本文介绍了一种在UI设计中使滑动列表每次打开都返回初始位置的方法。通过使用CUIPanelResetHelper组件，避免了直接修改UIPanel的baseClipRegion属性，实现了高效且官方推荐的滑动列表复位。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

需求

在每次打开界面滑动列表都是复位状态（未滑动）。

分析

在制作滑动列表时常常会结合UIPanel和UIScrollView

要让滑动列表回到未滑动时的位置，那么就需要改变Panel的Clipping和transform的position

演示

以前做法

以前是保存Panel的初始信息，每时打开面板时再还原

public class CUIShopVIP : CUIController
{
    private UIPanel GridPanel;
    private UIScrollView GridPanel_ScrollView;
    private float BakGridPanel_Y;
    private Vector4 BakGridPanel_ClipRegion;

    public override void OnInit()
    {
        base.OnInit();
        //...... 初始化代码

        GridPanel = GetControl<UIPanel>("GridPanel");
        GridPanel_ScrollView = GridPanel.GetComponent<UIScrollView>();

        BakGridPanel_Y = GridPanel.transform.GetLocalPositionY();
        BakGridPanel_ClipRegion = GridPanel.baseClipRegion;
    }

    public override void OnOpen(params object[] args)
    {
        base.OnOpen(args);

        //打开前 重设Scrollview的属性到初始

        GridPanel.baseClipRegion = BakGridPanel_ClipRegion;//NOTE 不建议直接修改此值
        GridPanel_ScrollView.UpdatePosition();
        GridPanel_ScrollView.ResetPosition();
        GridPanel.transform.SetLocalPositionY(BakGridPanel_Y);
    }
}

之前的做法是修改 Panel的 localPosition 和 Panel的 baseClipRegion，但官方不建议直接修改baseClipRegion。然后更新ScrollView的信息

/// <summary>
/// Clipping position (XY) and size (ZW).
/// Note that you should not be modifying this property at run-time to reposition the clipping. Adjust clipOffset instead.
/// </summary>

public Vector4 baseClipRegion

编写组件

现在做了一个PanelResetHelper，修改Panel的 clipOffset和 localPosition 而不直接修改baseClipRegion

/// <summary>
/// Clipping area offset used to make it possible to move clipped panels (scroll views) efficiently.
/// Scroll views move by adjusting the clip offset by one value, and the transform position by the inverse.
/// This makes it possible to not have to rebuild the geometry, greatly improving performance.
/// </summary>

public Vector2 clipOffset

原理

和之前做法一样，初始化时保存Panel的属性，界面打开时，再还原值。

组件源码

Helper代码如下

/// <summary>
/// 可以对UIPanel进行滚动复位
/// </summary>
public class CUIPanelResetHelper
{
    private UIPanel _panel;
    private Vector2 _initPanelClipOffset;
    private Vector3 _initPanelLocalPos;

    public CUIPanelResetHelper(UIPanel uiPanel)
    {
        _panel = uiPanel;
        _initPanelClipOffset = _panel.clipOffset;
        _initPanelLocalPos = _panel.cachedTransform.localPosition;
    }

    public void ResetScroll()
    {
        _panel.clipOffset = _initPanelClipOffset;
        _panel.cachedTransform.localPosition = _initPanelLocalPos;
    }
}

组件用法

public class CUIShopVIP : CUIController
{
    private UIPanel GridPanel;
    private CUIPanelResetHelper GridPanelResetHelper;

    public override void OnInit()
    {
        base.OnInit();
        //...... 初始化代码
        GridPanel = GetControl<UIPanel>("GridPanel");
        GridPanelResetHelper = new CUIPanelResetHelper(GridPanel);
    }

    public override void OnOpen(params object[] args)
    {
        base.OnOpen(args);

        //打开前 重设Scrollview的属性到初始
        GridPanelResetHelper.ResetScroll();
    }
}

UIScrollView

uiscrollview中的属性

/// <summary>
/// Whether the dragging will be restricted to be within the scroll view's bounds.
/// </summary>
public bool restrictWithinPanel = true;

/// <summary>
/// Whether dragging will be disabled if the contents fit.
/// </summary>
public bool disableDragIfFits = false;
