不得不说，微信支付接入比支付宝做的差多了，支付宝支付接入给人的感觉是简单，优雅。微信支付接入给人的感觉恶心，烦躁，想吐槽，踩了不少坑，最后发现使用完全使用官方提供的sdk肯定接入不成功，采用了自己的方式请求调用接口，终于调通了。

接入微信支付扫码支付，微信支付官方提供了两种模式，模式一商户必须在公众平台后台设置支付回调URL。URL实现的功能：接收用户扫码后微信支付系统回调的productid和openid；模式二，流程更为简单，不依赖设置的回调支付URL。商户后台系统先调用微信支付的统一下单接口，微信后台系统返回链接参数code_url，商户后台系统将code_url值生成二维码图片，用户使用微信客户端扫码后发起支付。注意：code_url有效期为2小时，过期后扫码不能再发起支付。本次接入采用模式二：

多说无用，直接晒代码：

1、微信官方下载微信支付接入sdk

2、配置WXPayConfig，自定义MyWXPayConfig继承sdk中WXPayConfig

import java.io.InputStream;

public class MyWXPayConfig extends WXPayConfig{

   @Override
   String getAppID() {
       // TODO Auto-generated method stub
       return "wxcf1*******";
//       return "wx839******";
   }

   @Override
   String getMchID() {
       // TODO Auto-generated method stub
       return "1557******";
//       return "147*****";
   }

   @Override
   String getKey() {
       // TODO Auto-generated method stub
       return "Xq1crLeoFeOxL6*******";
//       return "8A627A457********";
   }

   @Override
   InputStream getCertStream() {
       // TODO Auto-generated method stub
       return null;
   }

   @Override
   IWXPayDomain getWXPayDomain() {
       IWXPayDomain iwxPayDomain = new IWXPayDomain() {

public void report(String domain, long elapsedTimeMillis, Exception ex) {

}

public DomainInfo getDomain(WXPayConfig config) {
return new IWXPayDomain.DomainInfo(WXPayConstants.DOMAIN_API, true);
}
};
return iwxPayDomain;
   }

}

3、自定义微信支付服务

import java.util.Date;
import java.util.HashMap;
import java.util.LinkedHashMap;
import java.util.Map;

import com.alibaba.fastjson.JSONObject;

public class WXPayService {

//获取微信扫码支付二维码链接
   public static Map<String, String> getWXPay(TSecurityOrderEntity order) throws Exception{
       WXPayConfig config = new MyWXPayConfig();
WXPay wxpay = new WXPay(config);
String tradeNo = “aaabbbccc”; //随机字符串
Map<String, String> data = new LinkedHashMap<String, String>();
data.put("appid", config.getAppID());
data.put("body", "订阅支付");
data.put("mch_id", config.getMchID());
data.put("nonce_str", WXPayUtil.generateNonceStr());
data.put("notify_url", "http://a31ef7db.ngrok.io/WeChatPay/WeChatPayNotify");
data.put("out_trade_no", tradeNo);
data.put("spbill_create_ip", "127.0.0.1");
data.put("total_fee", “100”);
data.put("trade_type", "NATIVE"); // 此处指定为扫码支付
data.put("product_id", "12235413214070356458058");

//2.生成要发送的xml
       String xmlParam = WXPayUtil.generateSignedXml(data, config.getKey());
       System.out.println(xmlParam);
       HttpClient client=new HttpClient("https://api.mch.weixin.qq.com/pay/unifiedorder");
       client.setHttps(true);
       client.setXmlParam(xmlParam);
       client.post();
       //3.获得结果
       String result = client.getContent();
       System.out.println(result);
       Map<String, String> map = WXPayUtil.xmlToMap(result);
// report(reportParams.toString());
if (map.get("return_code").toString().equals("SUCCESS") && map.get("result_code").toString().equals("SUCCESS") ) {
String urlCode = (String) map.get("code_url");
System.out.println(urlCode);
map.put("tradeNo", tradeNo);
return map;
}
return null;

   }
//根据返回订单号tradeNo查询订单支付状态
   public static boolean tradeQuery(String tradeNo) throws Exception{
       WXPayConfig config = new MyWXPayConfig();
       Map param=new HashMap();
       param.put("appid", config.getAppID());//公众账号ID
       param.put("mch_id", config.getMchID());//商户号
       param.put("out_trade_no", tradeNo);//订单号
       param.put("nonce_str", WXPayUtil.generateNonceStr());//随机字符串
       String url="https://api.mch.weixin.qq.com/pay/orderquery";

       String xmlParam = WXPayUtil.generateSignedXml(param, config.getKey());
       HttpClient client=new HttpClient(url);
       client.setHttps(true);
       client.setXmlParam(xmlParam);
       client.post();
       String result = client.getContent();
       Map<String, String> map = WXPayUtil.xmlToMap(result);
       if (map.get("return_code").toString().equals("SUCCESS") && map.get("result_code").toString().equals("SUCCESS")
               && "SUCCESS".equals(map.get("trade_state").toString())) {
   System.out.println("支付成功");
           return true;
   }
       return false;

   }
   public static void main(String[] args) throws Exception {
       Map<String, String> map = getWXPay(new TSecurityOrderEntity());
       while(true){
           boolean flag = tradeQuery(map.get("tradeNo"));
           if(flag){
               System.out.println("支付成功");
           }else{
               System.out.println("未支付");
           }
           Thread.sleep(3000);
       }
   }
}

4、请求微信支付接口工具类

import java.io.IOException;
import java.security.GeneralSecurityException;
import java.security.cert.CertificateException;
import java.security.cert.X509Certificate;
import java.text.ParseException;
import java.util.HashMap;
import java.util.LinkedList;
import java.util.List;
import java.util.Map;

import javax.net.ssl.SSLContext;
import javax.net.ssl.SSLException;
import javax.net.ssl.SSLSession;
import javax.net.ssl.SSLSocket;
import javax.net.ssl.TrustManager;
import javax.net.ssl.X509TrustManager;

import org.apache.http.Consts;
import org.apache.http.HttpEntity;
import org.apache.http.NameValuePair;
import org.apache.http.client.ClientProtocolException;
import org.apache.http.client.config.RequestConfig;
import org.apache.http.client.entity.UrlEncodedFormEntity;
import org.apache.http.client.methods.CloseableHttpResponse;
import org.apache.http.client.methods.HttpEntityEnclosingRequestBase;
import org.apache.http.client.methods.HttpGet;
import org.apache.http.client.methods.HttpPost;
import org.apache.http.client.methods.HttpPut;
import org.apache.http.client.methods.HttpUriRequest;
import org.apache.http.conn.scheme.Scheme;
import org.apache.http.conn.ssl.SSLConnectionSocketFactory;
import org.apache.http.conn.ssl.SSLContextBuilder;
import org.apache.http.conn.ssl.SSLSocketFactory;
import org.apache.http.conn.ssl.TrustStrategy;
import org.apache.http.conn.ssl.X509HostnameVerifier;
import org.apache.http.entity.StringEntity;
import org.apache.http.impl.client.CloseableHttpClient;
import org.apache.http.impl.client.DefaultHttpClient;
import org.apache.http.impl.client.HttpClients;
import org.apache.http.impl.conn.PoolingHttpClientConnectionManager;
import org.apache.http.message.BasicNameValuePair;
import org.apache.http.util.EntityUtils;

/**
* http请求客户端
*
* @author Administrator
*
*/
public class HttpClient {
   private String url;
   private Map<String, String> param;
   private int statusCode;
   private String content;
   private String xmlParam;
   private boolean isHttps;

   public boolean isHttps() {
       return isHttps;
   }

   public void setHttps(boolean isHttps) {
       this.isHttps = isHttps;
   }

   public String getXmlParam() {
       return xmlParam;
   }

   public void setXmlParam(String xmlParam) {
       this.xmlParam = xmlParam;
   }

   public HttpClient(String url, Map<String, String> param) {
       this.url = url;
       this.param = param;
   }

   public HttpClient(String url) {
       this.url = url;
   }

   public void setParameter(Map<String, String> map) {
       param = map;
   }

   public void addParameter(String key, String value) {
       if (param == null)
           param = new HashMap<String, String>();
       param.put(key, value);
   }

   public void post() throws ClientProtocolException, IOException {
       HttpPost http = new HttpPost(url);
       setEntity(http);
       execute(http);
   }

   public void put() throws ClientProtocolException, IOException {
       HttpPut http = new HttpPut(url);
       setEntity(http);
       execute(http);
   }

   public void get() throws ClientProtocolException, IOException {
       if (param != null) {
           StringBuilder url = new StringBuilder(this.url);
           boolean isFirst = true;
           for (String key : param.keySet()) {
               if (isFirst)
                   url.append("?");
               else
                   url.append("&");
               url.append(key).append("=").append(param.get(key));
           }
           this.url = url.toString();
       }
       HttpGet http = new HttpGet(url);
       execute(http);
   }

   /**
   * set http post,put param
   */
   private void setEntity(HttpEntityEnclosingRequestBase http) {
       if (param != null) {
           List<NameValuePair> nvps = new LinkedList<NameValuePair>();
           for (String key : param.keySet())
               nvps.add(new BasicNameValuePair(key, param.get(key))); // 参数
           http.setEntity(new UrlEncodedFormEntity(nvps, Consts.UTF_8)); // 设置参数
       }
       if (xmlParam != null) {
           http.setEntity(new StringEntity(xmlParam, Consts.UTF_8));
       }
   }

   private void execute(HttpUriRequest http) throws ClientProtocolException,
           IOException {
       CloseableHttpClient httpClient = null;
       try {
           if (isHttps) {
               SSLContext sslContext = new SSLContextBuilder()
                       .loadTrustMaterial(null, new TrustStrategy() {
                           // 信任所有
                           public boolean isTrusted(X509Certificate[] chain,
                                   String authType)
                                   throws CertificateException {
                               return true;
                           }
                       }).build();
               SSLConnectionSocketFactory sslsf = new SSLConnectionSocketFactory(
                       sslContext);
               httpClient = HttpClients.custom().setSSLSocketFactory(sslsf)
                       .build();
           } else {
               httpClient = HttpClients.createDefault();
           }
           CloseableHttpResponse response = httpClient.execute(http);
           try {
               if (response != null) {
                   if (response.getStatusLine() != null)
                       statusCode = response.getStatusLine().getStatusCode();
                   HttpEntity entity = response.getEntity();
                   // 响应内容
                   content = EntityUtils.toString(entity, Consts.UTF_8);
               }
           } finally {
               response.close();
           }
       } catch (Exception e) {
           e.printStackTrace();
       } finally {
           httpClient.close();
       }
   }

   public int getStatusCode() {
       return statusCode;
   }

   public String getContent() throws ParseException, IOException {
       return content;
   }

}
5、根据返回链接生成图片二维码代码

import com.google.zxing.BarcodeFormat;
import com.google.zxing.EncodeHintType;
import com.google.zxing.MultiFormatWriter;
import com.google.zxing.common.BitMatrix;

import javax.imageio.ImageIO;
import javax.swing.filechooser.FileSystemView;
import java.awt.image.BufferedImage;
import java.io.File;
import java.io.IOException;
import java.io.OutputStream;
import java.util.HashMap;
import java.util.Map;

public class QrCodeUtil {
public static void main(String[] args) {
String url = "https://qr.alipay.com/bax03926jk9mvqchcxon00ec";
String path = FileSystemView.getFileSystemView().getHomeDirectory() + File.separator + "testQrcode";
String fileName = "temp.jpg";
createQrCode(url, path, fileName);
}

public static String createQrCode(String url, String path, String fileName) {
try {
Map<EncodeHintType, String> hints = new HashMap<>();
hints.put(EncodeHintType.CHARACTER_SET, "UTF-8");
BitMatrix bitMatrix = new MultiFormatWriter().encode(url, BarcodeFormat.QR_CODE, 400, 400, hints);
File file = new File(path, fileName);
if (file.exists() || ((file.getParentFile().exists() || file.getParentFile().mkdirs()) && file.createNewFile())) {
writeToFile(bitMatrix, "jpg", file);
System.out.println("搞定：" + file);
}
} catch (Exception e) {
e.printStackTrace();
}
return null;
}

static void writeToFile(BitMatrix matrix, String format, File file) throws IOException {
BufferedImage image = toBufferedImage(matrix);
if (!ImageIO.write(image, format, file)) {
throw new IOException("Could not write an image of format " + format + " to " + file);
}
}

static void writeToStream(BitMatrix matrix, String format, OutputStream stream) throws IOException {
BufferedImage image = toBufferedImage(matrix);
if (!ImageIO.write(image, format, stream)) {
throw new IOException("Could not write an image of format " + format);
}
}

private static final int BLACK = 0xFF000000;
private static final int WHITE = 0xFFFFFFFF;

private static BufferedImage toBufferedImage(BitMatrix matrix) {
int width = matrix.getWidth();
int height = matrix.getHeight();
BufferedImage image = new BufferedImage(width, height, BufferedImage.TYPE_INT_RGB);
for (int x = 0; x < width; x++) {
for (int y = 0; y < height; y++) {
image.setRGB(x, y, matrix.get(x, y) ? BLACK : WHITE);
}
}
return image;
}
}
