module top(
CLK,
start, /*EN*/
rst, /*reset*/
load, /*load signal*/
load_success, /*feedback signal when load success*/
input_ready, /*input available*/
output_ready, /*output available*/
FLOAT32_IN, /*IEEE x input*/
FLOAT32_OUT, /*IEEE e^x output*/
/*debug only*/
D_state,
D_FIX_taylor_output,
D_e,
D_x,
D_taylor_1,
D_taylor_2,
D_taylor_3
);
/*---------------------------------------------------*/
/*-----------------port declare----------------------*/
/*---------------------------------------------------*/
input CLK, start, rst, load;
output input_ready, output_ready, load_success;
output [2:0] D_state;
input [31:0] FLOAT32_IN;
output [31:0] FLOAT32_OUT;
output [25:0] D_FIX_taylor_output, D_e, D_x, D_taylor_3, D_taylor_2, D_taylor_1;
/*----------------------------------------------------*/
/*------------- stage 0 input reprocess---------------*/
/*----------------------------------------------------*/
wire [25:0] IN_A, stage_0_E;
wire [31:0] stage_0_FLOAT32_OUT;
wire stage_1_start;
input_process_stage my_stage_0(
.CLK(CLK),
.rst(rst),
.FLOAT32_IN(FLOAT32_IN), /*IEEE float32 x input*/
.FLOAT32_OUT(stage_0_FLOAT32_OUT), /*e^b IEEE 745 output*/
.A(IN_A), /*x - a Q3.23 output*/
.E(stage_0_E), /*e^a Q3.23 output*/
.next_stage_start(stage_1_start), /*next stage triger signal*/
/*---------control signal----------*/
.load(load), /*input data load*/
.start(start), /*function like OE*/
.input_ready(input_ready), /*input load available*/
.load_success(load_success),
.d_state(D_state)
);
assign D_x = IN_A;
/*----------------------------------------------------*/
/*------------- stage 1 taylor part 1 ---------------*/
/*----------------------------------------------------*/
wire stage_1_mul_ss, stage_1_add_ss, stage_1_output_ready, stage_1_is_pass, stage_1_mul_ss_en, stage_1_add_ss_en;
wire [25:0] stage_1_output;
wire [25:0] stage_1_E;
wire [31:0] stage_1_FLOAT32_OUT;
/*control*/
taylor_stage_1_control my_control_1(
.CLK(CLK),
.start(stage_1_start),
.rst(rst),
.output_ready(stage_1_output_ready),
.mul_ss(stage_1_mul_ss),
.add_ss(stage_1_add_ss),
.mul_ss_en(stage_1_mul_ss_en),
.add_ss_en(stage_1_add_ss_en)
);
/*datapath*/
taylor_stage_1 my_stage_1(
.CLK(CLK),
.IN_A(IN_A), /*x - a*/
.OUT(stage_1_output),
/*control signal*/
.mul_ss(stage_1_mul_ss),
.add_ss(stage_1_add_ss),
.mul_ss_en(stage_1_mul_ss_en),
.add_ss_en(stage_1_add_ss_en)
);
/*----------------------------------------------------*/
/*-------pipeline register part 1 && part 2-----------*/
/*----------------------------------------------------*/
reg [25:0] reg_stage1_stage2;
reg reg_stage2_start;
reg [25:0] reg_stage_1_E;
reg [25:0] reg_stage_1_A;
reg [31:0] reg_stage_1_FLOAT32_OUT;
assign D_taylor_1 = reg_stage1_stage2;
always @ (posedge CLK) begin
if(stage_1_output_ready) begin
reg_stage_1_A <= IN_A;
reg_stage_1_E <= stage_0_E;
reg_stage_1_FLOAT32_OUT <= stage_0_FLOAT32_OUT;
end
end
always @ (posedge CLK) begin
if(stage_1_output_ready) begin
reg_stage1_stage2 <= stage_1_output;
reg_stage2_start <= 1'b1;
end
else begin
reg_stage1_stage2 <= 26'd0;
reg_stage2_start <= 1'b0;
end
end
/*----------------------------------------------------*/
/*------------- stage 2 taylor part 2 ---------------*/
/*----------------------------------------------------*/
wire stage_2_mul_ss, stage_2_add_ss, stage_2_output_ready, stage_2_mul_ss_en, stage_2_add_ss_en;
wire [25:0] stage_2_output;
/*control*/
taylor_stage_2_control my_control_2(
.CLK(CLK),
.start(reg_stage2_start),
.rst(rst),
.output_ready(stage_2_output_ready),
.mul_ss(stage_2_mul_ss),
.add_ss(stage_2_add_ss),
.mul_ss_en(stage_2_mul_ss_en),
.add_ss_en(stage_2_add_ss_en)
);
/*datapath*/
taylor_stage_2 my_stage_2(
.CLK(CLK),
.IN_A(reg_stage_1_A), /*x - a*/
.IN_B(reg_stage1_stage2),
.OUT(stage_2_output),
/*control signal*/
.mul_ss(stage_2_mul_ss),
.add_ss(stage_2_add_ss),
.mul_ss_en(stage_2_mul_ss_en),
.add_ss_en(stage_2_add_ss_en)
);
/*----------------------------------------------------*/
/*-------pipeline register part 1 && part 2-----------*/
/*----------------------------------------------------*/
reg [25:0] reg_stage2_stage3;
reg reg_stage3_start;
reg [25:0] reg_stage_2_E;
reg [25:0] reg_stage_2_A;
reg [31:0] reg_stage_2_FLOAT32_OUT;
assign D_taylor_2 = reg_stage2_stage3;
always @ (posedge CLK) begin
if(reg_stage2_start) begin
reg_stage_2_E <= reg_stage_1_E;
reg_stage_2_FLOAT32_OUT <= reg_stage_1_FLOAT32_OUT;
end
end
always @ (posedge CLK) begin
if(stage_2_output_ready) begin
reg_stage_2_A <= reg_stage_1_A;
reg_stage2_stage3 <= stage_2_output;
reg_stage3_start <= 1'b1;
end
else begin
reg_stage2_stage3 <= 26'd0;
reg_stage3_start <= 1'b0;
end
end
/*----------------------------------------------------*/
/*------------- stage 3 taylor part 3 ---------------*/
/*----------------------------------------------------*/
wire stage_3_mul_ss, stage_3_output_ready, stage_3_mul_ss_en, stage_3_add_ss_en;
wire [25:0] stage_3_output;
/*control*/
taylor_stage_3_control my_control_3(
.CLK(CLK),
.start(reg_stage3_start),
.rst(rst),
.output_ready(stage_3_output_ready),
.mul_ss(stage_3_mul_ss),
.mul_ss_en(stage_3_mul_ss_en),
.add_ss_en(stage_3_add_ss_en)
);
/*datapath*/
taylor_stage_3 my_stage_3(
.CLK(CLK),
.IN_A(reg_stage_2_A), /*x - a*/
.IN_B(reg_stage2_stage3),
.OUT(stage_3_output),
/*control signal*/
.mul_ss(stage_3_mul_ss),
.mul_ss_en(stage_3_mul_ss_en),
.add_ss_en(stage_3_add_ss_en)
);
/*----------------------------------------------------*/
/*-------pipeline register part 2 && part 3-----------*/
/*----------------------------------------------------*/
reg [25:0] reg_stage3_stage4;
reg reg_stage4_start;
reg [25:0] reg_stage_3_E;
reg [31:0] reg_stage_3_FLOAT32_OUT;
assign D_taylor_3 = reg_stage3_stage4;
always @ (posedge CLK) begin
if(reg_stage3_start) begin
reg_stage_3_E <= reg_stage_2_E;
reg_stage_3_FLOAT32_OUT <= reg_stage_2_FLOAT32_OUT;
end
end
always @ (posedge CLK) begin
if(stage_3_output_ready) begin
reg_stage3_stage4 <= stage_3_output;
reg_stage4_start <= 1'b1;
end
else begin
reg_stage3_stage4 <= 26'd0;
reg_stage4_start <= 1'b0;
end
end
/*----------------------------------------------------*/
/*------------- stage 4 output process --------------*/
/*----------------------------------------------------*/
assign D_e = reg_stage_3_E;
output_process_stage my_stage_5(
.CLK(CLK),
.start(reg_stage4_start),
.rst(rst),
.FIXED_taylor_input(reg_stage3_stage4),
.FIXED_e_input(reg_stage_3_E),
.FLOAT_e_input(reg_stage_3_FLOAT32_OUT),
.FLOAT_result_output(FLOAT32_OUT),
.output_ready(output_ready),
.D_taylor_output(D_FIX_taylor_output)
);
endmodule分析一下这段代码
