cxf整合spring开发WebService



3.3 配置文件讲解

beans.xml：为Spring的配置文件，用来通过扫描包结构，通过注解进行管理依赖

cxf.xml：是CXF的核心配置文件，主要的有关CXF都在这里配置，如下:

 2 <?xml version="1.0" encoding="UTF-8"?>
   <beans xmlns="http://www.springframework.org/schema/beans"
 3     xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:jaxws="http://cxf.apache.org/jaxws"
 4     xmlns:jaxrs="http://cxf.apache.org/jaxrs" xmlns:cxf="http://cxf.apache.org/core"
 5     xsi:schemaLocation="http://www.springframework.org/schema/beans
 6           http://www.springframework.org/schema/beans/spring-beans.xsd
 7             http://cxf.apache.org/jaxrs http://cxf.apache.org/schemas/jaxrs.xsd
 8             http://cxf.apache.org/jaxws http://cxf.apache.org/schemas/jaxws.xsd
 9             http://cxf.apache.org/core http://cxf.apache.org/schemas/core.xsd">
10     <!-- 引入CXF Bean定义 -->
11     <import resource="classpath:META-INF/cxf/cxf.xml" />
12     <import resource="classpath:META-INF/cxf/cxf-servlet.xml" />
13     《《<!-- ========配置带有接口形式的webservice服务  serviceClass:服务接口的类 -->
14     <jaxws:server address="/person" serviceClass="com.service.PersonService">
15         <!-- 服务接口的实现类 -->
16         <jaxws:serviceBean>
17             <bean class="com.service.impl.PersonServiceImpl"></bean>
18         </jaxws:serviceBean>
        <!--配置消息拦截器-->
19         <jaxws:inInterceptors>
20             <bean class="org.apache.cxf.interceptor.LoggingInInterceptor"></bean>
21         </jaxws:inInterceptors>
22         <jaxws:outInterceptors>
23             <bean class="org.apache.cxf.interceptor.LoggingOutInterceptor"></bean>
24          </jaxws:outInterceptors>
25     </jaxws:server> 》》
26
27
28     《《 <!-- ===============配置类形式的webservice服务  implementor:指定具体的服务的类 -->

30      <jaxws:endpoint id="hello" address="/hello"  implementor="com.web.service.HelloService">
32
   <!--如果你想弹性的引用bean可以这样写：<bean id="hello" class="com.web.service.HelloService" />
33     <jaxws:endpoint id="hello" implementor="#hello" address="/hello" />-->
34        <!--配置拦截器，这样可以在控制台看到向webservice请求或相应的xml信息-->
35         <jaxws:outInterceptors>
36             <bean class="org.apache.cxf.interceptor.LoggingInInterceptor"></bean>
37         </jaxws:outInterceptors>
38         <jaxws:inInterceptors>
39             <bean class="org.apache.cxf.interceptor.LoggingOutInterceptor"></bean>
40         </jaxws:inInterceptors>
41     </jaxws:endpoint> 》》
42 </beans>

 上述文件中，有两种方式的服务发布，一种是以接口形式，一种是以类的形式

 web.xml：配置的是CXF的核心过滤器以及Spring的监听器，如下：



 1 <?xml version="1.0" encoding="UTF-8"?>
 2     <web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 3         xmlns="http://java.sun.com/xml/ns/javaee" xmlns:web="http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
 4         xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
 5         id="WebApp_ID" version="2.5">
 6     <listener>
 7         <listener-class>org.springframework.web.context.ContextLoaderListener</listener-class>
 8     </listener>
   <!-- 配置spring框架 beans.xml -->

       <context-param>
10         <param-name>contextConfigLocation</param-name>
11         <param-value>classpath:beans.xml</param-value>
12     </context-param>

9     <context-param>
10         <param-name>contextConfigLocation</param-name>
11         <param-value>classpath:cxf.xml</param-value>
12     </context-param>
13
14     <servlet>
15         <servlet-name>cxf</servlet-name>
16         <servlet-class>org.apache.cxf.transport.servlet.CXFServlet</servlet-class>
17         <!-- <init-param>
18             <param-name>config-location</param-name>
19             <param-value>classpath:cxf.xml</param-value>
20         </init-param>
21         <load-on-startup>1</load-on-startup> -->
22     </servlet>
23     <servlet-mapping>
24         <servlet-name>cxf</servlet-name>
25         <url-pattern>/service/*</url-pattern>
26     </servlet-mapping>
27
28 </web-app>

上面就是整个CXF+Spring的整合，部署到Tomact中，进行访问，访问地址如下

http://localhost:8080/Spring_CXF/service/person?wsdl
