Kamailio SIP Server + MySQL + Rocky Linux

Kamailio SIP Server + MySQL + Rocky Linux

MySQL 数据库

安装 mysql 模块


[root@netkiller ~]# dnf install -y kamailio-mysql



配置 kamailio


[root@netkiller ~]# cat /etc/kamailio/kamailio.cfg
#!KAMAILIO
#
# Kamailio SIP Server v6.0 - default configuration script
#     - web: https://www.kamailio.org
#     - git: https://github.com/kamailio/kamailio
#
# Direct your questions about this file to: <sr-users@lists.kamailio.org>
#
# Refer to the Core CookBook at https://www.kamailio.org/wikidocs/
# for an explanation of possible statements, functions and parameters.
#
# Note: the comments can be:
#     - lines starting with #, but not the pre-processor directives,
#       which start with #!, like #!define, #!ifdef, #!endif, #!else, #!trydef,
#       #!subst, #!substdef, ...
#     - lines starting with //
#     - blocks enclosed in between /* */
# Note: the config performs symmetric SIP signaling
#     - it sends the reply to the source address of the request
#     - remove the use of force_rport() for asymmetric SIP signaling
#
# Several features can be enabled using '#!define WITH_FEATURE' directives:
#
# *** To run in debug mode:
#     - define WITH_DEBUG
#     - debug level increased to 3, logs still sent to syslog
#     - debugger module loaded with cfgtrace enabled
#
# *** To enable mysql:
#     - define WITH_MYSQL
#
# *** To enable authentication execute:
#     - enable mysql
#     - define WITH_AUTH
#     - add users using 'kamctl' or 'kamcli'
#
# *** To enable IP authentication execute:
#     - enable mysql
#     - enable authentication
#     - define WITH_IPAUTH
#     - add IP addresses with group id '1' to 'address' table
#
# *** To enable persistent user location execute:
#     - enable mysql
#     - define WITH_USRLOCDB
#
# *** To enable presence server execute:
#     - enable mysql
#     - define WITH_PRESENCE
#     - if modified headers or body in config must be used by presence handling:
#     - define WITH_MSGREBUILD
#
# *** To enable nat traversal execute:
#     - define WITH_NAT
#     - option for NAT SIP OPTIONS keepalives: WITH_NATSIPPING
#     - install RTPProxy: http://www.rtpproxy.org
#     - start RTPProxy:
#        rtpproxy -l _your_public_ip_ -s udp:localhost:7722
#
# *** To use RTPEngine (instead of RTPProxy) for nat traversal execute:
#     - define WITH_RTPENGINE
#     - install RTPEngine: https://github.com/sipwise/rtpengine
#     - start RTPEngine:
#        rtpengine --listen-ng=127.0.0.1:2223 ...
#
# *** To enable PSTN gateway routing execute:
#     - define WITH_PSTN
#     - set the value of pstn.gw_ip
#     - check route[PSTN] for regexp routing condition
#
# *** To enable database aliases lookup execute:
#     - enable mysql
#     - define WITH_ALIASDB
#
# *** To enable speed dial lookup execute:
#     - enable mysql
#     - define WITH_SPEEDDIAL
#
# *** To enable multi-domain support execute:
#     - enable mysql
#     - define WITH_MULTIDOMAIN
#
# *** To enable TLS support execute:
#     - adjust CFGDIR/tls.cfg as needed
#     - define WITH_TLS
#
# *** To enable JSONRPC over HTTP(S) support execute:
#     - define WITH_JSONRPC
#     - adjust event_route[xhttp:request] for access policy
#
# *** To enable anti-flood detection execute:
#     - adjust pike and htable=>ipban settings as needed (default is
#       block if more than 16 requests in 2 seconds and ban for 300 seconds)
#     - define WITH_ANTIFLOOD
#
# *** To load htable module execute:
#     - define WITH_HTABLE
#
# *** To block 3XX redirect replies execute:
#     - define WITH_BLOCK3XX
#
# *** To block 401 and 407 authentication replies execute:
#     - define WITH_BLOCK401407
#
# *** To enable VoiceMail routing execute:
#     - define WITH_VOICEMAIL
#     - set the value of voicemail.srv_ip
#     - adjust the value of voicemail.srv_port
#
# *** To enhance accounting execute:
#     - enable mysql
#     - define WITH_ACCDB
#     - add following columns to database
#!ifdef ACCDB_COMMENT
  ALTER TABLE acc ADD COLUMN src_user VARCHAR(64) NOT NULL DEFAULT '';
  ALTER TABLE acc ADD COLUMN src_domain VARCHAR(128) NOT NULL DEFAULT '';
  ALTER TABLE acc ADD COLUMN src_ip varchar(64) NOT NULL default '';
  ALTER TABLE acc ADD COLUMN dst_ouser VARCHAR(64) NOT NULL DEFAULT '';
  ALTER TABLE acc ADD COLUMN dst_user VARCHAR(64) NOT NULL DEFAULT '';
  ALTER TABLE acc ADD COLUMN dst_domain VARCHAR(128) NOT NULL DEFAULT '';
  ALTER TABLE missed_calls ADD COLUMN src_user VARCHAR(64) NOT NULL DEFAULT '';
  ALTER TABLE missed_calls ADD COLUMN src_domain VARCHAR(128) NOT NULL DEFAULT '';
  ALTER TABLE missed_calls ADD COLUMN src_ip varchar(64) NOT NULL default '';
  ALTER TABLE missed_calls ADD COLUMN dst_ouser VARCHAR(64) NOT NULL DEFAULT '';
  ALTER TABLE missed_calls ADD COLUMN dst_user VARCHAR(64) NOT NULL DEFAULT '';
  ALTER TABLE missed_calls ADD COLUMN dst_domain VARCHAR(128) NOT NULL DEFAULT '';
#!endif

####### Include Local Config If Exists #########
import_file "kamailio-local.cfg"

####### Defined Values #########

# *** Value defines - IDs used later in config
#!ifdef WITH_DEBUG
#!define DBGLEVEL 3
#!else
#!define DBGLEVEL 2
#!endif

#!ifdef WITH_MYSQL
# - database URL - used to connect to database server by modules such
#       as: auth_db, acc, usrloc, a.s.o.
#!trydef DBURL "mysql://sip:13113668890@124.71.107.154/sip"
#!endif

#!ifdef WITH_MULTIDOMAIN
# - the value for 'use_domain' parameters
#!define MULTIDOMAIN 1
#!else
#!define MULTIDOMAIN 0
#!endif

#!ifdef WITH_ANTIFLOOD
# - hash table 'ipban' used to store blocked IP addresses
#!trydef WITH_HTABLE
#!endif

# - flags
# FLT_ - per transaction (message) flags
#!define FLT_ACC 1
#!define FLT_ACCMISSED 2
#!define FLT_ACCFAILED 3
#!define FLT_NATS 5

# FLB_ - per branch flags
#!define FLB_NATB 6
#!define FLB_NATSIPPING 7

####### Global Parameters #########

/* LOG Levels: 3=DBG, 2=INFO, 1=NOTICE, 0=WARN, -1=ERR, ... */
debug=DBGLEVEL

/* set to 'yes' to print log messages to terminal or use '-E' cli option */
log_stderror=no

memdbg=5
memlog=5

log_facility=LOG_LOCAL0
log_prefix="{$mt $hdr(CSeq) $ci} "

/* number of SIP routing processes for each UDP socket
 * - value inherited by tcp_children and sctp_children when not set explicitely */
children=8

/* uncomment the next line to disable TCP (default on) */
# disable_tcp=yes

/* number of SIP routing processes for all TCP/TLS sockets */
# tcp_children=8

/* UDP receiving mode:
 * - 0: multi-process (default)
 * - 1: multi-threaded with async worker group 'udp'
 * - 2: per socket configuration (see core cookbook) */
# async_workers_group="name=udp;workers=8"
# udp_receiver_mode = 1

/* uncomment the next line to disable the auto discovery of local aliases
 * based on reverse DNS on IPs (default on) */
# auto_aliases=no

/* add local domain aliases - it can be set many times */
alias="sip.netkiller.cn"

/* listen sockets - if none set, Kamailio binds to all local IP addresses
 * - basic prototype (full prototype can be found in Wiki - Core Cookbook):
 *      listen=[proto]:[localip]:[lport] advertise [publicip]:[pport]
 * - it can be set many times to add more sockets to listen to */
# listen=udp:10.0.0.10:5060
listen=udp:192.168.0.71:5060 advertise 139.19.54.21:5060
listen=tcp:192.168.0.71:5060 advertise 139.19.54.21:5060

/* life time of TCP connection when there is no traffic
 * - a bit higher than registration expires to cope with UA behind NAT */
tcp_connection_lifetime=3605

/* upper limit for TCP connections (it includes the TLS connections) */
tcp_max_connections=2048

/* upper limit for TCP connections for one ip address - default 1024 */
#tcp_accept_iplimit=1024

#!ifdef WITH_JSONRPC
tcp_accept_no_cl=yes
#!endif

#!ifdef WITH_TLS
enable_tls=yes

/* upper limit for TLS connections */
tls_max_connections=2048

/* For OpenSSL 3 integration
 * functions calling libssl3 can be invoked in a transient thread
 * 0: disable threaded calls
 * 1: use thread executors for process #0 only
 * 2: no thread executors, but use atfork handler to reset thread-locals to NULL */
tls_threads_mode=2

#!endif

/* set it to yes to enable sctp and load sctp.so module */
enable_sctp=no

####### Custom Parameters #########

/* These parameters can be modified at runtime via RPC interface
 * - see the documentation of 'cfg_rpc' module.
 *
 * Format: group.id = value 'desc' description
 * Access: $sel(cfg_get.group.id) or @cfg_get.group.id */

#!ifdef WITH_PSTN
/* PSTN GW Routing
 *
 * - pstn.gw_ip: valid IP or hostname as string value, example:
 * pstn.gw_ip = "10.0.0.101" desc "My PSTN GW Address"
 *
 * - by default is empty to avoid misrouting */
pstn.gw_ip = "" desc "PSTN GW Address"
pstn.gw_port = "" desc "PSTN GW Port"
#!endif

#!ifdef WITH_VOICEMAIL
/* VoiceMail Routing on offline, busy or no answer
 *
 * - by default Voicemail server IP is empty to avoid misrouting */
voicemail.srv_ip = "" desc "VoiceMail IP Address"
voicemail.srv_port = "5060" desc "VoiceMail Port"
#!endif

####### Modules Section ########

/* set paths to location of modules */
# mpath="/usr/lib64/kamailio/modules/"

# when using TLS with OpenSSL it is recomm
