP(String ipStr) {
        ipStr = ipStr.trim();
        String[] sa = ipStr.split("\\.");
        if (sa.length != 4)
            return -1L;
        long[] ipLong = new long[4];
        ipLong[0] = Long.parseLong(sa[0]);
        if (ipLong[0] < 0L || ipLong[0] > 255L)
            return -1L;
        ipLong[1] = Long.parseLong(sa[1]);
        if (ipLong[1] < 0L || ipLong[1] > 255L)
            return -1L;
        ipLong[2] = Long.parseLong(sa[2]);
        if (ipLong[2] < 0L || ipLong[2] > 255L)
            return -1L;
        ipLong[3] = Long.parseLong(sa[3]);
        if (ipLong[3] < 0L || ipLong[3] > 255L)
            return -1L;
        return (ipLong[0] << 24L) + (ipLong[1] << 16L) + (ipLong[2] << 8L) + ipLong[3];
    }

    public static class IPCityEntry implements Comparable<IPCityEntry> {
        private long startIP;

        private long endIP;

        private String country;

        private String province;

        private LinkedList<IPCityEntry> ipInfos;

        private IPCityEntry() {}

        public IPCityEntry(long startIP, long endIP, String country, String province) {
            this.startIP = startIP;
            this.endIP = endIP;
            this.country = country;
            this.province = province;
        }

        /**
         * 当前对象与后一个对象进行比较，如果比较结果为1进行交换，其他不进行交换。
         * 当后一个对象比当前对象大，返回结果值为1时，前后交换，说明是倒序排列。
         * 当后一个对象比当前对象小，返回结果值为1时，前后交换，说明是升序排列。
         * @param
         * @return
         */
        @Override
        public int compareTo(IPCityEntry o) {

            if(this.startIP==o.startIP){
                return 0;
            }
            if(this.startIP>o.startIP){
                return 1;
            }
            if(this.startIP<o.startIP){
                return -1;
            }
            return 0;
        }





        public int getIpRange(long ip) {
            if (ip >= this.startIP && ip <= this.endIP)
                return 0;
            return (ip > this.endIP) ? 1 : -1;
        }

        public long getStartIP() {
            return this.startIP;
        }

        public long getEndIP() {
            return this.endIP;
        }

        public void setStartIP(long startIP) {
            this.startIP = startIP;
        }

        public void setEndIP(long endIP) {
            this.endIP = endIP;
        }

        public String getCountry() {
            return this.country;
        }

        public void setCountry(String country) {
            this.country = country;
        }

        public String getProvince() {
            return this.province;
        }

        public void setProvince(String province) {
            this.province = province;
        }

        public String toString() {
            return this.country + "###" + this.province;
        }
    }

    public static void main(String[] args) throws Exception {
        GetIpInfoFromDisk demo = new GetIpInfoFromDisk();
        demo.open(null);
        System.out.println(demo.eval("12.12.12.12"));
    }

}

打包上传：

打包就是普通的打包形式，然后上传到Blink界面，查询以及使用基本和离线是一样的。

有兴趣的可以看下文档：链接–>blink资源和函数使用
